Page 26 of 456
unlocked, you have 60 seconds to enter the vehicle, insert
the key into the ignition, and move it to the RUN
position. Otherwise, the engine will cancel remote start
and automatically turn off.
Remote start will also cancel if any of the following occur:
•If the engine stalls or RPM exceeds 2500
•Any engine warning lamps come on
•The hood is opened
•The hazard switch is pressed
•The transmission is moved out of P (Park).
The vehicle can be started remotely up to a maximum of
two times. The vehicle is also allowed a maximum of one
failed start, where the remote start sequence was initiated
but cancelled before the engine begins to crank. After
either of these conditions, or if the Vehicle Theft Alarm is
alarming, or if the PANIC button was pressed, the vehicle
must be reset by inserting a valid key into the ignition
and moving it to the RUN position, then back to LOCK.
DOOR LOCKS
Manual Door Locks
Use the manual door lock plunger to lock the doors from
inside the vehicle. If the plunger is down when the door
is closed, the door will lock. Therefore, make sure the
keys are not inside the vehicle before closing the door.
WARNING!
•For personal security and safety in the event of an
accident, lock the vehicle doors when you drive as
well as when you park and leave the vehicle.
•When leaving the vehicle always remove the key
from the ignition lock, and lock your vehicle. Do
not leave children unattended in the vehicle, or
with access to an unlocked vehicle. Unsupervised
use of vehicle equipment may cause severe per-
sonal injuries and death.
26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
Page 72 of 456
▫Things You Should Know About Your
UConnect™ System.....................97
Seats................................103
▫Front Manual Seat Adjustment............103
▫Front Seat Adjustment — Recline..........104
▫Manual Lumbar Support Adjustment.......105
▫8 - Way Driver’s Power Seat..............105
▫4 - Way Passenger’s Power Seat —
If Equipped.........................106
▫Head Restraints......................106
▫Heated Seats—If Equipped..............106
▫40/20/40 Second Row Folding Seat........108
▫50/50 Third Row Folding Seat............111
Driver Memory Seat — If Equipped.........113▫Setting Memory Positions And Linking Remote
Keyless Entry Transmitter To Memory.......114
▫Memory Position Recall.................115
▫To Disable A Transmitter Linked To Memory . . 116
▫Easy Entry/Exit Seat...................116
To Open And Close The Hood.............118
Lights...............................119
▫Multi-Function Control Lever.............119
▫Battery Saver Feature—Exterior/Interior
Lights.............................120
▫Headlights And Parking Lights...........120
▫Automatic Headlight System — If Equipped . . 120
▫Smartbeams — If Equipped..............121
▫Instrument Panel And Interior Lights.......122
72 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 118 of 456
TO OPEN AND CLOSE THE HOOD
To open the hood, pull the release lever inside your
vehicle located below the instrument panel and in front
of the driver’s door.Then, reach under the hood, move safety latch to the left,
and lift the hood. To prevent possible damage, do not
slam the hood to close it. Use a firm downward push at
the center of the hood to ensure that both latches engage.
Hood Release LeverUnderhood Safety Latch
118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 185 of 456
•LIFTGATE/DOOR OPEN (with graphic)
•LIFTGATE/DOORS OPEN (with graphic)
•LIFTGLASS OPEN (with graphic)
•HOOD OPEN (with graphic)
•HOOD/DOOR OPEN (with graphic)
•HOOD/DOORS OPEN (with graphic)
•LIFTGATE/HOOD OPEN (with graphic)
•HOOD/GLASS/DOOR OPEN (with graphic)
•HOOD/GLASS/DOORS OPEN (with graphic)
•HOOD/GATE/DOOR OPEN (with graphic)
•HOOD/GATE/DOORS OPEN (with graphic)
•LIFTGLASS/DOOR OPEN (with graphic)
•LIFTGLASS/DOORS OPEN (with graphic)
•LIFTGLASS/HOOD OPEN (with graphic)
•WASHER FLUID LOW (with graphic)
•CHECK GAUGES
•AUTO HIGHBEAM ON
•AUTO HIGHBEAM OFF
•PARK ASSIST DISABLED
•SERVICE PARK ASSIST SYSTEM
•TRANSMISSION OVER TEMP
•CHECK SHIFT PROCEDURE
•SERVICE 4WD SYSTEM
•4WD SYSTEM IN NEUTRAL
•LOW BRAKE FLUID LEVEL
•WARNING! LIMIT SPEED
UNDERSTANDING YOUR INSTRUMENT PANEL 185
4
Page 375 of 456
Exhaust System
The best protection against carbon monoxide entry into
the vehicle body is a properly maintained engine exhaust
system.
If you notice a change in the sound of the exhaust system;
or if the exhaust fumes can be detected inside the vehicle;
or when the underside or rear of the vehicle is damaged;
have an authorized technician inspect the complete ex-
haust system and adjacent body areas for broken, dam-
aged, deteriorated, or mispositioned parts. Open seams
or loose connections could permit exhaust fumes to seep
into the passenger compartment. In addition, inspect the
exhaust system each time the vehicle is raised for lubri-
cation or oil change. Replace as required.
Cooling System
WARNING!
You or others can be badly burned by hot antifreeze/
coolant or steam from your radiator. If you see or
hear steam coming from under the hood, don’t open
the hood until the radiator has had time to cool.
Never try to open a cooling system pressure cap
when the radiator or coolant bottle is hot.
Engine Coolant Checks
Check antifreeze/coolant protection every 12 months
(before the onset of freezing weather, where applicable).
If antifreeze/coolant is dirty or rusty in appearance, the
system should be drained, flushed and refilled with fresh
antifreeze/coolant. Check the front of the A/C condenser
for any accumulation of bugs, leaves, etc. If dirty, clean by
gently spraying water from a garden hose vertically
down the face of the condenser.
MAINTAINING YOUR VEHICLE 375
7
Page 445 of 456
HomeLink(Garage Door Opener) Transmitter . . . 151
Hood Release.......................... 118
Hoses................................ 380
Ignition
Cables (Spark Plug Wires)................ 366
Key ................................. 14
Wiring System (Spark Plug Wires).......... 366
Illuminated Entry........................ 19
Infant Restraint.......................... 57
Inflation Pressure Tires.................... 289
Information Center, Vehicle................. 184
Inside Rearview Mirror.................... 76
Instrument Cluster....................175,176
Instrument Panel and Controls.............. 174
Instrument Panel Lens Cleaning............. 392
Integrated Power Module (Fuses)............ 398
Interior Appearance Care.................. 390
Interior Fuses.......................... 393Interior Lighting........................ 125
Interior Lights.......................122,125
Intermittent Wipers (Delay Wipers)........... 127
Introduction............................. 4
Jack Location........................... 342
Jack Operation.......................342,345
Jacking Instructions...................... 345
Jump Starting.......................... 348
Key, Programming........................ 17
Key, Replacement........................ 17
Key, Sentry (Immobilizer)................... 15
Key-In Reminder......................... 15
Keyless Entry System...................... 19
Keys................................. 14
Lap/Shoulder Belts....................... 38
INDEX 445
10
