WARNING!
•Use only refrigerants and compressor lubricants
approved by the manufacturer for your air condi-
tioning system. Some unapproved refrigerants are
flammable and can explode, injuring you. Other
unapproved refrigerants or lubricants can cause
the system to fail, requiring costly repairs. Refer
to Section 3 of the Warranty Information Book for
additional warranty information.
•The air conditioning system contains refrigerant
under high pressure. To avoid risk of personal
injury or damage to the system, adding refrigerant
or any repair requiring lines to be disconnected
should be done by an experienced repairman.
Refrigerant Recovery and Recycling
R-134a Air Conditioning Refrigerant is a hydrofluorocar-
bon (HFC) that is endorsed by the Environmental Pro-
tection Agency and is an ozone-saving product. How-
ever, the manufacturer recommends that air conditioning
service be performed by dealers or other service facilities
using recovery and recycling equipment.
Power Steering Fluid Check
The power steering system requires the use of Mopar
Hydraulic System Power Steering Fluid (P/N
05142893AA), or equivalent, which meets
DaimlerChrysler Material Standard MS-10838.
MAINTAINING YOUR VEHICLE 361
7

CAUTION!
Do not use Automatic Transmission Fluid (ATF) or
other types of power steering fluids when servicing
the power steering system of this vehicle. Damage to
the power steering system can result from the use of
the wrong power steering fluid.
Checking the power steering fluid level at a defined
service interval is not required. The fluid should only be
checked if a leak is suspected, abnormal noises are
apparent, and/or the system is not functioning as antici-
pated. Coordinate inspection efforts through a certified
“DaimlerChrysler Dealership.”
WARNING!
Fluid level should be checked on a level surface with
the engine off to prevent injury from moving parts,
and to insure accurate fluid level reading. Do not
overfill. Use only the manufacturer’s recommended
fluid.
If necessary, add fluid to restore to the proper indicated
level. With a clean cloth, wipe any spilled fluid from all
surfaces. Refer to Fluids, Lubricants, and Genuine Parts
for correct fluid type.
NOTE:Upon initial start-up in cold weather, the power
steering pump may make noise for a short period of time.
This is due to the cold, thick fluid in the steering system.
This noise should be considered normal, and does not in
any way damage the steering system.
362 MAINTAINING YOUR VEHICLE

Brake and Power Steering System Hoses
When servicing the vehicle for scheduled maintenance,
inspect surface of hoses for evidence of heat and me-
chanical damage. Hard and brittle rubber, cracking, tears,
cuts, abrasion, and excessive swelling suggest deteriora-
tion of the rubber. Particular attention should be made to
examining those hose surfaces nearest to high heat
sources, such as the exhaust manifold.
Inspect all hose clamps and couplings to make sure they
are secure and no leaks are present.
NOTE:Often fluids such as oil, power steering fluid,
and brake fluid are used during assembly plant opera-
tions to ease the assembly of hoses to couplings. There-
fore, oil wetness at the hose-coupling area is not neces-
sarily an indication of leakage. Actual dripping of hot
fluid when systems are under pressure (during vehicle
operation) should be noted before hose is replaced based
on leakage.NOTE:Inspection of brake hoses should be done when-
ever the brake system is serviced and every engine oil
change.
WARNING!
Worn brake hoses can burst and cause brake failure.
You could have an accident. If you see any signs of
cracking, scuffing, or worn spots, have the brake
hoses replaced immediately.
Brake Master Cylinder
The fluid level in the master cylinder should be checked
when performing under hood services, or immediately if
the brake system warning lamp shows system failure
Be sure to clean the top of the master cylinder area before
removing the cap. If necessary, add fluid to bring the
fluid level up to the requirements described on the brake
MAINTAINING YOUR VEHICLE 371
7

Front/Rear Axle Fluid
Front Axle Fluid Level Check
Lubricant should be to the bottom of the oil fill hole.
Rear Axle Fluid Level Check
Lubricant should be 1/2” (1 cm) below the oil fill hole.
Adding Fluid
Add lubricant only at the fill hole and only to the level
specified above.
Selection of Lubricant
Use only manufacturer’s recommended fluid, refer to
Fluids, Lubricants, and Genuine Parts for correct fluid
type.
Maintenance After Off-Pavement Driving
After extended operation in mud, sand or water, or
similar dirty conditions, have your brake discs, brake
linings, and axle joints inspected and cleaned as soon as
possible. This will prevent any abrasive material from
causing excessive wear or unpredictable braking action.
Following off-pavement usage, completely inspect the
underbody of your vehicle. Check tires, body structure,
steering, suspension and exhaust system for damage.
Check threaded fasteners for looseness, particularly on
the chassis, drivetrain components, steering and suspen-
sion. Retighten, if required, to torque values specified in
the Service Manual. Also check for accumulations of
vegetation or brush that could become a fire hazard, or
conceal damage to fuel lines, brake hoses, axle pinion
seals, and propeller shafts.
376 MAINTAINING YOUR VEHICLE

CAUTION!
Under frequent heavy-duty driving conditions,
change all lubricants and lubricate body compo-
nents, all driveline joints and steering linkage more
often than in normal service to prevent excessive
wear.
Appearance Care And Protection From Corrosion
Protection of Body and Paint from Corrosion
Vehicle body care requirements vary according to geo-
graphic locations and usage. Chemicals that make roads
passable in snow and ice, and those that are sprayed on
trees and road surfaces during other seasons, are highly
corrosive to the metal in your vehicle.
The following maintenance recommendations will enable
you to obtain maximum benefit from the corrosion
resistance built into your vehicle.
What Causes Corrosion?
Corrosion is the result of deterioration or removal of
paint and protective coatings from your vehicle.
The most common causes are:
•Road salt, dirt and moisture accumulation.
•Stone and gravel impact.
•Insects, tree sap and tar.
•Salt in the air near seacoast localities.
•Atmospheric fallout/industrial pollutants.
Washing
•
Wash your vehicle regularly. Always wash your ve-
hicle in the shade using MoparCar Wash or a mild
car wash soap, and rinse the panels completely with
clear water.
MAINTAINING YOUR VEHICLE 377
7

Seat Belt Maintenance
Do not bleach, dye or clean the belts with chemical
solvents or abrasive cleaners. This will weaken the fabric.
Sun damage will also weaken the fabric.
If the belts need cleaning, use MoparTotal Clean, a mild
soap solution, or lukewarm water. Do not remove the
belts from the vehicle to wash them.
Replace the belts if they appear frayed or worn or if the
buckles do not work properly.
FUSE PANEL
Interior Fuses
The fuse panel is on the lower instrument panel just to
the left of the steering column.
Fuse Panel Location
MAINTAINING YOUR VEHICLE 381
7

Chassis
Component Fluid, Lubricant, or Genuine Part
Automatic Transmission MoparATF+4 Automatic Transmission Fluid
Transfer Case (3.7L Engines) MoparATF+4 Automatic Transmission Fluid
Transfer Case (4.7L/5.7L Engines) MoparNV 247 Transfer Case Lubricant
Axle Differential (Front-Rear) MoparSynthetic Gear & Axle Lubricant SAE 75W-140 (API-GL5) or
equivalent with friction modifier additive.
Brake Master Cylinder MoparDOT 3 Brake Fluid, SAE J1703 should be used. If DOT 3, SAE
J1703 brake fluid is not available, then DOT 4 is acceptable. Use only rec-
ommended brake fluids.
Power Steering Reservoir This system requires the use of MoparHydraulic System Power Steering
Fluid (P/N 05142893AA) or equivalent, which meets DaimlerChrysler Ma-
terial Standard MS-10838.
390 MAINTAINING YOUR VEHICLE

Defroster, Rear Window................... 233
Defroster, Windshield................ 71,234,241
Diagnostic System, Onboard................ 348
Dimmer Switch, Headlight................. 126
Dipsticks
Automatic Transmission................. 373
Oil (Engine).......................... 352
Power Steering........................ 361
Disabled Vehicle Towing................... 341
Disposal
Engine Oil........................... 355
Used Engine Fluids..................... 355
Door Locks............................. 18
Door Locks, Automatic.................... 20
Door Opener, Garage..................... 152
Doors................................. 18
DriveBelts ............................ 355
Driving ............................... 275
Off-Pavement......................... 276Off-Road............................ 276
DVD Player (Video Entertainment System)...... 224
Electric Remote Mirrors.................... 81
Electrical Outlet, Auxiliary (Power Outlet)...... 162
Electronic Brake Control System............. 131
Electronic Speed Control (Cruise Control)...... 148
Electronic Stability Program (ESP)............ 135
Electronic Throttle Control Warning Light...... 184
Electronic Vehicle Information Center (EVIC) . 183,186
Emergency, In Case of
FreeingVehicleWhenStuck ............... 263
Hazard Warning Flasher................. 330
Jacking............................. 332
Jump Starting......................... 338
Tow Hooks.......................... 340
Emission Control System Maintenance......349,392
Engine
Air Cleaner.......................... 358
INDEX 423
10

Fluid Leaks............................. 71
Fluid Level Checks
Automatic Transmission...............372,373
Engine Oil........................... 352
Power Steering........................ 361
Fluids, Lubricants and Genuine Parts.......... 389
Fog Lights..........................126,185
Fold and Tumble Rear Seat................. 109
Folding Rear Seat.....................109,113
Four Wheel Drive....................... 264
Operation........................... 264
Systems............................. 264
Four Wheel Drive Operation................ 264
Four-Way Hazard Flasher.................. 330
Freeing A Stuck Vehicle................... 263
Front Axle (Differential)................... 376
Fuel................................. 305
Filler Cap (Gas Cap).................... 309
Filler Door (Gas Cap)................... 309Gasoline............................ 305
Gauge.............................. 184
Materials Added....................... 307
Octane Rating........................ 305
Requirements......................... 388
Tank Capacity........................ 388
Fuel System Caution...................307,310
Fuses................................ 381
Garage Door Opener (HomeLink) ........... 152
Gas Cap (Fuel Filler Cap)...............309,348
Gasoline (Fuel)......................... 305
Gasoline, Reformulated................... 306
Gasoline/Oxygenate Blends................ 306
Gauges
Coolant Temperature.................... 182
Fuel................................ 184
Speedometer......................... 178
Tachometer.......................... 180
INDEX 425
10

PolishingandWaxing ..................... 378
Power
Distribution Center..................... 383
Door Locks........................... 20
Mirrors .............................. 81
Outlet (Auxiliary Electrical Outlet).......... 162
Seats............................... 108
Steering..........................274,361
Sunroof............................. 159
Windows............................. 29
Pregnant Women and Seat Belts.............. 41
Preparation for Jacking.................... 334
Pretensioners
Seat Belts............................. 39
Programmable Electronic Features......154,158,189
Programming Transmitters
(Remote Keyless Entry).................154,158
Quadra-Trac........................... 264Radial Ply Tires......................... 293
Radio Broadcast Signals................... 199
Radio Operation...................200,214,232
Radio, Satellite.......................223,226
Radio (Sound Systems).................200,214
Rain Sensitive Wiper System................ 129
Rear Air Conditioning.................... 243
Rear Axle (Differential).................... 376
Rear Cup Holder........................ 164
Rear Heater............................ 243
Rear Liftgate............................ 18
Rear Park Assist System................... 141
Rear Seat, Fold and Tumble................ 109
Rear Seat, Folding....................109,113
Rear Window Defroster................... 233
Rear Window Features.................... 168
Rear Wiper/Washer...................... 168
Rearview Mirrors........................ 78
Reclining Front Seats..................... 106
INDEX 431
10
