FUEL INJECTOR NO. 1 (DIESEL) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K11 14BK/DB FUEL INJECTOR NO. 1 CONTROL
2 K63 14BK COMMON INJECTOR DRIVER
FUEL INJECTOR NO. 1 (GAS) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K11 18WT/DB FUEL INJECTOR NO. 1 DRIVER
2 F42 18DG/LG FUSED AUTO SHUT DOWN RELAY OUTPUT
FUEL INJECTOR NO. 2 (DIESEL) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K12 14BK/VT FUEL INJECTOR NO. 2 CONTROL
2 K63 14BK COMMON INJECTOR DRIVER
FUEL INJECTOR NO. 2 (GAS) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K12 18TN FUEL INJECTOR NO. 2 DRIVER
2 F42 18DG/LG FUSED AUTO SHUT DOWN RELAY OUTPUT
FUEL INJECTOR NO. 3 (DIESEL) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K13 14BK/RD FUEL INJECTOR NO. 3 CONTROL
2 K63 14BK COMMON INJECTOR DRIVER
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 79

FUEL INJECTOR NO. 3 (GAS) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K13 18YL/WT FUEL INJECTOR NO. 3 DRIVER
2 F42 18DG/LG FUSED AUTO SHUT DOWN RELAY OUTPUT
FUEL INJECTOR NO. 4 (DIESEL) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K14 14BK/YL FUEL INJECTOR NO. 4 CONTROL
2 K63 14BK COMMON INJECTOR DRIVER
FUEL INJECTOR NO. 4 (GAS) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K14 18LB/BR FUEL INJECTOR NO. 4 DRIVER
2 F42 18DG/LG FUSED AUTO SHUT DOWN RELAY OUTPUT
FUEL INJECTOR NO. 5 (DIESEL) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K38 14BK/DG FUEL INJECTOR NO. 5 CONTROL
2 K63 14BK COMMON INJECTOR DRIVER
8W - 80 - 80 8W-80 CONNECTOR PIN-OUTWJ

FUEL INJECTOR NO. 5 (GAS) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K38 18GY FUEL INJECTOR NO. 5 DRIVER
2 F42 18DG/LG FUSED AUTO SHUT DOWN RELAY OUTPUT
FUEL INJECTOR NO. 6 (GAS) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K58 18BR/DB FUEL INJECTOR NO. 6 DRIVER
2 F42 18DG/LG FUSED AUTO SHUT DOWN RELAY OUTPUT
FUEL INJECTOR NO. 7 (4.7L) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K26 18VT FUEL INJECTOR NO. 7 DRIVER
2 F42 18DG/LG FUSED AUTO SHUT DOWN RELAY OUTPUT
FUEL INJECTOR NO. 8 (4.7L) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K28 18GY/LB FUEL INJECTOR NO. 8 DRIVER
2 F42 18DG/LG FUSED AUTO SHUT DOWN RELAY OUTPUT
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 81

FUEL PRESSURE SENSOR (DIESEL) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 Y100 20BR/GY FUEL PRESSURE SENSOR GROUND
2 Y40 20DG/VT FUEL PRESSURE SENSOR SIGNAL
3 K7 20RD/WT FUEL PRESSURE SENSOR 5 VOLT SUPPLY
FUEL PRESSURE SOLENOID (DIESEL) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K46 20DB/BK FUEL PRESSURE SOLENOID CONTROL
2 F142 16RD/DG FUSED AUTO SHUT DOWN RELAY OUTPUT
FUEL PUMP MODULE (GAS) - BLACK 6 WAY
CAV CIRCUIT FUNCTION
1 A141 16DG/BK FUEL PUMP RELAY OUTPUT
2- -
3 K226 20LB/YL FUEL LEVEL SENSOR SIGNAL
4 K4 20BK/LB SENSOR GROUND
5- -
6 Z150 16BK GROUND
FUEL TANK MODULE (DIESEL) - BLACK 6 WAY
CAV CIRCUIT FUNCTION
1- -
2- -
3 K226 20LB/YL FUEL LEVEL SENSOR SIGNAL
4 K4 20BK/LB SENSOR GROUND
5- -
6- -
GENERATOR (DIESEL) - LT. GRAY 2 WAY
CAV CIRCUIT FUNCTION
1 F15 14DB/WT FUSED AUTO SHUT DOWN RELAY OUTPUT
2 K20 14DB GENERATOR FIELD CONTROL
8W - 80 - 82 8W-80 CONNECTOR PIN-OUTWJ

GENERATOR (GAS) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K125 18WT/DB GENERATOR SOURCE
2 K20 18DG GENERATOR FIELD DRIVER
GLOVE BOX LAMP - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 F70 20PK/BK FUSED B(+)
2 M20 20BR/OR COURTESY LAMP LOAD SHED
HEADLAMP LEVELING SWITCH (BUILT-UP-EXPORT) - WHITE 3 WAY
CAV CIRCUIT FUNCTION
1 Z234 20BK GROUND
2 L7 18BK/YL PARK LAMP RELAY OUTPUT
3 L13 20BR/YL HEADLAMP ADJUST SIGNAL
HOOD AJAR SWITCH (BUILT-UP-EXPORT) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 G70 20BR/TN HOOD AJAR SWITCH SENSE
2 Z141 20BK (DIESEL) GROUND
2 Z161 20BK (GAS) GROUND
HORN NO. 1 - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 Z307 18BK GROUND
2 X2 18DG/RD HORN RELAY OUTPUT
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 83

HORN NO. 2 - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 Z307 18BK GROUND
2 X2 18DG/RD HORN RELAY OUTPUT
HYDRAULIC COOLING MODULE - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 F15 18DB/WT (DIESEL) FUSED AUTO SHUT DOWN RELAY OUTPUT
1 F142 18OR/DG (GAS) FUSED AUTO SHUT DOWN RELAY OUTPUT
2 K173 18LG (DIESEL) HYDRAULIC RADIATOR FAN RELAY CONTROL
2 K173 18LG (GAS) RADIATOR FAN RELAY CONTROL
3 Z500 18BK GROUND
IDLE AIR CONTROL MOTOR - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 K59 18VT/BK IDLE AIR CONTROL NO. 4 DRIVER
2 K40 18BR/WT IDLE AIR CONTROL NO. 3 DRIVER
3 K60 18YL/BK IDLE AIR CONTROL NO. 2 DRIVER
4 K39 18GY/BK IDLE AIR CONTROL NO. 1 DRIVER
IGNITION SWITCH C1 - WHITE 6 WAY
CAV CIRCUIT FUNCTION
1 A41 12YL IGNITION SWITCH OUTPUT (START)
2 A2 12PK/BK FUSED B(+)
3 A22 12BK/OR IGNITION SWITCH OUTPUT (RUN)
4 A1 12RD FUSED B(+)
5 A31 12RD/BK IGNITION SWITCH OUTPUT (RUN-ACC)
6 A21 12DB IGNITION SWITCH OUTPUT (RUN-START)
IGNITION SWITCH C2 - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 G26 20LB KEY-IN IGNITION SWITCH SENSE
2 Z234 20BK GROUND
8W - 80 - 84 8W-80 CONNECTOR PIN-OUTWJ

INTAKE PORT SWIRL ACTUATOR (DIESEL) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 Z18 18BK GROUND
2 F15 18RD/DG FUSED AUTO SHUT DOWN RELAY OUTPUT
3 K900 18GY INTAKE PORT SWIRL ACTUATOR SIGNAL
INTRUSION TRANSCEIVER MODULE (BUILT-UP-EXPORT) - BLACK 6 WAY
CAV CIRCUIT FUNCTION
1 Z155 20BK GROUND
2- -
3 X75 20GY/LG SIREN SIGNAL CONTROL
4- -
5 D25 20YL/VT PCI BUS
6 F70 20PK FUSED B(+)
JUNCTION BLOCK BODY CONTROL MODULE - BLACK 26 WAY
CAV CIRCUIT FUNCTION
1 L308 PARK LAMP RELAY CONTROL
2 L26 FOG LAMP RELAY CONTROL
3 Q29 ACCESSORY DELAY RELAY CONTROL
4 L307 LOW BEAM RELAY CONTROL
5 G5 FUSED IGNITION SWITCH OUTPUT (RUN-START)
6 X4 HORN RELAY CONTROL
7 V16 WIPER HIGH/LOW RELAY CONTROL
8 G80 LIFTGATE FLIP-UP AJAR SWITCH SENSE
9 L11 HIGH BEAM RELAY CONTROL
10 L91 HAZARD SWITCH SENSE
11 C80 REAR WINDOW DEFOGGER RELAY CONTROL
12 Z2 GROUND
13 L96 (BUILT-UP-EXPORT) REAR FOG LAMP RELAY CONTROL
14 L7 PARK LAMP RELAY OUTPUT
15 Z1 GROUND
16 M2 COURTESY LAMP DRIVER
17 - -
18 - -
19 M20 COURTESY LAMP LOAD SHED
20 V55 WIPER PARK SWITCH SENSE
21 G78 LIFTGATE AJAR SWITCH SENSE
22 G10 SEAT BELT SWITCH SENSE
23 G77 LEFT REAR DOOR AJAR SWITCH SENSE
24 G73 LIFTGATE COURTESY DISABLE
25 V23 FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
26 M1 FUSED B(+)
8W - 80 - 86 8W-80 CONNECTOR PIN-OUTWJ

JUNCTION BLOCK C1 - BLACK 52 WAY
CAV CIRCUIT FUNCTION
1 Q30 16TN ACCESSORY DELAY RELAY OUTPUT
2 L63 18DG/RD LEFT TURN SIGNAL
3- -
4- -
5 L95 18DG/YL (BUILT-UP-EXPORT) REAR FOG LAMP RELAY OUTPUT
6- -
7- -
8- -
9 G73 20LG/OR LIFTGATE COURTESY DISABLE
10 G77 20TN/OR LEFT REAR DOOR AJAR SWITCH SENSE
11 L7 18BK/YL PARK LAMP RELAY OUTPUT
12 - -
13 - -
14 - -
15 F37 16RD (LHD EXCEPT BASE) FUSED B(+)
15 F37 16RD/LB (RHD) FUSED B(+)
16 M2 18YL (RHD) COURTESY LAMP DRIVER
16 M2 20YL/DG (LHD) COURTESY LAMP DRIVER
17 - -
18 - -
19 - -
20 - -
21 - -
22 F22 20WT/PK (RHD) FUSED IGNITION SWITCH OUTPUT (RUN)
23 - -
24 G80 20VT/YL LIFTGATE FLIP-UP AJAR SWITCH SENSE
25 G78 20TN/BK LIFTGATE AJAR SWITCH SENSE
26 M20 18YL/BK (RHD) COURTESY LAMP LOAD SHED
26 M20 20YL/BK (LHD) COURTESY LAMP LOAD SHED
27 - -
28 - -
29 - -
30 G5 20DB/WT FUSED IGNITION SWITCH OUTPUT (RUN-START)
31 - -
32 M1 18PK/RD (RHD) FUSED B(+)
33 - -
34 - -
35 F9 14RD/BK FUSED B(+)
36 F70 18PK FUSED B(+)
37 - -
38 - -
39 - -
40 - -
41 F30 14RD/TN (LHD) CIGAR LIGHTER RELAY OUTPUT
41 F30 16RD/TN (RHD) CIGAR LIGHTER RELAY OUTPUT
42 - -
43 - -
44 - -
45 - -
46 - -
47 - -
48 - -
49 - -
50 C15 12BK/WT REAR WINDOW DEFOGGER RELAY OUTPUT
51 - -
52 - -
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 87

JUNCTION BLOCK C2 (LHD) - BLACK 52 WAY
CAV CIRCUIT FUNCTION
1 X3 22GY/OR HORN RELAY CONTROL
2- -
3 L39 20LB FOG LAMP RELAY OUTPUT
4- -
5 L61 20TN/LG LEFT TURN SIGNAL
6- -
7- -
8 V6 16DB FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
9 V6 16DB (GAS) FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
10 L62 18BR/RD RIGHT TURN SIGNAL
11 F991 20OR/DB FUSED IGNITION SWITCH OUTPUT (RUN-START)
12 L39 20LB FOG LAMP RELAY OUTPUT
13 - -
14 - -
15 V16 22VT WIPER HIGH/LOW RELAY CONTROL
16 - -
17 - -
18 - -
19 - -
20 L7 20BK/YL PARK LAMP RELAY OUTPUT
21 L7 20BK/YL PARK LAMP RELAY OUTPUT
22 - -
23 - -
24 F37 16RD/LB (EXCEPT BASE) FUSED B(+)
25 F22 20WT/PK FUSED IGNITION SWITCH OUTPUT (RUN)
26 L60 20TN RIGHT TURN SIGNAL
27 F45 20YL/RD FUSED IGNITION SWITCH OUTPUT (START)
28 V55 16TN/RD WIPER PARK SWITCH SENSE
29 - -
30 - -
31 F72 16RD/YL FUSED B(+)
32 M1 20PK/RD FUSED B(+)
33 V55 16TN/RD (GAS) WIPER PARK SWITCH SENSE
34 - -
35 - -
36 A146 12OR/WT FUSED B(+)
37 - -
38 L34 18RD/OR FUSED RIGHT HIGH BEAM OUTPUT
39 L43 18VT FUSED LEFT LOW BEAM OUTPUT
40 - -
41 - -
42 F20 18DB/PK FUSED IGNITION SWITCH OUTPUT (RUN)
43 F12 20DB/WT FUSED IGNITION SWITCH OUTPUT (RUN-START)
44 - -
45 A146 12OR/WT FUSED B(+)
46 - -
47 F32 20PK/DB FUSED B(+)
48 - -
49 L44 18VT/RD FUSED RIGHT LOW BEAM OUTPUT
50 L33 18RD FUSED LEFT HIGH BEAM OUTPUT
51 - -
52 F60 14RD/WT (EXCEPT BASE) FUSED B(+)
8W - 80 - 88 8W-80 CONNECTOR PIN-OUTWJ

JUNCTION BLOCK C2 (RHD) - BLACK 52 WAY
CAV CIRCUIT FUNCTION
1 X3 22BK/RD HORN RELAY CONTROL
2- -
3 L39 20LB FOG LAMP RELAY OUTPUT
4- -
5 L61 20TN/LG LEFT TURN SIGNAL
6- -
7- -
8 V6 16DB FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
9 V6 16DB (GAS) FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
10 L62 20BR/RD RIGHT TURN SIGNAL
11 F991 20OR/DB (GAS) FUSED IGNITION SWITCH OUTPUT (RUN-START)
12 L39 20LB FOG LAMP RELAY OUTPUT
13 - -
14 - -
15 V16 22VT -
16 - -
17 - -
18 - -
19 - -
20 L7 20BK/YL PARK LAMP RELAY OUTPUT
21 L7 18BK/YL PARK LAMP RELAY OUTPUT
22 - -
23 - -
24 F37 16RD/LB FUSED B(+)
25 F22 18WT/TN FUSED IGNITION SWITCH OUTPUT (RUN)
26 L60 20TN RIGHT TURN SIGNAL
27 F45 20YL/RD FUSED IGNITION SWITCH OUTPUT (START)
28 V55 16TN/RD WIPER PARK SWITCH SENSE
29 - -
30 - -
31 - -
32 M1 20PK/RD FUSED B(+)
33 V55 16TN/RD (GAS) WIPER PARK SWITCH SENSE
34 - -
35 - -
36 A146 12OR/WT FUSED B(+)
37 - -
38 L34 18RD/OR FUSED RIGHT HIGH BEAM OUTPUT
39 L43 18VT FUSED LEFT LOW BEAM OUTPUT
40 - -
41 - -
42 F20 18DB/PK FUSED IGNITION SWITCH OUTPUT (RUN)
43 F12 20DB/WT (GAS) FUSED IGNITION SWITCH OUTPUT (RUN-START)
44 - -
45 A146 12OR/WT FUSED B(+)
46 - -
47 F32 20PK/DB FUSED B(+)
48 - -
49 L44 18VT/RD FUSED RIGHT LOW BEAM OUTPUT
50 L33 18RD FUSED LEFT HIGH BEAM OUTPUT
51 - -
52 F60 16RD/WT FUSED B(+)
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 89
