turn signal JEEP COMMANDER 2008 1.G Owner's Manual

Front Turn Signal
1. Turn the steering wheel all the way to the left or right.
2. Reach into the front wheel house ahead of the front
wheel to unsnap and lift the cover over the access hole in
the front of the wheel house splash shield. Access to the
bulb can be gained through the wheel liner hole.3. Reach through the access hole to access the park/turn
signal bulb socket on the bottom of the front lamp unit
housing.
1 Ð Low Beam Bulb
2 Ð High Beam Bulb
3 Ð Front Park/Turn Signal Bulb 430 MAINTAINING YOUR VEHICLE

3. Reach through the access hole to access the back of the
front fog light housing on the back of the front fascia.
4. Disconnect the electrical connector.
5. Turn the socket on the back of the housing 1/4 turn
counter clockwise to unlock it.
6. Pull the socket and bulb straight out from the opening
in the housing.
7. Pull the base of the bulb straight out of the socket.
CAUTION!
Do not touch the new bulb with your fingers. Oil
contamination will severely shorten bulb life. If the
bulb comes in contact with any oily surface, clean the
bulb with rubbing alcohol.
Rear Tail, Stop, Turn Signal, and Back-Up Lights
1. Raise the liftgate.
2. Remove the two push-pins that secure the rear lamp
unit to the side of the liftgate opening.
432 MAINTAINING YOUR VEHICLE

3. Pull the outboard side of the rear lamp unit rearward
far enough to unsnap the two ball studs on the outboard
side of the lamp housing from the two plastic grommets
in the quarter outer panel. Pull the lamp unit rearward
far enough away to access the bulbs.
4. Firmly grasp the appropriate bulb socket on the back
of the rear lamp unit housing, and turn 1/4 turn counter
clockwise to unlock it.
5. Disconnect the electrical connector.
6. Pull the socket and bulb straight out from the opening
in the housing.
1 Ð Rear Backup Lamp Bulb
2 Ð Rear Park/Stop Lamp Bulb
3 Ð Rear Park/Turn Signal Bulb
4 Ð Rear Side Marker Lamp BulbMAINTAINING YOUR VEHICLE 4337
