Page 76 of 408
▫Manual Lumbar— If Equipped............110
▫Driver’s Seat Back Recline...............111
▫Adjustable Head Restraints..............112
▫Heated Seats — If Equipped.............113
▫Fold Flat Front Passenger Seat............114
▫Folding Rear Seat.....................115
▫Reclining Rear Seat — If Equipped.........116
Lights...............................118
▫Map/Reading Lights...................118
▫Multi-Function Control Lever.............119
▫Headlights, Parking Lights, Instrument Panel
Lights.............................119
▫Daytime Running Lights (DRL) —
If Equipped.........................120▫Lights-On Reminder...................120
▫Fog Lights — If Equipped...............121
▫Turn Signals.........................121
▫Highbeam/Lowbeam Select Switch.........122
▫Passing Light........................123
To Open And Close The Hood.............123
Windshield Wipers And Washers...........125
▫Windshield Washers...................125
▫Mist Feature.........................126
▫Windshield Wiper Operation.............127
▫Intermittent Wiper System...............127
▫Adding Washer Fluid..................127
Tilt Steering Column....................128
76 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 125 of 408
WINDSHIELD WIPERS AND WASHERS
The wipers and washers are operated by a switch
on the control lever. The lever is located on the
right side of the steering column.
Windshield Washers
To use the washer, pull the control lever toward you and
hold while spray is desired. If the lever is pulled while in
the delay range, the wiper will operate in low speed for
two wipe cycles after the lever is released, and then
resume the intermittent interval previously selected.
If the lever is pulled while in the OFF position, the wipers
will operate for two wipe cycles, then turn OFF.
Washer Control
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 125
3
Page 126 of 408
Mist Feature
Push down on the wiper control lever to activate a single
wipe to clear the windshield of road mist or spray from
a passing vehicle. As long as the lever is held down, the
wipers will continue to operate.CAUTION!
In cold weather, always turn off the wiper switch
and allow the wipers to return to the park position
before turning off the engine. If the wiper switch is
left on and the wipers freeze to the windshield,
damage to the wiper motor may occur when the
vehicle is restarted.
Mist Control
126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 157 of 408
Fold Down Speakers – If Equipped
When the liftgate is open, the speakers can swing down
from the trim panel to face rearward, for tailgating and
other activities.
REAR WINDOW FEATURES
Rear Window Wiper/Washer
A switch on the right side of the steering column controls
operation of the rear wiper/washer function. Rotating
the center of the switch forward to the ON position will
activate the wiper. The rear wiper operates in an inter-
mittent mode only. Rotating the center of the switch all
the way forward will turn on the wash function. The
wash pump will continue to operate as long as the button
is pressed. Upon release, the wipers will cycle two times
before returning to the set position.
Fold Down Speakers
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 157
3
Page 182 of 408
when exiting the vehicle. Press and hold the EVIC button
when in this display until 0, 30, 60, or 90 appears to make
your selection.
Headlamps On With Wipers (Available with Auto
Headlights Only)
When ON is selected and the headlight switch is in the
AUTO position, the headlights will turn on approxi-
mately 10 seconds after the wipers are turned on. The
headlights will also turn off when the wipers are turned
off if they were turned on by this feature. Press and hold
the EVIC button when in this display until “ON” or
“OFF” appears to make your selection.
NOTE:Turning the headlights on during the daytime
causes the instrument panel lights to dim. To increase the
brightness, refer to “Lights” in this section.
Delay Power Off to Accessories Until Exit
When this feature is selected, the power window
switches, radio, hands–free system, power sunroof, andpower outlets will remain active for up to 60 minutes
after the ignition switch has been turned off. Opening a
vehicle door will cancel this feature. Press and hold the
EVIC button when in this display until “Off”, “45 sec.”,
“5 min.”, or “10 min.” appears to make your selection.
Turn Headlamps on with Remote Key Unlock
When this feature is selected the headlamps will activate
and remain on for up to 90 seconds when the doors are
unlocked using the remote keyless entry transmitter.
Press and hold the EVIC button when in this display until
“OFF”, “30 sec.”, “60 sec.”, or “90 sec.” appears to make
your selection.
Confirmation of Voice Commands — If Equipped
When ON is selected all voice commands from the
U-Connect system are confirmed. Press and hold the
EVIC button when in this display until “ON” or “OFF”
appears to make your selection.
182 UNDERSTANDING YOUR INSTRUMENT PANEL
Page 310 of 408
CAUTION!
Racing the engine or spinning the wheels too fast
may lead to transaxle overheating and failure. It can
also damage the tires. Do not spin the wheels above
30 mph (48 km/h). Do not spin the wheels continu-
ously for more than 30 seconds.
TOWING A DISABLED VEHICLE
With Ignition Key
Automatic And Manual Transaxle
Front-wheel-drive vehicles must have the front wheels
elevated; Four-wheel-drive vehicles must be hauled on a
flatbed truck.
All Transaxles
CAUTION!
If the vehicle being towed requires steering, the
ignition switch must be in the ACCESSORY posi-
tion, not in the LOCK position.
Do not attempt to use sling type equipment when
towing. When securing vehicle to flat bed truck, do
not attach to front or rear suspension components.
Damage to your vehicle may result from improper
towing.
If it is necessary to use the accessories while being towed
(wipers, defrosters, etc.), the key must be in the ON
position, not the ACCESSORY position. Make certain the
transaxle remains in NEUTRAL.
310 WHAT TO DO IN EMERGENCIES
Page 332 of 408
Windshield Wiper Blades
Clean the rubber edges of the wiper blades and the
windshield periodically with a sponge or soft cloth and a
mild non abrasive cleaner or use the washer solvent. This
will remove accumulations of salt, waxes or road film
and help reduce streaking and smearing.
Operation of the wipers on dry glass for long periods
may cause deterioration of the wiper blades. Always use
washer fluid when using the wipers to remove salt or dirt
from a dry windshield. Avoid using the wiper blades to
remove frost or ice from the windshield. make sure that
they are not frozen to the glass before turning them on to
avoid damaging the blade. Keep the blade rubber out of
contact with petroleum products such as engine oil,
gasoline, etc.
Windshield Wiper Blade Replacement
1. Lift the wiper arm away from the glass.2. Push the release tab shown in the illustration and slide
the wiper blade assembly down along the arm. Gently
place the wiper arm on the windshield.
3. Install the new blade assembly onto the wiper arm tip
until it locks in place.
Windshield Washer Reservoir
The washer fluid reservoir is located in the rear of the
engine compartment on the right side and should be
checked for fluid level at regular intervals. Fill the
reservoir with windshield washer solvent (not radiator
antifreeze).
Exhaust System
The best protection against carbon monoxide entry into
the vehicle body is a properly maintained engine exhaust
system.
If you notice a change in the sound of the exhaust system,
or if exhaust fumes can be detected inside the vehicle, or
332 MAINTAINING YOUR VEHICLE
Page 395 of 408
Selection of Coolant (Antifreeze)........... 334
Corrosion Protection..................... 345
Crankcase Emission Control System.......... 326
CruiseLight ........................... 171
CupHolder ............................ 152
Customer Assistance..................... 384
Data Recorder, Event...................... 62
Dealer Service.......................... 320
Defroster, Rear Window................... 159
Defroster, Windshield................... 74,222
Delay (Intermittent) Wipers................. 127
Diagnostic System, Onboard................ 317
Dimmer Switch, Headlight................. 122
Disposal
Antifreeze (Engine Coolant)............... 336
Engine Oil........................... 324
Door Locks............................. 18
Door Locks, Automatic.................... 20Door Opener, Garage..................... 132
Downshifting.......................... 242
DriveBelts ............................ 324
Driver’s Seat Back Tilt.................... 111
Driving
On Slippery Surfaces.................... 308
Electric Remote Mirrors.................... 81
Electrical Power Outlets................... 149
Electronic Speed Control (Cruise Control)...... 129
Electronic Stability Program (ESP)............ 142
Electronic Vehicle Information Center (EVIC).... 176
Emergency, In Case of
Jacking............................. 301
Jump Starting......................... 305
Towing ............................. 310
Emission Control System Maintenance......318,366
Engine............................... 316
Break-In Recommendations................ 72
INDEX 395
10
Page 398 of 408
Hands-Free Phone (UConnect™).............. 83
Hazard Warning Flasher................... 298
Head Restraints......................... 112
Headlights............................ 355
Cleaning............................ 348
High Beam........................122,167
High Beam/Low Beam Select Switch........ 122
Passing............................. 123
Replacing............................ 355
Switch .............................. 119
Heated Seats........................... 113
Hitches
TrailerTowing ........................ 287
HomeLink(Garage Door Opener) Transmitter . . . 132
Hood Release.......................... 123
Hoses................................ 338
Ignition............................... 12
Key ................................. 12Ignition Key Removal..................... 12
Immobilizer (Sentry Key)................. 14,31
Infant Restraint.......................... 64
Information Center, Vehicle................. 176
Inside Rearview Mirror.................... 79
Instrument Cluster....................... 166
Instrument Panel and Controls.............. 164
Instrument Panel Cover................... 349
Instrument Panel Lens Cleaning............. 349
Integrated Power Module (Fuses)............ 350
Interior Appearance Care.................. 347
Intermittent Wipers (Delay Wipers)........... 127
Introduction............................. 4
Jack Location........................... 301
Jack Operation.......................301,302
Jacking Instructions...................... 302
Jump Starting.......................... 305
398 INDEX
Page 408 of 408
Windows.............................. 34
Power............................... 34
Windshield Washers...................... 125
Windshield Wipers....................125,332Wiper Blade Replacement.................. 332
Wipers, Intermittent...................... 127
YES EssentialsFabric Cleaning Procedure...... 347
408 INDEX
