Cavity Cartridge FuseMini-FuseDescription
1840 Amp GreenAuto Shutdown Relay
1920 Amp YellowRadio Amplifiers
2015 Amp Lt BlueRadio
2110 Amp RedIntrusion Module/Siren – If Equipped
2210 Amp RedHeating, AC/Compass
2315 Amp Lt BlueAuto Shutdown Relay
2415 Amp Lt BluePower Sunroof – If Equipped
2510 Amp RedHeated Mirror – If Equipped
2615 Amp Lt BlueAuto Shutdown Relay
2710 Amp RedAirbag Control Module
2810 Amp RedAirbag Control Module/Occupant
Classification Module
29Hot Car (No Fuse Required)
3020 Amp YellowHeated Seat – If Equipped
3110 Amp RedHeadlamp Washer – If Equipped
7
MAINTAINING YOUR VEHICLE 509

Cavity Cartridge FuseMini-FuseDescription
3230 Amp PinkAuto Shutdown Relay
3310 Amp Red J1962 Conn/Powertrain Control Module
3430 Amp PinkAntilock BrakeValve
3540 Amp GreenAntilock Brake Pump
3630 Amp PinkHeadlamp/Washer Control/Smart Glass –
If Equipped
CAUTION!
•When installing the IPM cover, it is important to
ensure the cover is properly positioned and fully
latched. Failure to do so may allow water to get into
the IPM, and possibly result in an electrical system
failure.
(Continued)
CAUTION!(Continued)
•When replacing a blown fuse, it is important to
use only a fuse having the correct amperage rating.
The use of a fuse with a rating other than indicated
may result in a dangerous electrical system overload.
If a properly rated fuse continues to blow, it indicates
a problem in the circuit that must be corrected.
