sensor JEEP GRAND CHEROKEE 2002 WJ / 2.G Workshop Manual

BODY CONTROL MODULE C1 - GRAY 26 WAY
CAV CIRCUIT FUNCTION
1 Z132 20BK/OR GROUND
2 G52 20YL HEADLAMP SWITCH MUX
3 E19 20RD PANEL LAMPS DIMMER SIGNAL
4- -
5 G70 20BR/TN (BUILT-UP-EXPORT LHD
RHD)HOOD AJAR SWITCH SENSE
6 G26 20LB KEY-IN IGNITION SWITCH SENSE
7 G76 18TN/YL RIGHT REAR DOOR AJAR SWITCH SENSE
8 E2 20OR PANEL LAMPS DRIVER
9 E2 20OR PANEL LAMPS DRIVER
10 E2 20OR PANEL LAMPS DRIVER
11 - -
12 E2 20OR PANEL LAMPS DRIVER
13 E2 20OR PANEL LAMPS DRIVER
14 Z132 20BK/OR GROUND
15 D25 20YL/VT/WT PCI BUS
16 L80 20WT/DG HEADLAMP SWITCH RETURN
17 D19 20VT/OR BODY CONTROL MODULE FLASH ENABLE
18 - -
19 - -
20 G69 20BK/OR VTSS INDICATOR DRIVER
21 - -
22 V14 20RD/VT WIPER ON/OFF RELAY CONTROL
23 M20 20BR/OR COURTESY LAMP LOAD SHED
24 M2 20YL COURTESY LAMP DRIVER
25 Z234 20BK GROUND
26 - -
BODY CONTROL MODULE C2 - GRAY 22 WAY
CAV CIRCUIT FUNCTION
1 C103 20DG A/C SWITCH SIGNAL
2 V10 20BR WASHER PUMP SWITCH SENSE
3 V48 20RD/GY WIPER HIGH CONTROL
4 L40 20BR HIGH BEAM SWITCH SENSE
5 V11 20BK/TN WASHER FLUID SWITCH SENSE
6 P134 20TN/LG PASSENGER SEAT HEATER SWITCH MUX
7 P133 20TN/DG DRIVER SEAT HEATER SWITCH MUX
8 X20 20RD/YL RADIO CONTROL MUX
9 G31 20VT/LG AMBIENT TEMPERATURE SENSOR SIGNAL
10 L109 20WT ULTRALIGHT SENSOR SIGNAL
11 V52 20DG/RD WINDSHIELD WIPER SWITCH MUX
12 C81 20LB/WT REAR WINDOW DEFOGGER SWITCH SENSE
13 - -
14 - -
15 L27 20WT/TN FOG LAMP SWITCH SENSE
16 C201 20LB/YL EVAPORATOR TEMPERATURE SENSOR SIGNAL
17 G18 20PK/BK COOLANT LEVEL SWITCH SENSE
18 P132 20OR/BK SEAT HEATER SWITCH SENSOR GROUND
19 X10 20RD/BK RADIO CONTROL MUX RETURN
20 G32 20BK/LB SENSOR GROUND
21 L110 20BK/YL ULTRALIGHT SENSOR RETURN
22 V9 20WT/BK WINDSHIELD WIPER SWITCH RETURN
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 11

BOOST PRESSURE SENSOR (DIESEL) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K4 20BK/LB SENSOR GROUND
2 Y53 20BK/YL BOOST PRESSURE SENSOR SIGNAL
3 K6 20VT/WT SENSOR REFERENCE VOLTAGE B
BRAKE LAMP SWITCH - GRAY 6 WAY
CAV CIRCUIT FUNCTION
1 K29 18WT/PK SECONDARY BRAKE SWITCH SIGNAL
2 Z238 18BK (LHD) GROUND
2 Z243 18BK (RHD) GROUND
3 V32 22OR/DG (GAS) SPEED CONTROL POWER SUPPLY
4 V30 22DB/RD (GAS) SPEED CONTROL BRAKE SWITCH OUTPUT
5 L50 20VT/TN (LHD) PRIMARY BRAKE SWITCH SIGNAL
5 L50 20WT/TN (RHD) PRIMARY BRAKE SWITCH SIGNAL
6 F32 20PK/DB FUSED B(+)
C100 - BLACK (RIGHT HEADLAMP AND DASH
SIDE)
CAV CIRCUIT
1 T40 12LG
2 K125 18WT/DB
3 K20 18DG
C100 - BLACK (BATTERY SIDE)
CAV CIRCUIT
1 T40 12LG
2 K125 18WT/DB
3 K20 18DG
C101 (4.0L RHD) - LT. GRAY (ENGINE SIDE)
CAV CIRCUIT
1 B22 18DG/YL
2 K99 18BR/OR
3 K299 18BR/WT
4 K6 18VT/BK
5 C18 18DB
6-
8W - 80 - 12 8W-80 CONNECTOR PIN-OUTWJ

C318 - (OVERLAY SIDE)
CAV CIRCUIT
1 R72 20LB/WT (RHD)
1 R73 20LB/BR (LHD)
2 R74 20LB/YL (RHD)
2 R75 20LB/OR (LHD)
C319 - (RIGHT BODY SIDE (LHD)/ LEFT BODY
SIDE (RHD))
CAV CIRCUIT
1 R72 20LB/WT (LHD)
2 R74 20LB/YL (LHD)
C319 - (OVERLAY SIDE)
CAV CIRCUIT
1 R73 20LB/BR (RHD)
1 R72 20LB/WT (LHD)
2 R75 20LB/OR (RHD)
2 R74 20LB/YL (LHD)
CAMSHAFT POSITION SENSOR (DIESEL) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K944 20BR/DG CAMSHAFT POSITION SENSOR GROUND
2 K44 20YL/GY CAMSHAFT POSITION SENSOR SIGNAL
3 F15 18RD/DG FUSED AUTO SHUT DOWN RELAY OUTPUT
CAMSHAFT POSITION SENSOR (GAS) - GRAY 3 WAY
CAV CIRCUIT FUNCTION
1 K44 18TN/YL CAMSHAFT POSITION SENSOR SIGNAL
2 K4 18BK/LB SENSOR GROUND
3 K7 18OR 5 VOLT SUPPLY
CAPACITOR (4.0L) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 A142 16DG/OR (RHD) AUTO SHUT DOWN RELAY OUTPUT
1 A142 14DG/OR (LHD) AUTO SHUT DOWN RELAY OUTPUT
2- -
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 59

CLOCKSPRING C1 - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 X3 20GY/OR HORN RELAY CONTROL
2 V37 20RD/LG SPEED CONTROL SWITCH SIGNAL
3 K4 20BK/LB SENSOR GROUND
4- -
CLOCKSPRING C2-4WAY
CAV CIRCUIT FUNCTION
1 R63 20TN/LB DRIVER SQUIB 2 LINE 2
2 R61 20OR/LB DRIVER SQUIB 2 LINE 1
3 R43 20BK/LB DRIVER SQUIB 1 LINE 1
4 R45 20DG/LB DRIVER SQUIB 1 LINE 2
CLOCKSPRING C3 - GRAY 6 WAY
CAV CIRCUIT FUNCTION
1 X20 20RD/YL RADIO CONTROL MUX
2 X10 20RD/BK RADIO CONTROL MUX RETURN
3 X3 20GY/OR HORN RELAY CONTROL
4 V37 20RD/LG SPEED CONTROL SWITCH SIGNAL
5 K4 20BK/LB SENSOR GROUND
6- -
CLOCKSPRING C4 - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 X20 20RD/YL RADIO CONTROL MUX
2 X10 20RD/BK RADIO CONTROL MUX RETURN
COIL ON PLUG NO. 1 (4.7L) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K91 14TN/RD COIL DRIVER NO. 1
2 A142 14DG/OR AUTO SHUT DOWN RELAY OUTPUT
3- -
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 61

CONTROLLER ANTILOCK BRAKE - BLACK 24 WAY
CAV CIRCUIT FUNCTION
1 Z101 12BK/OR GROUND
2 B1 18YL/DB RIGHT REAR WHEEL SPEED SENSOR SIGNAL
3 B2 18YL RIGHT REAR WHEEL SPEED SENSOR 12 VOLT
SUPPLY
4- -
5 D25 18VT/YL PCI BUS
6 B6 18WT/DB RIGHT FRONT WHEEL SPEED SENSOR SIGNAL
7 B7 18WT RIGHT FRONT WHEEL SPEED SENSOR 12 VOLT
SUPPLY
8- -
9 A20 12RD/DB FUSED B(+)
10 F20 18DB/PK FUSED IGNITION SWITCH OUTPUT (RUN)
11 D52 18LG/WT (DIESEL) CAN C BUS(+)
12 - -
13 B22 18DG/YL VEHICLE SPEED SENSOR SIGNAL
14 D51 18DG/WT (DIESEL) CAN C BUS(-)
15 - -
16 Z102 12BK/OR GROUND
17 G9 18GY/BK BRAKE FLUID LEVEL SWITCH SENSE
18 L50 18WT/TN PRIMARY BRAKE SWITCH SIGNAL
19 B3 18LG/DB LEFT REAR WHEEL SPEED SENSOR SIGNAL
20 B4 18LG LEFT REAR WHEEL SPEED SENSOR 12 VOLT SUPPLY
21 Z231 18BK GROUND
22 B8 18RD/DB LEFT FRONT WHEEL SPEED SENSOR SIGNAL
23 B9 18RD LEFT FRONT WHEEL SPEED SENSOR 12 VOLT
SUPPLY
24 A10 12RD/DG FUSED B(+)
COOLANT LEVEL SENSOR - LT. GRAY 2 WAY
CAV CIRCUIT FUNCTION
1 G18 20PK/BK (EXCEPT LHD GAS) COOLANT LEVEL SWITCH SENSE
1 G18 18PK/BK (LHD GAS) COOLANT LEVEL SWITCH SENSE
2 Z307 20BK GROUND
CRANKCASE HEATER (DIESEL) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 Z18 20BR GROUND
2 F15 20RD/DG FUSED AUTO SHUT DOWN RELAY OUTPUT
8W - 80 - 64 8W-80 CONNECTOR PIN-OUTWJ

CRANKSHAFT POSITION SENSOR (DIESEL) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K924 20YL CRANKSHAFT POSITION SENSOR SIGNAL 2
2 K3 20BK CRANKSHAFT POSITION SENSOR SIGNAL 1
CRANKSHAFT POSITION SENSOR (GAS) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K24 18GY/BK CRANKSHAFT POSITION SENSOR SIGNAL
2 K4 18BK/LB SENSOR GROUND
3 K7 18OR 5 VOLT SUPPLY
DATA LINK CONNECTOR - BLACK 16 WAY
CAV CIRCUIT FUNCTION
1- -
2 D25 20YL/VT PCI BUS
3- -
4 Z305 20BK/OR GROUND
5 Z306 20BK/LG GROUND
6 D32 20LG/DG SCI RECEIVE
7 D21 20PK SCI TRANSMIT
8- -
9 D19 20VT/OR BODY CONTROL MODULE FLASH ENABLE
10 - -
11 - -
12 - -
13 - -
14 D20 20LG SCI RECEIVE
15 - -
16 F33 20PK/RD FUSED B(+)
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 65

DIAGNOSTIC JUNCTION PORT - BLACK 16 WAY
CAV CIRCUIT FUNCTION
1 D25 20YL/VT/BR PCI BUS (PCM/ECM TCM PDM CD SKIM)
2 D25 20YL/VT/DG (AZC) PCI BUS (AZC)
3 D25 20YL/VT/DB PCI BUS (RADIO)
4 D25 20YL/VT/OR PCI BUS (ACM)
5 D25 20YL/VT/RD PCI BUS (MIC)
6 D25 20YL/VT/WT PCI BUS (BCM)
7 D25 20YL/VT PCI BUS (DLC)
8 D25 20YL/VT/GY PCI BUS (DDM ABS MEM EVIC APM ITM RAIN
SENSOR)
9- -
10 - -
11 D25 20YL/VT (DIESEL) PCI BUS (SHIFTER ASSEMBLY)
12 - -
13 - -
14 - -
15 - -
16 - -
DRIVER AIRBAG SQUIB 1 - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 R43 20BK DRIVER SQUIB 1 LINE 1
2 R45 20BK DRIVER SQUIB 1 LINE 2
DRIVER AIRBAG SQUIB 2 - GREEN 2 WAY
CAV CIRCUIT FUNCTION
1 R63 20TN/LB DRIVER SQUIB 2 LINE 2
2 R61 20OR/LB DRIVER SQUIB 2 LINE 1
8W - 80 - 66 8W-80 CONNECTOR PIN-OUTWJ

DRIVER DOOR LOCK MOTOR/AJAR SWITCH - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 G75 18TN/RD DRIVER DOOR AJAR SWITCH SENSE
2 Z243 12BK (RHD) GROUND
2 Z28 12BK (LHD) GROUND
3 P34 18PK/BK DRIVER DOOR UNLOCK DRIVER
4 P35 18OR/BK DRIVER DOOR LOCK DRIVER
DRIVER DOOR MODULE C1 - WHITE 15 WAY
CAV CIRCUIT FUNCTION
1 A146 12OR/WT FUSED B(+)
2 Q23 16RD/WT DRIVER REAR WINDOW DRIVER (DOWN)
3 Q13 16DB DRIVER REAR WINDOW DRIVER (UP)
4 Z28 12BK (LHD) GROUND
4 Z234 12BK (RHD) GROUND
5 P35 18OR/BK DRIVER DOOR LOCK DRIVER
6- -
7 P34 18PK/BK DRIVER DOOR UNLOCK DRIVER
8 D30 20VT/YL (JAPAN) DIAGNOSTIC OUT
9 D25 20YL/VT PCI BUS
10 G73 20LG/OR DRIVER CYLINDER LOCK SWITCH SENSE
11 G75 18TN/RD DRIVER DOOR AJAR SWITCH SENSE
12 E21 20OR/RD DRIVER REAR DOOR SWITCH ILLUMINATION
13 Q11 16LB DRIVER WINDOW DRIVER (UP)
14 - -
15 Q21 16WT DRIVER WINDOW DRIVER (DOWN)
DRIVER DOOR MODULE C2 - BLACK 12 WAY
CAV CIRCUIT FUNCTION
1 P95 20OR MIRROR HORIZONTAL DRIVER
2 C118 20BK/WT MIRROR HEATER GROUND
3 P64 20VT MIRROR VERTICAL POSITION SIGNAL
4 P69 20GY MIRROR SENSOR GROUND
5 P65 20DG MIRROR HORIZONTAL POSITION SIGNAL
6 C117 20BK MIRROR HEATER 12 VOLT SUPPLY
7 P91 20WT MIRROR COMMON DRIVER
8 P93 20RD MIRROR VERTICAL DRIVER
9 M21 20PK/DG COURTESY LAMP DRIVER
10 P110 20YL (BUILT-UP-EXPORT) FOLDING MIRROR RETURN
11 P99 20DB (BUILT-UP-EXPORT) FOLDING MIRROR FEED
12 L121 20BK/RD COURTESY LAMP GROUND
8W - 80 - 68 8W-80 CONNECTOR PIN-OUTWJ

DRIVER DOOR MODULE C3 - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 BK MEMORY SWITCH RETURN
2 BR MEMORY SWITCH MUX
3 OR MEMORY SET INDICATOR DRIVER
4 GY SWITCH ILLUMINATION DRIVER
DRIVER FRONT DOOR COURTESY LAMP - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 M21 20PK/DG COURTESY LAMP DRIVER
2 L121 20BK/RD COURTESY LAMP GROUND
DRIVER FRONT POWER WINDOW MOTOR - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 Q21 16WT DRIVER WINDOW DRIVER (DOWN)
2 Q11 16LB DRIVER WINDOW DRIVER (UP)
DRIVER HEATED SEAT BACK (PREMIUM I/III)-3WAY
CAV CIRCUIT FUNCTION
1 P88 16BK/BR HEATED SEAT DRIVER
2 Z6 16BK/YL GROUND
3- -
DRIVER HEATED SEAT CUSHION (PREMIUM I/III)-4WAY
CAV CIRCUIT FUNCTION
1 P131 16BK/OR DRIVER SEAT HEATER B(+) DRIVER
2 P88 16BK/BR HEATED SEAT DRIVER
3 P135 20LB/BK DRIVER SEAT TEMPERATURE SENSOR INPUT
4 P29 20BR/WT SEAT SENSOR 5 VOLT SUPPLY
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 69

DRIVER HEATED SEAT SWITCH - WHITE 6 WAY
CAV CIRCUIT FUNCTION
1 P133 20TN/DG DRIVER SEAT HEATER SWITCH MUX
2 E2 20OR PANEL LAMPS DRIVER
3 F22 20WT/PK FUSED IGNITION SWITCH OUTPUT (RUN)
4- -
5 Z300 20BK GROUND
6 P132 20OR/BK SEAT HEATER SWITCH SENSOR GROUND
DRIVER LUMBAR MOTOR (MIDLINE/PREMIUM) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 P105 16LG/DB LUMBAR FORWARD SWITCH SENSE
2 P104 16YL/RD LUMBAR REARWARD SWITCH SENSE
DRIVER LUMBAR SWITCH (MIDLINE/PREMIUM) - WHITE 6 WAY
CAV CIRCUIT FUNCTION
1- -
2 Z238 16BK (RHD) GROUND
2 Z243 16BK (LHD) GROUND
3 P105 16LG/DB (RHD) LUMBAR FORWARD SWITCH SENSE
3 P104 16YL/RD (LHD) LUMBAR REAR WARD SWITCH SENSE
4 P104 16YL/RD (RHD) LUMBAR REAR WARD SWITCH SENSE
4 P105 16LG/DB (LHD) LUMBAR FORWARD SWITCH SENSE
5 Z238 16BK (RHD) GROUND
5 Z243 16BK (LHD) GROUND
6 F35 16RD FUSED B(+)
DRIVER POWER MIRROR - BLACK 12 WAY
CAV CIRCUIT FUNCTION
1 C117 20BK MIRROR HEATER 12 VOLT SUPPLY
2 P65 20DG MIRROR HORIZONTAL POSITION SIGNAL
3 P69 20GY MIRROR SENSOR GROUND
4 P64 20VT MIRROR VERTICAL POSITION SIGNAL
5 C118 20BK/WT MIRROR HEATER GROUND
6 P95 20OR MIRROR HORIZONTAL DRIVER
7 P114 20YL/RD AUTO DAY/NIGHT MIRROR(-)
8 P99 20DB (BUILT-UP-EXPORT) FOLDING MIRROR FEED
9 P110 20YL (BUILT-UP-EXPORT) FOLDING MIRROR RETURN
10 P112 20YL/WT AUTO DAY/NIGHT MIRROR(+)
11 P93 20RD MIRROR VERTICAL DRIVER
12 P91 20WT MIRROR COMMON DRIVER
8W - 80 - 70 8W-80 CONNECTOR PIN-OUTWJ
