Cavity Fuse/Color Description
19 20 Amp Yellow Ign Sw
20 20 Amp Yellow PCM Batt (Gasoline Only)
21 30 Amp Pink ABS Valves
22 Spare
23 20 Amp Yellow FDCM
24 20 Amp Yellow Fuel Pump
25 20 Amp Yellow FDCM/E-Diff.
26 15 Amp Blue Hyd/PCM (Diesel Only)
27 15 Amp Blue Brake/Stop Lamps
28 25 Amp Natu-
ralNGC/Injectors
29 Spare
30 Spare
31 Mini Relay Cabin Htr 1 Rly (Diesel
Only)
32 Micro Relay TCM Rly (Gasoline Only)Cavity Fuse/Color Description
33 Micro Relay Starter Rly
34 Micro Relay AC Clutch Rly
35 Micro Relay Fuel Pump Rly
36 Mini Relay Cabin Htr 3 Rly (Diesel
Only)
38 Mini Relay Cabin Htr 2 Rly (Diesel
Only)
39 Mini Relay HVAC Blower Rly
40 Mini Relay ASD Rly
MAINTAINING YOUR VEHICLE 383
7

Underhood Fuses (Integrated Power Module)
Cavity Fuse/Color Description
1 Micro Relay Wiper On/Off Rly
2 Micro Relay Wiper Hi/Lo Rly
3 Micro Relay Horn Rly
Cavity Fuse/Color Description
4 Micro Relay Rear Fog Rly (BUX Only)
5 Micro Relay Lt T-Tow Stop/Turn Rly
6 Micro Relay Rt T-Tow Stop/Turn Rly
7 Micro Relay Park Lamps Rly
8 10 Amp Red Lt Park Lamps
9 10 Amp Red T-Tow Park Lamps
10 10 Amp Red Rt Park Lamps
11 Mini Relay Rad Fan Hi Rly
12 20 Amp Yellow FCM Batt #4
13 20 Amp Yellow FCM Batt #2
14 20 Amp Yellow Adjustable Pedal
15 20 Amp Yellow Ft Fog Lamps
16 20 Amp Yellow Horn
17 20 Amp Yellow Rear Fogs
18 20 Amp Yellow FCM Batt #1
19 20 Amp Yellow Lt T-Tow Stop/Turn
Integrated Power Module
384 MAINTAINING YOUR VEHICLE

Cavity Fuse/Color Description
20 20 Amp Yellow FCM Batt #3
21 20 Amp Yellow Rt T-Tow Stop/Turn
22 30 Amp Pink FDCM Mod
23 50 Amp Red Rad Fan
24 Mini Relay Rad Fan Lo Rly
25 Micro Relay Ft Fog Lamps Rly
26 Micro Relay Adjustable Pedal Rly
27 15 Amp Blue IOD #1
28 20 Amp Yellow IOD #2 (Audio)
29 10 Amp Red ORC (Ign R/.S)
30 10 Amp Red ORC (Ign R/O)VEHICLE STORAGE
If you are leaving your vehicle dormant for more than 21
days you may want to take steps to protect your battery.
You may:
•Remove fuse #27 in the Intelligent Power Module
labeled Ignition-Off Draw (IOD#1).
•Or, disconnect the negative cable from the battery.
•Anytime you store your vehicle, or keep it out of
service (i.e. vacation) for two weeks or more, run the
air conditioning system at idle for about five minutes
in the fresh air and high blower setting. This will
insure adequate system lubrication to minimize the
possibility of compressor damage when the system is
started again.
