•If your vehicle is damaged due to an accident or
similar cause which destroys the paint and protective
coating have your vehicle repaired as soon as possible.
The cost of such repairs is considered the responsibil-
ity of the owner.
•If you carry special cargo such as chemicals, fertilizers,
de-icer salt, etc., assure that such materials are well
packaged and sealed.
•If a lot of driving is done on gravel roads, consider
mud or stone shields behind each wheel.
•Use MoparTouch Up Paint on scratches or chips as
soon as possible. Your authorized dealer has touch up
paint to match the color of your vehicle.
Wheel and Wheel Trim Care
All wheels and wheel trim, especially aluminum and
chrome plated wheels should be cleaned regularly with a
mild soap and water to prevent corrosion. To removeheavy soil, use MoparWheel Cleaner or select a non-
abrasive, non-acidic cleaner. Do not use scouring pads,
steel wool, a bristle brush or metal polishes. Only Mo-
parcleaners are recommended. Do not use oven cleaner.
Avoid automatic car washes that use acidic solutions or
harsh brushes that may damage the wheels’ protective
finish.
Interior Care
Use MoparTotal Clean to clean fabric upholstery and
carpeting.
Interior Trim should be cleaned starting with a damp
cloth, a damp cloth with MoparTotal Clean, then
MoparSpot & Stain Remover if absolutely necessary. Do
not use harsh cleaners or Armorall. Use MoparTotal
Clean to clean vinyl upholstery.
Leather Seat Care & Cleaning
MoparTotal Clean is specifically recommended for
leather upholstery.
MAINTAINING YOUR VEHICLE 391
7

Your leather upholstery can be best preserved by regular
cleaning with a damp soft cloth. Small particles of dirt
can act as an abrasive and damage the leather upholstery
and should be removed promptly with a damp cloth.
Stubborn soils can be removed easily with a soft cloth
and MoparTotal Clean. Care should be taken to avoid
soaking your leather upholstery with any liquid. Please
do not use polishes, oils, cleaning fluids, solvents, deter-
gents, or ammonia based cleaners to clean your leather
upholstery. Application of a leather conditioner is not
required to maintain the original condition.
WARNING!
Do not use volatile solvents for cleaning purposes.
Many are potentially flammable, and if used in
closed areas they may cause respiratory harm.
Cleaning Headlights
Your vehicle has plastic headlights that are lighter and
less susceptible to stone breakage than glass headlights.
Plastic is not as scratch resistant as glass and therefore
different lens cleaning procedures must be followed.
To minimize the possibility of scratching the lenses and
reducing light output, avoid wiping with a dry cloth. To
remove road dirt, wash with a mild soap solution fol-
lowed by rinsing.
Do not use abrasive cleaning components, solvents, steel
wool or other aggressive material to clean the lenses.
Glass Surfaces
All glass surfaces should be cleaned on a regular basis
with MoparGlass Cleaner or any commercial
household-type glass cleaner. Never use an abrasive type
cleaner. Use caution when cleaning inside rear windows
392 MAINTAINING YOUR VEHICLE

equipped with electric defrosters. Do not use scrapers or
other sharp instruments which may scratch the elements.
When cleaning the rear view mirror, spray cleaner on the
towel or rag that you are using. Do not spray cleaner
directly on the mirror.
Cleaning Plastic Instrument Cluster Lenses
The lenses in front of the instruments in this vehicle are
molded in clear plastic. When cleaning the lenses, care
must be taken to avoid scratching the plastic.
1. Clean with a wet soft rag. A mild soap solution may be
used, but do not use high alcohol content or abrasive
cleaners. If soap is used, wipe clean with a clean damp
rag.
2. Dry with a soft tissue.
Seat Belt Maintenance
Do not bleach, dye or clean the belts with chemical
solvents or abrasive cleaners. This will weaken the fabric.
Sun damage will also weaken the fabric.
If the belts need cleaning, use MoparTotal Clean, a mild
soap solution, or lukewarm water. Do not remove the
belts from the vehicle to wash them.
Replace the belts if they appear frayed or worn or if the
buckles do not work properly.
Dry with a soft tissue.
FUSE PANEL
Interior Fuses
The fuse panel is on the lower instrument panel just to
the left of the steering column.
MAINTAINING YOUR VEHICLE 393
7

CavityCartridge
FuseMini
FuseDescription
1 30 Amp
GreenAudio Amp (B+)
2 15 Amp
BlueSunroof (B+)
CavityCartridge
FuseMini
FuseDescription
3 10 Amp
RedHtd Mirror (EBL)
4 20 Amp
YellowRr Pwr Out (B+)
5 10 Amp
RedRr HVAC (R/O) (XK
Only)
6 Spare (B+)
7 20 Amp
YellowDoor Locks (B+)
8 15 Amp
BlueSteer Col Lock (B+)
(ELV)
9 20 Amp
YellowPwr Outlet (B+)
Fuse Panel Location
394 MAINTAINING YOUR VEHICLE

CavityCartridge
FuseMini
FuseDescription
10 10 Amp
RedFinal Drive Control
Module (FDCM),
Heater Ventilation,
Air Conditioning
(HVAC), Switch Bank,
Transfer Case Switch,
O/H, Heater Ventila-
tion, Air Conditioning
(HVAC) Relay, Rear
Park Assist
11 Spare (B+)
12 10 Amp
RedDoor Mods, Mem.
Sw, O/H Lamps, IP
Courtesy Lamps,
Glove Box Lamp (B+)
13 10 Amp
RedAutowipe (R/A)CavityCartridge
FuseMini
FuseDescription
14 20 Amp
YellowCigar Ltr (R/A)
15 10 Amp
RedTire Pressure Trans-
ducers (R/O)
16 10 Amp
RedSteering Control
Module (SCM), Diag.
Connector, Cluster
(B+)
17 15 Amp
BlueFlipper Glass (B+)
19 Spare
(R/S)
20 10 Amp
RedSentry Key Remote
Entry Module
(SKREEM), Cluster
(R/S)
MAINTAINING YOUR VEHICLE 395
7

CavityCartridge
FuseMini
FuseDescription
21 Spare
(Acc De-
lay)
22 15 Amp
BlueRear Wiper (B+)
24 10 Amp
RedPower Distribution
Center (PDC) Relays,
Final Drive Control
Module (FDCM),
Front Control Module
(FCM) (R/S), A580
(R/S)
25 10 Amp
RedShifter Assy (BTSI),
Trans. Case Switch,
ESP/ABS, Brake Supp
Rly Coil (R/S)Underhood Fuses (Power Distribution Center)
CavityCartridge
FuseMini
FuseDescription
1 40 Amp
GreenHVAC Blower
Power Distribution Center
396 MAINTAINING YOUR VEHICLE

CavityCartridge
FuseMini
FuseDescription
2 30 Amp
PinkPower Outlets
3 30 Amp
PinkRr Wiper/Ign R/O
4 30 Amp
PinkABS Pump
5 50 Amp
RedCabin Htr 1 (Diesel
Only)
6 50 Amp
RedAuto Shut Down
(ASD)
7 30 Amp
PinkRr HVAC (XK Only)
8 40 Amp
GreenAcc Delay/Seats
9 40 Amp
GreenPwr Liftgate (XK
Only)CavityCartridge
FuseMini
FuseDescription
10 40 Amp
GreenStarter/Junction Block
(JB) Power
11 30 Amp
PinkCig Ltr/T-Tow
12 40 Amp
GreenRear Window Defog-
ger (EBL)/Htd Mirror
13 40 Amp
GreenJunction Block (JB)
Power
14 50 Amp
RedCabin Htr 2 (Diesel
Only)
15 50 Amp
RedCabin Htr 3 (Diesel
Only)
16 25 Amp
NaturalIntegrated Power
Module (IPM)/Coils
17 Spare
MAINTAINING YOUR VEHICLE 397
7

CavityCartridge
FuseMini
FuseDescription
18 20 Amp
YellowEATX/AC Clutch
19 20 Amp
YellowIgn Sw
20 20 Amp
YellowPCM Batt (Gasoline
Only)
21 30 Amp
GreenABS Valves
22 20 Amp
YellowT-Tow (BUX)
23 20 Amp
YellowFinal Drive Control
Module (FDCM)
24 20 Amp
YellowFuel Pump
25 20 Amp
YellowFinal Drive Control
Module (FDCM)CavityCartridge
FuseMini
FuseDescription
26 15 Amp
BluePowertrain Control
Module (PCM) Auto
Shut Down (ASD)
(Diesel Only)
27 15 Amp
BlueBrake/Stop Lamps
28 25 Amp
NaturalNext Generation Con-
troller (NGC)/
Injectors
398 MAINTAINING YOUR VEHICLE

Underhood Fuses (Integrated Power Module)
CavityCartridge
FuseMini
FuseDescription
8 10 Amp
RedLt Park Lamps
CavityCartridge
FuseMini
FuseDescription
9 10 Amp
RedTrailer-Tow Park
Lamps
10 10 Amp
RedRt Park Lamps
12 20 Amp
YellowFront Control Module
(FCM) Batt #4
13 20 Amp
YellowFront Control Module
(FCM) Batt #2
14 20 Amp
YellowAdjustable Pedal
15 20 Amp
YellowFt Fog Lamps
16 20 Amp
YellowHorn
17 20 Amp
YellowRear Wiper
Integrated Power Module
MAINTAINING YOUR VEHICLE 399
7

CavityCartridge
FuseMini
FuseDescription
18 20 Amp
YellowFront Control Module
(FCM) Batt #1
19 20 Amp
YellowLt Trailer-Tow Stop/
Turn
20 20 Amp
YellowFront Control Module
(FCM) Batt #3
21 20 Amp
YellowRt Trailer-Tow Stop/
Turn
22 30 Amp
PinkFinal Drive Control
Module (FDCM)
MOD
23 50 Amp
RedRadiator Fan
27 15 Amp
BlueIgnition Off Draw
(IOD) #1
28 20 Amp
YellowIgnition Off Draw
(IOD) #2CavityCartridge
FuseMini
FuseDescription
29 10 Amp
RedOccupant Restraint
Controller (ORC) R/S
30 10 Amp
RedOccupant Restraint
Controller (ORC)
R/O
VEHICLE STORAGE
If you are leaving your vehicle dormant for more than 21
days you may want to take steps to protect your battery.
You may:
•Remove fuse #27 in the Intelligent Power Module
labeled Ignition-Off Draw (IOD#1).
•Or, disconnect the negative cable from the battery.
•Anytime you store your vehicle, or keep it out of
service (i.e. vacation) for two weeks or more, run the
air conditioning system at idle for about five minutes
