WARNING!
When replacing a blown fuse, always use
an appropriate replacement fuse with the
same amp rating as the original fuse. Never
replace a fuse with another fuse of higher
amp rating. Never replace a blown fuse with
metal wires or any other material. Do not
place a fuse inside a circuit breaker cavity
or vice versa. Failure to use proper fuses
may result in serious personal injury, fire
and/or property damage.
Before replacing a fuse, make sure that the
ignition is off and that all the other services
are switched off and/or disengaged.
If the replaced fuse blows again, contact an
authorized dealer.
If a general protection fuse for safety
systems (air bag system, braking systemyf
power unit systems (engine system, trans-
mission systemyfRUVWHHULQJV\VWHPEORZV
contact an authorized dealer.
1 — Fuse Element
2 — Blade Fuse With A Good/Functional Fuse Ele -
ment.
3 — Blade Fuse With A Bad / Not Functional Fuse
Element (Blown Fuseyf.
6

20_KL_OM_EN_USC_t.book Page 285

CavityBlade Fuse Cartridge Fuse Description
F06– – Not Used
F07 15 Amp Blue –Powertrain Control Mod - PCM (Dieselyf6XUJH6ROHQRLG3XUJH
Valve (Gasyf
