Page 176 of 392
INSTRUMENT CLUSTER DESCRIPTION
1. Speedometer
Indicates vehicle speed.
2. Brake Warning Light
The BRAKE warning light will come on when
the ignition is first turned on, and stay on
briefly as a bulb check. If the bulb does not
come on during starting, have the bulb re-
paired promptly. If the light stays on longer, it may be an
indication that the parking brake has not been released.
If the light remains on when the parking brake is off, it
indicates a possible brake hydraulic system malfunction
or low fluid level. In this case, the light will remain on
until the cause is corrected. If a brake malfunction is
indicated, immediate repair is necessary and continued
operation of the vehicle in this condition is dangerous.3. Turn Signal Indicator Light
The arrow will flash with the exterior turn signal
when the turn signal lever is operated.
If the vehicle electronics sense that the vehicle has
traveled about one mile with the turn signals on, a chime
will sound to alert you to turn the signals off. If either
indicator flashes at a rapid rate, check for a defective
outside light bulb.
4. High Beam Indicator Light
Indicates that headlights are on high beam.
5. Malfunction Indicator Light
This light is part of an onboard diagnostic system
called OBD II that monitors engine and auto-
matic transmission control systems. The light will
illuminate when the key is in the ON position before
176 UNDERSTANDING YOUR INSTRUMENT PANEL
Page 185 of 392
•WASHER FLUID LOW (with graphic)
•UPSHIFT (with graphic)
•CHECK GAUGES
•AUTO HIGHBEAM ON
•AUTO HIGHBEAM OFF
•PARK ASSIST DISABLED
•SERVICE PARK ASSIST SYSTEM
•TRANSMISSION OVER TEMP
•LOW BRAKE FLUID LEVEL
•WARNING! LIMIT SPEED
•CHECK GAS CAP
•ESP OFF
•MEMORY #1 POSITIONS SET
•MEMORY #2 POSITIONS SET
•MEMORY SYSTEM DISABLED — SEATBELT FAS-
TENED (with graphic)
•MEMORY SYSTEM DISABLED — VEHICLE NOT IN
PARK
•DRIVER 1 MEMORY
•DRIVER 2 MEMORY
•PEDAL ADJUST DISABLED — CRUISE CONTROL
SET
•PEDAL ADJUST DISABLED — SHIFTER IN RE-
VERSE
•SERVICE TIRE PRESS SYSTEM
•LEFT FRONT LOW PRESSURE
•RIGHT FRONT LOW PRESSURE
UNDERSTANDING YOUR INSTRUMENT PANEL 185
4
Page 284 of 392
Towing Tips
Before setting out on a trip, practice turning, stopping
and backing the trailer in an area away from heavy
traffic.
Towing Tips — Automatic Transmission
The “D” range can be selected when towing. However, if
frequent shifting occurs while in this range, the “3” range
should be selected.
NOTE:Using the “3” range while operating the vehicle
under heavy operating conditions will improve perfor-
mance and extend transmission life by reducing exces-
sive shifting and heat build up. This action will also
provide better engine braking.
The automatic transmission fluid and filter should be
changed if you REGULARLY tow a trailer for more than
45 minutes of continuous operation. See Schedule “B” in
section 8 of this manual for transmission fluid change
intervals.
NOTE:Check the automatic transmission fluid level
before towing.
7- Pin Connector
284 STARTING AND OPERATING
Page 294 of 392
▫Power Steering Fluid Check..............310
▫Body Lubrication.....................311
▫Windshield Wiper Blades................312
▫Windshield Washers — Front And Rear.....312
▫Exhaust System......................313
▫Cooling System.......................314
▫Hoses And Vacuum/Vapor Harnesses.......319
▫Brake System........................319
▫Brake Fluid Level Check................321
▫Fuel System Hoses....................322
▫Automatic Transmission................323
▫Front And Rear Wheel Bearings...........324▫Appearance Care And Protection From
Corrosion...........................324
Fuse Panel...........................328
▫Interior Fuses........................328
▫Underhood Fuses (Power Distribution Center) . 330
▫Underhood Fuses (Integrated Power Module) . 332
Vehicle Storage........................334
Replacement Bulbs......................334
Bulb Replacement......................335
▫Head Light..........................335
▫Front Turn Signal.....................337
▫Front Fog Light......................338
▫Rear Tail, Stop, Turn Signal, And Back-Up
Lights.............................339
294 MAINTAINING YOUR VEHICLE
Page 310 of 392
Refrigerant Recovery and Recycling
R-134a Air Conditioning Refrigerant is a hydrofluorocar-
bon (HFC) that is endorsed by the Environmental Pro-
tection Agency and is an ozone-saving product. How-
ever, the manufacturer recommends that air conditioning
service be performed by dealers or other service facilities
using recovery and recycling equipment.
NOTE:Use only manufacturer approved A/C System
Sealers, Stop Leak Products, Seal Conditioners, Compres-
sor Oil, or Refrigerants.
Power Steering Fluid Check
The power steering system requires the use of Mopar
Hydraulic System Power Steering Fluid (P/N
05142893AA), or equivalent, which meets
DaimlerChrysler Material Standard MS-10838.
CAUTION!
Do not use Automatic Transmission Fluid (ATF) or
other types of power steering fluids when servicing
the power steering system of this vehicle. Damage to
the power steering system can result from the use of
the wrong power steering fluid.
Checking the power steering fluid level at a defined
service interval is not required. The fluid should only be
checked if a leak is suspected, abnormal noises are
apparent, and/or the system is not functioning as antici-
pated. Coordinate inspection efforts through a certified
“DaimlerChrysler Dealership.”
310 MAINTAINING YOUR VEHICLE
Page 323 of 392
Care should be taken in installing quick connect fittings
to insure they are properly installed and fully connected.
See your authorized dealer for service.
Automatic Transmission
Fluid Level Check
Regular automatic transmission fluid level checks are not
required. For this reason the dipstick is omitted.
If you notice fluid loss or gear shift malfunction, have
your authorized dealer check the transmission fluid level.
CAUTION!
Using a transmission fluid other than the manufac-
turer’s recommended fluid may cause deterioration
in transmission shift quality and/or torque converter
shudder. Using a transmission fluid other than that
recommended by the manufacturer will result in
more frequent fluid and filter changes. Refer to the
Fluids, Lubricants and Genuine Parts section for
correct fluid type.
MAINTAINING YOUR VEHICLE 323
7
Page 324 of 392
CAUTION!
The fluid level is preset at the factory and does not
require adjustment under normal operating condi-
tions. If a transmission fluid leak occurs, visit your
authorized dealer immediately. Severe damage to the
transmission may occur. Your authorized dealer has
the proper tools to accurately adjust the fluid level.
Fluid and Filter Changes
Automatic transmission fluid and filter should be
changed as follows:
Maintenance Schedule “A”— No change necessary.
Maintenance Schedule “B”– Every 60,000 miles (100 000
km) change fluid and filter under the following condi-
tions:
•Police, taxi, limousine, commercial type operation, or
trailer towing where the vehicle is drivenregularlyfor
more than 45 minutes of continuous operation.
If the transmission is disassembled for any reason, the
fluid and filter should be changed.
Front And Rear Wheel Bearings
Front and rear wheel bearings are permanently sealed.
No regular maintenance is required for these compo-
nents.
Appearance Care And Protection From Corrosion
Protection of Body and Paint from Corrosion
Vehicle body care requirements vary according to geo-
graphic locations and usage. Chemicals that make roads
passable in snow and ice, and those that are sprayed on
trees and road surfaces during other seasons, are highly
corrosive to the metal in your vehicle.
324 MAINTAINING YOUR VEHICLE
Page 343 of 392
Chassis
Component Fluid, Lubricant, or Genuine Part
Automatic Transmission MoparATF+4 Automatic Transmission Fluid
Transfer Case CastrolBOT89 M1 Plus Lubricant Usage of other fluid/lubricants isNOT
recommended.
Axle Differential (Front-Rear) MoparSynthetic Gear & Axle Lubricant SAE 75W-140 (API-GL5) or
equivalent.
Brake Master Cylinder MoparDOT 3 Brake Fluid, SAE J1703 should be used. If DOT 3, SAE
J1703 brake fluid is not available, then DOT 4 is acceptable. Use only rec-
ommended brake fluids.
Power Steering Reservoir This system requires the use of MoparHydraulic System Power Steering
Fluid (P/N 05142893AA) or equivalent, which meets DaimlerChrysler Ma-
terial Standard MS-10838.
MAINTAINING YOUR VEHICLE 343
7
Page 353 of 392
Miles 48,000 51,000 54,000 57,000 60,000
(Kilometers) (80 000) (85 000) (90 000) (95 000) (100 000)
Change the engine oil and engine oil filter, if not
replaced at 3 months.X X XXX
Inspect the engine air cleaner filter, replace if nec-
essary.X
Inspect the PCV Valve, replace if necessary.X
Inspect drive belt, replace if necessary. X
Inspect the brake linings. X X
Drain and refill the front and rear axles. X
Drain and refill the transfer case fluid. X
Drain and refill the automatic transmission fluid,
and replace filter.X
Flush and replace engine coolant/anti-freeze. X
SCHEDULE “B” 353
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S
Page 357 of 392
Miles 108,000 111,000 114,000 117,000 120,000
(Kilometers) (180 000) (185 000) (190 000) (195 000) (200 000)
Change the engine oil and engine oil filter, if not replaced
at 3 months.X X XXX
Inspect the engine air cleaner filter, replace if necessary.X
Inspect the PCV Valve, replace if necessary.X
Inspect the drive belt, replace if necessary.* X
Inspect the brake linings. X X
Drain and refill the front and rear axle fluid. X
Drain and refill the automatic transmission fluid, and re-
place filter.X
Drain and refill the transfer case fluid. X
Flush and replace the engine coolant/anti-freeze at 120
months, if not replaced at 102,000 miles (170 000 km).X
Inspection and service should also be performed anytime a
malfunction is observed or suspected. Retain all receipts.
This maintenance is recommended by the manufac-
turer to the owner, but is not required to maintain
emissions warranty.* This maintenance is not required if the belt was
previously replaced.
SCHEDULE “B” 357
