air condition JEEP COMPASS 2016 1.G Owner's Guide

If an examination of your engine compartment shows no
evidence of radiator or hose leaks, the vehicle may be
safely driven. The vapor will soon dissipate.
•Do not overfill the coolant expansion bottle.
• Check the coolant freeze point in the radiator and in
the coolant expansion bottle. If engine coolant (anti-
freeze) needs to be added, the contents of the coolant
expansion bottle must also be protected against freez-
ing.
• If frequent engine coolant (antifreeze) additions are
required, the cooling system should be pressure tested
for leaks.
• Maintain engine coolant (antifreeze) concentration at a
minimum of 50% OAT coolant (conforming to
MS.90032) and distilled water for proper corrosion
protection of your engine which contains aluminum
components. •
Make sure that the coolant expansion bottle overflow
hoses are not kinked or obstructed.
• Keep the front of the radiator clean. If your vehicle is
equipped with air conditioning, keep the front of the
condenser clean.
• Do not change the thermostat for Summer or Winter
operation. If replacement is ever necessary, install
ONLY the correct type thermostat. Other designs may
result in unsatisfactory engine coolant (antifreeze)
performance, poor gas mileage, and increased emis-
sions.
Brake System
In order to assure brake system performance, all brake
system components should be inspected periodically.
Refer to the “Maintenance Schedule” for the proper
maintenance intervals.
514 MAINTAINING YOUR VEHICLE

Power Transfer Unit (PTU) — AWD/4WD Models
Only
Lubricant Selection
Use only the manufacturer’s recommended fluid. Refer
to “Fluids, Lubricants, And Genuine Parts” in “Maintain-
ing Your Vehicle” for further information.
Fluid Level Check
Visually inspect the unit at each oil change for leakage. If
leakage is detected, Check the fluid level by removing the
fill plug. The fluid level should be maintained between
the bottom of the fill hole to 1/8 inch (4 mm) below the
fill hole.
Add fluid, if necessary, to maintain the proper level.
Frequency Of Fluid Change
Refer to the “Maintenance Schedule” for the proper
maintenance intervals.
Appearance Care And Protection From Corrosion
Protection Of Body And Paint From Corrosion
Vehicle body care requirements vary according to geo-
graphic locations and usage. Chemicals that make roads
passable in snow and ice and those that are sprayed on
trees and road surfaces during other seasons are highly
corrosive to the metal in your vehicle. Outside parking,
which exposes your vehicle to airborne contaminants,
road surfaces on which the vehicle is operated, extreme
hot or cold weather and other extreme conditions will
have an adverse effect on paint, metal trim, and under-
body protection.
The following maintenance recommendations will enable
you to obtain maximum benefit from the corrosion
resistance built into your vehicle.
522 MAINTAINING YOUR VEHICLE

Interior Care
Use MOPAR Total Clean to clean fabric upholstery and
carpeting.
Use MOPAR Total Clean to clean vinyl upholstery.
MOPAR Total Clean is specifically recommended for
leather upholstery.
Your leather upholstery can be best preserved by regular
cleaning with a damp soft cloth. Small particles of dirt
can act as an abrasive and damage the leather upholstery
and should be removed promptly with a damp cloth.
Stubborn soils can be removed easily with a soft cloth
and MOPAR Total Clean. Care should be taken to avoid
soaking your leather upholstery with any liquid. Please
do not use polishes, oils, cleaning fluids, solvents, deter-
gents, or ammonia-based cleaners to clean your leather
upholstery. Application of a leather conditioner is not
required to maintain the original condition.
WARNING!
Do not use volatile solvents for cleaning purposes.
Many are potentially flammable, and if used in
closed areas they may cause respiratory harm.
CAUTION!
Direct contact of air fresheners, insect repellents,
suntan lotions, or hand sanitizers to the plastic,
painted, or decorated surfaces of the interior may
cause permanent damage. Wipe away immediately.
CAUTION!
Damage caused by these type of products may not be
covered by your New Vehicle Limited Warranty.
526 MAINTAINING YOUR VEHICLE

VEHICLE STORAGE
If you will not be using your vehicle for more than 21
days, you may want to take steps to preserve your
battery.
•Disengage the mini-fuse in the Power Distribution
Center labeled IOD (Ignition Off-Draw).
• Or disconnect the negative cable from the battery. •
Anytime you store your vehicle, or keep it out of
service (i.e., vacation) for two weeks or more, run the
air conditioning system at idle for about five minutes
in the fresh air and high blower setting. This will
ensure adequate system lubrication to minimize the
possibility of compressor damage when the system is
started again.
REPLACEMENT BULBS
Interior Bulbs
Bulb Number
Front Header Lamp T578
Center Dome Lamp T578
Rear Cargo Lamp/Flashlight 8–A35LFAA
7
MAINTAINING YOUR VEHICLE 535

Required Maintenance Intervals.
Refer to the maintenance schedules on the following
page for the required maintenance intervals.At Every Oil Change Interval As Indicated By OilChange Indicator System:
•Change oil and filter.
• Rotate the tires. Rotate at the first sign of irregu-
lar wear, even if it occurs before the oil indicator
system turns on.
• Inspect battery and clean and tighten terminals as
required.
• Inspect brake pads, shoes, rotors, drums, hoses
and park brake.
• Inspect engine cooling system protection and
hoses.
• Inspect exhaust system.
• Inspect engine air cleaner if using in dusty or
off-road conditions.
546 MAINTENANCE SCHEDULES

Mileage or time passed (whichever comes first)
20,000
30,000
40,000
50,000
60,000
70,000
80,000
90,000
100,000
110,000
120,000
130,000
140,000
150,000
Or Years: 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Or Kilometers:
32,000
48,000
64,000
80,000
96,000
112,000
128,000
144,000
160,000
176,000
192,000
208,000
224,000
240,000
Additional Maintenance
Replace engine air cleaner filter. XX X X X
Replace air conditioning/cabin air filter. X X X X X X X
Replace spark plugs** XX X X X
Flush and replace the engine coolant at 10 years
or 150,000 miles (240,000 km) whichever comes
first. XX
Replace rear drive assembly (RDA) fluid. XX
Replace power transfer unit (PTU) fluid. XX
Change automatic transmission fluid and filter if
using your vehicle for any of the following: police,
taxi, fleet, or frequent trailer towing. (CVT only) XX
548 MAINTENANCE SCHEDULES

Adding Engine Coolant (Antifreeze)............511
Adding Fuel ............................ .430
Adding Washer Fluid ..................... .505
Additives, Fuel .......................... .428
Adjust Down .............................. .151
Forward ............................. .151
Rearward ............................ .151
Up ................................ .151
AirBag.................................61 Advance Front Air Bag ....................63
Air Bag Operation .......................64
Air Bag Warning Light ....................72
Enhanced Accident Response ................71
Event Data Recorder (EDR) .................74
FrontAirBag...........................61
If A Deployment Occurs ...................70
Knee Impact Bolsters .....................65
Maintaining Your Air Bag System ............73Side Air Bags
...........................65
Transporting Pets ........................96
Air Bag Deployment ........................61
Air Bag Light ...................... .72, 99, 225
Air Bag Maintenance .......................73
Air Cleaner, Engine (Engine Air Cleaner Filter) . . . .500
Air Conditioner Maintenance .................502
Air Conditioning ......................... .318
Air Conditioning Controls ...................318
Air Conditioning Filter ..................330, 503
Air Conditioning, Operating Tips ...........329, 331
Air Conditioning Refrigerant ..............502, 503
Air Conditioning System .............318, 323, 502
Air Pressure, Tires ........................ .403
Alarm (Security Alarm) .....................228
Alarm System (Security Alarm) ................18
Alterations/Modifications, Vehicle ...............8
Antenna, Satellite Radio .................278, 305
Antifreeze (Engine Coolant) ...............510, 538
566 INDEX

Emergency, In Case OfJacking .............................. .456
Jump Starting ......................... .477
Towing ............................. .484
Emission Control System Maintenance ..........494
Engine ............................. .491, 492
Air Cleaner .......................... .500
Block Heater ......................... .340
Break-In Recommendations .................96
Checking Oil Level ..................... .497
Coolant (Antifreeze) ..................509, 539
Cooling ............................. .509
Exhaust Gas Caution ..................98, 430
Fuel Requirements ..................... .426
Jump Starting ......................... .477
Oil .......................... .497, 538, 539
Oil Filler Cap ...................491, 492, 499
Oil Filter ............................ .500
Oil Selection .......................... .498Oil Synthetic
......................... .499
Overheating .......................... .453
Enhanced Accident Response Feature ............71
Ethanol ............................... .427
Event Data Recorder ........................74
Exhaust Gas Caution ....................98, 430
Exhaust System ....................... .98, 506
Exterior Lights .......................... .101
Filters Air Cleaner .......................... .500
Air Conditioning ....................330, 503
Engine Oil ........................ .500, 539
Engine Oil Disposal .....................500
Flashers Hazard Warning ....................... .453
Turn Signal .....................101, 244, 537
Flooded Engine Starting ....................339
Fluid, Brake ............................ .541
10
INDEX 571
