wipers INFINITI QX60 2014 Quick Reference Guide

17
Windshield Wiper and Washer Switch
Move the lever to the following positions to operate
the windshield wipers:
01 Mist (MIST) — One sweep operation of the
front wipers.
02 Auto (A UTO ) — Operates the speed-sensing
and rain-sensing (if so equipped) front
wipers intermittently. The intermittent speed
can be adjusted by twisting the time control
ring
03 to increase or decrease wiper speed

or sensitivity
04 Low (LO) — Front wipers operate at a
continuous low-speed.
05 High (HI) — Front wipers operate at a
continuous high-speed.
06 Pull the lever toward you to activate the
front washer. The front wipers will operate
several times.
RAIN-SENSING AUTO WIPER S
y STEM (if so equipped)
The rain-sensing auto wiper system can automatically turn on the wipers \
an d adjust the
wiper speed depending on the rainfall and the vehicle speed.
To set the rain-sensing auto wiper system, push the lever down to the AUTO
position
02.
The wiper will sweep once while the ignition switch is in the ON position.
The rain sensor sensitivity level can be adjusted by turning the time co\
ntrol ring
03 toward
the front or toward the rear.
REAR WINDSHIELD WIPER AND WASHER
07 Intermittent (INT) — Rear wiper operates
intermittently.
08 Low (ON) — Rear wiper operates at a
continuous low-speed.
09 Push the lever forward to activate the
rear washer. The rear wiper will operate
several times.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.
MIST
OFFAUTO LO
HI
INT
ON
01
02
04
06
07
08
05
09
03
