wheel INFINITI QX56 2006 Factory Service Manual

-1
QUICK REFERENCE INDEX
AGENERAL INFORMATIONGIGeneral Information
BENGINEEMEngine Mechanical
LUEngine Lubrication System
COEngine Cooling System
ECEngine Control System
FLFuel System
EXExhaust System
ACCAccelerator Control System
CTRANSMISSION/
TRANSAXLEATAutomatic Transmission
DDRIVELINE/AXLETFTransfer
PRPropeller Shaft
FFDFront Final Drive
RFDRear Final Drive
FAXFront Axle
RAXRear Axle
ESUSPENSIONFSUFront Suspension
RSURear Suspension
WTRoad Wheels & Tires
FBRAKESBRBrake System
PBParking Brake System
BRCBrake Control System
GSTEERINGPSPower Steering System
HRESTRAINTSSBSeat Belts
SRSSupplemental Restraint System (SRS)
IBODYBLBody, Lock & Security System
GWGlasses, Window System & Mirrors
RFRoof
EIExterior & Interior
IPInstrument Panel
SESeat
APAdjustable Pedal
JAIR CONDITIONERATCAutomatic Air Conditioner
KELECTRICALSCStarting & Charging System
LTLighting System
DIDriver Information System
WWWiper, Washer & Horn
BCSBody Control System
LANLAN System
AVAudio Visual, Navigation & Telephone System
ACSAuto Cruise Control System
PGPower Supply, Ground & Circuit Elements
LMAINTENANCEMAMaintenance
MINDEXIDXAlphabetical Index
Edition: July 2005
Revision: November 2009
Publication No. SM6E-1J60U2
B
D
© 2009 NISSAN NORTH AMERICA, INC.
All rights reserved. No part of this Service Manual may be reproduced or stored in a retrieval system, or transmitted in any
form, or by any means, electronic, mechanical, photo-copying, recording or otherwise, without the prior written permission
of Nissan North America, Inc.
A
C
E
F
G
H
I
J
K
L
M

2006
QUICK REFERENCE CHART: QX56

Drive Belt Deflection and Tension
Spark Plugs (Double Platinum Tipped)
Front Wheel Alignment (Unladen*1 )ELS001QR
*1: Fuel, radiator coolant and engine oil full. Spare tire, jack, hand tools and mats in designated positions.
*2: Target value 37° 31′ (37.52° )
*3: Target value 33 ° 59′ (33.98° )
*4: Target value 37 ° 44′ (37.73° )
*5: Target value 33 ° 29′ (33.48° )
Tension of drive belts Auto adjustment by auto tensioner
Make NGK
Standard type PLFR5A-11
Hot type PLFR4A-11
Cold type PLFR6A-11
Gap (nominal) 1.1 mm (0.043 in)
Drive type2WD 4WD
Camber
Degree minute (decimal degree) Minimum -0
° 51′ (-0.85 °)- 0° 33 ′ (-0.55 °)
Nominal -0° 6 ′ (-0.10 °)0 ° 12′ (0.20 °)
Maximum 0° 39′ (0.65 °)0 ° 57′ (0.95 °)
Cross camber 0° 45 ′ (0.75 °) or less 0 ° 45′ (0.75 °) or less
Caster
Degree minute (decimal degree) Minimum
3° 15′ (3.25 °)2 °45′ (2.75 °)
Nominal 4° 0 ′ (4.00 °)3 ° 30′ (3.50 °)
Maximum 4° 45′ (4.75 °)4 ° 15′ (4.25 °)
Cross caster 0° 45′ (0.75 °) or less 0 ° 45′ (0.75 °) or less
Kingpin inclination
Degree minute (decimal degree) 13
° 32′ (13.53° )1 3°13 ′ (13.22 °)
Total toe-in Distance (A
− B) Minimum
1.8 mm (0.07 in) 1.8 mm (0.07 in)
Nominal 2.8 mm (0.11 in) 2.8 mm (0.11 in)
Maximum 3.8 mm (0.15 in) 3.8 mm (0.15 in)
Angle (left side and right side)
Degree minute (decimal degree) Minimum
0° 3 ′ (0.05 °)0 ° 3′ (0.05 °)
Nominal 0° 5 ′ (0.08 °)0 ° 5′ (0.08 °)
Maximum 0° 7 ′ (0.12 °)0 ° 7′ (0.12 °)
Wheel turning angle
(full turn) Inside
Degree minute (decimal degree)
34° 31′
– 38° 31′ *2
(34.52 ° – 38.52 °) 34°
44′ – 38° 44 ′ *4
(34.73° – 38.73° )
Outside
Degree minute (decimal degree) 30° 59′
– 34° 59′ *3
(30.98 ° – 34.98 °) 30°
29′ – 34° 29 ′ *5
(30.48° – 34.48° )
SFA234AC

QUICK REFERENCE CHART: QX56
2006

Rear Wheel AlignmentELS001QS
BrakeELS001QT
Unit: mm (in)
Camber
Degree minute (decimal degree)
Minimum
0° 0 ′ (0 °)
Nominal - 0° 30′ (-0.5 °)
Maximum - 1° 0 ′ (-1.0 °)
Cross camber 0° 45 ′ (0.75 °)
To e - i n Distance (A - B)
Minimum
0 mm (0 in)
Nominal 3.3 mm (0.130 in)
Maximum 6.6 mm (0.260 in)
Cross toe 2 mm (0.079 in)
Angle (left, right)
Degree minute (decimal degree) Minimum
0° 0 ′ (0 °)
Nominal 0° 7 ′ (0.11 °)
Maximum 0° 14 ′ (0.22 °)
Cross toe 0° 8 ′ (0.14 °)
SFA234AC
Front brake Brake model CLZ31VCAD41VA
Rotor outer diameter × thickness 320 × 26 (12.60 × 1.02) 350 x 30 (13.78 x 1.181)
Pad Length × width × thickness 111 . 0
× 73.5 × 11.88 (4.73 ×
2.894 × 0.468) 151.6 x 56.5 x 12 (5.968 x
2.224 x 0.47)
Cylinder bore diameter 51 (2.01)51 (2.01)
Rear brake Brake model AD14VE
Rotor outer diameter × thickness 320 × 14 (12.60 × 0.55)
Pad Length × width × thickness 83.0 × 33.0 × 8.5 (3.268 × 1.299 × 0.335)
Cylinder bore diameter 48 (1.89)
Control valve Valve model Electric brake force distribution
Brake booster Booster model
C215T
Diaphragm diameter 215 (8.46)
Recommended brake fluid Genuine NISSAN Super Heavy Duty Brake Fluid or equivalent

DESCRIPTIONACS-7
[ICC]
C
DE
F
G H
I
J
L
M A
B
ACS
Revision: November 2009 2006 QX56
Components DescriptionEKS00BLI
CAN CommunicationEKS00BLJ
SYSTEM DESCRIPTION
Refer to LAN-26, "CAN COMMUNICATION" .
Switch OperationEKS00BLK
The system is operated by a master ON/OFF switch and four control switches, all mounted on the steering
wheel.
Component Vehicle-to-vehicle
distance control mode Conventional
(fixed speed)
cruise control mode Brake assist
(with preview brake) Description
ICC unit ××× Controls vehicle speed through ECM via CAN
communication.
ICC sensor ×× Irradiate laser beam, and receives reflected
laser beam to measure distance from preceding
vehicle.
ECM ××× Transmits throttle position signal and ICC steer-
ing switch signal to ICC unit.
ABS actuator and electric
unit (control unit) ××× Transmits wheel speed signal to ICC unit.
Operates brake booster based on CAN commu-
nication.
Brake pressure sensor ×× Detects fluid pressure in master cylinder.
Brake booster ×× Adjusts brake fluid pressure based on command
from ABS actuator and electric unit (control
unit).
BCM × Transmit front wiper request signal to ICC unit.
TCM ×× Transmits gear position signal and output shaft
revolution signal to ICC unit.
No.
Switch name Description
1 ACCEL/RES switch Resumes set speed or increases speed incrementally.
2 COAST/SET switch Sets desired cruise speed, reduces speed incrementally.
3 ON/OFF switch Master switch to activate the system.
SKIA5973E

TROUBLE DIAGNOSIS — GENERAL DESCRIPTIONACS-27
[ICC]
C
DE
F
G H
I
J
L
M A
B
ACS
Revision: November 2009 2006 QX56
6. Touch “WORK SUPPORT ”, “SELF-DIAG RESULTS ”, “DATA
MONITOR ”, "CAN DIAG SUPPORT MNTR", “ACTIVE TEST” or
“ECU PART NUMBER ” on selection screen.
WORK SUPPORT
Work Item
Cause of Auto-Cancel
1. Touch “WORK SUPPORT ” on "SELECT DIAG MODE" screen.
2. Touch “CAUSE OF AUTO-CANCEL ” on "SELECT WORK ITEM"
screen.
3. Cause of automatic cancellation screen will be shown.
4. The last five causes of automatic cancellation of ICC system will be displayed.
Possible Causes of "Auto-Cancel"
Laser Beam Adjust
For details, refer to ACS-12, "LASER BEAM AIMING ADJUSTMENT" .
BCIA0031E
Operation Function
CAUSE OF AUTO-CANCEL Indicates causes of automatic cancellation of the ICC system.
LASER BEAM ADJUST Outputs laser beam, calculates dislocation of the beam, and indicates adjustment direction.
SKIA6191E
Cause of cancellation Description
OPERATING WIPER Windshield wipers were operated at HI or LO speed operation.
OPERATING ABS ABS function was operated.
OPERATING TCS TCS function was operated.
OPERATING VDC VDC function was operated.
ECM CIRCUIT ECM did not permit ICC operation.
OPE SW VOLT CIRC Voltage outside the standard was detected.
LASER SUN BEAM Intense light such as sunlight entered ICC sensor light sensing part.
LASER TEMP Temperature around ICC sensor became low.
WHL SPD ELEC NOISE Wheel speed sensor signal caught electromagnetic noise.
OP SW DOUBLE TOUCH ICC steering switches were pressed at the same time.
VDC/TCS OFF SW VDC OFF switch was pressed.
WHEEL SPD UNMATCH Wheel speed became different from AT vehicle speed.
TIRE SLIP Wheel slipped.
PKB SW ON Parking brake is applied.
IGN LOW VOLT Power supply voltage became low.
NO RECORD —

ACS-28
[ICC]
TROUBLE DIAGNOSIS — GENERAL DESCRIPTION
Revision: November 20092006 QX56
SELF-DIAGNOSTIC RESULTS
For details, refer to ACS-36, "Diagnostic Trouble Code (DTC) Chart" .
DATA MONITOR
Operation Procedure
1. Touch “DATA MONITOR ” on "SELECT DIAG MODE" screen.
2. Touch “ECU INPUT SIGNALS ”, “MAIN SIGNALS “, or “SELEC-
TION FROM MENU ” on "SELECT MONITOR ITEM" screen.
Monitored Item
×: Applicable
BCIA0031E
WDIA0084E
Monitored Item [unit] MAIN SIGNALS ECU
INPUT
SIGNALS SELECTION
FROM MENU Description
VHCL SPEED SE
[km/h] or [mph] ××× Indicates vehicle speed calculated from
wheel speed sensor signal.
SET VHCL SPD
[km/h] or [mph] ×× Indicates set vehicle speed stored in ICC
unit.
THRTL OPENING
[%] ×××
Indicates throttle angle calculated from sig-
nal voltage of throttle position sensor.
ENGINE RPM
[rpm] ××Indicates engine speed read by ICC unit via
CAN communication (ECM transmits
engine speed via CAN communication).
DISTANCE ADJ
[SHOR/MID/LONG] ×××
Indicates set distance stored in ICC unit.
WIPER SW
[OFF/LOW/HIGH] ××Indicates wiper [OFF/LOW/HIGH] status.
MAIN SW
[ON/OFF] ××× Indicates [ON/OFF] status as judged from
control switch signal.
SET/COAST SW
[ON/OFF] ×××
Indicates [ON/OFF] status as judged from
control switch signal.
CANCEL SW
[ON/OFF] ××× Indicates [ON/OFF] status as judged from
control switch signal.
RESUME/ACC SW
[ON/OFF] ××× Indicates [ON/OFF] status as judged from
control switch signal.
CRUISE OPE
[ON/OFF] ××
Indicates whether vehicle speed is being
controlled or not (ON means “
controlling”).

ACS-36
[ICC]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: November 20092006 QX56
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMSPFP:00000
Diagnostic Trouble Code (DTC) ChartEKS00BLZ
×:Applicable
DTC No. CONSULT-II screen terms ICC sys-
tem
warning
lamp Fail-safe
Malfunctions detected where... Refer-
ence
page
Ve h ic le -
to-vehi-cle dis-
tance
control mode Conven-
tional
(fixed
speed) cruise
control mode Brake
assist
(with pre- view
function)
11 CONTROL UNIT ××××

ICC unit internal malfunctionACS-37
12 VDC CONTROL UNIT ××××

VDC malfunction

Brake booster signal harness is
open or shortedACS-37
20 CAN COMM CIRCUIT
××××
ICC unit detected CAN communi-
cation malfunctionACS-38
31 POWER SUPPLY CIR1
××××
ICC unit power supply voltage is
excessively low (less than 8V)ACS-38
34 POWER SUPPLY CIR2
××××
ICC unit power supply voltage is
excessively high.ACS-38
41 VHCL SPEED SE CIRC
××××

Wheel sensor malfunction

ABS actuator and electric unit
(control unit) malfunction

A/T vehicle speed sensor mal-
function

TCM malfunctionACS-39
43 VDC/TCS/ABS CIRC
××××
VDC/TCS/ABS system malfunc-
tionACS-39
45 BRAKE SW/ STOP L SW
××××

ICC brake switch or stop lamp
switch harness is open or shorted

ICC brake switch or stop lamp
switch is stuck to OFF

ICC brake switch or stop lamp
switch is stuck to ONACS-40
46 OPERATION SW CIRC
×××

ICC steering switch harness or
spiral cable is open or shorted

ICC steering switch malfunctionACS-41
74 LASER BEAM OFF CNTR
×××
Laser beam of ICC sensor is off
the aiming point ACS-42
90 STOP LAMP RLY FIX
×××
Normally open terminal of stop
lamp relay is stuck ACS-43
92 ECM CIRCUIT
××××

ECM malfunction

Accelerator pedal position sensor
malfunction

ICC unit malfunctionACS-47
96 NP RANGE
×××

Park/neutral position switch har-
ness is open or shorted

Park/neutral position switch mal-
function

TCM malfunctionACS-48
97 AT CIRCUIT
×××
TCM malfunctionACS-48

REMOVAL AND INSTALLATIONACS-59
[ICC]
C
DE
F
G H
I
J
L
M A
B
ACS
Revision: November 2009 2006 QX56
REMOVAL AND INSTALLATIONPFP:00000
ICC UnitEKS00BMV
ICC SensorEKS00BMW
CAUTION:
Perform the laser beam aiming procedure every time the ICC sensor is removed or installed. Refer to
ACS-12, "
LASER BEAM AIMING ADJUSTMENT" .
ICC Steering SwitchEKS00BMX
Replace ICC steering switch as switch kit assembly. Refer to AV- 5 9 , "STEERING WHEEL AUDIO CONTROL
SWITCHES" .
1. Rear inner side panel LH (shown
with finisher removed) 2. ICC unit harness connector 3. ICC unit
⇐ Vehicle front
WKIA4607E
1. ICC sensor bracket 2. ICC frame bracket3. ICC sensor
4. Frame side rail ⇐Vehicle front
WKIA4608E

AT-36
A/T CONTROL SYSTEM
Revision: November 20092006 QX56
Engine Brake ControlECS00CE2

The forward one-way clutch transmits the drive force from the engine to the rear wheels. But the reverse
drive from the rear wheels is not transmitted to the engine because the one-way clutch is idling.
Therefore, the low coast brake solenoid is operated to prevent the forward one-way clutch from idling and
the engine brake is operated in the same manner as conventionally.

The operation of the low coast brake solenoid switches the low coast brake switching valve and controls
the coupling and releasing of the low coast brake.
The low coast brake reducing valve controls the low coast brake coupling force.
Control ValveECS00CE3
FUNCTION OF CONTROL VALVE
SCIA1520E
NameFunction
Torque converter regulator valve In order to prevent the pressure supplied to the torque converter from being excessive,
the line pressure is adjusted to the optimum pressure (torque converter operating pres-
sure).
Pressure regulator valve
Pressure regulator plug
Pressure regulator sleeve Adjusts the oil discharged from the oil pump to the optimum pressure (line pressure) for
the driving state.
Front brake control valve When the front brake is coupled, adjusts the line pressure to the optimum pressure
(front brake pressure) and supplies it to the front brake. (In 1st, 2nd, 3rd, and 5th gears,
adjusts the clutch pressure.)
Accumulator control valve Adjusts the pressure (accumulator control pressure) acting on the accumulator piston
and low coast reducing valve to the pressure appropriate to the driving state.
Pilot valve A Adjusts the line pressure and produces the constant pressure (pilot pressure) required
for line pressure control, shift change control, and lock-up control.
Pilot valve B Adjusts the line pressure and produces the constant pressure (pilot pressure) required
for shift change control.
Low coast brake switching valve During engine braking, supplies the line pressure to the low coast brake reducing valve.
Low coast brake reducing valve When the low coast brake is coupled, adjusts the line pressure to the optimum pressure
(low coast brake pressure) and supplies it to the low coast brake.
N-R accumulator Produces the stabilizing pressure for when N-R is selected.
Direct clutch piston switching valve Operates in 4th gear and switches the direct clutch coupling capacity.
High and low reverse clutch control valve When the high and low reverse clutch is coupled, adjusts the line pressure to the opti-
mum pressure (high and low reverse clutch pressure) and supplies it to the high and low
reverse clutch. (In 1st, 3rd, 4th and 5th gears, adjusts the clutch pressure.)

AT-42
TROUBLE DIAGNOSIS
Revision: November 20092006 QX56
TROUBLE DIAGNOSISPFP:00004
DTC Inspection Priority ChartECS00CE9
If some DTCs are displayed at the same time, perform inspections one by one based on the following priority
chart.
NOTE:
If DTC U1000 is displayed with other DTCs, first perform the trouble diagnosis for DTC U1000. Refer to
AT- 9 6
.
Fail-SafeECS00CEA
The TCM has an electrical fail-safe mode. This mode makes it possible to operate even if there is an error in a
main electronic control input/output signal circuit. In fail-safe mode the transmission is fixed in 2nd, 4th or 5th
(depending on the breakdown position), so the customer should feel “slipping” or “poor acceleration ”.
Even when the electronic circuits are normal, under special conditions (for example, when slamming on the
brake with the wheels spinning drastically and stopping the tire rotation), the transmission can go into fail-safe
mode. If this happens, switch “OFF ” the ignition switch for 10 seconds, then switch it “ON” again to return to
the normal shift pattern. Therefore, the customer's vehicle has returned to normal, so handle according to the
“diagnostics flow ” (Refer to AT- 4 5 , "
WORK FLOW" ).
FAIL-SAFE FUNCTION
If any malfunction occurs in a sensor or solenoid, this function controls the A/T to make driving possible.
Vehicle Speed Sensor

Signals are input from two systems - from vehicle speed sensor A/T (revolution sensor) installed on the
transmission and from combination meter so normal driving is possible even if there is a malfunction in
one of the systems. And if vehicle speed sensor A/T (revolution sensor) has unusual cases, 5th gear is
prohibited.
Accelerator Pedal Position Sensor

If there is a malfunction in one of the systems, the accelerator opening angle is controlled by ECM accord-
ing to a pre-determined accelerator angle to make driving possible. And if there are malfunctions in tow
systems, the engine speed is fixed by ECM to a pre-determined engine speed to make driving possible.
Throttle Position Sensor

If there is a malfunction in one of the systems, the accelerator opening angle is controlled by ECM accord-
ing to a pre-determined accelerator angle to make driving possible. And if there are malfunctions in tow
systems, the accelerator opening angle is controlled by the idle signal sent from the ECM which is based
on input indicating either idle condition or off-idle condition (pre-determined accelerator opening) in order
to make driving possible.
PNP Switch

In the unlikely event that a malfunction signal enters the TCM, the position indicator is switched “OFF”, the
starter relay is switched “OFF ” (starter starting is disabled), the back-up lamp relay switched “OFF” (back-
up lamp is OFF) and the position is fixed to the “D” range to make driving possible.
Starter Relay

The starter relay is switched “OFF”. (Starter starting is disabled.)
Priority Detected items (DTC)
1 U1000 CAN communication line
2 Except above
