< COMPONENT DIAGNOSIS >[AUDIO SYSTEM]
U1204 GPS COMM
U1204 GPS COMM
DescriptionINFOID:0000000001696051
Refer to
AV- 9 , "System Description".
DTC LogicINFOID:0000000001696052
DTC DETECTION LOGIC
DTC CONSULT-III display Detection conditionAction to take
U1204 GPS COMM
[U1204] An internal malfunction is detected in AV control unit (GPS
malfunction). Replace AV control unit. Refer
to
AV- 1 6 4 , "
Removal and Instal-
lation".
Revision: March 2010 2008 QX56

AV
U1205 GPS ROMAV-41
< COMPONENT DIAGNOSIS > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
U1205 GPS ROM
DescriptionINFOID:0000000001696053
Refer to AV-13, "System Description".
DTC LogicINFOID:0000000001696054
DTC DETECTION LOGIC
DTC CONSULT-III display Detection conditionAction to take
U1205 GPS ROM
[U1205] An internal malfunction is detected in AV control unit (GPS
malfunction). Replace AV control unit. Refer
to
AV-164, "
Removal and Instal-
lation".
Revision: March 2010 2008 QX56

AV-42
< COMPONENT DIAGNOSIS >[AUDIO SYSTEM]
U1206 GPS RAM
U1206 GPS RAM
DescriptionINFOID:0000000001696055
Refer to
AV-13, "System Description".
DTC LogicINFOID:0000000001696056
DTC DETECTION LOGIC
DTC CONSULT-III display Detection conditionAction to take
U1206 GPS RAM
[U1206] An internal malfunction is detected in AV control unit (GPS
malfunction). Replace AV control unit. Refer
to
AV- 1 6 4 , "
Removal and Instal-
lation".
Revision: March 2010 2008 QX56

AV
U1207 GPS RTCAV-43
< COMPONENT DIAGNOSIS > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
U1207 GPS RTC
DescriptionINFOID:0000000001696057
Refer to AV-13, "System Description".
DTC LogicINFOID:0000000001696058
DTC DETECTION LOGIC
DTC CONSULT-III display Detection conditionAction to take
U1207 GPS RTC
[U1207] An internal malfunction is detected in AV control unit (GPS
malfunction). Replace AV control unit. Refer
to
AV-164, "
Removal and Instal-
lation".
Revision: March 2010 2008 QX56

AV-44
< COMPONENT DIAGNOSIS >[AUDIO SYSTEM]
U1216 AV CONTROL UNIT
U1216 AV CONTROL UNIT
DescriptionINFOID:0000000001696059
Replace the AV control unit if this DTC is displayed. Refer to
AV-164, "Removal and Installation".
DTC LogicINFOID:0000000001696060
Part name Description
AV CONTROL UNIT • It is the master unit of the MULTI AV system and it is connected to each control
unit by means of communication. It operates each system according to com-
munication signals from the AV control unit.
• AV control unit includes audio function and vehicle information function.
• It is connected to ECM and combination meter via CAN communication to ob- tain necessary information for the vehicle information function.
• It inputs the automatic brightness ON/OFF signals that are required for the dis- play dimming control.
• It inputs the signals for driving status recognition (vehicle speed, reverse and parking brake).
DTC Display contents of CONSULT-III DTC Detection Condition Action to take
U1216 CAN CONT
[U1216] Internal malfunction of AV control unit (CAN controller) is
detected. Replace AV control unit.
Refer to
AV- 1 6 4 , "
Remov-
al and Installation".
Revision: March 2010 2008 QX56

AV
U1217 AV CONTROL UNITAV-45
< COMPONENT DIAGNOSIS > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
U1217 AV CONTROL UNIT
DescriptionINFOID:0000000001696061
Refer to AV-13, "System Description".
DTC LogicINFOID:0000000001696062
DTC DETECTION LOGIC
DTC CONSULT-III display Detection conditionAction to take
U1217 BLUETOOTH CONN
[U1217] An internal malfunction is detected in AV control unit (Blue-
tooth module connection malfunction). Replace AV control unit. Refer
to
AV-164, "
Removal and Instal-
lation".
Revision: March 2010 2008 QX56

AV-46
< COMPONENT DIAGNOSIS >[AUDIO SYSTEM]
U1218 AV CONTROL UNIT
U1218 AV CONTROL UNIT
DescriptionINFOID:0000000001696063
Replace the AV control unit if this DTC is displayed. Refer to
AV-164, "Removal and Installation".
DTC LogicINFOID:0000000001696064
Part name Description
AV CONTROL UNIT • Integrates HDD (hard disk dr
ive) allowing map data and music data to be
stored.
• It is the master unit of the MULTI AV system, and it is connected to each control unit by means of communication. It operates each system according to com-
munication signals from the AV control unit.
• The AV control unit includes the audio, hands-free phone, voice control, navi- gation, and vehicle information functions.
• It is connected to ECM and combination meter via CAN communication to ob-
tain necessary information for the vehicle information function.
• It inputs the automatic brightness ON/OFF signals that are required for the dis- play dimming control.
• It inputs the signals for driving status recognition (vehicle speed, reverse and
parking brake).
DTC Display contents of
CONSULT-III DTC Detection Condition
Action to take
U1218 HDD-CONN
[U1218] Internal malfunction of AV control unit (HDD connection
malfunction) is detected. Replace AV control unit. Refer to
AV-
164, "Removal and Installation".
Revision: March 2010 2008 QX56

AV
U1219 AV CONTROL UNITAV-47
< COMPONENT DIAGNOSIS > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
U1219 AV CONTROL UNIT
DescriptionINFOID:0000000001696065
Replace the AV control unit if this DTC is displayed. Refer to AV-164, "Removal and Installation".
DTC LogicINFOID:0000000001696066
Part name Description
AV CONTROL UNIT • Integrates HDD (hard disk
drive) allowing map data and music data to be
stored.
• It is the master unit of the MULTI AV system, and it is connected to each control unit by means of communication. It operates each system according to com-
munication signals from the AV control unit.
• The AV control unit includes the audio, hands-free phone, voice control, navi- gation, and vehicle information functions.
• It is connected to ECM and combination meter via CAN communication to ob-
tain necessary information for the vehicle information function.
• It inputs the automatic brightness ON/OFF signals that are required for the dis- play dimming control.
• It inputs the signals for driving status recognition (vehicle speed, reverse and
parking brake).
DTC Display contents of
CONSULT-III DTC Detection Condition
Action to take
U1219 HDD-READ
[U1219] Internal malfunction of AV co
ntrol unit (HDD read malfunc-
tion) is detected. Replace AV control unit. Refer to
AV-
164, "Removal and Installation".
Revision: March 2010 2008 QX56

AV-48
< COMPONENT DIAGNOSIS >[AUDIO SYSTEM]
U121A AV CONTROL UNIT
U121A AV CONTROL UNIT
DescriptionINFOID:0000000001696067
Replace the AV control unit if this DTC is displayed. Refer to
AV-164, "Removal and Installation".
DTC LogicINFOID:0000000001696068
Part name Description
AV CONTROL UNIT • Integrates HDD (hard disk dr
ive) allowing map data and music data to be
stored.
• It is the master unit of the MULTI AV system, and it is connected to each control unit by means of communication. It operates each system according to com-
munication signals from the AV control unit.
• The AV control unit includes the audio, hands-free phone, voice control, navi- gation, and vehicle information functions.
• It is connected to ECM and combination meter via CAN communication to ob-
tain necessary information for the vehicle information function.
• It inputs the automatic brightness ON/OFF signals that are required for the dis- play dimming control.
• It inputs the signals for driving status recognition (vehicle speed, reverse and
parking brake).
DTC Display contents of
CONSULT-III DTC Detection Condition
Action to take
U121A HDD-WRITE
[U121A] Internal malfunction of AV control unit (HDD write mal-
function) is detected. Replace AV control unit. Refer to
AV-
164, "Removal and Installation".
Revision: March 2010 2008 QX56

AV
U121B AV CONTROL UNITAV-49
< COMPONENT DIAGNOSIS > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
U121B AV CONTROL UNIT
DescriptionINFOID:0000000001696069
Replace the AV control unit if this DTC is displayed. Refer to AV-164, "Removal and Installation".
DTC LogicINFOID:0000000001696070
Part name Description
AV CONTROL UNIT • Integrates HDD (hard disk
drive) allowing map data and music data to be
stored.
• It is the master unit of the MULTI AV system, and it is connected to each control unit by means of communication. It operates each system according to com-
munication signals from the AV control unit.
• The AV control unit includes the audio, hands-free phone, voice control, navi- gation, and vehicle information functions.
• It is connected to ECM and combination meter via CAN communication to ob-
tain necessary information for the vehicle information function.
• It inputs the automatic brightness ON/OFF signals that are required for the dis- play dimming control.
• It inputs the signals for driving status recognition (vehicle speed, reverse and
parking brake).
DTC Display contents of
CONSULT-III DTC Detection Condition
Action to take
U121B HDD-COMM
[U121B] Internal malfunction of AV
control unit (HDD communica-
tion error) is detected. Replace AV control unit. Refer to
AV-
164, "Removal and Installation".
