trip computer INFINITI QX80 2018 Owner's Manual

0-8Illustrated table of contents
JVC1128X
1. Power liftgate switch (if so equipped)(P.3-21)
2. Heated steering wheel switch (P.2-45)
3. Instrument brightness control switch (P.2-43) 4. TRIP/RESET switch for twin trip od-
ometer (P.2-7)
5. Headlight, fog light and turn signal switch
— Headlight (P.2-37)
— Turn signal (P.2-44) — Fog light (P.2-44)
6. Steering-wheel-mounted controls (left side)
— Audio control steering switch (See
Infiniti InTouch Owner’s Manual.)
— Hands-Free Phone System switch
(See Infiniti InTouch Owner’s Manual.)
7. Trip computer switch (P.2-28)
8. Wiper and washer switch (P.2-33)
9. Steering-wheel-mounted controls (right side)
— Cruise control system (if so
equipped) (P.5-65)
— Intelligent Cruise Control (ICC) sys-
tem (if so equipped) (P.5-66)
10. Dynamic driver assistance switch (if so equipped)
— Lane Departure Prevention (LDP)
system (if so equipped) (P.5-22)
— Distance Control Assist (DCA) sys-
tem (if so equipped) (P.5-87)
— Blind Spot Intervention
®(BSI) sys-
tem (if so equipped) (P.5-42)
11. Shift lever (P.5-17)
12. Four-Wheel Drive (4WD) shift switch (if so equipped) (P.5-120)/SNOW
mode switch (P.2-49)/TOW mode
switch (P.2-50)/Vehicle Dynamic Con-
trol (VDC) OFF switch (P.5-133)
COCKPIT

2 Instruments and controls
Cockpit ........................................................................\
......... 2-3
Instrument panel ............................................................... 2-5
Meters and gauges .......................................................... 2-6Speedometer and odometer ..................................... 2-7
Tachometer ................................................................... 2-8
Engine coolant temperature gauge ....................... 2-8
Fuel gauge ..................................................................... 2-9
Engine oil pressure gauge ......................................... 2-9
Voltmeter ..................................................................... 2-10
Meter/ring illumination and needle sweep ........ 2-10
Warning lights, indicator lights and
audible reminders ............................................................ 2-11 Checking lights ........................................................... 2-12
Warning lights ............................................................ 2-12
Indicator lights ........................................................... 2-18
Audible reminders ..................................................... 2-21
Vehicle information display .......................................... 2-21 Operational indicators ............................................. 2-24
Maintenance indicators ........................................... 2-27
Trip computer ............................................................. 2-28
Security systems ............................................................. 2-31 Vehicle Security System .......................................... 2-31
INFINITI Vehicle Immobilizer System .................. 2-32 Wiper and washer switch ............................................ 2-33
Washer operation ................................................... 2-34
Rain-sensing auto wiper system ........................ 2-35
Rear window wiper and washer operation ..... 2-36
Rear window and outside mirror
defroster switch ............................................................. 2-36
Rear window and outside mirror defroster ..... 2-36
Headlight and turn signal switch ............................... 2-37 Headlight switch ..................................................... 2-37
Headlight washer (if so equipped) ..................... 2-42
Instrument brightness control ............................. 2-43
Turn signal switch .................................................. 2-44
Fog light switch ...................................................... 2-44
Heated steering wheel ................................................. 2-45
Horn ........................................................................\
........... 2-45
Heated seats (if so equipped) ..................................... 2-46 Front ........................................................................\
... 2-46
Rear ........................................................................\
..... 2-47
Climate controlled seats (if so equipped) ............... 2-48
Warning systems switch (if so equipped) ............... 2-49
SNOW mode switch ..................................................... 2-49
TOW mode switch ........................................................ 2-50
Vehicle Dynamic Control (VDC) OFF switch ........ 2-50

JVC1128X
1. Power liftgate switch (if so equipped)
2. Heated steering wheel switch
3. Instrument brightness control switch
4. TRIP/RESET switch for twin trip od-ometer
5. Headlight, fog light and turn signal switch
— Headlight
— Turn signal
— Fog light
6. Steering-wheel-mounted controls (left side) — Audio control steering switch
— Hands-Free Phone System switch
7. Trip computer switch
8. Wiper and washer switch
9. Steering-wheel-mounted controls (right side)
— Cruise control system (if so
equipped)
— Intelligent Cruise Control (ICC) sys-
tem (if so equipped)
10. Dynamic driver assistance switch (if so equipped)
— Lane Departure Prevention (LDP)
system (if so equipped)
— Distance Control Assist (DCA) sys-
tem (if so equipped)
— Blind Spot Intervention
®(BSI) sys-
tem (if so equipped)
11. Shift lever
12. Four-Wheel Drive (4WD) shift switch (if so equipped)/SNOW mode switch/
TOW mode switch/Vehicle Dynamic
Control (VDC) OFF switch
13. Headlight aiming control (if so equipped)
14. Power liftgate main switch
15. Warning systems switch (if so equipped)
— Lane Departure Warning (LDW) (if
Instruments and controls2-3
COCKPIT

2-10Instruments and controls
to check the oil level. (See “Engine oil”
(P.8-6).)
. If the gauge needle does not move
with the proper amount of engine oil,
have the vehicle checked. It is recom-
mended you visit an INFINITI retailer
for this service. Continued vehicle
operation in such a condition could
cause serious damage to the engine.
SIC4376
VOLTMETER
When the ignition switch is pushed to the
ON position, the volt meter indicates the
battery voltage. When the engine is running,
it indicates the generator voltage.
While cranking the engine, the volt drop
below the normal range. If the needle is not
in the normal range (10.5 to 15.5 volt) while
the engine is running, it may indicate that the
charging system is not functioning properly.
Have the system checked. It is recommended
you visit an INFINITI retailer for this service.
METER/RING ILLUMINATION
AND NEEDLE SWEEP
The ring illumination surrounding meters and
gauges illuminates when the driver’s door is
closed after getting into the vehicle with the
Intelligent Key carried in.
When the engine is started, the indicator
needles will sweep in the speedometer and
tachometer and the ring illumination will be
brightened gradually. This function can be
turned off. (See “Trip computer” (P.2-28).)

2-26Instruments and controls
.Distance Control Assist (DCA) system (if
so equipped)
. Forward Emergency Braking (FEB) with
pedestrian detection system (if so
equipped)
. Predictive Forward Collision Warning
(PFCW) system (if so equipped)
For more details, see “Intelligent Cruise
Control (ICC)” (P.5-66), “Distance Control
Assist (DCA)” (P.5-87), “Forward Emer-
gency Braking (FEB) with pedestrian detec-
tion” (P.5-100) or “Predictive Forward
Collision Warning (PFCW)” (P.5-110).
19. “TIMER” indicator
This indicator appears when the set “TIMER”
indicator activates. You can set the time for
up to 6 hours. (See “Trip computer” (P.2-
28).)
20. Low outside temperature
warning
This warning appears if the outside tem-
perature is below 37°F (3°C). The warning
can be set not to be displayed. (See “Trip
computer” (P.2-28).)
21. Four-Wheel Drive (4WD) shift
indicator (4WD models)
This indicator shows the Four-Wheel Drive
(4WD) driving mode (AUTO, 4HI or 4LO) that is selected by the 4WD shift switch.
(See “INFINITI all-mode 4WD
®” (P.5-120).)
22. Intelligent Cruise Control (ICC)
system MAIN switch indicator (if so
equipped)
The Intelligent Cruise Control (ICC) system
main switch indicator (CRUISE) is displayed
when the ICC main switch is pushed. When
the main switch is pushed again, the indi-
cator disappears. While the CRUISE indica-
tor is displayed, the ICC system is
operational.
The cruise control set indicator (SET) is
displayed while the vehicle is controlled by
the conventional (fixed speed) cruise control
mode of the ICC system.
For more details, see “Intelligent Cruise
Control (ICC)” (P.5-66).
23. Distance Control Assist (DCA)
system switch indicator (if so
equipped)
The indicator is displayed when the Distance
Control Assist (DCA) system switch is
pushed on. When the switch is pushed again,
the indicator disappears. While the indicator
is displayed, the DCA system is operational.
(See “Distance Control Assist (DCA)” (P.5-
87) .)
24. Back-up Collision Intervention
(BCI) system indicator (if so
equipped)
The BCI ON indicator (SYSTEM ON) ap-
pears when the shift lever is in the R
(Reverse) position with the Back-up Collision
Intervention (BCI) system turned on.
If the BCI system is turned off, the BCI OFF
indicator (SYSTEM OFF) appears.
For more details, see “Back-up Collision
Intervention (BCI)” (P.5-55).

SIC4325
MAINTENANCE INDICATORS
1. Engine oil replacement indicator
This indicator appears when the customer
set time comes for changing the engine oil.
You can set or reset the distance for
changing the engine oil. (See “Trip computer”
(P.2-28).)
2. Oil filter replacement indicator
This indicator appears when the customer
set time comes for replacing the oil filter.
You can set or reset the distance for
replacing the oil filter. (See “Trip computer”
(P.2-28).)
3. Tire replacement indicator
This indicator appears when the customer
set distance comes for replacing tires. You
can set or reset the distance for replacing
tires. (See “Trip computer” (P.2-28).)
WARNING
The tire replacement indicator is not a
substitute for regular tire checks, includ-
ing tire pressure checks. See “Changing
wheels and tires” (P.8-34). Many fac-
tors including tire inflation, alignment,
driving habits and road conditions affect
tire wear and when tires should bereplaced. Setting the tire replacement
indicator for a certain driving distance
does not mean your tires will last that
long. Use the tire replacement indicator
as a guide only and always perform
regular tire checks. Failure to perform
regular tire checks, including tire pres-
sure checks could result in tire failure.
Serious vehicle damage could occur and
may lead to a collision, which could result
in serious personal injury or death.
4. “OTHER” indicator
This indicator appears when the customer
set time comes for replacing items other
than the engine oil, oil filter and tires. You
can set or reset the distance for replacing
the items. (See “Trip computer” (P.2-28).)
More maintenance reminders are also avail-
able on the center display. (See Infiniti
InTouch Owner’s Manual.)
Instruments and controls2-27

2-28Instruments and controls
SIC4494
SIC4420
TRIP COMPUTER
Switches for the trip computer are located
on the right side of the combination meter
panel. To operate the trip computer, push
the switches as shown above.
switch
switch
When the ignition switch is pushed to the
ON position, modes of the trip computer can
be selected by pushing the
switch.
Each time the
switchis pushed, the
display will change as follows:
Current fuel consumption ?Average fuel
consumption and speed ?Elapsed time and
trip odometer ?Distance to empty (dte) ?

Extended storage fuse warning ...................... 2-25
Extended storage switch .................................. 8-20
F
F.M.V.S.S./C.M.V.S.S. certification label .... 10-12
FilterAir cleaner housing filter ............................. 8-14
Changing engine oil and filter ...................... 8-6
Flashers (See hazard warning
flasher switch) ......................................................... 6-2
Flat tire ...................................................................... 6-3
Flat towing ......................................................... 10-30
Flexible seating ..................................................... 1-11
Floor mat cleaning ................................................. 7-6
Fluid
Automatic Transmission Fluid (ATF) ......... 8-8
Brake fluid ......................................................... 8-9
Capacities and
recommended fluids/lubricants ................. 10-2
Engine coolant .................................................. 8-4
Engine oil ........................................................... 8-6
Power steering fluid ....................................... 8-8
Window washer fluid .................................. 8-10
Fog light switch ................................................... 2-44
Forward Emergency Braking (FEB) with
pedestrian detection system ......................... 5-100
Forward Emergency Braking system
warning light ......................................................... 2-15
Front passenger air bag and status light ..... 1-60
Front power seat adjustment ............................. 1-4 Front seat
Front seat adjustment ........................ 1-4, 1-10
Front-seat active head restraint ...................... 1-17
Fuel
Capacities and
recommended fluids/lubricants ................. 10-2
Fuel economy .............................................. 5-120
Fuel information ........................................... 10-4
Fuel octane rating ........................................ 10-4
Fuel-filler cap .................................................. 3-26
Fuel-filler door ............................................... 3-26
Gauge .................................................................. 2-9
LOOSE FUEL CAP warning ...................... 3-28
Fuel efficient driving tips ................................. 5-119
Fuses ....................................................................... 8-18
Fusible links ........................................................... 8-19
G
Garage door opener HomeLink®
Universal Transceiver ....................... 2-68, 2-72
Gas cap ................................................................... 3-26
Gauge ........................................................................\
. 2-6 Engine coolant temperature gauge ............ 2-8
Engine oil pressure gauge ............................. 2-9
Fuel gauge ......................................................... 2-9
Odometer ............................................................ 2-7
Speedometer ...................................................... 2-7
Tachometer ....................................................... 2-8
Trip computer ................................................. 2-28
General maintenance ............................................. 9-2 Glove box ............................................................... 2-56
H
Hazard warning flasher switch ........................... 6-2
Head restraints/headrests ................................ 1-13
Headlight washer ................................................ 2-42
Headlights
Aiming control ................................................ 2-41
Aiming control (See adaptive front
lighting system (AFS)) .................................. 2-42
Bulb replacement .......................................... 8-24
Headlight switch ............................................ 2-37
Heated seats ......................................................... 2-46
Heated steering wheel ....................................... 2-45
Heater Automatic climate control ............. 4-26, 4-28
Engine block heater .................................... 5-137
High beam assist ................................................. 2-39
Hill start assist system ..................................... 5-128
HomeLink
®Universal Transceiver ...... 2-68, 2-72
Hood release ......................................................... 3-21
Hook Coat hooks ...................................................... 2-59
Luggage hook ................................................. 2-59
Horn ........................................................................\
. 2-45
I
Ignition switch (Push-button) .......................... 5-12
Immobilizer system .............................................. 2-32
In-cabin microfilter .............................................. 4-35
11-3

Low tire pressure warning system (See tire
pressure monitoring system (TPMS)) ............... 5-5
Luggage hooks ..................................................... 2-59
M
MaintenanceBattery .............................................................. 8-11
General maintenance ...................................... 9-2
Inside the vehicle ............................................. 9-3
Maintenance indicators ............................... 2-27
Maintenance log ............................................ 9-14
Maintenance precautions .............................. 8-2
Maintenance requirements ........................... 9-2
Maintenance schedules ................................. 9-6
Maintenance under severe
driving conditions .......................................... 9-13
Outside the vehicle ......................................... 9-2
Seat belt maintenance ................................. 1-28
Standard maintenance .................................... 9-7
Maintenance schedules ........................................ 9-6
Malfunction indicator light (MIL) .................... 2-19
Map lights .............................................................. 2-66
Master warning light ........................................... 2-17
Mechanical key (Intelligent Key system) .......... 3-3
Memory storage, Automatic
drive positioner .................................................... 3-39
Meter
Trip computer ................................................. 2-28
Meters and gauges ................................................ 2-6 Instrument brightness control ................... 2-43 Mirror
Inside mirror ................................................... 3-30
Outside mirrors .............................................. 3-36
Smart Rearview Mirror ................................ 3-31
Vanity mirror ................................................... 3-38
Monitor Around View®Monitor .................................. 4-3
Moonroof ............................................................... 2-64
Moving Object Detection (MOD) ................... 4-20
N
New vehicle break-in ........................................ 5-119
O
Odometer .................................................................. 2-7
Off-road recovery .................................................. 5-9
Oil Capacities and
recommended fluids/lubricants ................. 10-2
Changing engine oil and filter ...................... 8-6
Checking engine oil level ............................... 8-6
Engine oil ........................................................... 8-6
Engine oil pressure gauge ............................. 2-9
Engine oil viscosity ........................................ 10-7
Oil filter replacement indicator .................. 2-27
Operation, operational indicators ................... 2-24
Outside air temperature .................................... 2-29
Outside mirrors .................................................... 3-36
Overheat, If your vehicle overheats ............... 6-14 Owner’s Manual/Service Manual
order information ............................................. 10-34
P
Panic alarm ............................................................ 3-16
Parking
Brake break-in .............................................. 5-131
Parking brake operation .............................. 5-22
Parking on hills ............................................. 5-129
Phone Car phone or CB radio ................................. 4-36
Pocket ..................................................................... 2-58
Power Front seat adjustment ................................... 1-4
Moonroof ......................................................... 2-64
Power door lock ............................................... 3-4
Power outlet ................................................... 2-51
Power steering fluid ....................................... 8-8
Power steering system .............................. 5-131
Power windows ............................................. 2-61
Precautions
Braking precautions .................................... 5-131
Child restraints ............................................... 1-31
Cruise control ................................................. 5-65
Driving safety ................................................. 5-10
Maintenance ..................................................... 8-2
On-pavement and off-road driving ........... 5-8
Seat belt usage .............................................. 1-18
Supplemental restraint system .................. 1-52
When starting and driving ............................ 5-4
11-5

Supplemental air bag warning light .... 1-69, 2-17
Supplemental restraint system ........................ 1-52Precautions on supplemental
restraint system ............................................. 1-52
Switch Autolight switch ............................................. 2-37
Fog light switch ............................................ 2-44
Hazard warning flasher switch .................... 6-2
Headlight aiming control ............................. 2-41
Headlight switch ............................................ 2-37
Ignition switch ................................................ 5-18
Power door lock switch ................................. 3-5
Snow mode switch ........................................ 2-49
Turn signal switch ........................................ 2-44
Vehicle dynamic control (VDC)
off switch ........................................................ 2-50
T
Tachometer ............................................................. 2-8
Temperature gauge, Engine coolant
temperature gauge ............................................... 2-8
Theft (INFINITI Vehicle Immobilizer System),
Engine start ........................................................... 2-32
Three-way catalyst ............................................... 5-4
Tilt/telescopic steering ...................................... 3-29
TirePressure, Low tire pressure
warning light ................................................... 2-15
Tire replacement indicator .......................... 2-27
Tires
Flat tire ............................................................... 6-3 Low tire pressure warning system ............. 5-5
Tire and Loading
information label ............................. 8-29, 10-13
Tire chains ........................................................ 8-33
Tire dressing ...................................................... 7-4
Tire pressure ................................................... 8-27
Tire pressure monitoring
system (TPMS) ........................................ 5-5, 6-3
Tire rotation ................................................... 8-34
Types of tires .................................................. 8-33
Uniform tire quality grading .................... 10-30
Wheel/tire size ............................................... 10-9
Wheels and tires ............................................ 8-27
Top Tether strap child restraints ....................... 1-36
TOW mode ......................................................... 5-130
TOW mode switch .............................................. 2-50
Towing Flat towing ................................................... 10-30
Tow truck towing .......................................... 6-15
Towing a trailer ........................................... 10-18
Towing safety .............................................. 10-22
TPMS, Tire pressure monitoring system ......... 5-5 TPMS with Tire Inflation Indicator ............. 5-7
TPMS, Tire pressure warning system .............. 6-3
Trailer towing .................................................... 10-18
Transceiver HomeLink
®
Universal Transceiver ....................... 2-68, 2-72
Transmission
Automatic Transmission Fluid (ATF) ......... 8-8 Driving with automatic transmission ....... 5-18
Transmission shift lever lock release ....... 5-21
Transmitter (See remote keyless
entry system) ........................................................ 3-15
Traveling or registering your vehicle in
another country ................................................. 10-11
Trip computer ....................................................... 2-28
Trip odometer ....................................................... 2-29
Turn signal switch ............................................... 2-44
U
Underbody cleaning ............................................... 7-3
Uniform tire quality grading .......................... 10-30
USB (Universal Serial Bus)
charging connector ............................................. 2-53
V
Vanity mirror ......................................................... 3-38
Vanity mirror lights ............................................. 2-68
Variable voltage control system ..................... 8-13
Vehicle Dimensions ................................................... 10-10
Identification number (VIN) ...................... 10-11
Loading information .................................. 10-14
Recovery (freeing a stuck vehicle) ............ 6-18
Security system .............................................. 2-31
Vehicle dynamic control (VDC)
off switch ........................................................ 2-50
Vehicle dynamic control
(VDC) system ................................................ 5-133
11-7
