CavityCartridge Fuse Mini-FuseDescription
13 20 Amp YellowCigar Lighter
14 10 Amp RedInstrument Cluster
15 40 Amp Green Radiator Fan
16 15 Amp Lt BlueDome Lamp/Sunroof/Rear
Wiper Motor
17 10 Amp RedWireless Control Module
18 40 Amp Green Auto Shutdown Relay
19 20 Amp YellowRadio Amplifiers
20 15 Amp Lt BlueRadio
21 10 Amp RedIntrusion Module/Siren – If
Equipped
22 10 Amp RedHeating, AC/Compass
23 15 Amp Lt BlueAuto Shutdown Relay
24 15 Amp Lt Blue Power Sunroof – If Equipped
25 10 Amp RedHeated Mirror – If Equipped
7
MAINTAINING YOUR VEHICLE 521

CavityCartridge Fuse Mini-FuseDescription
26 15 Amp Lt BlueAuto Shutdown Relay
27 10 Amp RedAirbag Control Module
28 10 Amp RedAirbag Control Module/
Occupant Classification Mod- ule
29 Hot Car (No Fuse Required)
30 20 Amp YellowHeated Seat – If Equipped
31 10 Amp RedHeadlamp Washer – If
Equipped
32 30 Amp Pink Auto Shutdown Relay
33 10 Amp RedJ1962 Conn/Powertrain Con-
trol Module
34 30 Amp Pink Antilock BrakeValve
35 40 Amp Green Antilock Brake Pump
522 MAINTAINING YOUR VEHICLE

In Mexico Contact:
Av. Prolongacion Paseo de la Reforma, 1240
Sante Fe C.P. 05109
Mexico, D. F.
In Mexico City: 5081-7568
Outside Mexico City: 1-800-505-1300
Customer Assistance For The Hearing Or Speech
Impaired (TDD/TTY)
To assist customers who have hearing difficulties, the
manufacturer has installed special TDD (Telecommuni-
cation Devices for the Deaf) equipment at its customer
center. Any hearing or speech impaired customer, who
has access to a TDD or a conventional teletypewriter
(TTY) in the United States, can communicate with the
manufacturer by dialing 1–800–380–CHRY.Canadian residents with hearing difficulties that require
assistance can use the special needs relay service offered
by Bell Canada. For TTY teletypewriter users, dial 711
and for Voice callers, dial 1-800-855-0511 to connect with
a Bell Relay Service operator.
Service Contract
You may have purchased a service contract for a vehicle
to help protect you from the high cost of unexpected
repairs after the manufacturer’s New Vehicle Limited
Warranty expires. The manufacturer stands behind only
the manufacturer’s service contracts. If you purchased a
manufacturer’s service contract, you will receive Plan
Provisions and an Owner Identification Card in the mail
within three weeks of the vehicle delivery date. If you
have any questions about the service contract, call the
manufacturer’s Service Contract National Customer
Hotline at 1-800-521-9922 (Canadian residents, call (800)
465–2001 English / (800) 387–9983 French).
9
