INFINITI QX60 2019 Owner's Manual

∙Fan speed control
Press the fan speed
(decrease)
and
(increase) buttons to manually
control the fan speed. Fan screen can
also be controlled using the display
screen. Touch the
orkey to
set the desired fan speed.
Rear Heating (A/C off)1. To control the rear automatic air condi- tioning system with the front air condi-
tioner control panel, press the CLIMATE
button. When the display shows front
climate control, touch the Rear Climate
key displayed on the screen.
2. Press the AUTO button. The AUTO indi- cator light will illuminate in the display.
Touch the AUTO key on the display and
the feature will activate. ∙ Do not set the temperature lower than
the outside air temperature. Doing so
may cause the temperature to not be
controlled properly.
Turning the system off
1. Press the REAR ON-OFF button on the front control panel and the indicator light
will turn off.
2. Or, press the OFF button. The Rear Cli- mate Controls will turn off.
Turning the system off using the display
screen 1. To control the rear automatic air condi- tioning system with the front air condi-
tioner control panel, press the CLIMATE
button. When the display shows front
climate control, touch the Rear Climate
key displayed on the screen.
2. Touch the
ON/OFF key to turn
off the rear controls using the Rear Cli-
mate display screen.
LHA4929
Monitor, climate, audio, phone and voice recognition systems4-51

Rear control buttons1. OFF button
2.
Fan speed (increase) button
3. AUTO button
4.
Temperature (increase) button
5.
Temperature (decrease) button
6. Display
7.
Fan speed (decrease) button The rear seat passengers can adjust the rear
automatic air conditioning system using the
control switches at the rear of the center
console.
The rear control buttons do not function
when the Rear Climate screen is shown on
the front display. To activate the rear control
buttons, press the CLIMATE button and the
screen will return to Front Climate control. This will enable the second row Rear Climate
controls.
∙ OFF button Turns rear automatic air
conditioning system off.
∙ Fan speed
increase andde-
crease buttons Adjusts the rear fan
speed up or down.
∙ AUTO button Turns rear automatic air
conditioning system on, AUTO mode on.
∙ Temperature
increase anddecrease buttons Adjusts the rear tem-
perature up or down.
Rear Controls
LHA2134
4-52Monitor, climate, audio, phone and voice recognition systems

The air conditioner system in your INFINITI
vehicle is charged with a refrigerant designed
with the environment in mind.
This refrigerant does not harm the earth’s
ozone layer.
Special charging equipment and lubricant is
required when servicing your INFINITI air
conditioner. Using improper refrigerants or
lubricants will cause severe damage to your
air conditioner system. For additional infor-
mation, refer to “Air conditioner system re-
frigerant and oil recommendations” in the
“Technical and consumer information” sec-
tion of this manual.
It is recommended that you visit an INFINITI
retailer for servicing your “environmentally
friendly” air conditioning system.
WARNING
The air conditioner system contains refrig-
erant under high pressure. To avoid per-
sonal injury, any air conditioner service
should be done only by an experienced
technician with proper equipment.There are USB/iPod® charging ports located
in the 1st row beneath the instrument panel,
in the 2nd row on the back of the center
console (if so equipped) and in the 3rd row
above the cup holders. These ports will
charge compatible devices.
NOTE:
The USB/iPod® charging ports will not op-
erate with the display screen. Only the USB
connection port located inside the console
box will operate USB/iPod® devices.
1st row
LHA4791
2nd row (if so equipped)
LHA4869
SERVICING AIR CONDITIONER USB/iPod® CHARGING PORTS
Monitor, climate, audio, phone and voice recognition systems4-53

The vehicle is equipped with a shark fin an-
tenna and an antenna pattern is printed in-
side the rear window.
CAUTION
∙ Do not place metalized film near the rearwindow glass or attach any metal parts
to it. This may cause poor reception or
noise.
∙ When cleaning the inside of the rear win- dow, be careful not to scratch or damage
the rear window antenna. Lightly wipe
along the antenna with a dampened soft
cloth. When installing a CB, ham radio or car phone
in your vehicle, be sure to observe the follow-
ing precautions; otherwise, the new equip-
ment may adversely affect the engine control
system and other electronic parts.WARNING
∙ A cellular phone should not be used for
any purpose while driving so full atten-
tion may be given to vehicle operation.
Some jurisdictions prohibit the use of cel-
lular phones while driving.
∙ If you must make a call while your vehicle is in motion, the hands free cellular phone
operational mode is highly recom-
mended. Exercise extreme caution at all
times so full attention may be given to
vehicle operation.
∙ If you are unable to devote full attention to vehicle operation while talking on the
phone, pull off the road to a safe location
and stop your vehicle.
3rd row
LHA4064
ANTENNA CAR PHONE OR CB RADIO
4-54Monitor, climate, audio, phone and voice recognition systems

CAUTION
∙ Keep the antenna as far away as possiblefrom the electronic control modules.
∙ Keep the antenna wire more than 8 in (20 cm) away from the electronic control
system harnesses. Do not route the an-
tenna wire next to any harness.
∙ Adjust the antenna standing-wave ratio as recommended by the manufacturer.
∙ Connect the ground wire from the CB ra- dio chassis to the body.
∙ For additional information,, it is recom- mended that you visit an INFINITI re-
tailer for servicing.
Monitor, climate, audio, phone and voice recognition systems4-55

MEMO
4-56Monitor, climate, audio, phone and voice recognition systems

5 Starting and driving
Precautions when starting and driving.............5-4
Exhaust gas (carbon monoxide) ................5-4
Three-way catalyst ............................5-4
Tire Pressure Monitoring System (TPMS) .......5-5
On-pavement and off-road driving
precautions ...................................5-8
Avoiding collision and rollover ..................5-9
Off-road recovery .............................5-9
Rapid air pressure loss .........................5-9
Drinking alcohol/drugs and driving ...........5-10
Driving safety precautions ...................5-10
Intelligent All-Wheel Drive (AWD) driving
safety precautions (if so equipped) ............5-12
Push-button ignition switch ....................5-13
Operating range ............................ 5-14
Push-button ignition switch positions ........5-14
Emergency engine shut off ...................5-15
INFINITI Intelligent Key battery
discharge ................................... 5-16
INFINITI Vehicle Immobilizer System .........5-16
Before starting the engine .......................5-17
Starting the engine .............................. 5-17
Remote Engine Start (if so equipped) .........5-18
Driving the vehicle .............................. 5-18Continuously Variable Transmission
(CVT)
....................................... 5-18
Parking brake .................................. 5-23
INFINITI Drive Mode Selector ..................5-24
Standard mode ............................. 5-24
Sport mode ................................. 5-24
Snow mode ................................. 5-24
ECO mode .................................. 5-24
Lane Departure Warning (LDW)
(if so equipped) ................................. 5-27
LDW system operation ......................5-28
How to enable/disable the LDW system .....5-30
LDW system limitations .....................5-30
System temporarily unavailable ..............5-31
System maintenance ........................ 5-32
Lane Departure Prevention (LDP)
(if so equipped) ................................. 5-32
L D

P system operation ....................... 5-34
How to enable/disable the LDP system ......5-35
LDP system limitations ......................5-35
System temporarily unavailable ..............5-37
System maintenance ........................ 5-38
Blind Spot Warning (BSW) ......................5-38
BSW system operation ......................5-40

How to enable/disable the BSW system.....5-42
BSW system limitations .....................5-42
BSW driving situations ......................5-43
System temporarily unavailable ..............5-46
System maintenance ........................ 5-47
Blind Spot Intervention® (BSI) (if so equipped) . . . 5-48 BSI system operation ........................ 5-50
How to enable/disable the BSI system .......5-51
BSI system limitations ....................... 5-52
BSI driving situations ........................ 5-53
System temporarily unavailable ..............5-58
System malfunction ......................... 5-58
System maintenance ........................ 5-58
Backup Collision Intervention (BCI)
(if so equipped) ................................. 5-60
BCI system operation ....................... 5-62
Turning the BCI system on/off ...............5-64
BCI system limitations ....................... 5-65
System temporarily not available .............5-66
System malfunction ......................... 5-67
System maintenance ........................ 5-67
Rear Cross Traffic Alert (RCTA) (if so equipped) . 5-68 RCTA system operation .....................5-69How to enable/disable the RCTA system
.....5-71
RCTA system limitations .....................5-72
System temporarily unavailable ..............5-74
System maintenance ........................ 5-75
Cruise control (if so equipped) ..................5-76
Precautions on cruise control ................5-76
Cruise control operations .....................5-77
Intelligent Cruise Control (ICC) (if so equipped) . . 5-78 ICC system operation ....................... 5-79
The ICC switch .............................. 5-82
Operating ICC .............................. 5-85
Operating conventional (fixed speed)
cruise control mode ......................... 5-90
ICC system limitations ....................... 5-92
System temporarily unavailable ..............5-95
System maintenance ........................ 5-97
Distance

Control Assist (DCA) (if so equipped) . . . 5-98
DCA system operation ......................5-98
How to enable/disable the DCA system .....5-101
DCA system limitations .....................5-102
DCA driving situations ......................5-104
System temporarily unavailable .............5-106
System maintenance ....................... 5-108

Forward Emergency Braking (FEB) with
Pedestrian Detection system..................5-109
System operation .......................... 5-110
Turning the FEB with Pedestrian
Detection system on/off ...................5-112
FEB with Pedestrian Detection system
limitations ................................. 5-113
System temporarily unavailable .............5-115
System malfunction ........................ 5-116
System maintenance ....................... 5-116
Predictive Forward Collision Warning (PFCW) . . 5-117 PFCW system operation ...................5-119
Turning the PFCW system on/off ..........5-120
PFCW system limitations ...................5-122
System temporarily unavailable .............5-126
System malfunction ........................ 5-127
System maintenance ....................... 5-127
Break-in schedule ............................. 5-128
Fuel efficient driving tips .......................5-128
Increasing fuel economy .......................5-130
Intelligent All-Wheel Drive (AWD)
(if so equipped) ................................ 5-130
Parking/parking on hills .......................5-133
Power steering ................................ 5-134Brake system
................................. 5-134
Brake precautions .......................... 5-134
Anti-lock Braking System (ABS) .............5-135
Brake Assist ............................... 5-136
Vehicle Dynamic Control (VDC) system .........5-137
Active Trace Control (if so equipped) ........5-138
Brake force distribution .....................5-138
Hill start assist system ......................... 5-139
Front and rear sonar system (if so equipped) ....5-140
System operation .......................... 5-141
How to enable/disable the sonar system ....5-143
Sonar limitations ........................... 5-143
System temporarily unavailable .............5-143
System maintenance ....................... 5-144
Cold weather

driving.......................... 5-144
Freeing a frozen door lock ..................5-144
Antifreeze ................................. 5-144
Battery .................................... 5-144
Draining of coolant water ..................5-145
Tire equipment ............................. 5-145
Special winter equipment ...................5-145
Driving on snow or ice ...................... 5-145
Engine block heater (if so equipped) .........5-146

WARNING
∙ Do not leave children or adults whowould normally require the assistance of
others alone in your vehicle. Pets should
also not be left alone. They could acciden-
tally injure themselves or others through
inadvertent operation of the vehicle.
Also, on hot, sunny days, temperatures in
a closed vehicle could quickly become
high enough to cause severe or possibly
fatal injuries to people or animals.
∙ Properly secure all cargo with ropes or straps to help prevent it from sliding or
shifting. Do not place cargo higher than
the seatbacks. In a sudden stop or colli-
sion, unsecured cargo could cause per-
sonal injury.
EXHAUST GAS (carbon monoxide)
WARNING
∙ Do not breathe exhaust gases; they con-tain colorless and odorless carbon mon-
oxide. Carbon monoxide is dangerous. It
can cause unconsciousness or death.
∙ If you suspect that exhaust fumes are en- tering the vehicle, drive with all windows
fully open, and have the vehicle inspected
immediately. ∙ Do not run the engine in closed spaces
such as a garage.
∙ Do not park the vehicle with the engine running for any extended length of time.
∙ Keep the rear vent windows, liftgates, doors and trunk lids (if so equipped)
closed while driving, otherwise exhaust
gases could be drawn into the passenger
compartment. If you must drive with one
of these open, follow these precautions:
1. Open all the windows.
2. Set the
air recirculation button
to off and the fan control dial to high
to circulate the air.
∙ If electrical wiring or other cable connec- tions must pass to a trailer through the
seal on the liftgate or the body, follow
the manufacturer’s recommendation to
prevent carbon monoxide entry into the
vehicle.
∙ The exhaust system and body should be inspected by a qualified mechanic
whenever:
a. The vehicle is raised for service.
b.
You suspect that exhaust fumes are en-
tering into the passenger compartment.
c. You notice a change in the sound of the exhaust system.
d. You have had an accident involving damage to the exhaust system, un-
derbody, or rear of the vehicle.
THREE-WAY CATALYST
The three-way catalyst is an emission control
device installed in the exhaust system. Ex-
haust gases in the three-way catalyst are
burned at high temperatures to help reduce
pollutants.
WARNING
∙ The exhaust gas and the exhaust systemare very hot. Keep people, animals or
flammable materials away from the ex-
haust system components.
∙ Do not stop or park the vehicle over flam- mable materials such as dry grass, waste
paper or rags. They may ignite and cause
a fire.
CAUTION
∙ Do not use leaded gasoline. Depositsfrom leaded gasoline will seriously reduce
the three-way catalyst’s ability to help
reduce exhaust pollutants.
PRECAUTIONS WHEN STARTING
AND DRIVING
5-4Starting and driving
