Remote Start Abort Message On Electronic Vehicle
Information Center (EVIC) — If Equipped
The following messages will display in the EVIC if the
vehicle fails to remote start or exits remote start prema-
turely:
•Remote Start Aborted — Door Ajar
• Remote Start Aborted — Hood Ajar
• Remote Start Aborted — L/Gate Ajar
• Remote Start Aborted — Fuel Low
• Remote Start Aborted — System Fault
The EVIC message stays active until the ignition is turned
to the ON/RUN position.
To Enter Remote Start
Press and release the REMOTE START button
on the RKE transmitter twice within five sec-
onds. The vehicle doors will lock, the parking
lights will flash and the horn will chirp twice (if
programmed). Then, the engine will start and the vehicle
will remain in the Remote Start mode for a 15-minute
cycle.
NOTE:
• The park lamps will turn on and remain on during
Remote Start mode.
• For security, power window and power sunroof op-
eration (if equipped) are disabled when the vehicle is
in the Remote Start mode.
• If your power door locks were unlocked, Remote Start
will automatically lock the doors.
28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

WARNING!(Continued)
•Do not use accessory seat covers or place objects
between you and the SAB; the performance could
be adversely affected and/or objects could be
pushed into you, causing serious injury.
• Your vehicle is equipped with SABIC air bags, do
not have any accessory items installed which will
alter the roof, including adding a sunroof to your
vehicle. Do not add roof racks that require perma-
nent attachments (bolts or screws) for installation
on the vehicle roof. Do not drill into the roof of the
vehicle for any reason.
SAB and SABIC air bags are a supplement to the seat belt
restraint system. Occupants, including children who are
up against or very close to SAB or SABIC air bags can be
seriously injured or killed. Occupants, especially chil-
dren, should not lean on or sleep against the door, side windows, or area where the SAB or SABIC air bags
inflate, even if they are in an infant or child restraint.
Always sit upright as possible with your back against the
seat back, use the seat belts properly, and use the
appropriate sized child restraint, infant restraint or
booster seat recommended for the size and weight of the
child.
Knee Impact Bolsters
The Knee Impact Bolsters help protect the knees of the
driver and front passengers, and position front occupants
for the best interaction with the Advanced Front Air
Bags.
Along with seat belts and pretensioners, Advanced Front
Air Bags work with the knee impact bolsters to provide
improved protection for the driver and front passenger.
68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

WINDSHIELD WIPERS AND WASHERS ......172
▫ Windshield Wiper Operation .............173
▫ Intermittent Wiper System ...............174
▫ Windshield Washers ...................174
▫ Mist Feature ........................ .175
 TILT STEERING COLUMN ...............176
 ELECTRONIC SPEED CONTROL — IF
EQUIPPED .......................... .177
▫ To Activate ......................... .178
▫ To Set A Desired Speed .................178
▫ To Deactivate ....................... .179
▫ To Resume Speed .....................179
▫ To Vary The Speed Setting ...............179 ▫
To Accelerate For Passing ................180
 PARKVIEW® REAR BACK UP CAMERA — IF
EQUIPPED .......................... .181
 GARAGE DOOR OPENER — IF EQUIPPED . . .183
▫ Before You Begin Programming HomeLink® . .185
▫ Programming A Rolling Code .............185
▫ Programming A Non-Rolling Code .........187
▫ Canadian/Gate Operator Programming ......189
▫ Using HomeLink® ....................190
▫ Security ........................... .190
▫ Troubleshooting Tips ...................191
▫ General Information ....................192
 POWER SUNROOF — IF EQUIPPED ........193
▫ Opening Sunroof — Express ..............194
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 107

▫Opening Sunroof — Manual Mode .........194
▫ Closing Sunroof — Express ...............194
▫ Closing Sunroof — Manual Mode ..........194
▫ Pinch Protect Feature ...................194
▫ Venting Sunroof — Express ..............195
▫ Sunshade Operation ....................195
▫ Wind Buffeting ...................... .195
▫ Sunroof Maintenance ...................195
▫ Ignition Off Operation ..................195
 ELECTRICAL POWER OUTLETS ...........196
 POWER INVERTER — IF EQUIPPED .........199
 CUPHOLDERS ........................ .201
 STORAGE ........................... .202▫
Glove Compartment And Storage Bin .......202
▫ Door Storage ........................ .203
 CONSOLE FEATURES ...................204
 CARGO AREA FEATURES ................205
▫ Cargo Light/Removable Self-Recharging
Flashlight .......................... .205
▫ Cargo Cover ....................... .206
▫ Removable Load Floor .................208
▫ Cargo Tie-Down Loops .................209
▫ Fold Down Speakers — If Equipped ........210
 REAR WINDOW FEATURES ..............211
▫ Rear Window Wiper/Washer .............211
▫ Rear Window Defroster .................212
 ROOF LUGGAGE RACK — IF EQUIPPED . . . .213
108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

POWER SUNROOF — IF EQUIPPED
The power sunroof switch is located on the overhead
console.
WARNING!
•Never leave children alone in a vehicle, or with
access to an unlocked vehicle. Never leave the Key
Fob in or near the vehicle, or in a location acces-
sible to children. Occupants, particularly unat-
tended children, can become entrapped by the
power sunroof while operating the power sunroof
switch. Such entrapment may result in serious
injury or death.
• In a collision, there is a greater risk of being thrown
from a vehicle with an open sunroof. You could
also be seriously injured or killed. Always fasten
your seat belt properly and make sure all passen-
gers are properly secured.
• Do not allow small children to operate the sunroof.
Never allow your fingers, other body parts, or any
object to project through the sunroof opening.
Injury may result.
Power Sunroof Switch
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 193

Opening Sunroof — Express
Press the switch rearward and release it within one-half
second. The sunroof and sunshade will open automati-
cally from any position. The sunroof and sunshade will
open fully and stop automatically. This is called “Express
Open”. During Express Open operation, any movement
of the sunroof switch will stop the sunroof.
Opening Sunroof — Manual Mode
To open the sunroof, press and hold the switch rearward
to full open. Any release of the switch will stop the
movement. The sunroof and sunshade will remain in a
partially opened condition until the switch is pushed and
held rearward again.
Closing Sunroof — Express
Press the switch forward and release it within one-half
second and the sunroof will close automatically from anyposition. The sunroof will close fully and stop automati-
cally. This is called “Express Close”. During Express
Close operation, any movement of the switch will stop
the sunroof.
Closing Sunroof — Manual Mode
To close the sunroof, press and hold the switch in the
forward position. Any release of the switch will stop the
movement and the sunroof will remain in a partially
closed condition until the switch is pushed and held
forward again.
Pinch Protect Feature
This feature will detect an obstruction in the opening of
the sunroof during Express Close operation. If an ob-
struction in the path of the sunroof is detected, the
sunroof will automatically retract. Remove the obstruc-
tion if this occurs. Next, press the switch forward and
release to Express Close.
194 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Venting Sunroof — Express
Press and release the Vent button within one half second
and the sunroof will open to the vent position. This is
called “Express Vent”, and it will occur regardless of
sunroof position. During Express Vent operation, any
movement of the switch will stop the sunroof.
Sunshade Operation
The sunshade can be opened manually. However, the
sunshade will open automatically as the sunroof opens.
NOTE:The sunshade cannot be closed if the sunroof is
open.
Wind Buffeting
Wind buffeting can be described as the perception of
pressure on the ears or a helicopter-type sound in the
ears. Your vehicle may exhibit wind buffeting with the
windows down, or the sunroof (if equipped) in certain open or partially open positions. This is a normal occur-
rence and can be minimized. If the buffeting occurs with
the rear windows open, open the front and rear windows
together to minimize the buffeting. If the buffeting occurs
with the sunroof open, adjust the sunroof opening to
minimize the buffeting or open any window.
Sunroof Maintenance
Use only a non-abrasive cleaner and a soft cloth to clean
the glass panel.
Ignition Off Operation
For Vehicles Not Equipped With The Electronic Vehicle
Information Center (EVIC)
The power sunroof switch will remain active for 45
seconds after the ignition switch is turned to the LOCK
position. Opening either front door will cancel this
feature.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 195

For Vehicles Equipped With The EVIC
The power sunroof switch will remain active for up to
approximately ten minutes after the ignition switch is
turned to the LOCK position. Opening either front door
will cancel this feature.
ELECTRICAL POWER OUTLETS
There is a standard 12 Volt (13 Amp) power outlet located
in the Integrated Center Stack (ICS) for added conve-
nience. This power outlet can power mobile phones,
electronics and other low power devices.Power is available when the ignition switch is in the ON
or ACC position. Insert the cigar lighter or accessory plug
into the outlet for use.To preserve the heating element,
do not hold the lighter in the heating position.
12 Volt Power Outlet
196 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

when exiting the vehicle. Press and hold the SELECT
button when in this display until 0, 30, 60, or 90 appears
to make your selection.
Key Off Power Delay
When this feature is selected the power window
switches, radio, Uconnect® phone, power sunroof, and
power outlets will remain active for up to 10 minutes
after the ignition switch has been turned OFF. Opening
either front vehicle door will cancel this feature. Press
and hold the SELECT button when in this display until
“OFF”, “45 sec.”, “5 min.”, or “10 min.” appears to make
your selection.
Illuminated Approach
When this feature is selected the headlights will activate
and remain on for up to 90 seconds when the doors are
unlocked using the RKE transmitter. Press and hold theSELECT button when in this display until “OFF”, “30
sec.”, “60 sec.”, or “90 sec.” appears to make your
selection.
Hill Start Assist (HSA) — If Equipped
When on is selected, the HSA system is active. Refer to
“Electronic Brake Control System” in “Starting And
Operating” for system function and operating informa-
tion. To make your selection, press and release the
SELECT button until “On” or “Off” appears.
Display Units In
The EVIC, odometer, and Uconnect® gps system units
can be changed between English and Metric.
Press and hold the SELECT button when in this display
until “ENGLISH” or “METRIC” appears to make your
selection.
246 UNDERSTANDING YOUR INSTRUMENT PANEL

CavityCartridge Fuse Mini-FuseDescription
13 20 Amp YellowCigar Lighter
14 10 Amp RedInstrument Cluster
15 40 Amp Green Radiator Fan
16 15 Amp Lt BlueDome Lamp/Sunroof/Rear
Wiper Motor
17 10 Amp RedWireless Control Module
18 40 Amp Green Auto Shutdown Relay
19 20 Amp YellowRadio Amplifiers
20 15 Amp Lt BlueRadio
21 10 Amp RedIntrusion Module/Siren – If
Equipped
22 10 Amp RedHeating, AC/Compass
23 15 Amp Lt BlueAuto Shutdown Relay
24 15 Amp Lt Blue Power Sunroof – If Equipped
25 10 Amp RedHeated Mirror – If Equipped
7
MAINTAINING YOUR VEHICLE 521
