JEEP GRAND CHEROKEE 2002 WJ / 2.G Workshop Manual INTRODUCTION
TABLE OF CONTENTS
page page
BODY CODE PLATE
DESCRIPTION..........................1
FASTENER IDENTIFICATION
DESCRIPTION..........................1
FASTENER USAGE
DESCRIPTION - FASTENER USA

Page 5 of 2199

JEEP GRAND CHEROKEE 2002 WJ / 2.G Workshop Manual FASTENER USAGE
DESCRIPTION - FASTENER USAGE
WARNING: USE OF AN INCORRECT FASTENER
MAY RESULT IN COMPONENT DAMAGE OR PER-
SONAL INJURY.
Fasteners and torque specifications references in
this Service Ma

Page 6 of 2199

JEEP GRAND CHEROKEE 2002 WJ / 2.G Workshop Manual METRIC SYSTEM
DESCRIPTION
The metric system is based on quantities of one,
ten, one hundred, one thousand and one million.The following chart will assist in converting metric
units to equivalent Engli

Page 8 of 2199

JEEP GRAND CHEROKEE 2002 WJ / 2.G Workshop Manual TORQUE REFERENCES
DESCRIPTION
Individual Torque Charts appear within many or
the Groups. Refer to the Standard Torque Specifica-tions Chart for torque references not listed in the
individual torque ch

Page 24 of 2199

JEEP GRAND CHEROKEE 2002 WJ / 2.G Workshop Manual WHEEL ALIGNMENT
TABLE OF CONTENTS
page page
WHEEL ALIGNMENT
DESCRIPTION..........................3
OPERATION............................3
STANDARD PROCEDURE
STANDARD PROCEDURE - CAMBER.......3STANDARD

Page 27 of 2199

JEEP GRAND CHEROKEE 2002 WJ / 2.G Workshop Manual FRONT
TABLE OF CONTENTS
page page
FRONT
DESCRIPTION..........................6
STANDARD PROCEDURE - SERVICE
WARNINGS AND CAUTIONS..............6
SPECIFICATIONS
TORQUE CHART......................7
SPEC

Page 28 of 2199

JEEP GRAND CHEROKEE 2002 WJ / 2.G Workshop Manual SPECIFICATIONS
TORQUE CHART
TORQUE SPECIFICATIONS
DESCRIPTION N´m Ft. Lbs. In. Lbs.
Shock Absorber Upper Nut 35 26 Ð
Shock Absorber Lower Nut 28 Ð 250
Suspension Arm Upper Axle Bracket Nut 61 45 Ð

Page 31 of 2199

JEEP GRAND CHEROKEE 2002 WJ / 2.G Workshop Manual ing (Fig. 4) from the steering knuckle and off the
axle shaft.
INSTALLATION
(1) Install the hub bearing to the knuckle.
(2) Install the hub bearing to knuckle bolts and
tighten to 102 N´m (75 ft. lbs

Page 35 of 2199

JEEP GRAND CHEROKEE 2002 WJ / 2.G Workshop Manual (6) Install the track bar to the axle bracket and
install the mounting bolt.
NOTE: It may be necessary to pry the axle assem-
bly over to install the track bar bolt.
(7) Remove the hydraulic jack from

Page 38 of 2199

JEEP GRAND CHEROKEE 2002 WJ / 2.G Workshop Manual REAR
TABLE OF CONTENTS
page page
REAR
DESCRIPTION.........................17
WARNING.............................17
DIAGNOSIS AND TESTING - REAR
SUSPENSION........................18
SPECIFICATIONS
TOR
