Weight Distributing Hitch SystemImproper Adjustment of Weight Distributing System
STARTING AND OPERATING 321
5

Trailer Hitch Classification
Your vehicle may be factory equipped for safe towing of
trailers weighing over 3,500 lbs (1 587 kg) with the
optional Trailer Tow Prep Package. See your dealer for
package content.
The following chart provides the industry standard for
the maximum trailer weight a given trailer hitch class can
tow and should be used to assist you in selecting the
correct trailer hitch for your intended towing condition.
Refer to the Trailer Towing Weights (Maximum Trailer
Weight Ratings) chart for the Max. GTW towable for your
given drivetrain.Trailer Hitch Classification
Class Max. GTW (Gross Trailer
Wt.)
ClassI-LightDuty 2,000lbs(907 kg)
Class II - Medium
Duty3,500 lbs (1 587 kg)
Class III - Heavy Duty 5,000 lbs (2 268 kg)
Class IV - Extra
Heavy Duty10,000 lbs (4 540 kg)
All trailer hitches should be professionally installed on
your vehicle.
322 STARTING AND OPERATING

Trailer Towing Weights (Maximum Trailer Weight Ratings)
The following chart provides the maximum trailer weight ratings towable for your given drivetrain.
Engine/
TransmissionModel GCWR (Gross Com-
bined Wt. Rating)Frontal Area Max. GTW (Gross
Trailer Wt.)Max. Tongue
Wt. (See Note 1)
3.7L/Automatic 4x2 8,000 lbs (3 629 kg) 35 Sq. Ft. (3.25
square meters)3,500 lbs (1 587 kg) 350 lbs (159 kg)
3.7L/Automatic 4x4 8,200 lbs (3 719 kg) 35 Sq. Ft. (3.25
square meters)3,500 lbs (1 587 kg) 350 lbs (159 kg)
4.7L/Automatic 4x2 8.560 lbs (3 883 kg) 35 Sq. Ft. (3.25
square meters)3,500 lbs (1 587 kg) 350 lbs (159 kg)
4.7L/Automatic 4x4 8,650 lbs (3 924 kg) 35 Sq. Ft. (3.25
square meters)3,500 lbs (1 587 kg) 350 lbs (159 kg)
4.7L/Automatic
(w/Trailer Tow
Group IV)4x2 11,200 lbs (5 080 kg) 64 Sq. Ft. (5.95
square meters)6,500 lbs (2 948 kg) 650 lbs (295 kg)
4.7L/Automatic
(w/Trailer Tow
Group IV)4x4 11,450 lbs (5 194 kg) 64 Sq. Ft. (5.95
square meters)6,500 lbs (2 948 kg) 650 lbs (295 kg)
STARTING AND OPERATING 323
5

5.7L/Automatic 4x2 12,200 lbs (5 534 kg) 64 Sq. Ft. (5.95
square meters)7,400 lbs (3 357 kg) 740 lbs (336 kg)
5.7L/Automatic
(Overland)4x2 12,200 lbs (5 534 kg) 64 Sq. Ft. (5.95
square meters)7,395 lbs (3 354 kg) 740 lbs (336 kg)
5.7L/Automatic 4x4 12,200 lbs (5 534 kg) 64 Sq. Ft. (5.95
square meters)7,200 lbs (3 266 kg) 720 lbs (327 kg)
3.0L Diesel/
Automatic4x4 12,200 lbs (5 534 kg) 64 Sq. Ft. (5.95
square meters)7,200 lbs (3 266 kg) 720 lbs (327 kg)
Refer to local laws for maximum trailer towing speeds.
NOTE:The trailer tongue weight must be considered as
part of the combined weight of occupants and cargo, and
should never exceed the weight referenced on the Tire
and Loading Information placard. The addition of pas-
sengers and cargo may require reducing tongue load andGross Trailer Weight (GTW). Redistributing cargo (to the
trailer) may be necessary to avoid exceeding Rear Gross
Axle Weight Rating (GAWR) of 3,200 lbs (1 451 kg). Refer
to “Weight Distributing Hitch” in this section. Refer to
the Tire–Safety Information section in this manual.
324 STARTING AND OPERATING

Trailer and Tongue Weight
Always load a trailer with 60% to 65% of the weight in
the front of the trailer. This places 10% to 15% of the
Gross Trailer Weight (GTW) on the tow hitch of your
vehicle. Loads balanced over the wheels or heavier in the
rear can cause the trailer to swayseverelyside to side
which will cause loss of control of vehicle and trailer.
Failure to load trailers heavier in front is the cause of
many trailer accidents.
Never exceed the maximum tongue weight stamped on
your trailer hitch.
Consider the following items when computing the
weight on the front/rear axles of the vehicle:
•The tongue weight of the trailer.
•The weight of any other type of cargo or equipment
put in or on your vehicle.
•The weight of the driver and all passengers.
STARTING AND OPERATING 325
5

NOTE:Remember that everything put into or on the
trailer adds to the load on your vehicle. Also, additional
factory-installed options, or dealer-installed options,
must be considered as part of the total load on your
vehicle. Refer to the Tire and Loading Information plac-
ard in the Tire Safety Information section of this manual
for the maximum combined weight of occupants and
cargo for your vehicle.
Towing Requirements
To promote proper break-in of your new vehicle drivetrain
components the following guidelines are recommended:
CAUTION!
•Avoid towing a trailer for the first 500 miles (805 km)
of vehicle operation. Doing so may damage your
vehicle.
•During the first 500 miles (805 km) of trailer towing,
limit your speed to 50 mph (80 km/h).
Perform the maintenance listed in Section 8 of this
manual. When towing a trailer, never exceed the GAWR,
or GCWR, ratings.
WARNING!
Improper towing can lead to an injury accident.
Follow these guidelines to make your trailer towing
as safe as possible:
Make certain that the load is secured in the trailer
and will not shift during travel. When trailering
cargo that is not fully secured, dynamic load shifts
can occur that may be difficult for the driver to
control. You could lose control of your vehicle and
have an accident.
•When hauling cargo or towing a trailer, do not over-
load your vehicle or trailer. Overloading can cause a
326 STARTING AND OPERATING

loss of control, poor performance or damage to brakes,
axle, engine, transmission, steering, suspension, chas-
sis structure or tires.
•Safety chains must always be used between your
vehicle and trailer. Always connect the chains to the
hook retainers of the vehicle hitch. Cross the chains
under the trailer tongue and allow enough slack for
turning corners.
•Vehicles with trailers should not be parked on a grade.
When parking, apply the parking brake on the tow
vehicle. Put the tow vehicle automatic transmission in
P (Park). For four-wheel-drive vehicles, make sure the
transfer case is not in neutral. Always, block orchock
the trailer wheels.
•GCWR must not be exceeded.
•Total weight must be distributed between the tow
vehicle and the trailer such that the following four
ratings are not exceeded:
1. GVWR
2. GTW
3. GAWR
4. Tongue weight rating for the trailer hitch utilized
(This requirement may limit the ability to always
achieve the 10% to 15% range of tongue weight as a
percentage of total trailer weight).
STARTING AND OPERATING 327
5

Towing Requirements — Tires

Do not attempt to tow a trailer while using a compact
spare tire.
Proper tire inflation pressures are essential to the safe
and satisfactory operation of your vehicle. Refer to the
Tires–General Information section of this manual on
Tire Pressures for proper tire inflation procedures.
Also, check the trailer tires for proper tire inflation
pressures before trailer usage.
Check for signs of tire wear or visible tire damage
before towing a trailer. Refer to the Tires–General
Information section of this manual on Tread Wear
Indicators for the proper inspection procedure.
When replacing tires, refer to the Tires–General Infor-
mation section of this manual on Replacement Tires forproper tire replacement procedures. Replacing tires
with a higher load carrying capacity will not increase
the vehicle’s GVWR and GAWR limits.
Towing Requirements — Trailer Brakes

Donotinterconnect the hydraulic brake system or
vacuum system of your vehicle with that of the trailer.
This could cause inadequate braking and possible
personal injury.
An electronically actuated trailer brake controller is
required when towing a trailer with electronically
actuated brakes. When towing a trailer equipped with
a hydraulic surge actuated brake system, an electronic
brake controller is not required.
Trailer brakes are recommended for trailers over 1,000
lbs (454 kg) and required for trailers in excess of 2,000
lbs (907 kg).
328 STARTING AND OPERATING

CAUTION!
If the trailer weighs more than 1,000 lbs (454 kg) loaded,
it should have its own brakes and they should be of
adequate capacity. Failure to do this could lead to
accelerated brake lining wear, higher brake pedal ef-
fort, and longer stopping distances.
WARNING!
Do not connect trailer brakes to your vehicle’s hydrau-
lic brake lines. It can overload your brake system and
cause it to fail. You might not have brakes when you
need them and could have an accident.
Towing any trailer will increase your stopping distance.
When towing you should allow for additional space
between your vehicle and the vehicle in front of you.
Failure to do so could result in an accident.
Towing Requirements — Trailer Lights & Wiring
Whenever you pull a trailer, regardless of the trailer size,
stop lights and turn signals on the trailer are required for
motoring safety.
The Trailer Tow Package may includea4and7pin
wiring harness. Use a factory approved trailer harness
and connector.
The electrical connections are all complete to the vehicle
but you must mate the harness to a trailer connector.
Refer to the following illustrations.
STARTING AND OPERATING 329
5

Towing Tips
Before setting out on a trip, practice turning, stopping
and backing the trailer in an area away from heavy
traffic.
4 - Pin Connector7- Pin Connector
