N (Neutral)
Neutral — Disengages both the front and rear driveshafts
from the powertrain. To be used for flat towing behind
another vehicle. Refer to “Recreational Towing” in Sec-
tion 5 of this manual.
4 LOW
Four Wheel Drive Low Range — Low speed 4 wheel
drive. Locks the front and rear driveshafts together.
Forces the front and rear wheels to rotate at the same
speed. Additional traction and maximum pulling power
for loose, slippery road surfaces only. Do not exceed 25
mph (40 km/h).
Shifting Procedures
4HIto4LOW
With the vehicle at speeds of 0 to 3 mph (0 to 5 km/h),
key ON or engine running, shift the transmission into N
(Neutral), and raise the transfer case T-handle. “The 4WD
LOW Indicator Lamp” in the instrument cluster will
begin to flash and remain on solid when the shift is
complete. Release the T-handle.
NOTE:If shift conditions/interlocks are not met, or a
transfer case motor temperature protection condition
exists, a “CHECK SHIFT PROCEDURES” message will
flash from the EVIC (Electronic Vehicle Information Cen-
ter). Refer to “Electronic Vehicle Information Center
(EVIC)” in Section 4 of this manual. (See page 186 for
more information.)
266 STARTING AND OPERATING

WARNING!
Significant over or under inflation of tires, or mixing
sizes of tires or wheels on the vehicle can lead to loss
of braking effectiveness.
The Anti-Lock Brake System conducts a low-speed self-
test at about 12 mph (20 km/h). If you have your foot
lightly on the brake while this test is occurring you may
feel slight pedal movement. The movement can be more
apparent on ice and snow. This is normal.
The Anti-Lock Brake System pump motor runs during
the self-test at 12 mph (20 km/h) and during an ABS stop.
The pump motor makes a low humming noise during
operation, which is normal.
WARNING!
Pumping of the Anti-Lock Brakes will diminish
their effectiveness and may lead to an accident.
Pumping makes the stopping distance longer. Just
press firmly on your brake pedal when you need to
slow down or stop.
272 STARTING AND OPERATING

Chains, Tire............................ 303
Changing A Flat Tire..................... 332
Chart, Tire Sizing........................ 282
Checks, Safety......................... 70,71
Child Restraint.................... 58,59,64,66
Child Restraint Tether Anchors............. 63,64
Child Safety Locks........................ 19
Climate Control......................... 232
Clock ...........................202,216,223
Command View Skylights.................. 161
Compact Disc (CD) Maintenance............. 231
Compass.............................. 193
Compass Variance....................... 198
Computer, Trip/Travel.................... 193
Console, Overhead....................... 152
Contract, Service........................ 414
Converter, Catalytic...................... 356
Cooling System......................... 365
Adding Coolant (Antifreeze).............. 367Coolant Capacity...................... 388
Coolant Level......................... 368
Disposal of Used Coolant................ 368
Drain, Flush, and Refill.................. 366
Inspection........................... 365
Points to Remember.................... 369
Pressure Cap......................... 367
Radiator Cap......................... 367
Selection of Coolant (Antifreeze).........366,388
Courtesy Lights......................... 121
Crankcase Emission Control System.......... 358
Cruise Control (Speed Control).............. 148
CruiseLight ........................... 184
CupHolder ............................ 164
Customer Assistance..................... 412
Data Recorder, Event...................... 56
Daytime Running Lights................... 125
Dealer Service.......................... 351
422 INDEX
