GENERAL INFORMATION
AXIOM
GENERAL INFORMATION
CONTENTS
General Information 0A. . . . . . . . . . . . . . . . . . . . .
Maintenance and Lubrication 0B. . . . . . . . . . . . .
General Information
CONTENTS
General Repair Instruction 0A±1. . . . . . . . . . . . . . . .
Illustration Arrows 0A±2. . . . . . . . . . . . . . . . . . . . . . .
Identification 0A±3. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Theft Prevention Standard 0A±5. . . . . . . . . . . . . . . . Lifting Instructions 0A±9. . . . . . . . . . . . . . . . . . . . . . .
Standard Bolts Torque Specifications 0A±11. . . . . .
Abbreviations Charts 0A±12. . . . . . . . . . . . . . . . . . . .
Service Parts Identification Plate 0A±13. . . . . . . . . .
General Repair Instruction
1. If a floor jack is used, the following precautions are
recommended.
Park vehicle on level ground, ªblockº front or rear
wheels, set jack against the recommended lifting
points (see ªLifting Instructionsº in this section), raise
vehicle and support with chassis stands and then
perform the service operations.
2. Before performing service operations, disconnect
ground cable from the battery to reduce the chance of
cable damage and burning due to short circuiting.
3. Use a cover on body, seats and floor to protect them
against damage and contamination.
4. Brake fluid and anti±freeze solution must be handled
with reasonable care, as they can cause paint
damage.
5. The use of proper tools and recommended essential
and available tools, where specified, is important for
efficient and reliable performance of service repairs.
6. Use genuine Isuzu parts.
7. Used cotter pins, plastic clips, gaskets, O±rings, oil
seals, lock washers and self±locking nuts should be
discarded and new ones should be installed, as
normal function of the parts cannot be maintained if
these parts are reused.
8. To facilitate proper and smooth reassembly
operation, keep disassembled parts neatly in groups.
Keeping fixing bolts and nuts separate is very
important, as they vary in hardness and design
depending on position of installation.
9. Clean the parts before inspection or reassembly. Also
clean oil ports, etc. using compressed air, and make
certain they are free from restrictions.
10. Lubricate rotating and sliding faces of the parts with
oil or grease before installation.
11. When necessary, use a sealer on gaskets to prevent
leakage.
12. Carefully observe all specifications for bolt and nut
torques.13. When removing or replacing parts that require
refrigerant to be discharged from the air conditioning
system, be sure to use the Vehicle Refrigerant
Recovery and Recycling Equipment (VRRRE) to
recover and recycle Refrigerant±134a.
14. When a service operation is completed, make a final
check to be sure the service has been done properly
and the problem has been corrected.
15. SUPPLEMENTAL RESTRAINT SYSTEM
The vehicle is equipped with a Supplemental
Restraint System (SRS) ± Air Bags. This system is
not to be serviced without consulting the appropriate
service information. Consult Section 9J ªSRS
Systemº if work is to be done on the front of the
vehicle such as bumper, sheet metal, seats, wiring,
steering wheel or column. Also review SRS system
information if any arc welding is to be done on the
vehicle. The SRS system equipped vehicle can be
identified by:
1. ªAIR BAGº warning light on the instrument
cluster.
2. A Code ªKº or ªMº for fifth digit of Vehicle
Identification Number.

0A±4
GENERAL INFORMATION
Engine Serial Number
The gasoline engine serial number is stamped on the left
rear lower area of the cylinder block above the starter.
240R200014Automatic : Stamped on the identification plate, located
on the left side of the transmission above the mode
switch.
240R200013

0A±12
GENERAL INFORMATION
Abbreviations Charts
List of automotive abbreviations which may be used
in this manual
A Ð Ampere(s)
ABS Ð Antilock Brake System
AC Ð Alternating Current
A/C Ð Air Conditioning
ACCEL Ð Accelerator
ACC Ð Accessory
ACL Ð Air Cleaner
Adj Ð Adjust
A/F Ð Air Fuel Ratio
AIR Ð Secondary Air Injection System
Alt Ð Altitude
AMP Ð Ampere(s)
ANT Ð Antenna
ASM Ð Assembly
A/T Ð Automatic Transmission/Transaxle
ATDC Ð After Top Dead Center
ATF Ð Automatic Transmission Fluid
Auth Ð Authority
Auto Ð Automatic
BARO Ð Barometric Pressure
Bat Ð Battery
B+ Ð Battery Positive Voltage
Bbl Ð Barrel
BHP Ð Brake Horsepower
BPT Ð Backpressure Transducer
BTDC Ð Before Top Dead Center

C Ð Degrees Celsius
CAC Ð Charge Air Cooler
Calif Ð California
cc Ð Cubic Centimeter
CID Ð Cubic Inch Displacement
CKP Ð Crankshaft Position
CL Ð Closed Loop
CLCC Ð Closed Loop Carburetor Control
CMP Ð Camshaft Position
CO Ð Carbon Monoxide
Coax Ð Coaxial
Conn Ð Connector
Conv Ð Converter
Crank Ð Crankshaft
Cu. In. Ð Cubic Inch
CV Ð Constant Velocity
Cyl Ð Cylinder(s)
DI Ð Distributor Ignition
Diff Ð Differential
Dist Ð Distributor
DLC Ð Data Link Connector
DOHC Ð Double Overhead Camshaft
DTC Ð Diagnostic Trouble Code
DTM Ð Diagnostic Test Mode
DTT Ð Diagnostic Test Terminal
DVM Ð Digital Voltmeter (10 meg.)
DVOM Ð Digital Volt Ohmmeter
EBCM Ð Electronic Brake Control Module
ECM Ð Engine Control Module
ECT Ð Engine Coolant Temperature
EEPROM Ð Electronically Erasable Programmable
Read Only Memory
EGR Ð Exhaust Gas Recirculation
EI Ð Electronic Ignition
ETR Ð Electronically Tuned Receiver
EVAP Ð Evaporation EmissionExh Ð Exhaust

F Ð Degrees Fahrenheit
Fed Ð Federal (All States Except Calif.)
FF Ð Front Drive Front Engine
FL Ð Fusible Link
FLW Ð Fusible Link Wire
FP Ð Fuel Pump
FRT Ð Front
ft Ð Foot
FWD Ð Front Wheel Drive
4WD Ð Four Wheel Drive
4 x 4 Ð Four Wheel Drive
4 A/T Ð Four Speed Automatic Transmission/Transaxle
Gal Ð Gallon
GEN Ð Generator
GND Ð Ground
Gov Ð Governor
g Ð Gram
Harn Ð Harness
HC Ð Hydrocarbons
HD Ð Heavy Duty
Hg Ð Hydrargyrum (Mercury)
HiAlt Ð High Altitude
HO2S Ð Heated Oxygen Sensor
HVAC Ð Heater±Vent±Air±Conditioning
IAC Ð Idle Air Control
IAT Ð Intake Air Temperature
IC Ð Integrated Circuit / Ignition Control
ID Ð Identification / Inside Diameter
IGN Ð Ignition
INJ Ð Injection
IP Ð Instrument Panel
IPC Ð Instrument Panel Cluster
Int Ð Intake
ISC Ð Idle Speed Control
J/B Ð Junction Block
kg Ð Kilograms
km Ð Kilometers
km/h Ð Kilometer per Hour
kPa Ð Kilopascals
kV Ð Kilovolts (thousands of volts)
kW Ð Kilowatts
KS Ð Knock Sensor
L Ð Liter
lb ft Ð Foot Pounds
lb in Ð Inch Pounds
LF Ð Left Front
LH Ð Left Hand
LR ÐLeft Rear
LS Ð Left Side
LWB Ð Long Wheel Base
L±4 Ð In±Line Four Cylinder Engine
MAF Ð Mass Air Flow
MAN Ð Manual
MAP Ð Manifold Absolute Pressure
Max Ð Maximum
MC Ð Mixture Control
MFI Ð Multiport Fuel Injection
MIL Ð Malfunction Indicator Lamp
Min Ð Minimum
mm Ð Millimeter
MPG Ð Miles Per Gallon
MPH Ð Miles Per Hour
M/T Ð Manual Transmission/Transaxle
MV Ð Millivolt

0A±13
GENERAL INFORMATION
N Ð Newtons
NA Ð Natural Aspirated
NC Ð Normally Closed
N´M Ð Newton Meters
NO Ð Normally Open
NOX Ð Nitrogen, Oxides of
OBD Ð On-Board Diagnostic
OD Ð Outside Diameter
O/D Ð Over Drive
OHC Ð Overhead Camshaft
OL Ð Open Loop
O2 Ð Oxygen
O2S Ð Oxygen Sensor
PAIR Ð Pulsed Secondary Air Injection System
P/B Ð Power Brakes
PCM Ð Powertrain Control Module
PCV Ð Positive Crankcase Ventilation
PRESS Ð Pressure
PROM Ð Programmable Read Only Memory
PNP Ð Park/Neutral Position
P/S Ð Power Steering
PSI Ð Pounds per Square Inch
PSP Ð Power Steering Pressure
Pt. Ð Pint
Pri Ð Primary
PWM Ð Pulse Width Modulate
Qt. Ð Quart
REF Ð Reference
RF Ð Right Front
RFI Ð Radio Frequency Interference
RH Ð Right Hand
RPM Ð Revolutions Per Minute
RPM Sensor Ð Engine Speed Sensor
RPO Ð Regular Production Option
RR Ð Right Rear
RS Ð Right Side
RTV Ð Room Temperature Vulcanizing
RWAL Ð Rear Wheel Antilock Brake
RWD Ð Rear Wheel Drive
SAE Ð Society of Automotive Engineers
Sec Ð Secondary
SFI Ð Sequential Multiport Fuel Injection
SI Ð System International
SIR Ð Supplemental Inflatable Restraint System
SOHC Ð Single Overhead Camshaft
Sol Ð Solenoid
SPEC Ð Specification
Speedo Ð Speedometer
SRS Ð Supplemental Restraint System
ST Ð Start / Scan Tool
Sw Ð Switch
SWB Ð Short Wheel Base
SYN Ð Synchronize
Tach Ð Tachometer
TB Ð Throttle Body
TBI Ð Throttle Body Fuel Injection
TCC Ð Torque Converter Clutch
TCM Ð Transmission Control Module
TDC Ð Top Dead Center
Term Ð Terminal
TEMP Ð Temperature
TODÐ Torque On Demand
TP Ð Throttle Position
TRANS Ð Transmission/Transaxle
TURBO Ð TurbochargerTVRS Ð Television & Radio Suppression
TVV Ð Thermal Vacuum Valve
TWC Ð Three Way Catalytic Converter
3 A/T Ð Three Speed Automatic Transmission/Transaxle
2WD Ð Two Wheel Drive
4 x 2 Ð Two Wheel Drive
U±joint Ð Universal Joint
V Ð Volt(s)
VAC Ð Vacuum
VIN Ð Vehicle Identification Number
VRRRE Ð Vehicle Refrigerant Recovery and Recycling
Equipment
V±ref Ð ECM Reference Voltage
VSS Ð Vehicle Speed Sensor
VSV Ð Vacuum Switch Valve
V±6 Ð Six Cylinder ªVº Engine
V±8 Ð Eight Cylinder ºVº Engine
W Ð Watt(s)
w/ Ð With
w/b Ð Wheel Base
w/o Ð Without
WOT Ð Wide Open Throttle
Service Parts Identification Plate
The Vehicle Information Plate (Service Parts ID plate) is
provided on all vehicle models.
It is located on the center dash wall inside the engine
compartment. The plate lists the VIN (Vehicle
Identification Number), paint information and all
production options and special equipment on the vehicle
when it was shipped from the factory.
905R200002

0B±1 MAINTENANCE AND LUBRICATION
AXIOM
GENERAL INFORMATION
Maintenance and Lubrication
CONTENTS
Maintenance Schedule List 0B±1. . . . . . . . . . . . . . .
Explanation of Complete Vehicle Maintenance
Schedule 0B±5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Recommended Fluids and Lubricants 0B±8. . . .
Lubricant Viscosity Chart 0B±9. . . . . . . . . . . . . . . . . Recommended Liquid Gasket 0B±11. . . . . . . . . . .
Recommended Thread Locking Agents 0B±11. . .
Maintenance Service Data 0B±12. . . . . . . . . . . . . . . .
Maintenance Schedule List
Normal Vehicle Use
The maintenance instructions in this Maintenance
Schedule are based on the assumption that the vehicle
will be used as designed:

to carry passengers and cargo within the limitations
specified on the tire placard located on the inside of
the glove compartment door;

to be driven on reasonable road surfaces within legal
operating limits;

to be driven on a daily basis, as a general rule, for at
least several miles/kilometers;

to be driven on unleaded fuel
Unusual or severe operating conditions will require more
frequent vehicle maintenance, as specified in the
following sections.
Severe Driving Conditions
If the vehicle is usually operated under any of the severe
driving conditions listed below, it is recommended that the
applicable maintenance services be performed at the
specified interval shown in the chart below.
Severe driving conditions:

Towing a trailer, using a camper or car top carrier.

Repeated short trips of less than 8 Km (5 miles) with
outside temperature remaining below freezing.

Extensive idling and/or low speed driving for long
distances, such as police, taxi or door±to±door
delivery use.

Operating on dusty, rough, muddy or salt spread
roads.
ITEMS
INTERVAL
CHANGE ENGINE OIL AND OIL FILTEREvery 3,000 miles (4,800 km) or 3 months
CHANGE AUTOMATIC TRANSMISSION FLUIDEvery 20,000 miles (32,000 km)
CHANGE REAR AXLE OILEvery 15,000 miles (24,000 km)
REPLACE TIMING BELTEvery 75,000 miles (120,000 km)
REPLACE AIR CLEANER FILTERSee explanation of service, page 0B±5
CHANGE POWER STEERING FLUIDEvery 30,000 miles (48,000 km)

0B±6MAINTENANCE AND LUBRICATION
Always change the oil and the oil filter as soon as possible
after driving in a dust storm.
Engine Cooling System Inspection
Inspect the coolant/anti±freeze. If the coolant is dirty or
rusty, drain, flush and refill with new coolant. Keep coolant
at the proper mixture for proper freeze protection,
corrosion inhibitor level and best engine operating
temperature. Inspect hoses and replace if cracked,
swollen or deteriorated. Tighten the hose clamps if
equipped with screw±type clamps. Clean outside of
radiator and air conditioning condenser. Wash filler cap
and neck. To help ensure proper operation, a pressure
test of both the cooling system and the cap is also
recommended.
Exhaust System Inspection
Visually inspect the exhaust pipes, muffler, heat shields
and hangers for cracks, deterioration, or damage.
Be alert to any changes in the sound of the exhaust
system or any smell of fumes. These are signs the system
may be leaking or overheating. Repair the system at
once, if these conditions exist. (See also ªEngine Exhaust
Gas Safetyº and ªThree Way Catalytic Converterº in the
Owner's manual.)
Fuel Cap, Fuel Lines, and Fuel Tank
Inspection
Inspect the fuel tank, the fuel cap and the fuel lines every
60,000 miles (96,000 km) for damage which could cause
leakage.
Inspect the fuel cap and the gasket for correct sealing and
physical damage. Replace any damaged parts.
Drive Belt Inspection
Check the serpentine belt driving for cracks, fraying,
wear, and correct tension every 30,000 miles (48,000
km). Replace as necessary.
Wheel Alignment, Balance and Tires
Operation
Uneven or abnormal tire wear, or a pull right or left on a
straight and level road may show the need for a wheel
alignment. A vibration of the steering wheel or seat at
normal highway speeds means a wheel balancing is
needed. Check tire pressure when the tires are ªcoldº
(include the spare).
Maintain pressure as shown in the tire placard, which is
located on the driver's door lock pillar.
Steering System Operation
Be alert for any changes in steering operation. An
inspection or service is needed when the steering wheel
is harder to turn or has too much free play, or if there are
unusual sounds when turning or parking.
Brake Systems Operation
Watch for the ªBRAKEº light coming on. Other signs of
possible brake trouble are such things as repeated pulling
to one side when braking, unusual sounds when braking
or between brake applications, or increased brake pedaltravel. If you note one of these conditions, repair the
system at once.
For convenience, the following should be done when
wheels are removed for rotation: Inspect lines and hoses
for proper hookup, bindings, leaks, crack, chafing etc.
Inspect disc brake pads for wear and rotors for surface
condition.
Inspect other brake parts, including parking brake drums,
linings etc., at the same time. Check parking brake
adjustment.
Inspect the brakes more often if habit or conditions
result in frequent braking.
Parking Brake and Transmission Park
Mechanism Operation
Park on a fairly steep hill and hold the vehicle with the
parking brake only. This checks holding ability. On
automatic transmission vehicles, shifting from ªPº
position to the other positions cannot be made unless the
brake pedal is depressed when the key switch is in the
ªONº position or the engine is running.
WARNING: B E F O R E C H E C K I N G T H E S TA R T E R
SAFETY SWITCH OPERATION BELOW, BE SURE TO
HAVE ENOUGH ROOM AROUND THE VEHICLE.
THEN FIRMLY APPLY BOTH THE PARKING BRAKE
AND THE REGULAR BRAKE. DO NOT USE THE
ACCELERATOR PEDAL. IF THE ENGINE STARTS,
BE READY TO TURN OFF THE KEY PROMPTLY.
TAKE THESE PRECAUTIONS BECAUSE THE
VEHICLE COULD MOVE WITHOUT WARNING AND
POSSIBLY CAUSE PERSONAL INJURY OR
PROPERTY DAMAGE.
Starter Safety Switch Operation
Check by trying to start the engine in each gear while
setting the parking brake and the foot brake. The starter
should crank only in ªPº (Park) or ªNº (Neutral).
Accelerator Linkage Lubrication
Lubricate the accelerator pedal fulcrum pin with chassis
grease.
Steering and Suspension Inspection
Inspect the front and rear suspension and steering
system for damaged, loose or missing parts or signs of
wear. Inspect power steering lines and hoses for proper
hookup, binding, leaks, cracks, chafing, etc.
Body and Chassis Lubrication
Lubricate the key lock cylinders, the hood latch, the hood
and door hinges, the door check link, the parking cable
guides, the underbody contact points, and the linkage.
Propeller Shaft Inspection and Lubrication
Check the propeller shaft flange±to±pinion bolts for
proper torque to 63 Nwm (46 lb ft) for front and rear
propeller shaft.

0B±8MAINTENANCE AND LUBRICATION
Recommended Fluids and Lubricants
USAGEFLUID/LUBRICANT
EngineAPI SE, SF, SG, SH or ILSAC GF-1 Engine oil (See oil
chart on the following page for proper viscosity)
Engine coolantMixture of water and good quality ethylene glycol base
type antifreeze.
Brake systemDOT-3 hydraulic brake fluid.
Power steering systemDEXRON) -III Automatic transmission fluid.
Automatic transmissionDEXRON) -III Automatic transmission fluid.
TOD SYSTEM (TOD system model only)DEXRON) -IIE or DEXRON) -III Automatic transmis-
sion fluid.
Rear axle and front axleGL-5 gear lubricant (Standard differential)
GL-5 Limited slip differential gear lubricant together
with limited slip differential lubricant additive (Part No.
8-01052-358-0) or equivalent (If equipped with optional
limited slip differential) (See oil chart in this section for
proper viscosity)
Hood latch assembly
a. Pivots and spring anchorEngine oil
b. Release pawlChassis grease
Hood and door hingesEngine oil
Chassis lubricationChassis grease
Parking brake cablesChassis grease
Front wheel bearingsMultipurpose grease
Shift on the fly systemGL-5 gear lubricant (SAE 75W-90)
Body door hinge pins and linkage, fuel door hinge, rear
compartment lid hingesEngine oil
Windshield washer solventWasher fluid
Key lock cylinderSynthetic light weight engine oil (SAE 5W-30)
Accelerator linkageChassis grease

0B±11 MAINTENANCE AND LUBRICATION
Recommended Liquid Gasket
TypeBrand NameManufacturerRemarks
RTV*
Silicon Base
Three Bond 1207B
Three Bond 1207C
Three Bond 1215
Three Bond 1280
Three Bond 1281Three Bond
Three Bond
Three Bond
Three Bond
Three BondFor Engine Repairs
For Axle Case
Repairs T/M
Repairs T/M
Water BaseThree Bond 1141EThree BondFor Engine Repairs
Solvent
Three Bond 1104
Belco Bond 4
Belco Bond 401
Belco Bond 402Three Bond
Isuzu
Isuzu
Isuzu
For Engine Repairs
Anaerobic
LOCTITE 515
LOCTITE 518
LOCTITE 17430Loctite
Loctite
Loctite
All
* RTV: Room Temperature Vulcanizer
NOTE:
1. It is very important that the liquid gaskets listed above
or their exact equivalent be used on the vehicle.
2. Be careful to use the specified amount of liquid
gasket.
Follow the manufacturer's instructions at all times.
3. Be absolutely sure to remove all lubricants and
moisture from the connecting surfaces before
applying the liquid gasket.
The connecting surfaces must be perfectly dry.
4. Do not apply LOCTITE 17430, LOCTITE 515 and
LOCTITE 518 between two metal surfaces having a
clearance of greater than 0.25 mm (0.01 in). Poor
adhesion will result.
Recommended Thread Locking
Agents
LOCTITE TypeLOCTITE Color
LOCTITE 242Blue
LOCTITE 262Red
LOCTITE 271Red
Application Steps
1. Completely remove all lubricant and moisture from
the bolts and the female-threaded surfaces of the
parts to be joined.
The surfaces must be perfectly dry.
2. Apply LOCTITE to the bolts.
F00RW014
3. Tighten the bolts to the specified torque.
After tightening, be sure to keep the bolts free from
vibration and torque for at least an hour until
LOCTITE hardens.
NOTE: When the application procedures are specified in
this manual, follow them.

1A±2
HEATING, VENTILATION AND AIR CONDITIONING (HVAC)
Compressor 1A±53. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service Precaution 1A±53. . . . . . . . . . . . . . . . . . . .
General Description 1A±53. . . . . . . . . . . . . . . . . . . . . .
Diagnosis 1A±54. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Magnetic Clutch Assembly (DKV-14G Type) 1A±55
Parts Location View 1A±55. . . . . . . . . . . . . . . . . . . .
Removal 1A±55. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inspection and Repair 1A±57. . . . . . . . . . . . . . . . . .
Installation 1A±57. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Compressor Oil 1A±59. . . . . . . . . . . . . . . . . . . . . . . . .
Oil Specification 1A±59. . . . . . . . . . . . . . . . . . . . . . .
Handling of Oil 1A±59. . . . . . . . . . . . . . . . . . . . . . . .
Compressor Oil Check 1A±59. . . . . . . . . . . . . . . . .
Checking and Adjusting Oil Quantity for
Used Compressor 1A±59. . . . . . . . . . . . . . . . . . . . .
Checking and Adjusting for Compressor
Replacement 1A±60. . . . . . . . . . . . . . . . . . . . . . . . .
Contamination of Compressor Oil 1A±60. . . . . . . .
Oil Return Operation 1A±60. . . . . . . . . . . . . . . . . . .
Replacement of Component Parts 1A±60. . . . . . .
Main Data and Specifications 1A±61. . . . . . . . . . . . .
Special Tools 1A±63. . . . . . . . . . . . . . . . . . . . . . . . . .
Automatic Air Conditioning System 1A±64. . . . . . . .
General Description 1A±64. . . . . . . . . . . . . . . . . . . . . .
Automatic Air Conditioner Parts
Configuration 1A±64. . . . . . . . . . . . . . . . . . . . . . . . .
Circuit Diagram 1A±65. . . . . . . . . . . . . . . . . . . . . . .
Functions and Features 1A±70. . . . . . . . . . . . . . . .
Automatic Air Conditioner Block Diagram 1A±71.
Control Panel Layout 1A±72. . . . . . . . . . . . . . . . . . .
Air Control Functions 1A±73. . . . . . . . . . . . . . . . . . .
Control Panel Switch Operation 1A±74. . . . . . . . .
Overview of Construction, Movement and
Control of Major Parts of Automatic Air
Conditioner System 1A±77. . . . . . . . . . . . . . . . . . .
Overview of Automatic Control of Automatic
Air Conditioner 1A±81. . . . . . . . . . . . . . . . . . . . . . .
Automatic Air Conditioning System 1A±82. . . . . .
Troubleshooting 1A±86. . . . . . . . . . . . . . . . . . . . . . . . .
Troubleshooting, Its Overview and
Procedures 1A±86. . . . . . . . . . . . . . . . . . . . . . . . . .
Auto Air Conditioner Control Unit Power
Supply Diagnosis 1A±87. . . . . . . . . . . . . . . . . . . . . Performance and Movement checklist for
Automatic Air Conditioner Related Parts 1A±89.
Troubleshooting With Self-Diagnosis
Function 1A±91. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inspection By Failed Location 1A±97. . . . . . . . . . . . .
Inspection of the Sensors 1A±97. . . . . . . . . . . . . . .
Inspection of the Intake Actuator System 1A±101.
Inspection of the Mix Actuator System 1A±104. . . .
Inspection of the Mode Actuator System 1A±107. .
Inspection of the Fan Motor System 1A±110. . . . . .
Inspection of the Magnetic Clutch System 1A±115
Individual Inspection 1A±118. . . . . . . . . . . . . . . . . . .
On-Vehicle Service 1A±121. . . . . . . . . . . . . . . . . . . . . .
Power Transistor 1A±121. . . . . . . . . . . . . . . . . . . . . .
Removal 1A±121. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation 1A±121. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Automatic Heater/Air Conditioner Control
Unit 1A±121. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Removal 1A±121. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation 1A±121. . . . . . . . . . . . . . . . . . . . . . . . . . . .
In Car Sensor 1A±122. . . . . . . . . . . . . . . . . . . . . . . . .
Removal 1A±122. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation 1A±122. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ambient Sensor 1A±122. . . . . . . . . . . . . . . . . . . . . . .
Removal 1A±122. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation 1A±122. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sun Sensor 1A±123. . . . . . . . . . . . . . . . . . . . . . . . . . .
Removal 1A±123. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation 1A±123. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Duct Sensor 1A±123. . . . . . . . . . . . . . . . . . . . . . . . . .
Removal 1A±123. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation 1A±123. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Mode Actuator 1A±124. . . . . . . . . . . . . . . . . . . . . . . .
Removal 1A±124. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation 1A±124. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Mix Actuator 1A±124. . . . . . . . . . . . . . . . . . . . . . . . . .
Removal 1A±124. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation 1A±124. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Intake Actuator 1A±125. . . . . . . . . . . . . . . . . . . . . . . .
Removal 1A±125. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation 1A±125. . . . . . . . . . . . . . . . . . . . . . . . . . . .
