Page 16 of 392
General Information
The Sentry Key Immobilizer System complies with FCC
rules part 15 and with RSS-210 of Industry Canada.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference that may be
received, including interference that may cause undes-
ired operation.
ILLUMINATED ENTRY
The interior lights come on when you open any door.
They will remain on for about 30 seconds after all doors
are closed then fade to off.
The lights also will fade to off if you turn on the ignition
after you close all the doors.
DOORS AND DOOR LOCKS
Manual Door Locks
Use the manual door lock plunger to lock the doors from
inside the vehicle. If the plunger is down when the door
is closed, the door will lock. Therefore, make sure the
keys are not inside the vehicle before closing the door.
WARNING!
For personal security, and safety in the event of an
accident, lock the vehicle doors as you drive as well
as when you park and leave the vehicle.
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
Page 22 of 392
To Release the Liftgate Flipper Glass
Press the “Flipper Glass/Trunk Release” button on the
transmitter two times to release the flipper glass.
WARNING!
Driving with the flipper glass open can allow poi-
sonous exhaust gases into your vehicle. You and your
passengers could be injured by these fumes. Keep
the flipper glass closed when you are operating the
vehicle.
Using The Panic Alarm
To turn the panic alarm feature ON or OFF, press and
hold the PANIC button on the transmitter for at least one
second and release. When the panic alarm is on, the
headlights and park lights will flash, the horn will pulse
on and off and the interior lights will turn on.
The panic alarm will stay on for 3 minutes unless you
turn it off by pressing the PANIC button a second time or
if the vehicle speed is 15 mph (24 km/h) or greater.
NOTE:The interior lights will turn off when the ignition
is switched to the ACC or ON position after the panic
alarm is activated. However, the exterior lights and horn
will remain on.
NOTE:When you turn off the panic alarm by pressing
the PANIC button a second time, you may have to be
closer to the vehicle due to the radio frequency noises of
the system.
22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
Page 56 of 392
WARNING!
Deployed airbags and seat belt pretensioners cannot
protect you in another collision. Have the airbags,
seat belt pretensioner, and seat belt retractor assem-
bly, replaced by an authorized dealer as soon as
possible. Also, have the Occupant Classification
System serviced as well.
Enhanced Accident Response Feature
If the airbags deploy after an impact and the electrical
system remains functional, vehicles equipped with
power door locks will unlock automatically. In addition,
approximately 5 seconds after the vehicle has stopped
moving, the interior lights will illuminate to aid visibility.
NOTE:The interior lights can only be deactivated if the
key is removed from the ignition switch or the vehicle is
driven.
Maintaining Your Airbag System
WARNING!
•Modifications to any part of the airbag system could cause it to fail
when you need it. You could be injured if the airbag system is not
there to protect you. Do not modify the components or wiring,
including adding any kind of badges or stickers to the steering
wheel hub trim cover or the upper right side of the instrument
panel. Do not modify the front bumper or vehicle body structure.
•Do not attempt to modify any part of your advanced airbag system. The
airbag may inflate accidentally or may not function properly if modi-
fications are made. Take your vehicle to an authorized dealer for any
advanced airbag system service. If your seat including your trim cover
and cushion needs to be serviced in any way (including removal or
loosening/tightening of seat attachment bolts), take the vehicle to your
authorized dealer. Only manufacturer approved seat accessories may
be used. If it is necessary to modify an advanced airbag system for
persons with disabilities, contact your authorized dealer.
•Do not place or hang any items such as add-on video players on the
right front passenger seat back. The additional weight may cause
the Occupant Classification System to be unable to correctly classify
the right front occupant. This could allow the passenger frontal
airbag to inflate when it is not desired.
•You need proper knee impact protection in a collision. Do not mount or
locate any aftermarket equipment on or behind the knee bolsters.
•It is dangerous to try to repair any part of the airbag system yourself.
Be sure to tell anyone who works on your vehicle that it has an
airbag system.
56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
Page 74 of 392
▫Manual Lumbar Support Adjustment.......106
▫Head Restraints......................107
▫8 - Way Driver’s Power Seat..............108
▫4 - Way Passenger’s Power Seat —
If Equipped.........................108
▫Heated Seats—If Equipped..............108
▫60/40 Split Rear Seat...................109
Driver Memory Seat — If Equipped.........112
▫Setting Memory Positions And Linking Remote
Keyless Entry Transmitter To Memory.......113
▫Memory Position Recall.................114
▫To Disable A Transmitter Linked To Memory . . 115
▫Easy Entry/Exit Seat...................115
To Open And Close The Hood.............117Lights...............................118
▫Interior Lighting......................118
▫Front Map/Reading Lights..............119
▫Multi-Function Control Lever.............120
▫Battery Saver Feature—
Exterior/Interior Lights.................120
▫Headlights And Parking Lights...........121
▫Automatic Headlight System — If Equipped . . 121
▫Smartbeams — If Equipped..............122
▫Instrument Panel And Interior Lights.......123
▫Daytime Running Lights — Canada Only....124
▫Lights-On Reminder...................124
▫Fog Lights — If Equipped...............124
74 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 118 of 392
WARNING!
If the hood is not fully latched, it could fly up when
the vehicle is moving and block your forward vision.
Be sure all hood latches are fully latched before
driving.
LIGHTS
Interior Lighting
The interior lighting consists of courtesy lights mounted
below the instrument panel, an overhead console light
assembly which contains both driver and passenger
reading lights, reading lights located above the rear
doors, and a rear cargo light. Opening a door or turning
the center of the multi-function control lever to the
extreme up position will activate all interior courtesy
lights.
118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 120 of 392
Multi-Function Control Lever
The multi-function control lever controls the operation of
the headlights, turn signals, headlight beam selection,
instrument panel light dimming, passing light, interior
courtesy/dome lights, and optional fog lights.
Turn Signal Auto-Mode — If Equipped
Tap the multi-function control lever once and the turn
signal (left or right) will flash 3 times, and automatically
turn off.
Battery Saver Feature—Exterior/Interior Lights
If the multi-function control lever is left in the interior
light position, parking light position, or the headlight
position when the ignition switch is moved to the OFF
position, the battery saver feature will automatically turn
off the exterior and interior lights after eight minutes.
Normal operation will resume when the ignition is
turned ON or when the headlight switch is turned to
another position.
Multi-Function Control Lever
120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 122 of 392
If your vehicle is equipped with a “Rain Sensitive Wiper
System,” and it is activated, the headlights will automati-
cally turn on after the wipers complete five wipe cycles
within approximately 1 minute, and they will turn off
approximately four minutes after the wipers completely
stop. Refer to “Windshield Wipers and Washers” in this
section for more information.
NOTE:When your headlights come on during the
daytime, the instrument panel lights will automatically
dim to the lower nighttime intensity. Refer to “Instru-
ment Panel and Interior Lights” below for setting the
instrument panel lights to full daytime intensity.
SmartBeams — If Equipped
The SmartBeam system provides increased forward light-
ing at night by automating high beam control through
the use of a digital camera mounted on the inside
rearview mirror. This camera detects vehicle specific lightand automatically switches from high beams to low
beams until the approaching vehicle is out of view.
NOTE:If the windshield or SmartBeam mirror is re-
placed, the SmartBeam mirror must be re-aimed to
ensure proper performance. See your local authorized
dealer.
To Activate
1. Select “Auto Headlamp Low/High Beams? — Low/
High Beam.” Refer to “EVIC — Customer Programmable
Features” in Section 4 of this manual.
2. Turn the end of the multi-function control lever to the
A (Auto) headlight position.
NOTE:This system will not activate until the vehicle is
at or above 20 mph (32 km/h).
122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 123 of 392
To Deactivate
1. Pull back on the muti-function control lever to manu-
ally deactivate the system (normal operation of high
beams).
2. Pull back on the multi-function control lever once
again to re-activate the system.
NOTE:Broken, muddy, or obstructed headlights and
taillights of vehicles in the field of view will cause
headlights to remain on longer (closer to the vehicle).
Also, dirt, film, and other obstructions (sticker, toll box,
etc.) on the windshield or camera lens will cause the
system to function improperly.
Instrument Panel and Interior Lights
When the multi-function control lever is in the parklight,
headlight, or A (Auto) position (if equipped), rotating the
center portion of the lever up and down will increase and
decrease the brightness (dimmer control) of the instru-
ment panel lights. Full daytime brightness on all elec-
tronic displays (odometer, overhead console, radio, and
Automatic Climate Control (if equipped) is obtained by
rotating the center portion of the control to the first
detent above the dimmer range. Rotating the control to
the second detent above the dimmer range turns the
interior lights on. Rotating the control to the “Off”
(extreme bottom) position disables all the interior lights,
even when the doors and liftgate are open. While in the
“Off” position the instrument panel lighting is at the
lowest light level and may not be suitable for night
driving.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 123
3
Page 163 of 392
CARGO AREA FEATURES
Cargo Light
The cargo area light is activated by opening the liftgate,
opening any door, or by rotating the dimmer control on
the multi-function control lever to the extreme top posi-
tion. If all doors are closed and only the liftgate is open,
pushing on the cargo light lens surface will turn off all
interior lamps. Push on the lens surface a second time to
restore the interior lights to normal operation.
Rear Storage Compartment
The rear storage compartment is located on the driver’s
side behind the second row seat.
Rear Storage Compartment
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 163
3
Page 294 of 392
▫Power Steering Fluid Check..............310
▫Body Lubrication.....................311
▫Windshield Wiper Blades................312
▫Windshield Washers — Front And Rear.....312
▫Exhaust System......................313
▫Cooling System.......................314
▫Hoses And Vacuum/Vapor Harnesses.......319
▫Brake System........................319
▫Brake Fluid Level Check................321
▫Fuel System Hoses....................322
▫Automatic Transmission................323
▫Front And Rear Wheel Bearings...........324▫Appearance Care And Protection From
Corrosion...........................324
Fuse Panel...........................328
▫Interior Fuses........................328
▫Underhood Fuses (Power Distribution Center) . 330
▫Underhood Fuses (Integrated Power Module) . 332
Vehicle Storage........................334
Replacement Bulbs......................334
Bulb Replacement......................335
▫Head Light..........................335
▫Front Turn Signal.....................337
▫Front Fog Light......................338
▫Rear Tail, Stop, Turn Signal, And Back-Up
Lights.............................339
294 MAINTAINING YOUR VEHICLE
