JEEP COMPASS LATITUDE 2018 Owners Manual

5. Raise the vehicle just enough to remove the flat tire.

7. Remove the alignment pin from the jack assembly andthread the pin into the wheel hub to assist in mounting
the spare tire.
8. Mount the spare tire.

Specifications” for the proper lug bolt torque. If in
doubt about the correct tightness, have them checked
with a torque wrench by your authorized dealer or at a
service station.
12. Place the jack on the foam tray and open it far enough so that it is secured. Once placed in position, rotate it
clockwise to lock it in. Replace the alignment pin in the
center hole to lock the jack in place.

7
IN CASE OF EMERGENCY 333

WARNING!
•Do not attempt to seal a tire on the side of the vehicle
closest to traffic. Pull far enough off the road to avoid
the danger of being hit when using the Tire Service Kit.
•Do not use Tire Service Kit or drive the vehicle under
the following circumstances:
– If the puncture in the tire tread is approximately 1/4 inch (6 mm) or larger.
– If the tire has any sidewall damage.
– If the tire has any damage from driving with extremely low tire pressure.
–
If the tire has any damage from driving on a flat tire.
– If the wheel has any damage.
– If you are unsure of the condition of the tire or the wheel.
• Keep Tire Service Kit away from open flames or heat
source.
• A loose Tire Service Kit thrown forward in a collision
or hard stop could endanger the occupants of the
(Continued)

7
IN CASE OF EMERGENCY 337
