service INFINITI QX56 2004 Factory Service Manual

ACC-1
ACCELERATOR CONTROL SYSTEM
B ENGINE
CONTENTS
C
D
E
F
G
H
I
J
K
L
M
SECTION ACC
A
ACC
Revision: August 20072004 QX56 ACCELERATOR CONTROL SYSTEM ...................... 2
Removal and Installation .......................................... 2
REMOVAL ............................................................. 2
INSTALLATION ..................................................... 3
INSPECTION AFTER INSTALLATION ................. 3SERVICE DATA AND SPECIFICATIONS (SDS) ........ 4
Accelerator Control ................................................... 4
ADJUSTABLE ACCELERATOR PEDAL ............... 4

ACC-4Revision: August 2007
SERVICE DATA AND SPECIFICATIONS (SDS)
2004 QX56
SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
Accelerator ControlEBS00IKX
ADJUSTABLE ACCELERATOR PEDAL
Total Pedal Travel and Stroke
Unit: mm (in)
Adjustable accelerator pedal - total pedal applied stroke 48.3 (1.90)
Adjustable accelerator pedal - total pedal adjustment travel 73.2 (2.88)

ACS-1
AUTO CRUISE CONTROL SYSTEM
K ELECTRICAL
CONTENTS
C
D
E
F
G
H
I
J
L
M
SECTION ACS
A
B
ACS
Revision: August 20072004 QX56
ASCD
AUTOMATIC SPEED CONTROL DEVICE (ASCD) ..... 3
Description ............................................................... 3
ICC
PRECAUTIONS .......................................................... 4
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 4
Precautions for ICC System Service ........................ 4
Wiring Diagrams and Trouble Diagnosis .................. 4
PREPARATION ........................................................... 5
Special Service Tool ................................................. 5
DESCRIPTION ............................................................ 6
Outline ...................................................................... 6
VEHICLE-TO-VEHICLE DISTANCE CONTROL
MODE ................................................................... 6
CONVENTIONAL (FIXED SPEED) CRUISE
CONTROL MODE ................................................. 6
BRAKE ASSIST (WITH PREVIEW FUNCTION) ..... 6
System Diagram ....................................................... 7
Components Description .......................................... 7
CAN Communication ................................................ 7
SYSTEM DESCRIPTION ...................................... 7
Switch Operation ...................................................... 8
ICC System Display ................................................. 8
ACTION TEST ............................................................ 9
ICC System Running Test ........................................ 9
VEHICLE-TO-VEHICLE DISTANCE CONTROL
MODE ................................................................... 9
CONVENTIONAL (FIXED SPEED) CRUISE
CONTROL MODE ............................................... 10
LASER BEAM AIMING ADJUSTMENT ................... 12
Outline of Laser Beam Aiming Adjustment Proce-
dure ........................................................................ 12
Preparation ............................................................. 12
Setting up the ICC Target Board ............................ 12
ADJUSTING HEIGHT OF THE ICC TARGET
BOARD ............................................................... 12ADJUSTING THE POSITION OF THE ICC TAR-
GET BOARD STRING ......................................... 13
POSITIONING THE ICC TARGET BOARD ........ 13
Sensor Adjustment ................................................. 14
CHECK AFTER THE ADJUSTMENT .................. 17
ELECTRICAL UNITS LOCATION ............................ 18
Component Parts and Harness Connector Location ... 18
WIRING DIAGRAM ................................................... 19
Schematic ............................................................... 19
Wiring Diagram — ICC — ...................................... 20
TERMINALS AND REFERENCE VALUE ................. 25
Terminals and Reference Values for ICC Unit ........ 25
Terminals and Reference Values for ICC Sensor ... 25
TROUBLE DIAGNOSIS — GENERAL DESCRIP-
TION .......................................................................... 26
Work Flow ............................................................... 26
CONSULT-II Function (ICC) ................................... 27
CONSULT-II OPERATION ................................... 27
WORK SUPPORT ............................................... 28
SELF-DIAGNOSTIC RESULTS ........................... 28
DATA MONITOR ................................................. 29
ACTIVE TEST ..................................................... 30
Self-Diagnostic Function ......................................... 32
WITH CONSULT-II .............................................. 32
WITHOUT CONSULT-II ....................................... 32
SELF-DIAGNOSIS BY ICC SYSTEM DISPLAY
WILL NOT RUN ................................................... 34
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC
ITEMS ........................................................................ 36
Diagnostic Trouble Code (DTC) Chart ................... 36
DTC 11 CONTROL UNIT ....................................... 37
DTC 12 VDC CONTROL UNIT ............................... 37
DTC 20 CAN COMM CIRCUIT ............................... 38
DTC 31 POWER SUPPLY CIR 1, DTC 34 POWER
SUPPLY CIR 2 ....................................................... 38
DTC 41 VHCL SPEED SE CIRC ............................ 39
DTC 43 VDC/TCS/ABS CIRC ................................ 39
DTC 45 BRAKE SW/STOP L SW ........................... 40
DTC 46 OPERATION SW CIRC ............................. 41
DTC 74 LASER BEAM OFF CENTER ................... 42

ACS-4
[ICC]
PRECAUTIONS
Revision: August 20072004 QX56
PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
EKS007YA
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WAR NIN G:

To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.

Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.

Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
Precautions for ICC System ServiceEKS007YB

Do not look straight into the laser beam discharger when adjusting laser beam aiming.

Turn the ON/OFF switch OFF during chassis dynamometer testing.

Do not remove, disassemble, or reposition the ICC sensor unless told to do so.

Erase DTC when replacing parts of ICC system, then check the operation of ICC system after adjusting
laser beam aiming if necessary.
Wiring Diagrams and Trouble Diagnosis EKS007YC
When you read wiring diagrams, refer to the following:

Refer to GI-15, "How to Read Wiring Diagrams" in GI section.

Refer to PG-4, "POWER SUPPLY ROUTING CIRCUIT" for power distribution circuit in PG section.
When you perform trouble diagnosis, refer to the following:

Refer to GI-11, "HOW TO FOLLOW TEST GROUPS IN TROUBLE DIAGNOSES" in GI section.

Refer to GI-27, "How to Perform Efficient Diagnosis for an Electrical Incident" in GI section.

PREPARATION
ACS-5
[ICC]
C
D
E
F
G
H
I
J
L
MA
B
ACS
Revision: August 20072004 QX56
PREPARATIONPFP:00002
Special Service ToolEKS007YD
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Tool number
(Kent-Moore No.)
Tool nameDescription
KV99110100
(J-45718)
ICC target boardPerforming laser beam aiming ad-
justment
PKIA0358J
