BOOST PRESSURE SENSOR (DIESEL) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K4 20BK/LB SENSOR GROUND
2 Y53 20BK/YL BOOST PRESSURE SENSOR SIGNAL
3 K6 20VT/WT SENSOR REFERENCE VOLTAGE B
BRAKE LAMP SWITCH - GRAY 6 WAY
CAV CIRCUIT FUNCTION
1 K29 18WT/PK SECONDARY BRAKE SWITCH SIGNAL
2 Z238 18BK (LHD) GROUND
2 Z243 18BK (RHD) GROUND
3 V32 22OR/DG (GAS) SPEED CONTROL POWER SUPPLY
4 V30 22DB/RD (GAS) SPEED CONTROL BRAKE SWITCH OUTPUT
5 L50 20VT/TN (LHD) PRIMARY BRAKE SWITCH SIGNAL
5 L50 20WT/TN (RHD) PRIMARY BRAKE SWITCH SIGNAL
6 F32 20PK/DB FUSED B(+)
C100 - BLACK (RIGHT HEADLAMP AND DASH
SIDE)
CAV CIRCUIT
1 T40 12LG
2 K125 18WT/DB
3 K20 18DG
C100 - BLACK (BATTERY SIDE)
CAV CIRCUIT
1 T40 12LG
2 K125 18WT/DB
3 K20 18DG
C101 (4.0L RHD) - LT. GRAY (ENGINE SIDE)
CAV CIRCUIT
1 B22 18DG/YL
2 K99 18BR/OR
3 K299 18BR/WT
4 K6 18VT/BK
5 C18 18DB
6-
8W - 80 - 12 8W-80 CONNECTOR PIN-OUTWJ

C101 (4.0L RHD) - LT. GRAY (HEADLAMP AND
DASH SIDE)
CAV CIRCUIT
1 B22 18DG/YL
2 K99 18LB/OR
3 K299 18BR/WT
4 K6 18VT/BK
5 C18 18DB
6-
C101 (4.7L RHD) - BLACK (ENGINE SIDE)
CAV CIRCUIT
1 K4 18BK/LB (HIGH OUTPUT)
2 K99 18BR/OR
3 C18 18DB
4 K299 18BR/WT
5 T6 18VT/WT
6 K6 18VT/BK
7 K4 18BK/LB (HIGH OUTPUT)
8 K142 18GY/BK (HIGH OUTPUT)
9 T10 18YL/DG
10 -
11 -
12 B22 18DG/YL
13 -
14 K42 18DB/LG (HIGH OUTPUT)
C101 (4.7L RHD) - BLACK (LEFT HEADLAMP
AND DASH SIDE)
CAV CIRCUIT
1 K4 18BK/LB
2 K99 18BR/OR
3 C18 18DB
4 K299 18BR/WT
5 T6 18OR/WT
6 K6 18VT/BK
7 K4 18BK/LB
8 K142 18GY/BK
9 T10 18YL/DG
10 -
11 -
12 B22 18DG/YL
13 -
14 K42 18DB/LG
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 13

C102 (DIESEL) - BLACK (LEFT HEADLAMP AND
DASH SIDE)
CAV CIRCUIT
1 D21 18PK
2 D25 18VT/YL
3 K226 18DB/WT
4 D52 18LG/VT
5 D51 18DG/WT
6 B22 18DG/YL
7 F991 20OR/DB
8 T752 18DG/OR
9 K236 18GY/PK
10 K132 18BR/PK
11 A82 18PK/LG
12 K152 18WT
13 L50 18WT/TN
14 K29 18WT/PK
C102 (DIESEL) - BLACK (ENGINE SIDE)
CAV CIRCUIT
1 D21 20PK
2 D25 20VT/YL
3 K226 20DB/WT
4 D52 16DG/WT
5 D51 16WT
6 B22 20DG/YL
7 F991 20RD/DB
8 T752 20DG/RD
9 K236 20GY/PK
10 K132 20BR/PK
11 A82 16PK/DG
12 K152 20WT
13 L50 20WT/DB
14 K29 20WT/PK
C102 (GAS RHD) - BLACK (RIGHT HEADLAMP
AND DASH SIDE)
CAV CIRCUIT
1 A30 14RD/WT (4.7L)
2 F991 20OR/DB
3 K173 18LG
4 F42 18DG/LG
5 A7 14RD/BK
6 L1 18VT/BK
7 Z306 20BK/LG
8 T41 18BK/WT
9-
10 K4 20BK/LB
11 K200 18VT/OR (4.7L)
12 C2 18DB/YL
13 -
14 A142 14DG/OR
8W - 80 - 14 8W-80 CONNECTOR PIN-OUTWJ

C102 (GAS RHD) - BLACK (ENGINE SIDE)
CAV CIRCUIT
1 A30 14RD/WT (4.7L)
2 F991 18OR/DB
3 K173 18LG
4 F42 18DG/LG
5 A7 14RD/BK
6 L1 18VT/BK
7 Z306 20BK/LG
8 T41 18BK/WT
9-
10 K4 18BK/LB
11 K200 18VT/OR (4.7L)
12 C2 18DB/YL
13 -
14 A142 14DG/OR
C103 (DIESEL) - GRAY (LEFT HEADLAMP AND
DASH SIDE)
CAV CIRCUIT
1 T41 18BK/WT
2 K173 18LG
3 C2 18DB/PK
4-
5 F142 14OR/DG
6 K51 18DB/YL
7 K25 18VT/LG
8 Y42 18OR/DB
9 C18 18DB
10 K4 20BK/LB
11 K6 18VT/WT
12 -
13 T40 12BR
14 F15 18DB/WT
C103 (DIESEL) - GRAY (ENGINE SIDE)
CAV CIRCUIT
1 T41 20BK/WT
2 K173 20GY
3 C3 14DB/BK
4-
5 F142 16RD/DG
6 K51 20DB/YL
7 K25 20VT/DG
8 Y42 20RD/DB
9 C18 20DB
10 K4 16BK/LB
11 K6 16VT/WT
12 -
13 T40 12DG
14 F15 20DB/WT
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 15

C103 (GAS) - GRAY (RIGHT HEADLAMP AND DASH SIDE)
CAV CIRCUIT
1 F22 20WT/PK (EXCEPT 4.7L RHD)
1 F22 18WT/TN (4.7L RHD)
2 T6 18OR/WT (4.7L LHD)
2 C18 20DB (4.0L LHD BUILT-UP-EXPORT)
2 C18 18DB (4.0L EXCEPT BUILT-UP-EXPORT)
3 D20 20LG (4.7L LHD)
3 D20 18LG (4.7L RHD)
4 D21 20PK (4.7L LHD)
4 K299 18BR/WT (4.0L LHD)
4 D21 18PK (4.7L RHD)
5 B22 18DG/YL (LHD)
6 K20 18DG
7 K30 20PK (4.0L RHD)
7 K30 18PK/YL (4.7L RHD)
7 K30 20PK/YL (LHD)
8 A142 14DG/OR (4.0L LHD)
8 T10 18DG/LG (4.7L LHD)
9 T16 14RD (4.7L LHD)
10 D25 18VT/YL (4.7L RHD)
10 D25 18VT/YL (4.7L EXCEPT BUILT-UP-EXPORT)
10 D25 20VT/YL (4.7L LHD BUILT-UP-EXPORT)
11 Z305 20BK/OR
12 F45 18YL/RD (4.7L RHD)
12 T15 18YL/BR (4.0L)
12 F45 18YL/RD (4.7L EXCEPT BUILT-UP-EXPORT)
12 F45 20YL/RD (4.7L LHD BUILT-UP-EXPORT)
13 K6 18VT/BK (4.0L LHD)
14 F142 18OR/DG
C103 (GAS) - GRAY (ENGINE SIDE)
CAV CIRCUIT
1 F22 18WT/PK
2 C18 18DB (4.0L LHD)
2 K200 18VT/OR (4.7L RHD)
3 K99 18BR/OR (4.0L LHD)
3 D20 18LG (4.7L RHD)
4 K299 18BR/WT (4.0L BUILT-UP-EXPORT)
4 D21 18PK (4.7L RHD)
5 B22 18DG/YL (4.0L LHD)
6 K20 18DG
7 K30 18PK/YL
8 A142 14DG/OR (4.0L LHD)
9 T16 14RD (4.7L)
10 D25 18WT/VT (4.7L)
11 Z305 20BK/OR
12 T15 18LG (4.0L LHD)
12 F45 18YL/RD (4.7L)
13 K6 18VT/BK (4.0L LHD)
13 K199 18DB/WT (4.7L LHD)
14 F142 18OR/DG
8W - 80 - 16 8W-80 CONNECTOR PIN-OUTWJ

C104 - LT. GRAY (RIGHT HEADLAMP AND DASH SIDE)
CAV CIRCUIT
1 K200 18VT/OR (4.0L EXCEPT BUILT-UP-EXPORT)
1 K4 18BK/LB (4.7L HIGH OUTPUT)
2 K99 18BR/OR (4.7L)
2 F991 20OR/DB (4.0L)
3 K173 18LG (4.0L)
4 F42 18DG/LG (4.0L)
5 A7 14RD/BK (4.0L)
5 K4 18BK/LB (4.7L HIGH OUTPUT)
6 L1 18VT/BK (4.0L)
6 K142 18GY/BK (4.7L HIGH OUTPUT)
7 Z306 20BK/LG (4.0L)
7 K299 18BR/WT (4.7L)
8 C18 18DB (4.7L)
8 T41 18BK/WT (4.0L)
9 K6 18VT/BK (4.7L)
9 C2 18DB/YL (4.0L)
10 K4 18BK/LB (4.0L)
10 K42 18DB/LG (4.7L HIGH OUTPUT)
C104 - LT. GRAY (ENGINE SIDE)
CAV CIRCUIT
1 K200 18VT/OR (EXCEPT 4.0L BUILT-UP-EXPORT)
2 F991 18OR/DB
3 K173 18LG
4 F42 18DG/LG
5 A7 14RD/BK
6 L1 18VT/BK
7 Z306 20BK/LG
8 T41 18BK/WT
9 C2 18DB/YL
10 K4 18BK/LB
C105 (DIESEL) - GRAY (LEFT HEADLAMP AND DASH SIDE)
CAV CIRCUIT
1 C13 18DB/OR
2 F300 18RD/BK
3 V37 18RD/LG
4 Z305 20BK/OR
5 Z306 20BK/LG
6 L1 18VT/BK
7-
8-
9-
10 -
11 -
12 -
13 -
14 -
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 17

C106 (DIESEL) - GRAY (RIGHT HEADLAMP AND
DASH SIDE)
CAV CIRCUIT
A-
B-
C-
D-
E-
F-
G-
H-
J-
K-
L-
M-
1 F15 18DB/WT
2-
3 G31 20VT/LG
4 G32 20BK/LB
5 G18 20PK/BK
6-
7-
8-
9-
10 Z231 18BK (RHD)
11 K4 18BK/LB (LHD)
11 G9 18GY/BK (RHD)
12 K6 18VT/WT (LHD)
13 -
14 -
15 -
16 K173 18LG
17 -
18 X2 18DG/RD
19 C18 18DB (LHD)
20 Y42 18OR/DB
21 -
22 -
23 -
24 -
25 B7 18WT
26 B6 18WT/DB
27 -
28 -
29 -
30 -
31 -
8W - 80 - 20 8W-80 CONNECTOR PIN-OUTWJ

C106 (DIESEL) - GRAY (RIGHT HEADLAMP AND
DASH SIDE)
CAV CIRCUIT
32 -
33 -
34 -
35 -
36 -
37 -
38 L13 18BR/YL
39 -
40 -
41 -
42 R46 18BR/LB
43 R47 18TN
44 -
45 -
46 -
47 -
48 -
49 -
50 -
51 -
52 -
53 L7 20BK/YL
54 L60 20TN
55 -
56 -
57 L39 20LB
58 -
59 L44 18VT/RD
60 L34 18RD/OR
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 21

C106 (GAS) - GRAY/RHD BLACK/LHD (RIGHT
HEADLAMP AND DASH SIDE)
CAV CIRCUIT
A A149 12RD/TN
B A148 16LG/RD
C C1 12DG
D-
E A10 12RD/DG
F A1 12RD
G A145 10WT/RD
H A146 10OR/WT
J A147 10RD/GY
L A2 12PK/BK
K A148 10PK/WT
M A20 12RD/DB
1 A141 16DG/BK (RHD)
1 A141 16DG/WT (LHD)
2 F42 18DG/LG (RHD)
2 G18 18PK/BK (LHD)
3 V3 16BR/WT
4 V4 16RD/YL
5 V55 16TN/RD
6 V6 16DB
7 F22 18WT/TN (4.7L RHD)
7 F22 20WT/PK (EXCEPT 4.7L RHD)
8 F12 18DB/WT
9 K52 18PK/BK (LHD)
10 K29 18WT/PK (LHD)
10 Z231 18BK (RHD)
11 K226 18LB/YL (LHD)
11 K512 18RD/YL (4.7L RHD)
12 K107 18OR/PK (EXCEPT
BUILT-UP-EXPORT)
13 K106 18WT/DG (EXCEPT
BUILT-UP-EXPORT)
14 C13 18DB/OR (RHD)
14 T41 18BK/WT (LHD)
15 V35 20LG/RD (RHD)
16 V36 20TN/RD (RHD)
17 G9 18GY/BK (RHD)
18 K25 18VT/LG (RHD)
19 K51 18DB/YL (RHD)
20 K125 18WT/DB (EXCEPT
BUILT-UP-EXPORT)
21 K125 18WT/DB (RHD)
22 K31 18BR (RHD)
23 -
24 -
25 B7 18WT
26 B6 18WT/DB
27 X3 20BK/RD
28 G32 20BK/LB
29 -
30 G31 20VT/LG
31 -
32 V32 18OR/DG (LHD)
33 V30 20DB/RD
34 V16 20VT
8W - 80 - 24 8W-80 CONNECTOR PIN-OUTWJ

C106 (GAS) - GRAY/RHD BLACK/LHD (RIGHT
HEADLAMP AND DASH SIDE)
CAV CIRCUIT
35 V14 20RD/VT
36 -
37 F45 18YL/RD (LHD/4.7L RHD)
37 F45 20YL/RD (RHD)
38 L13 18BR/YL (BUILT-UP-EXPORT)
39 -
40 Z306 20BK/LG
41 Z305 20BK/OR
42 R46 18BR/LB
43 R48 18TN
44 F991 20OR/DB
45 B22 18DG/YL (LHD)
46 -
47 -
48 D25 18VT/YL (LHD/4.7L RHD)
49 D21 18PK (4.0L LHD/4.7L RHD)
49 D21 20PK (4.7L LHD)
50 D20 20LG (4.7L LHD)
50 D20 18LG (4.7L RHD)
51 D32 18LG (EXCEPT BUILT-UP-EXPORT)
51 D32 18LG/DG (LHD BUILT-UP-EXPORT)
52 T41 18BK/WT (RHD)
52 T6 18OR/WT (LHD)
53 L7 20BK/YL
54 L60 20TN
55 G18 20PK/BK (RHD)
55 V37 18RD/LG (LHD)
56 L1 18VT/BK
57 L39 20LB
58 K4 18BK/LB (LHD)
58 K4 20BK/LB (RHD)
59 L44 18VT/RD
60 L34 18RD/OR
