If the ignition key is cycled, this sequence will repeat,
providing the system fault still exists. If the system fault
no longer exists, the Tire Pressure Monitoring Telltale
Light will no longer flash, the9CHECK TPM SYSTEM9
text message will not be present, and a pressure value
will be displayed instead of dashes. A system fault can
occur by any of the following scenarios:1. Jamming due to electronic devices or driving next to
facilities emitting the same Radio Frequencies as the TPM
sensors.
2. Installing some form of aftermarket window tinting
that affects radio wave signals.
3. Lots of snow or ice around the wheels or wheel
housings.
4. Using tire chains on the vehicle.
5. Using wheels/tires not equipped with TPM sensors.
NOTE:If your vehicle is equipped with a matching full
size spare wheel and tire assembly, it has a tire pressure
monitoring sensor, and can be monitored by the Tire
Pressure Monitoring System (TPMS). In the event that the
matching full size spare tire is swapped with a low
pressure road tire, the next ignition key cycle will still
show the ªTire Pressure Monitoring Telltale Lightº to be
ON, a chime to sound, a Low Pressure message to appear
STARTING AND OPERATING 331
5

Carbon Monoxide Warnings
WARNING!
Carbon monoxide (CO) in exhaust gases is deadly.
Follow the precautions below to prevent carbon
monoxide poisoning:
²Do not inhale exhaust gases. They contain carbon
monoxide, a colorless and odorless gas which can kill.
Never run the engine in a closed area, such as a
garage, and never sit in a parked vehicle with the
engine running for an extended period. If the vehicle is
stopped in an open area with the engine running for
more than a short period, adjust the ventilation system
to force fresh, outside air into the vehicle.
²Guard against carbon monoxide with proper mainte-
nance. Have the exhaust system inspected every timethe vehicle is raised. Have any abnormal conditions
repaired promptly. Until repaired, drive with all side
windows fully open.
²Keep the liftgate closed when driving your vehicle to
prevent carbon monoxide and other poisonous ex-
haust gases from entering the vehicle.
FLEXIBLE FUEL (4.7L ENGINE ONLY) Ð IF
EQUIPPED
E-85 General Information
The information in this section is for Flexible Fuel ve-
hicles only. These vehicles can be identified by a unique,
yellow fuel filler cap (gas cap) that statesEthanol (E-85)/
Unleaded Gasoline,and by theFLEXFUELbadge that
will be located on the body of your vehicle. This section
only covers those subjects that are unique to these
vehicles. Please refer to the other sections of this manual
for information on features that are common between
Flexible Fuel and gasoline only powered vehicles.
STARTING AND OPERATING 337
5

Windshield Wiper Blades
The rubber edges of the wiper blades and the windshield
should be cleaned periodically with a sponge or soft cloth
and a mild nonabrasive cleaner to remove accumulations
of salt or road film.
Operation of the wipers on dry glass for long periods
may cause deterioration of the wiper blades. Always use
washer fluid when using the wipers to remove salt or dirt
from a dry windshield.
Avoid using the wiper blades to wipe frost or ice from the
windshield. Keep the blade rubber out of contact with
petroleum products such as engine oil, gasoline, etc.
Windshield Washers Ð Front and Rear
On vehicles equipped with a Electronic Vehicle Informa-
tion Center (EVIC), the low washer fluid level will be
indicated. When the sensor detects a low fluid level, the
windshield will light on the vehicle graphic outline and
the ªWasher Fluid Lowº message will be displayed.The fluid reservoir for the windshield washers and the
rear window washer is shared. The fluid reservoir is
located in the engine compartment, be sure to check the
fluid level at regular intervals. Fill the reservoir with
windshield washer solvent only (not radiator antifreeze).
When refilling the washer fluid reservoir, take some
washer fluid and apply it to a cloth or towel and wipe
clean the wiper blades, this will help blade performance.
To prevent freeze-up of your windshield washer system
in cold weather, select a solution or mixture that meets or
exceeds the temperature range of your climate. This
rating information can be found on most washer fluid
containers.
400 MAINTAINING YOUR VEHICLE

WARNING!
Do not use volatile solvents for cleaning purposes.
Many are potentially flammable, and if used in
closed areas they may cause respiratory harm.
Cleaning Headlights
Your vehicle has plastic headlights that are lighter and
less susceptible to stone breakage than glass headlights.
Plastic is not as scratch resistant as glass and therefore
different lens cleaning procedures must be followed.
To minimize the possibility of scratching the lenses and
reducing light output, avoid wiping with a dry cloth. To
remove road dirt, wash with a mild soap solution fol-
lowed by rinsing.
Do not use abrasive cleaning components, solvents, steel
wool or other aggressive material to clean the lenses.
Glass Surfaces
All glass surfaces should be cleaned on a regular basis
with MopartGlass Cleaner or any commercial
household-type glass cleaner. Never use an abrasive type
cleaner. Use caution when cleaning inside rear windows
equipped with electric defrosters. Do not use scrapers or
other sharp instruments which may scratch the elements.
When cleaning the rear view mirror, spray cleaner on the
towel or rag that you are using. Do not spray cleaner
directly on the mirror.
Cleaning Plastic Instrument Cluster Lenses
The lenses in front of the instruments in this vehicle are
molded in clear plastic. When cleaning the lenses, care
must be taken to avoid scratching the plastic.
1. Clean with a wet soft rag. A mild soap solution may be
used, but do not use high alcohol content or abrasive
cleaners. If soap is used, wipe clean with a clean damp
rag.
418 MAINTAINING YOUR VEHICLE

Cav-
ityCartridge
FuseMini Fuse Description
11 40 Amp
GreenHVAC Blower
12 30 Amp
PinkRear Wiper, Ign R/O
13 40 Amp
GreenRear Window De-
froster (EBL)/Heated
Mirror
14 30 Amp
PinkRear HVAC (If
Equipped)
15 Ð Spare
16 50 Amp
RedASD
17 30 Amp
PinkABS Pump
18 40 Amp
GreenAccessory Delay, SeatsCav-
ityCartridge
FuseMini Fuse Description
19 40 Amp
GreenJB Power
20 Ð Spare
21 20 Amp
YellowFuel Pump
22 20 Amp
YellowTCM, A/C Clutch
23 25 Amp
NaturalPower Inverter
24 20 Amp
YellowRear Heated Seats
25 20 Amp
YellowFinal Drive Control
Module (FDCM)
26 15 Amp
BlueBrake Lamps
MAINTAINING YOUR VEHICLE 423
7

ABS (Anti-Lock Brake System)............188,302
Adding Fuel........................... 341
Adding Washer Fluid..................... 177
Adjustable Pedals....................... 135
Air Cleaner, Engine (Engine Air Cleaner Filter) . . . 393
Air Conditioner Maintenance............... 397
Air Conditioning........................ 259
Air Conditioning, Operating Tips............ 269
Air Conditioning, Rear Zone................ 267
Air Conditioning Refrigerant............... 398
Air Conditioning System.................. 259
Air Filter.............................. 393
Air Pressure, Tires....................... 316
Airbag................................ 48
Airbag Deployment....................... 55
Airbag Light.......................57,71,188
Airbag Maintenance....................... 57
Alarm, Panic............................ 24
Alarm (Security Alarm).................20,189Alarm System (Security Alarm)............... 20
Alignment and Balance................... 321
Alterations/Modifications, Vehicle............. 9
Antenna, Satellite Radio................... 250
Antifreeze (Engine Coolant)................ 435
Disposal............................ 405
Anti-Lock Brake System (ABS)............139,302
Anti-Lock Warning Light.................. 188
Anti-Theft System.....................20,189
Appearance Care........................ 415
Assist, Hill Start........................ 148
Audio Systems (Radio).................... 239
Auto Down Power Windows................ 32
Automatic Dimming Mirror................. 78
Automatic Door Locks..................... 29
Automatic Headlights.................... 126
Automatic Temperature Control (ATC)......... 260
Automatic Transmission................283,411
Adding Fluid......................... 412
458 INDEX

Pressure Cap......................... 404
Radiator Cap......................... 404
Selection of Coolant (Antifreeze).........402,435
Courtesy Lights......................... 130
Crankcase Emission Control System.......... 395
Cruise Light........................... 193
Cup Holder............................ 172
Customer Assistance..................... 448
Data Recorder, Event...................... 58
Daytime Running Lights................... 128
Dealer Service.......................... 388
Defroster, Rear Window................... 177
Defroster, Windshield................71,258,265
Diagnostic System, Onboard................ 385
Digital Video Disc (DVD) Player............. 239
Dimmer Switch, Headlight................. 129
Dipsticks
Automatic Transmission................. 412Oil (Engine).......................... 389
Power Steering........................ 398
Disabled Vehicle Towing................... 378
Disposal
Antifreeze (Engine Coolant)............... 405
Engine Oil........................... 391
Used Engine Fluids..................... 391
Door Locks............................. 28
Door Locks, Automatic.................... 29
Door Opener, Garage..................... 159
Drive Belts............................ 392
Driving............................... 296
Off-Pavement......................... 296
Off-Road............................ 296
DVD Player (Video Entertainment System)...... 253
E-85 Fuel............................. 337
Electric Remote Mirrors.................... 80
Electrical Outlet, Auxiliary (Power Outlet)...... 169
INDEX 461
10

Instrument Panel and Controls.............. 185
Instrument Panel Lens Cleaning............. 418
Integrated Power Module (Fuses)............ 425
Interior Appearance Care.................. 417
Interior Fuses.......................... 419
Interior Lighting........................ 130
Interior Lights.......................127,130
Intermittent Wipers (Delay Wipers)........... 132
Introduction............................. 4
Inverter, Power......................... 170
Jack Location........................... 368
Jack Operation.......................368,371
Jacking Instructions...................... 371
Jump Starting.......................... 374
Key, Programming........................ 19
Key, Replacement........................ 18
Key, Sentry (Immobilizer)................... 17Key-In Reminder......................... 17
Keyless Entry System...................... 21
Keys................................. 14
Lap/Shoulder Belts....................... 39
LATCH (Lower Anchors and Tether for
CHildren)............................64,65
Lead Free Gasoline...................... 333
Leaks, Fluid............................ 72
Life of Tires............................ 320
Liftgate................................ 34
Liftgate Flipper Glass...................... 35
Liftgate Window Wiper/Washer............. 176
Lights..............................72,124
Airbag............................57,188
Alarm............................... 71
Anti-Lock........................... 188
Automatic Headlights................... 126
Back-Up............................. 432
466 INDEX

Overheating, Engine...................192,367
Owner's Manual (Operator Manual).......... 452
Paint Care............................. 415
Paint Damage.......................... 415
Panic Alarm............................ 24
Park Sense System, Rear................... 153
Parking Brake.......................... 300
Passing Light........................... 129
Pedals, Adjustable....................... 135
Personal Settings........................ 205
Pets.................................. 69
Pets, Transporting........................ 69
Phone, Cellular.......................... 82
Phone, Hands-Free (UConnectŸ)............. 82
Placard, Tire and Loading Information......... 311
Polishing and Waxing..................... 415
Port
Universal Serial Bus (USB)................ 239USB ................................ 239
Power
Distribution Center (Fuses)............... 422
Door Locks........................... 29
Inverter............................. 170
Lift Gate............................. 36
Mirrors.............................. 80
Outlet (Auxiliary Electrical Outlet).......... 169
Seats............................... 110
Steering..........................305,398
Sunroof............................. 165
Windows............................. 31
Pregnant Women and Seat Belts.............. 47
Preparation for Jacking.................... 370
Pretensioners
Seat Belts............................. 46
Programmable Electronic Features............ 205
Programming Transmitters (Remote Keyless
Entry)................................. 21
470 INDEX

Quadra-Trac.........................290,291
Radial Ply Tires......................... 318
Radio Broadcast Signals................... 210
Radio, Navigation....................... 242
Radio Operation......................240,256
Radio, Satellite.................239,240,243,249
Radio (Sound Systems).................... 239
Rain Sensitive Wiper System................ 133
Rear Air Conditioning.................... 267
Rear Axle (Differential).................... 410
Rear Camera........................... 157
Rear Cup Holder........................ 172
Rear Heater............................ 267
Rear Park Sense System................... 153
Rear Seat, Fold and Tumble................ 113
Rear Seat, Folding..................... 113,117
Rear Window Defroster................... 177
Rear Window Features.................... 176Rear Wiper/Washer...................... 176
Rearview Mirrors........................ 78
Reclining Front Seats..................... 108
Recorder, Event Data...................... 58
Recreational Towing...................... 359
Shifting into Transfer Case Neutral (N)....... 360
Shifting out of Transfer Case Neutral (N)..... 361
Reformulated Gasoline.................... 334
Refrigerant............................ 398
Reminder, Lights On..................... 128
Reminder, Seat Belt....................... 46
Remote Keyless Entry (RKE)................. 21
Remote Sound System (Radio) Controls........ 254
Remote Starting System.................... 26
Replacement Bulbs....................... 427
Replacement Keys........................ 18
Replacement Tires....................... 320
Reporting Safety Defects................... 451
Restraints, Child......................... 60
INDEX 471
10
