The BCI system uses radar sensors*1
installed on both sides near the rear
bumper to detect an approaching vehicles
and sonar sensors
*2to detect objects in
the rear.
The radar sensors
*1detect the approach-
ing vehicle from up to approximately 49 ft
(15 m) away. The sonar sensors
*2detect
a rear obstacle at up to approximately 4.9
ft (1.5 m) from the bumper. Refer to the
illustration for approximate zone coverage
areas
*3.
If the radar detects a vehicle approaching
from the side or the sonar detects close
objects in the rear, the system gives visual and audible warnings, and applies the
brake for a moment when the vehicle is
moving backwards. After the automatic
brake application, the driver must depress
the brake pedal to maintain brake pres-
sure. If the driver’s foot is on the accel-
erator pedal, the system pushes the
accelerator upward before applying the
brake. If you continue to press the accel-
erator, the system will not engage the
brake.
WARNING
.
The BCI system is not a replacement for
proper driving procedure and is not
designed to prevent contact with vehi-
cles or objects. When backing out of
parking space, always use the inside
and outside rearview mirrors and turn
and look in the direction you will move.
Never rely solely on the BCI system.
. There is a limitation to the detection
capability of the radar or the sonar.
Using the BCI system under some road,
ground, lane marker, traffic or weather
conditions could lead to improper sys-
tem operation. Always rely on your own operation to avoid accidents.

JVS0197X
BCI ON indicator
BCI SYSTEM OPERATION (if so
equipped)
When the shift lever is placed in the R
(Reverse) position, the BCI ON indicator
appears in the vehicle information display.
SSD1086
Blind spot warning indicator light
JVS0171X
Vehicle center displayThe BCI system operates by detecting
vehicles and/or objects using either the
radar or sonar sensors.
An approaching vehicle from the side:
If the radar detects an approaching vehicle
from the side, the system chimes a sound
(single beep), the Blind spot warning
indicator light on the side the approaching
vehicle flashes and a yellow rectangular
frame
*Aappears on the center display.
Starting and driving5-47

5-48Starting and driving
JVS0172X
JVS0173X
NOTE:
.In the case of several vehicles ap-
proaching in a row or from the opposite
direction, a chime may not be output to
the BCI system after the first vehicle
passes the sensors.
. When the parking sensor of the Around
View Monitor sounds a tone, the BCI
system does not chime a sound (single
beep).
If the detected vehicle approaches closer
and your vehicle is backing up toward the
detected vehicle, the system chimes a
sound (three times) and a red rectangular
frame
*Aappears on the center display.
The system applies the brake for a
moment. After the automatic brake appli-
cation, the driver must depress the brake
pedal to maintain brake pressure.
If the driver’s foot is on the accelerator
pedal, the system pushes the accelerator
pedal upward before applying the brake. If
you continue to press the accelerator
pedal, the system will not engage the
brake. A close object behind the vehicle:
If the sonar detects a close object behind
the vehicle when your vehicle is backing
up, the system chimes a sound (three
times) and a red rectangular frame
*A
appears on the center display. The system
applies the brake for a moment. After the
automatic brake application, the driver
must depress the brake pedal to maintain
brake pressure.
If the driver’s foot is on the accelerator
pedal, the system pushes the accelerator
pedal upward before applying the brake. If
you continue to press the accelerator
pedal, the system will not engage the
brake.
NOTE:
The BCI system does not operate if the
object is very close to the bumper.

JVS0170X
Precautions on BCI system
WARNING
.When the radar sensors may not be able
to detect certain objects such as:
—Pedestrians, bicycles or animals
—A vehicle that passing at speeds
greater than approximately 15 MPH
(24 km/h)
. The radar sensors may not detect approaching vehicles in certain situa-
tions.
—When the vehicle parked aside
obstruct the beam of the radar
sensor.
—When the vehicle is parked in an
angled parking space.
—When the vehicle is parked on theinclined ground.
—When the vehicle turns around into
your vehicle’s aisle.
—When the angle formed by yourvehicle and approaching vehicle is
small
. Severe weather or road spray conditions
may reduce the ability of the radar to
detect other vehicles.
. The sonar sensor may not detect:
—Small or moving objects
—Wedge-shaped objects
—Object close to the bumper (less
than approximately 1 ft (30 cm)) -
Thin objects such as rope, wire and
chain, etc.
Starting and driving5-51

JVS0184X
BCI malfunction
When the BCI system malfunctions, it will
be turned off automatically, a beep will
sound and“BCI MALFUNCTION” warning
will appear in the vehicle information
display.
Stop the vehicle in a safe location, turn the
engine off and restart the engine. If the
warning message continues to appear,
have the system checked by an INFINITI
retailer.
JVS0098X
SYSTEM MAINTENANCE
. The two radar sensor units*1for the
BSW, Blind Spot InterventionTMand BCI
(if so equipped) systems are located
near the rear bumper.
— Always keep the area near the radar
sensors clean.
— Do not attach stickers (including
transparent material), install acces-
sories or apply additional paint near
the radar sensors.
— Do not strike or damage the area
around the radar sensors. —
Consult an INFINITI retailer if the
area around the radar sensors is
damaged due to a collision.
. The Blind Spot Intervention
TMsystem
uses the same camera
*2that is used
by the LDW/LDP system located in front
of the inside mirror.
For maintenance of the camera, see “Lane
Departure Warning (LDW)/Prevention (LDP)
system ”earlier in this section.
Radio frequency statement
This device complies with part 15 of the
FCC Rules and RSS-310 of Industry Canada.
Operation is subject to the following two
conditions:
1. This device may not cause harmful
interference.
2. This device must accept any interfer- ence received, including interference
that may cause undesired operation.
Frequency of operation: 24.05GHz —
24.25GHz
Field Strength: Not greater than 2.5V/m
peak (0.25V/m average) at a distance of 3
m
The manufacturer is not responsible for
any radio or TV interference caused by
Starting and driving5-53
