WHAT TO DO IN EMERGENCIES
CONTENTS

Hazard Warning Flashers.................330

If Your Engine Overheats.................331

Jacking And Tire Changing................332
▫Jack Location........................332
▫Spare Tire Stowage....................333
▫Spare Tire Removal....................334
▫Preparations For Jacking................334▫Jacking Instructions....................335

Jump Starting Procedure..................338

Emergency Tow Hooks — If Equipped........340

Towing A Disabled Vehicle................341
▫2WD Models Only....................341
▫4WD Models Only....................341
6

IF YOUR ENGINE OVERHEATS
In any of the following situations, you can reduce the
potential for overheating by taking the appropriate ac-
tion.
•On the highways — Slow down.
•In city traffic — While stopped, put transmission in N
(Neutral), but do not increase engine idle speed.
NOTE:There are steps that you can take to slow down
an impending overheat condition. If your air conditioner
is on, turn it off. The air conditioning system adds heat to
the engine cooling system and turning off the A/C
removes this heat. You can also turn the Temperature
Control to maximum heat, the Mode Control to floor, and
the Fan Control to High. This allows the heater core to act
as a supplement to the radiator and aids in removing heat
from the engine cooling system.
CAUTION!
Driving with a hot cooling system could damage
your vehicle. If the temperature gauge reads “H”,
pull over and stop the vehicle. Idle the vehicle with
the air conditioner turned off until the pointer drops
back into the normal range. If the pointer remains on
the “H”, and you hear continuous chimes, turn the
engine off immediately, and call for service.
WHAT TO DO IN EMERGENCIES 331
6

5. Connect the other cable, first to the negative terminal
of the booster battery and then connect the other end to
a non-paint metal surface on the engine of the vehicle
with the discharged battery. Make sure you have a good
contact on the engine.
6. Start the engine in the vehicle which has the booster
battery, let the engine idle a few minutes, then start the
engine in the vehicle with the discharged battery.
7. When removing the jumper cables, reverse the above
sequence exactly. Be careful of the moving belts and fan.
NOTE:To start the vehicle following connection of a
booster battery, the Security Alarm System must first be
disabled by cycling a front door key cylinder or by using
the keyless entry transmitter.WARNING!
Jump starting can be dangerous. To avoid personal
injury or damage to electrical components in vehicle,
observe the following warnings:
•Battery fluid is a corrosive acid solution and can burn
or even blind you. Don’t allow battery fluid to contact
your eyes, skin, or clothing. Don’t lean over a battery
when attaching clamps. If acid splashes in eyes or on
skin, flush the area immediately with large amounts of
water.
•Do not use a booster battery or any other booster
source that has a greater than 12–volt system, i.e., do
not use a 24–volt power source.
•Never attempt to jump start a discharged battery that
is frozen, because it could rupture or explode during
jump starting.
WHAT TO DO IN EMERGENCIES 339
6

•Be sure your vehicle is not touching the jump start
vehicle.
•Observe all Battery Warnings in Section 7 of this
manual, while jump starting your vehicle.
WARNING!
Do not attempt to push or tow your vehicle to get it
started. Unburned fuel could enter the catalytic
converter and, once the engine has started, ignite and
damage the converter and vehicle.
EMERGENCY TOW HOOKS — IF EQUIPPED
If your vehicle is equipped with tow hooks, there will be
one in the rear and two mounted on the front of the
vehicle. The rear hook will be located on the driver’s side
of the vehicle.
NOTE:For off-road recovery, it is recommended to use
both of the front tow hooks to minimize the risk of
damage to the vehicle.
CAUTION!
Tow hooks are for emergency use only, to rescue a
vehicle stranded off road. Do not use tow hooks for
tow truck hookup or highway towing. You could
damage your vehicle.
340 WHAT TO DO IN EMERGENCIES

MAINTAINING YOUR VEHICLE
CONTENTS

3.7L Engine...........................345

4.7L Engine...........................346

5.7L Engine...........................347

Onboard Diagnostic System — OBD II........348
▫Loose Fuel Filler Cap Message............348

Emissions Inspection And Maintenance
Programs............................349

Replacement Parts......................350

Dealer Service.........................351
Maintenance Procedures..................351
▫Engine Oil..........................352
▫Drive Belts — Check Condition And
Tensioner...........................355
▫Spark Plugs.........................356
▫Catalytic Converter....................356
▫Crankcase Emission Control System........358
▫Air Cleaner Filter.....................358
▫Maintenance-Free Battery................359
7

▫Air Conditioner Maintenance.............360
▫Power Steering Fluid Check..............361
▫Body Lubrication.....................363
▫Windshield Wiper Blades................363
▫Windshield Washers — Front And Rear.....363
▫Exhaust System......................364
▫Cooling System.......................365
▫Hoses And Vacuum/Vapor Harnesses.......370
▫Brake System........................370
▫Automatic Transmission................372
▫Transfer Case........................375
▫Front/Rear Axle Fluid..................376▫Appearance Care And Protection From
Corrosion...........................377

Fuse Panel...........................381
▫Interior Fuses........................381
▫Underhood Fuses
(Power Distribution Center)..............383
▫Underhood Fuses (Integrated Power Module) . 385

Vehicle Storage........................386

Replacement Bulbs......................387

Fluid Capacities........................388

Fluids, Lubricants, And Genuine Parts........389
▫Engine.............................389
▫Chassis............................390
344 MAINTAINING YOUR VEHICLE

3.7L ENGINE
MAINTAINING YOUR VEHICLE 345
7

4.7L ENGINE
346 MAINTAINING YOUR VEHICLE

5.7L ENGINE
MAINTAINING YOUR VEHICLE 347
7

ONBOARD DIAGNOSTIC SYSTEM — OBD II
Your vehicle is equipped with a sophisticated onboard
diagnostic system called OBD II. This system monitors
the performance of the emissions, engine, and automatic
transmission control systems. When these systems are
operating properly, your vehicle will provide excellent
performance and fuel economy, as well as engine emis-
sions well within current government regulations.
If any of these systems require service, the OBD II system
will turn on the “Malfunction Indicator Light.” It will
also store diagnostic codes and other information to
assist your service technician in making repairs. Al-
though your vehicle will usually be drivable and not
need towing, see your dealer for service as soon as
possible.CAUTION!
•Prolonged driving with the “Malfunction Indica-
tor Light” on could cause further damage to the
emission control system. It could also affect fuel
economy and driveability. The vehicle must be
serviced before any emissions tests can be per-
formed.
•If the “Malfunction Indicator Light” is flashing
while the engine is running, severe catalytic con-
verter damage and power loss will soon occur.
Immediate service is required.
Loose Fuel Filler Cap Message
After fuel is added, the vehicle diagnostic system can
determine if the fuel filler cap is loose, improperly
installed, or damaged. A loose fuel filler cap message will
be displayed in the instrument cluster. Tighten the gas
348 MAINTAINING YOUR VEHICLE
