Page 101 of 225
R
(FM8) SEMCON JLR OWNER GUIDE VER 1.00 EURO
LANGUAGE: english-en; MARQUE: jaguar; MODEL: XF
Adaptive cruise control
101
The sensitivity of th e warning can only be
adjusted with ACC disengaged. Adjust as
follows:
• Roll the gap adjustment control
downwards to decrease the sensitivity of
the alert.
• Roll the gap adjustment control upwards to
increase the sensitivity of the alert.
Note: The forward alert set gap is retained
when the ignition is switched off.
Forward Alert is displayed in the message
centre.ADVANCED EMERGENCY BRAKE
ASSIST
The system may not react to slow
moving vehicles and will not react to
stationary vehicles or vehicles
travelling in the opposite direction.
Warnings may not appear if the
distance to the vehicle ahead is very
small or if steering wheel or pedal
movements are large (e.g. to avoid a
collision).
The system utilises the same radar
sensor as ACC and Forward alert - the
same limitations of performance
apply.
Advanced emergency brake assist is available
at speeds above approximately 7 km/h (5 mph)
and improves brakin g response during
emergency braking, when a moving vehicle is
detected close ahead.
If the risk of collision increases after the
Forward Alert warning is displayed, advanced
emergency brake assist is activated. The
brakes are automatically applied gently in
preparation for rapid braking (this may be
noticeable). If the brake pedal is then pressed
quickly, full braking is implemented, even if
only light pressure is ap plied to the pedal. See
87, EMERGENCY BRAKE ASSIST (EBA) .
Note: Braking performance will only be
improved if the driver applies the brakes.
Advanced emergency brake assist will function
even if Forward Alert and ACC are switched off.
If there is a fault with the system, Forward
Alert Unavailable is displayed in the message
centre. The vehicle can st ill be driven and the
braking system will still operate, but without
advanced emergency brake assistance. Seek
qualified assistance to have the fault rectified.
Page 102 of 225
L
(FM8) SEMCON JLR OWNER GUIDE VER 1.00 EURO
LANGUAGE: english-en; MARQUE: jaguar; MODEL: XF
Adaptive cruise control
102
INTELLIGENT EMERGENCY BRAKING
The system may not react to slow
moving vehicles.
The system will not react to stationary
vehicles, or vehicles that are not
travelling in the same direction as
your vehicle.
Warnings and automatic braking may
not occur if the dist ance to the vehicle
ahead is very small, or if the steering
wheel and pedal movements are large
(to avoid a collis ion for example).
IEB (Intelligent Em ergency Braking)
uses the same radar sensor as
Adaptive Cruise Control and Forward
Alert. The same performance
limitations apply, see 96, ADAPTIVE
CRUISE CONTROL OVERVIEW.
IEB is available at all speeds to automatically
apply the brakes if an unavoidable collision
with a moving vehicle in front is detected.
If there is an imminent risk of collision, an
audible warning is given. If the collision then
becomes unavoidable, the IEB system applies
the brakes at up to maximum pressure. After
IEB has activated, IEB System Was Activated
is displayed in the message centre and the
system is inhibited from further operation until
reset by a Dealer/Authorised Repairer.
IEB will function even if Forward Alert and ACC
are switched off. If the radar sensor is blocked,
by snow or heavy rain for example, or there is
a fault with the system, IEB Not Available is
displayed in the message centre. The vehicle
can still be driven and the braking system will
still operate, but without IEB. If the cause of
this message being disp layed is thought to be
other than a blocked rada r sensor, consult your
Dealer/Authorised Repairer.
Page 134 of 225
L
(FM8) SEMCON JLR OWNER GUIDE VER 1.00 EURO
LANGUAGE: english-en; MARQUE: jaguar; MODEL: XF
Navigation system
134
Navigation systemTHE NAVIGATION SYSTEM
Navigation instruction is by map and turn
information displayed on the touch screen and
can be complemented by voice guidance if
required. The system uses signals from Global
Positioning System (GPS) satellites combined
with information from vehicle sensors and
from data stored on the hard drive, to establish
the true vehicle position.
Note: Mapping data loaded on the hard drive is
relevant to the market in which the vehicle is
first sold and will provide guidance and
information only for that area. Your local Dealer
will have details of software updates.
Using this combination of data sources the
vehicle navigation com puter enables you to
plan and follow a route map to your desired
destination.
The touch screen is used to control navigation
via menus, text screens and map displays.
Operate the system only when it is
safe to do so.
The requirements of na tional Road Traffic
Regulations always apply.
Observation of traffic signs and local traffic
regulations always take priority.
The navigation system serves solely as an aid
to navigation. In part icular, the navigation
system cannot be used as an aid to orientation
when visibility is poor.
GPS signals may occasion ally be interrupted
due to physical barriers such as tunnels and
roads under raised highways.
However, direction and speed sensors on the
vehicle will minimise any adverse effect on the
navigation system. Normal operation will
resume once the obstruc tion has been passed. Under certain conditions it is possible for the
vehicle position show
n on screen to be
incorrect. This may happen when:
• Driving on a spiral ramp in a building.
• Driving on or beneath elevated roads.
• Two roads are close and parallel.
• The vehicle is transported to another
destination.
• After the vehicle is rotated on a turntable.
• After vehicle batte ry disconnection.
USING THE NAVIGATION SYSTEM
1. NAV shortcut button.
2. Navigation soft key.
From the Home menu touch the Navigation
soft key. Alternatively, press the NAV shortcut
button on the facia. A caution screen will be
displayed.
If the navigation screen language has not been
set, now is the time to set it. Select Language,
make a selection and confirm it by touching the
OK soft key. You will be returned to the
CAUTION screen.
After touching the Agree soft key, the touch
screen will display the Nav menu (which is the
navigation system Ma in menu and covered
over two screens) or the screen that was in use
when you last switched off the system.
Page 198 of 225
L
(FM8) SEMCON JLR OWNER GUIDE VER 1.00 EURO
LANGUAGE: english-en; MARQUE: jaguar; MODEL: XF
After a collision
198
After a collisionBEFORE STARTING OR DRIVING
If the vehicle is involved in a collision
it should be checked by a Dealer/
Authorised repairer, or suitably
qualified personnel, before starting or
driving.
PEDESTRIAN PROTECTION SYSTEM
The bumper includes sensors that detect a
collision with a pedestrian and includes energy
absorbing foam and plastics in its
construction, to re duce leg injuries.
During a pedestrian co llision, the sensors
initiate a bonnet deploy ment system that
releases the bonnet hinge system and raises
the rear edge of the bonnet by approximately
130 mm (5.1 inches).
This increases the gap between the bonnet and
the components within the engine
compartment to create a cushion to mitigate
injury caused to the pedestrian.
The bonnet deployment system is active only
when the ignition is on and the vehicle is driven
between the speeds of approximately 20 km/h
(12 mph) and 45 km/h (28 mph).
AFTER DEPLOYMENT OF THE
PEDESTRIAN PROTECTION SYSTEM
Do not attempt to open the bonnet if the
pedestrian protection system has been
deployed.
The vehicle must be stopped as soon as it is
safe to do so.
The hazard warning lamp s will be activated and
can only be switched off by pressing the engine
START/STOP button to turn the engine off and
on again.
A warning message CHECK PEDESTRIAN
SYSTEM will appear on the message centre
and the vehicle should be transported to the
nearest Dealer/Author ised Repairer. The
vehicle must not be driven when the bonnet
has been deployed.
Note: If the warning message CHECK
PEDESTRIAN SYSTEM appears in the message
centre when the bonnet ha s not been deployed,
the vehicle should be taken to the nearest
Dealer/Authorised Repairer immediately. It can
be driven.
If any significant damage occurs to the front
bumper it should be inspected by a
Dealer/Authorised Repairer as soon as
possible.
Page 205 of 225
R
english-en (10, 18, 21 & 25)
Index
205
A
ABS (Anti-lock braking system)warning lamp . . . . . . . . . . . . . . . . . . . . . 52
ACC (Adaptive cruise control) . . . . . . . . . . 96 ASL (Active speed limiter) . . . . . . . . . . 103
ASL (Automatic speed limiter)
setting . . . . . . . . . . . . . . . . . . . . . . . 103
suspending . . . . . . . . . . . . . . . . . . . 103
automatic switch-off . . . . . . . . . . . . . . . 98
driving hints . . . . . . . . . . . . . . . . . . . . . 99
fault . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
follow mode. . . . . . . . . . . . . . . . . . . . . . 97
gap change . . . . . . . . . . . . . . . . . . . . . . 98
low speed switch-off . . . . . . . . . . . . . . . 98
malfunction . . . . . . . . . . . . . . . . . . . . . 100
override . . . . . . . . . . . . . . . . . . . . . . . . . 98
resume follow mode . . . . . . . . . . . . . . . 99
resume set speed . . . . . . . . . . . . . . . . . 99
warning lamp . . . . . . . . . . . . . . . . . . . . . 53
ACC (adaptive cruise control)
operating . . . . . . . . . . . . . . . . . . . . . . . . 96
Active differential control. . . . . . . . . . . . . . 85
Active head restraints
airbags. . . . . . . . . . . . . . . . . . . . . . . . . . 32
Adaptive dynamics . . . . . . . . . . . . . . . . . . 84
Adaptive front light ing system (AFS)
warning lamp . . . . . . . . . . . . . . . . . . . . . 53
AFS (Adaptive front lighting system) . . . . . 37
After a collision
pedestrian protection system . . . . . . . 198
Age degradation (tyres) . . . . . . . . . . . . . . 186
Air conditioning
air quality sensor . . . . . . . . . . . . . . . . . . 65
auto . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Air quality sensor . . . . . . . . . . . . . . . . . . . 65
Airbags active head restraints. . . . . . . . . . . . . . . 32
deployment . . . . . . . . . . . . . . . . . . . 33, 34
module covers . . . . . . . . . . . . . . . . . . . 167
service information . . . . . . . . . . . . . . . . 35
SRS (Supplementary re straint system) 158
warning lamps . . . . . . . . . . . . . . . . . 34, 53
Alarm. . . . . . . . . . . . . . . . . . . . . . . . . 10, 158 automatic relocking and arming . . . . . . . 11
battery backed sounder. . . . . . . . . . . . . . 11
deactivating. . . . . . . . . . . . . . . . . . . . . . . 11
passive arming . . . . . . . . . . . . . . . . . . . . 11
perimeter . . . . . . . . . . . . . . . . . . . . . . . . 11
sensor fault . . . . . . . . . . . . . . . . . . . . . . . 11
tilt sensor . . . . . . . . . . . . . . . . . . . . . . . . 11
Anchor points (ISOFIX). . . . . . . . . . . . . . . . 30
Anchor points (luggage) . . . . . . . . . . . . . . . 68
Antifreeze level check . . . . . . . . . . . . . . . . 170
Anti-theft system . . . . . . . . . . . . . . . . . . . 158
Anti-trap mechanism
sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Anti-trap protection windows . . . . . . . . . . . . . . . . . . . . . . . . . 43
Approach lamps . . . . . . . . . . . . . . . . . . . . . 37
Arduous driving conditions. . . . . . . . . . . . 159
ASL (Automatic speed limiter) . . . . . . . . . 103 gap change . . . . . . . . . . . . . . . . . . . . . . . 98
resuming. . . . . . . . . . . . . . . . . . . . . . . . 103
setting . . . . . . . . . . . . . . . . . . . . . . . . . . 103
suspending . . . . . . . . . . . . . . . . . . . . . . 103
warning lamp . . . . . . . . . . . . . . . . . 53, 103
Audible warnings . . . . . . . . . . . . . . . . . . . . 55
Audio Settings. . . . . . . . . . . . . . . . . . . . . . . . . 105
Audio system . . . . . . . . . . . . . . . . . . . . . . 166
Audio/video CD controls . . . . . . . . . . . . . . . . . . . . . . . 120
controls. . . . . . . . . . . . . . . . . . . . . . . . . 104
DAB reception . . . . . . . . . . . . . . . . . . . . . . 112
loading CDs . . . . . . . . . . . . . . . . . . . . . 119
loading DVDs . . . . . . . . . . . . . . . . . . . . 125
MP3 . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
portable media connections. . . . . . . . . . . . . . . . . . . . 113
controls . . . . . . . . . . . . . . . . . . . . . . . 115
pairing . . . . . . . . . . . . . . . . . . . . 117, 118
play . . . . . . . . . . . . . . . . . . . . . . . . . . 117
television
controls . . . . . . . . . . . . . . . . . . . . . . . 122
Page 206 of 225
L
english-en (10, 18, 21 & 25)
Index
206
video media playercontrols . . . . . . . . . . . . . . . . . . . . . . 124
Auto high beam . . . . . . . . . . . . . . . . . . . . . 38
Auto mode (climate) . . . . . . . . . . . . . . . . . 65
Automatic gearbox . . . . . . . . . . . . . . . . . . 81
Automatic locking . . . . . . . . . . . . . . . . . . . . 7
Automatic reconnection (portable audio) 118
Automatic Stop/Start . . . . . . . . . . . . . . . . . 79
Automatic switch off (ACC) . . . . . . . . . . . . 98
Automatic switch off (cruise) . . . . . . . . . . 95
Auxiliary devices connecting multiple devices . . . . . . . . 117
B
Batteryboost starting . . . . . . . . . . . . . . . . . . . 183
care . . . . . . . . . . . . . . . . . . . . . . . . . . . 182
changingtimed climate remote . . . . . . . . . . . . 184
charging . . . . . . . . . . . . . . . . . . . . . . . 184
jump starting connecting cables . . . . . . . . . . . . . . 183
disconnecting cables . . . . . . . . . . . . 183
monitoring system. . . . . . . . . . . . . . . . 183
warning symbols . . . . . . . . . . . . . . . . . 182
Battery backed sounder . . . . . . . . . . . . . . . 11
Beltminder . . . . . . . . . . . . . . . . . . . . . . . . . 26 warning lamp . . . . . . . . . . . . . . . . . . 26, 52
Belts . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167 safety . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
seatbelt warning lamp . . . . . . . . . . . 26, 52
Bluetooth . . . . . . . . . . . . . . . . . . . . . . . . . 129 audioautomatic reconnection . . . . . . . . . . 118
pairing . . . . . . . . . . . . . . . . . . . 117, 118
media pairing . . . . . . . . . . . . . . . . . . . . . . . 117
telephone compatibility . . . . . . . . . . . . . . . . . . 130
icons . . . . . . . . . . . . . . . . . . . . . . . . 131
overview . . . . . . . . . . . . . . . . . . . . . 128
pairing . . . . . . . . . . . . . . . . . . . . . . . 130 phonebook . . . . . . . . . . . . . . . . . . . . 132
safety . . . . . . . . . . . . . . . . . . . . . . . . 129
Bonnet closing . . . . . . . . . . . . . . . . . . . . . . . . . 160
opening . . . . . . . . . . . . . . . . . . . . . . . . . 160
Boost starting . . . . . . . . . . . . . . . . . . . . . . 183
Brakes ABS warning lamp . . . . . . . . . . . . . . . . . 52
advanced emergency assist . . . . . . . . . 101
EBA (Emergency brake assist) . . . . . . . . 87
EBD (Electronic brake force distribution) 87
fluid
check. . . . . . . . . . . . . . . . . . . . . . . . . 171
specification . . . . . . . . . . . . . . . . . . . 172
top up . . . . . . . . . . . . . . . . . . . . . . . . 172
handbrake . . . . . . . . . . . . . . . . . . . . . . . . 88
pedal travel . . . . . . . . . . . . . . . . . . . . . . 180
warning lamp . . . . . . . . . . . . . . . . . . . . . 51
warning lamps . . . . . . . . . . . . . . . . . . . . 87
BSM (Blind spot monitor) . . . . . . . . . . . . . . 46 detection beam issues . . . . . . . . . . . . . . 99
sensor blockage . . . . . . . . . . . . . . . . . . . 47
system fault . . . . . . . . . . . . . . . . . . . . . . 47
Bulbs
license plate . . . . . . . . . . . . . . . . . . . . . 163
number plate . . . . . . . . . . . . . . . . . . . . . 163
C
Call volume . . . . . . . . . . . . . . . . . . . . . . . . 132
Camerasrear view . . . . . . . . . . . . . . . . . . . . . . . . . 93
Capacities . . . . . . . . . . . . . . . . . . . . . . . . . 179
Carpets and mats . . . . . . . . . . . . . . . . . . . 167
Car-wash . . . . . . . . . . . . . . . . . . . . . . . . . 165
CD player controls. . . . . . . . . . . . . . . . . . . . . . . . . 120
loading discs . . . . . . . . . . . . . . . . . . . . . 119
Chairs child seats tether straps . . . . . . . . . . . . . . . . . . . . 31
memory recalling a position . . . . . . . . . . . . . . . 15
Page 207 of 225
R
english-en (10, 18, 21 & 25)
Index
207
rearsafety . . . . . . . . . . . . . . . . . . . . . . . . . 17
seatbelts . . . . . . . . . . . . . . . . . . . . . . . 167 seatbelt safety . . . . . . . . . . . . . . . . . . 23
warning lamp . . . . . . . . . . . . . . . . 26, 52
sitting correctly . . . . . . . . . . . . . . . . . . . 15
Changing a fuse. . . . . . . . . . . . . . . . . . . . 188
Changing a tyre . . . . . . . . . . . . . . . . . . . . . 90
Changing a wheel . . . . . . . . . . . . . . . . . . . 90
Changing the battery (timed climate) . . . 184
Charging the vehicle battery . . . . . . . . . . 184
Chassis number. . . . . . . . . . . . . . . . . . . . 200
Child restraints . . . . . . . . . . . . . . . . . . . . . 27 check list . . . . . . . . . . . . . . . . . . . . . . . . 28
positioning. . . . . . . . . . . . . . . . . . . . . . . 29
Child seats . . . . . . . . . . . . . . . . . . . . . . . . . 27 check list . . . . . . . . . . . . . . . . . . . . . . . . 28
ISOFIX anchor points. . . . . . . . . . . . . . . 30
positioning. . . . . . . . . . . . . . . . . . . . . . . 29
tether straps . . . . . . . . . . . . . . . . . . . . . 31
Cleaning
alloy wheels . . . . . . . . . . . . . . . . . . . . . 164
carpets and mats . . . . . . . . . . . . . . . . . 167
exterior . . . . . . . . . . . . . . . . . . . . . . . . 164paintwork . . . . . . . . . . . . . . . . . . . . . 165
glass . . . . . . . . . . . . . . . . . . . . . . . . . . 165
interior . . . . . . . . . . . . . . . . . . . . . 165, 166
leather . . . . . . . . . . . . . . . . . . . . . . . . . 166
parking sensors . . . . . . . . . . . . . . . . . . . 93
polishing . . . . . . . . . . . . . . . . . . . . . . . 165
rear screen. . . . . . . . . . . . . . . . . . . . . . 165
removing grease . . . . . . . . . . . . . . . . . 165
removing stains . . . . . . . . . . . . . . . . . . 166
removing tar . . . . . . . . . . . . . . . . . . . . 165
sunroof . . . . . . . . . . . . . . . . . . . . . . . . 165
underbonnet . . . . . . . . . . . . . . . . . . . . 165
using a car-wash . . . . . . . . . . . . . . . . . 165
Climate control auto . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
overview . . . . . . . . . . . . . . . . . . . . . . . . 65
recirculation. . . . . . . . . . . . . . . . . . . . . . 64
temperature . . . . . . . . . . . . . . . . . . . . . . 65
Climate seats . . . . . . . . . . . . . . . . . . . . . . . 66 Clock. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 166
Closing
alarm sensor faults . . . . . . . . . . . . . . . . . 11
single locking . . . . . . . . . . . . . . . . . . . . . . 9
Closing the bonnet . . . . . . . . . . . . . . . . . . 160
Closing the luggage compartment . . . . . . . 67
Column lock . . . . . . . . . . . . . . . . . . . . . . . . 75
Condensation (headlamps) . . . . . . . . . . . . . 38
Conformity declarations . . . . . . . . . . 146, 202
Consumption fuel urban cycle . . . . . . . . . . . . . . . . . . . . 157
Consumption (fuel). . . . . . . . . . . . . . . . . . 157
Controls headlamps . . . . . . . . . . . . . . . . . . . . . . . 36
steering wheel set cruise speed . . . . . . . . . . . . . . . . . 94
Coolant
checking the level . . . . . . . . . . . . . . . . . 170
specification . . . . . . . . . . . . . . . . . . . . . 171
top up . . . . . . . . . . . . . . . . . . . . . . . . . . 171
Cruise control ACC (Adaptive cruise control) . . . . . . . . . 96 low speed switch-off . . . . . . . . . . . . . . 98
malfunction . . . . . . . . . . . . . . . . . . . . 100
operating . . . . . . . . . . . . . . . . . . . . . . . 96
override . . . . . . . . . . . . . . . . . . . . . . . . 98
resume follow mode . . . . . . . . . . . . . . 99
resume set speed . . . . . . . . . . . . . . . . 99
automatic switch off . . . . . . . . . . . . . . . . 95
change speed . . . . . . . . . . . . . . . . . . . . . 94
follow mode . . . . . . . . . . . . . . . . . . . . . . 97
operating. . . . . . . . . . . . . . . . . . . . . . . . . 94
resume . . . . . . . . . . . . . . . . . . . . . . . . . . 94
setting vehicle speed. . . . . . . . . . . . . . . . 94
D
DAB ensembles. . . . . . . . . . . . . . . . . . . . . . . 112
reception . . . . . . . . . . . . . . . . . . . . . . . . 112
DAB radio controls. . . . . . . . . . . . . . . . . . . . . . . . . 111
Page 208 of 225
L
english-en (10, 18, 21 & 25)
Index
208
Daily checks . . . . . . . . . . . . . . . . . . . . . . 158
Data recording . . . . . . . . . . . . . . . . . . . . . 199
Daylight running lamps . . . . . . . . . . . . . . . 37
Dealer locations (Jaguar). . . . . . . . . . . . . 141
Declarations of conformity . . . . . . . . . . . 202navigation system . . . . . . . . . . . . . . . . 146
Derv sulphur content . . . . . . . . . . . . . . . . . . 153
Deselecting valet mode . . . . . . . . . . . . . . . 62
Destination entry . . . . . . . . . . . . . . . . . . . 138 postcode . . . . . . . . . . . . . . . . . . . . . . . 140
search area . . . . . . . . . . . . . . . . . . . . . 138
town . . . . . . . . . . . . . . . . . . . . . . . . . . 141
Detection beam issues . . . . . . . . . . . . . . . 99
Dialling a number . . . . . . . . . . . . . . . . . . 132
Diesel engine . . . . . . . . . . . . . . . . . . . . . 153, 154starting . . . . . . . . . . . . . . . . . . . . . . . 74
switching off . . . . . . . . . . . . . . . . . . . 75
filler flap. . . . . . . . . . . . . . . . . . . . 154, 155
fuel consumption . . . . . . . . . . . . . . . . . 157
misfuel device . . . . . . . . . . . . . . . . . . . 155
specification . . . . . . . . . . . . . . . . . . . . 156
sulphur content . . . . . . . . . . . . . . . . . . 153
water in fuel . . . . . . . . . . . . . . . . . . . . . 153
Diesel particulate filter (DPF) . . . . . . . . . . 159
Differential control . . . . . . . . . . . . . . . . . . . 85
Dimensions . . . . . . . . . . . . . . . . . . . . . . . 178
Direction indicators . . . . . . . . . . . . . . . . . . 36 warning lamp . . . . . . . . . . . . . . . . . . . . . 54
Disability modifications . . . . . . . . . . . . . . 158
Door mirrors BSM (Blind spot monitor)
sensor blockage . . . . . . . . . . . . . . . . . 47
system fault . . . . . . . . . . . . . . . . . . . . 47
Door transceiver
entry gate. . . . . . . . . . . . . . . . . . . . . . . . 50
garage door opener . . . . . . . . . . . . . . . . 48
programming. . . . . . . . . . . . . . . . . . . . . 48
programming a single button . . . . . . . . 49
rolling code device programming . . . . . 49
Double locking. . . . . . . . . . . . . . . . . . . . . . . 9
DPF (Diesel particulate filter) . . . . . . . . . . 159 Drive away locking . . . . . . . . . . . . . . . . . . . . 7
Drive control
operation. . . . . . . . . . . . . . . . . . . . . . . . . 86
Driver controls . . . . . . . . . . . . . . . . . . . . . 226
Driver information module information messages. . . . . . . . . . . . . . . 56
trip computer . . . . . . . . . . . . . . . . . . . . . 56
warning lamps . . . . . . . . . . . . . . . . . . . . 51
warning messages . . . . . . . . . . . . . . . . . 56
Driving ACC (Adaptive cruise c ontrol) . . . . . . 96, 99
override . . . . . . . . . . . . . . . . . . . . . . . . 98
adaptive cruise control automatic switch off . . . . . . . . . . . . . . 98
arduous conditions . . . . . . . . . . . . . . . . 159
ASL (Automatic speed limiter) . . . . . . . 103 setting . . . . . . . . . . . . . . . . . . . . . . . . 103
before starting. . . . . . . . . . . . . . . . . . . . 198
BSM (Blind spot monitor) sensor blockage . . . . . . . . . . . . . . . . . 47
controls. . . . . . . . . . . . . . . . . . . . . . . . . 226
cruise control automatic switch off . . . . . . . . . . . . . . 95
change speed . . . . . . . . . . . . . . . . . . . 94
set speed . . . . . . . . . . . . . . . . . . . . . . . 94
daily checks . . . . . . . . . . . . . . . . . . . . . 158
DSC warning lamp
active. . . . . . . . . . . . . . . . . . . . . . . . . . 53
off . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
dynamic mode . . . . . . . . . . . . . . . . . . . . 83
EBA (Emergency brake assist) . . . . . . . . 87
EBD (Electronic brake force distribution) 87
forward alert . . . . . . . . . . . . . . . . . . . . . 100
mirror dip when reversing. . . . . . . . . . . . 45
sitting correctly . . . . . . . . . . . . . . . . . . . . 15
wipers
rain sensor . . . . . . . . . . . . . . . . . . . . . 40
DSC (Dynamic st ability control)
switching between DSC and tracDSC . . . 84
switching off . . . . . . . . . . . . . . . . . . . . . . 84
switching on . . . . . . . . . . . . . . . . . . . . . . 84
Page 210 of 225
L
english-en (10, 18, 21 & 25)
Index
210
pairing . . . . . . . . . . . . . . . . . . . . . . . 130
phonebook . . . . . . . . . . . . . . . . . . . . 132
settings . . . . . . . . . . . . . . . . . . . . . . 133
television
analogue/digital option. . . . . . . . . . . 123
controls . . . . . . . . . . . . . . . . . . . . . . 122
touch screen . . . . . . . . . . . . . . . . . . . . 166 display icons . . . . . . . . . . . . . . . . . . . 59
home menu . . . . . . . . . . . . . . . . . . . . 58
operating . . . . . . . . . . . . . . . . . . . . . . 59
setup . . . . . . . . . . . . . . . . . . . . . . . . . 59
system settings . . . . . . . . . . . . . . . . . 60
touch screen care . . . . . . . . . . . . . . . 59
video media player controls . . . . . . . . . . . . . . . . . . . . . . 124
Entry and exit mode. . . . . . . . . . . . . . . . . . 22
EPB (Electric parking brake) . . . . . . . . . . . 88
Ethanol . . . . . . . . . . . . . . . . . . . . . . . . . . 152
EU conformity (navigati on system) . . . . . 146
Event data recording . . . . . . . . . . . . . . . . 199
Exiting the vehicle
door locks and release levers. . . . . . . . . . 9
global closing . . . . . . . . . . . . . . . . . . . . 10
keyless locking . . . . . . . . . . . . . . . . . . . 10
Exterior cleaning . . . . . . . . . . . . . . . . . . . 164
Exterior mirrors . . . . . . . . . . . . . . . . . . . . . 44
External temperature display . . . . . . . . . . . 65
Extinguisher . . . . . . . . . . . . . . . . . . . . . . 164
F
Faulty alarm sensors . . . . . . . . . . . . . . . . . 11
Fire extiguisher . . . . . . . . . . . . . . . . . . . . 164
First aid kit . . . . . . . . . . . . . . . . . . . . . . . . 164
Flat spots . . . . . . . . . . . . . . . . . . . . . . . . . 186
Fluids brakecheck . . . . . . . . . . . . . . . . . . . . . . . . 171
specification. . . . . . . . . . . . . . . . . . . 172
top up . . . . . . . . . . . . . . . . . . . . . . . 172
capacities. . . . . . . . . . . . . . . . . . . . . . . 179
coolant specification. . . . . . . . . . . . . . . . . . . 171 top up . . . . . . . . . . . . . . . . . . . . . . . . 171
engine oil check. . . . . . . . . . . . . . . . . . . . . . . . . 168
specification . . . . . . . . . . . . . . . . . . . 169
fuel tank capacity . . . . . . . . . . . . . . . . . 156
power steering check. . . . . . . . . . . . . . . . . . . . . . . . . 173
specification . . . . . . . . . . . . . . . . . . . 173
specifications . . . . . . . . . . . . . . . . . . . . 175
washer specification . . . . . . . . . . . . . . . . . . . 174
top up . . . . . . . . . . . . . . . . . . . . . . . . 174
Fog lamps warning lamp . . . . . . . . . . . . . . . . . . . . . 53
Follow mode
entering. . . . . . . . . . . . . . . . . . . . . . . . . . 97
gap change . . . . . . . . . . . . . . . . . . . . . . . 98
override. . . . . . . . . . . . . . . . . . . . . . . . . . 98
resume . . . . . . . . . . . . . . . . . . . . . . . . . . 99
suspending . . . . . . . . . . . . . . . . . . . . . . 103
Forward alert. . . . . . . . . . . . . . . . . . . . . . . 100
Front parking aid operation. . . . . . . . . . . . . . . . . . . . . . . . . 92
system fault . . . . . . . . . . . . . . . . . . . . . . 93
Fuel and refuelling consumption . . . . . . . . . . . . . . . . . . . . . 157 extra-urban cycle. . . . . . . . . . . . . . . . 157
urban cycle . . . . . . . . . . . . . . . . . . . . 157
diesel . . . . . . . . . . . . . . . . . . . . . . . . . . 153 sulphur content . . . . . . . . . . . . . . . . . 153
ethanol . . . . . . . . . . . . . . . . . . . . . . . . . 152
Filler flap . . . . . . . . . . . . . . . . . . . . . . . . 155
filler flap . . . . . . . . . . . . . . . . . . . . . . . . 154
fuel consumption urban cycle . . . . . . . . . . . . . . . . . . . . 157
fuel specification . . . . . . . . . . . . . . . . . . 156
fuel system . . . . . . . . . . . . . . . . . . . . . . 160
methanol . . . . . . . . . . . . . . . . . . . . . . . . 152
misfuel device . . . . . . . . . . . . . . . . . . . . 155
MTBE (Methyl tertiary butyl ether) . . . . 153
octane rating . . . . . . . . . . . . . . . . . . . . . 152
running out . . . . . . . . . . . . . . . . . . . . . . 153
safety precautions . . . . . . . . . . . . . . . . . 152
Page 213 of 225
R
english-en (10, 18, 21 & 25)
Index
213
warning lamps . . . . . . . . . . . . . . . . . . . . 51side lights . . . . . . . . . . . . . . . . . . . . . 54
TPMS (Tyre pressure monitoring system) . . . . . . . . . . . . . . . . . . . . . 53
wiper detection . . . . . . . . . . . . . . . . . . . 37
Leather cleaning . . . . . . . . . . . . . . . . . . . 166
License plate bulb . . . . . . . . . . . . . . . . . . 163
Lights condensation . . . . . . . . . . . . . . . . . . . . . 38
controls . . . . . . . . . . . . . . . . . . . . . . . . . 36
Limp home mode . . . . . . . . . . . . . . . . . . . 82
List soft key (navigation) . . . . . . . . . . . . . 142
Load securing . . . . . . . . . . . . . . . . . . . . . . 68
Loading DVDs . . . . . . . . . . . . . . . . . . . . . 125
Locking
alarm sensor faults . . . . . . . . . . . . . . . . 11
automatic relocking . . . . . . . . . . . . . . . . 11
confirmation . . . . . . . . . . . . . . . . . . . . . . 9
door locks and release leve rs . . . . . . . . . 9
double locking . . . . . . . . . . . . . . . . . . . . . 9
drive away . . . . . . . . . . . . . . . . . . . . . . . . 7
global closing . . . . . . . . . . . . . . . . . . . . 10
keyless. . . . . . . . . . . . . . . . . . . . . . . . . . 10
mislock . . . . . . . . . . . . . . . . . . . . . . . . . 10
Locking and unlocking alarmperimeter . . . . . . . . . . . . . . . . . . . . . . 11
sensor faults . . . . . . . . . . . . . . . . . . . 11
passive arming . . . . . . . . . . . . . . . . . . . 11
single locking. . . . . . . . . . . . . . . . . . . . . . 9
unlocking . . . . . . . . . . . . . . . . . . . . . . . . . 4
Locking column . . . . . . . . . . . . . . . . . . . . . 75
Lubricants
specifications. . . . . . . . . . . . . . . . . . . . 175
Luggage anchor points . . . . . . . . . . . . . . . . . . . . 68
Luggage compartment closing . . . . . . . . . . . . . . . . . . . . . . . . . . 67
fuse box . . . . . . . . . . . . . . . . . . . . . . . . 192
opening . . . . . . . . . . . . . . . . . . . . . . . . . 67M
Main beam (auto) . . . . . . . . . . . . . . . . . . . . 38
Maintenance
blocked washer jets . . . . . . . . . . . . . . . 162
boost starting connecting cables . . . . . . . . . . . . . . . 183
disconnecting cables. . . . . . . . . . . . . 183
brake fluid check . . . . . . . . . . . . . . . . . . 171
capacities . . . . . . . . . . . . . . . . . . . . . . . 179
changing a fuse. . . . . . . . . . . . . . . . . . . 188
checking the tyre pressures . . . . . . . . . 185
checking the tyre pressures after a repair . . . . . . . . . . . . . . . . . . . . . . . 150
cleaning
polishing . . . . . . . . . . . . . . . . . . . . . . 165
removing grease and tar . . . . . . . . . . 165
removing stains . . . . . . . . . . . . . . . . 166
cleaning alloy wheels . . . . . . . . . . . . . . 164
cleaning glass . . . . . . . . . . . . . . . . . . . . 165
cleaning parking sensors . . . . . . . . . . . . 93
cleaning rear screen . . . . . . . . . . . . . . . 165
closing the bonnet . . . . . . . . . . . . . . . . 160
coolant level checking . . . . . . . . . . . . . . 170
daily checks . . . . . . . . . . . . . . . . . . . . . 158
DPF . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159
engine compartment . . . . . . . . . . . . . . . 161
exterior cleaning . . . . . . . . . . . . . . . . . . 164
fuse box (luggage compartment) . . . . . 192
interior cleaning . . . . . . . . . . . . . . 165, 166
jump starting . . . . . . . . . . . . . . . . . . . . 183
label locations . . . . . . . . . . . . . . . . . . . . 200
leather cleaning. . . . . . . . . . . . . . . . . . . 166
lubricants and fliud sp ecifications. . . . . 175
number plate bulb . . . . . . . . . . . . . . . . . 163
paintwork repair . . . . . . . . . . . . . . . . . . 164
smart key battery changing. . . . . . . . . . . . 8
sunroof wind deflector . . . . . . . . . . . . . 165
weekly checks . . . . . . . . . . . . . . . . . . . . 158
Manual head restraints . . . . . . . . . . . . . . . . 21
Map (navigation system) . . . . . . . . . . . . . 140
Map split screen (navigations system) . . . 137
Media . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125 inhibited . . . . . . . . . . . . . . . . . . . . . . . . 125
