CD player JEEP COMMANDER 2008 1.G User Guide

CAUTION!
²This CD player will accept 4 3/4 inch (12 cm) discs
only. The use of other sized discs may damage the
CD player mechanism.
²Do not use adhesive labels. These labels can peel
away and jam the player mechanism.
²RES is a single CD player. Do not attempt to insert
a second CD if one is already loaded.
²Dual-media disc types (one side is a DVD, the
other side is a CD) should not be used, and they
can cause damage to the player.
EJECT Button - Ejecting a CD
Press the EJECT button to eject the CD.If you have ejected a disc and have not removed it within
10 seconds, it will be reloaded. If the CD is not removed,
the radio will reinsert the CD but will not play it.
A disc can be ejected with the radio and ignition OFF.
NOTE:Ejecting with ignition OFF is not allowed on
convertible or soft-top models (if equipped).
SEEK Button
Press the right SEEK button for the next selection on the
CD. Press the left SEEK button to return to the beginning
of the current selection, or return to the beginning of the
previous selection if the CD is within the first second of
the current selection. Pressing and holding the SEEK
button will allow to scroll through tracks faster in CD,
MP3 modes.
SCAN Button
Press the Scan button to scan through each track on the
CD currently playing.
234 UNDERSTANDING YOUR INSTRUMENT PANEL

TIME Button
Press this button to change the display from a large CD
playing time display to a small CD playing time display.
RW/FF
Press the RW button to stop the CD at the beginning of
the current CD track/title.
Press and hold FF (Fast Forward) and the CD player will
begin to fast forward until FF is released or RW or
another CD button is pressed. The RW (Reverse) button
works in a similar manner.
AM or FM Button
Switches the Radio to the Radio mode.
RND Button (Random Play Button)
Press this button while the CD is playing to activate
Random Play. This feature plays the selections on the
compact disc in random order to provide an interesting
change of pace.Press the right SEEK button to move to the next ran-
domly selected track.
Press the RND button a second time to stop Random
Play.
Notes On Playing MP3 Files
The radio can play MP3 files; however, acceptable MP3
file recording media and formats are limited. When
writing MP3 files, pay attention to the following restric-
tions.
Supported Media (Disc Types)
The MP3 file recording media supported by the radio are
CDDA, CD-R, CD-RW, MP3, and CDDA+MP3.
Supported Medium Formats (File Systems)
The medium formats supported by the radio are ISO 9660
Level 1 and Level 2 and includes the Joliet extension.
When reading discs recorded using formats other than
ISO 9660 Level 1 and Level 2, the radio may fail to read
UNDERSTANDING YOUR INSTRUMENT PANEL 235
4

LIST Button (CD Mode for MP3 Play)
Pressing the LIST button will bring up a list of all folders
on the disc. Scrolling up or down the list is done by
turning the TUNE control knob. Selecting a folder by
pressing the TUNE control knob will begin playing the
files contained in that folder (or the next folder in
sequence if the selection does not contain playable files).
The folder list will time out after 5 seconds.
INFO Button (CD Mode for MP3 Play)
Pressing the INFO button repeatedly will scroll through
the following TAG information: Song Title, Artist, File
Name, and Folder Name (if available).
Press the INFO button once more to return to9elapsed
time9priority mode.
Press and hold the INFO button for 3 seconds or more
and radio will display song titles for each file.Press and hold the INFO button again for 3 seconds to
return to9elapsed time9display.
Operation Instructions - Auxiliary Mode
The auxiliary (AUX) jack is an audio input jack, which
allows the user to plug in a portable device such as an
MP3 player, or cassette player, and utilize the vehicle's
audio system to amplify the source and play through the
vehicle speakers.
Pushing the AUX button will change the mode to auxil-
iary device if the AUX jack is connected.
NOTE:The AUX device must be turned on and the
device's volume set to proper level. If the AUX audio is
not loud enough, turn the device's volume up. If the AUX
audio sounds distorted, turn the device's volume down.
238 UNDERSTANDING YOUR INSTRUMENT PANEL

TIME Button (Auxiliary Mode)
Press this button to change the display to time of day. The
time of day will display for 5 seconds (when ignition is
off).
Operating Instructions - Hands Free Phone
(UConnectŸ) (If Equipped)
Refer to ªHands-Free Communication (UConnectŸ)º in
Section 3 of this manual.
Operating Instructions - Satellite Radio Mode (If
Equipped)
Refer to ªSatellite Radioº in this section.
Operating Instructions - Video Entertainment
System (VESt) (If Equipped)
Refer to separate ªVideo Entertainment System (VESt)
Guide.º
SALES CODE REN Ð MULTIMEDIA SYSTEM Ð IF
EQUIPPED
NOTE:The sales code is located on the lower right side
of the unit's faceplate.
The REN multimedia system contains a radio, CD/DVD
player, USB port, a 20 gigabyte Hard Drive (HDD), and a
ªJukeBoxº (virtual CD changer). Sirius Satellite Radio is
optional. The 6.5-inch touch screen allows for easy menu
selection.
A 20 gigabyte Hard Drive (HDD) allows uploads of
music and photos from CDs or through the USB port.
While the Gracenote database finds the artist, track, and
title for the music.
An auxiliary input jack permits passengers to listen to a
portable MP3 player through the vehicle's speakers. For
vehicles equipped with the Vehicle Entertainment System
(VES), separate audio outputs allow passengers to listen
UNDERSTANDING YOUR INSTRUMENT PANEL 239
4

Changing the Time Zone
1. Turn on the system.
2. Touch the screen where the time is displayed. The
clock setting menu will appear on the screen.
3. Touch the screen where the words ªSet Time Zoneº are
displayed. The time zone selection menu will appear on
the screen.
4. Select a time zone by touching the screen where your
selection appears. If you do not see a time zone that you
want to select, touch the screen where the word ªPageº is
displayed to view additional time zones in the menu.
5. Touch the screen where the word ªSaveº is displayed.
SALES CODE RER Ð AM/FM/CD/DVD RADIO
WITH NAVIGATION SYSTEM Ð IF EQUIPPED
NOTE:The radio sales code is located on the lower right
side of your radio faceplate.
Satellite Navigation Radio with CD Player with MP3
Capability (RER) - combines a Global-Positioning
System-based navigation system with an integrated color
screen to provide maps, turn identification, selection
menus, and instructions for selecting a variety of desti-
nations and routes.
This radio has a hard drive. CD's can be ripped to the
hard drive, and the map data comes loaded on the hard
drive. Refer to your ªNavigation User's Manualº for
detailed operating instructions.
242 UNDERSTANDING YOUR INSTRUMENT PANEL

The right hand control is a rocker type switch with a
push-button in the center and controls the volume and
mode of the sound system. Pressing the top of the rocker
switch will increase the volume and pressing the bottom
of the rocker switch will decrease the volume.
Pressing the center button will make the radio switch
between the various modes available (AM/FM/TAPE/
CD, Etc.).
The left hand control is a rocker type switch with a
push-button in the center. The function of the left hand
control is different depending on which mode you are in.
The following describes the left hand control operation in
each mode.Radio Operation
Pressing the top of the switch will ªSeekº up for the next
listenable station and pressing the bottom of the switch
will ªSeekº down for the next listenable station.
The button located in the center of the left hand control
will tune to the next preset station that you have pro-
grammed in the radio preset push-button.
CD Player
Pressing the top of the switch once will go to the next
track on the CD. Pressing the bottom of the switch once
will go to the beginning of the current track or to the
beginning of the previous track if it is within one second
after the current track begins to play.
If you press the switch up or down twice it plays the
second track, three times, it will play the third, etc.
UNDERSTANDING YOUR INSTRUMENT PANEL 255
4

The center button on the left side rocker switch has no
function for a single disc CD player. However, when a
multiple disc CD player is equipped on the vehicle, the
center button will select the next available CD in the
player.
CD/DVD DISC MAINTENANCE
To keep the CD/DVD discs in good condition, take the
following precautions:
1. Handle the disc by its edge; avoid touching the
surface.
2. If the disc is stained, clean the surface with a soft cloth,
wiping from center to edge.
3. Do not apply paper, paper CD labels, or tape to the
disc; avoid scratching the disc.
4. Do not use solvents such as benzine, thinner, cleaners,
or antistatic sprays.5. Store the disc in its case after playing.
6. Do not expose the disc to direct sunlight.
7. Do not store the disc where temperatures may become
too high.
RADIO OPERATION AND CELLULAR PHONES
Under certain conditions, the cellular phone being On in
your vehicle can cause erratic or noisy performance from
your radio. This condition may be lessened or eliminated
by relocating the cellular phone antenna. This condition
is not harmful to the radio. If your radio performance
does not satisfactorily ªclearº by the repositioning of the
antenna, it is recommended that the radio volume be
turned down or off during cellular phone operation.
256 UNDERSTANDING YOUR INSTRUMENT PANEL

Cargo Compartment...................... 174
Luggage Carrier....................... 177
Cargo Load Floor........................ 174
Catalytic Converter...................... 393
CD (Compact Disc) Player................. 239
Cellular Phone.......................... 82
Center High Mounted Stop Light............ 434
Certification Label....................... 344
Chains, Tire............................ 322
Changing A Flat Tire..................... 368
Chart, Tire Sizing........................ 308
Checks, Safety.........................71,72
Child Restraint....................60,61,65,67
Child Restraint Tether Anchors.............64,65
Child Safety Locks........................ 30
Climate Control......................... 257
Clock........................213,229,240,243
Cold Weather Operation................... 278
Command View Skylights.................. 168Compact Disc (CD) Maintenance............. 256
Compass.............................. 203
Compass Calibration..................... 204
Compass Variance....................... 204
Computer, Trip/Travel.................... 200
Connector
UCI ................................ 244
Universal Consumer Interface (UCI)......... 244
Console, Overhead....................... 158
Contract, Service........................ 450
Converter, Catalytic...................... 393
Cooling System......................... 401
Adding Coolant (Antifreeze).............. 403
Coolant Capacity...................... 435
Coolant Level......................... 405
Disposal of Used Coolant................ 405
Drain, Flush, and Refill.................. 402
Inspection........................401,405
Points to Remember.................... 405
460 INDEX

Pressure Cap......................... 404
Radiator Cap......................... 404
Selection of Coolant (Antifreeze).........402,435
Courtesy Lights......................... 130
Crankcase Emission Control System.......... 395
Cruise Light........................... 193
Cup Holder............................ 172
Customer Assistance..................... 448
Data Recorder, Event...................... 58
Daytime Running Lights................... 128
Dealer Service.......................... 388
Defroster, Rear Window................... 177
Defroster, Windshield................71,258,265
Diagnostic System, Onboard................ 385
Digital Video Disc (DVD) Player............. 239
Dimmer Switch, Headlight................. 129
Dipsticks
Automatic Transmission................. 412Oil (Engine).......................... 389
Power Steering........................ 398
Disabled Vehicle Towing................... 378
Disposal
Antifreeze (Engine Coolant)............... 405
Engine Oil........................... 391
Used Engine Fluids..................... 391
Door Locks............................. 28
Door Locks, Automatic.................... 29
Door Opener, Garage..................... 159
Drive Belts............................ 392
Driving............................... 296
Off-Pavement......................... 296
Off-Road............................ 296
DVD Player (Video Entertainment System)...... 253
E-85 Fuel............................. 337
Electric Remote Mirrors.................... 80
Electrical Outlet, Auxiliary (Power Outlet)...... 169
INDEX 461
10

Modifications/Alterations, Vehicle............. 9
Monitor, Tire Pressure System............... 323
Mopar Parts.........................388,451
MP3 Player............................ 239
Multi-Displacement Engine System........... 306
Multi-Function Control Lever............... 124
Navigation Radio........................ 242
Navigation System....................... 242
New Vehicle Break-In Period................ 69
Occupant Restraints....................... 38
Octane Rating, Gasoline (Fuel)............333,334
Odometer..........................192,193
Trip ................................ 192
Off-Pavement Driving (Off-Road)..........296,414
Off-Road Driving (Off-Pavement)..........296,414
Oil Change Indicator..................... 200
Oil Change Indicator, Reset................. 200Oil, Engine............................ 389
Capacity............................ 435
Change Interval....................... 390
Dipstick............................. 389
Disposal............................ 391
Filter............................... 391
Filter Disposal........................ 391
Identification Logo..................... 390
Materials Added to..................... 391
Pressure Warning Light.................. 189
Recommendation...................390,435
Synthetic............................ 391
Viscosity..........................390,435
Onboard Diagnostic System..............385,386
Opener, Garage Door (HomeLinkt) ........... 159
Outside Rearview Mirrors.................. 79
Overdrive............................. 286
Overdrive OFF Switch.................... 286
Overhead Console....................... 158
INDEX 469
10
