Multifunction Lever
The multifunction lever is located on the left side of the
steering column.
Turn Signals
Move the multifunction lever up or down and the arrows
on each side of the instrument cluster flash to show
proper operation of the front and rear turn signal lights.
NOTE:If either light remains on and does not flash, or
there is a very fast flash rate, check for a defective outside
light bulb. If an indicator fails to light when the lever is
moved, it would suggest that the indicator bulb is
defective.
Lane Change Assist
Tap the lever up or down once, without moving beyond
the detent, and the turn signal (right or left) will flash
three times then automatically turn off.
Flash-To-Pass
You can signal another vehicle with your headlights by
partially pulling the multifunction lever toward the steer-
ing wheel. This will cause the high beam headlights to
turn on until the lever is released.Multifunction Lever
188 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

5. TOW/HAUL Indicator Light — If EquippedThis light will illuminate when the TOW/
HAUL button has been selected. The TOW/
HAUL button is located in the center of the
instrument panel (below the climate controls).
6. Turn Signal Indicator The arrows will flash with the exterior turn signals
when the turn signal lever is operated. A tone will
chime, and an EVIC message will appear if the turn
signals are left on for more than 1 mile (1.6 km).
NOTE: If either indicator flashes at a rapid rate, check
for a defective outside light bulb.
7. High Beam Indicator Indicates that headlights are on high beam.
8. Front Fog Light Indicator — If Equipped This indicator will illuminate when the front fog
lights are on. 9. Hill Descent Control Indicator Light — If Equipped
The symbol indicates the status of the Hill
Decent Control (HDC) feature. The lamp will
be on solid when HDC is armed. HDC can only
be armed when the transfer case is in the “4WD
Low” position and the vehicle speed is less then 30 mph
(48 km/h). If these conditions are not met while attempt-
ing to use the HDC feature, the HDC indicator lamp will
flash on/off.
10. Electronic Vehicle Information Center (EVIC)
Display/Odometer Display
The odometer display shows the total distance the ve-
hicle has been driven.
U.S. Federal regulations require that upon transfer of
vehicle ownership, the seller certify to the purchaser the
correct mileage that the vehicle has been driven. If your
odometer needs to be repaired or serviced, the repair
technician should leave the odometer reading the same
4
UNDERSTANDING YOUR INSTRUMENT PANEL 287

12. Park/Headlight ON Indicator — If EquippedThis indicator will illuminate when the park
lights or headlights are turned on.
13. Seat Belt Reminder Light When the ignition switch is first turned to the
ON/RUN position, this light will turn on for four
to eight seconds as a bulb check. During the bulb
check, if the driver’s seat belt is unbuckled, a chime will
sound. After the bulb check or when driving, if the driver
or front passenger seat belt remains unbuckled, the Seat
Belt Indicator Light will flash or remain on continuously.
Refer to “Occupant Restraints” in “Things To Know
Before Starting Your Vehicle” for further information. 14. Brake Warning Light
This light monitors various brake functions,
including brake fluid level and parking brake
application. If the brake light turns on it may
indicate that the parking brake is applied, that
the brake fluid level is low, or that there is a problem with
the anti-lock brake system reservoir.
If the light remains on when the parking brake has been
disengaged, and the fluid level is at the full mark on the
master cylinder reservoir, it indicates a possible brake
hydraulic system malfunction or that a problem with the
Brake Booster has been detected by the Anti-Lock Brake
System (ABS) / Electronic Stability Control (ESC) system.
In this case, the light will remain on until the condition
has been corrected. If the problem is related to the brake
booster, the ABS pump will run when applying the brake
and a brake pedal pulsation may be felt during each stop.
290 UNDERSTANDING YOUR INSTRUMENT PANEL

Gasoline, Clean Air...................... 510
Gasoline, Reformulated ................... 510
Gauges Coolant Temperature .................. 294
Fuel .............................. 293
Speedometer ........................ 292
Tachometer ......................... 285
Gear Ranges ........................ 422,430
Gear Select Lever Override ................. 565
General Information ............20,29,151,222,508
Glass Cleaning .......................... 609
Gross Axle Weight Rating ...............521,524
Gross Vehicle Weight Rating .............521,523
GVWR ............................... 521
Hands-Free Phone (Uconnect™) ............. 121
Hazard Warning Flasher ................... 548
Headlights ............................ 617
Bulb Replacement .................... 618 Cleaning
........................... 608
On With Wipers ..................... 181
Replacing .......................... 618
Heated Mirrors ......................... 111
Heater ............................... 394
Heater, Engine Block ..................... 418
High Beam Indicator ..................... 287
Hill Descent Control ..................... 474
Hill Descent Control Indicator ............... 287
Hill Start Assist ......................... 471
Hitches Trailer Towing ....................... 528
Holder, Cup ........................... 264
HomeLink® (Garage Door Opener) Transmitter . . 242
Hood Release .......................... 178
Ignition ............................... 16
Key ............................. 14,16
Ignition Key Removal ..................... 16
10
INDEX 663

Light Bulbs............................. 98
Lights .............................. 98,180
Airbag ...................... 74,79,96,285
Anti-Lock .......................... 292
Automatic Headlights ................. 181
Back-Up ........................... 620
Brake Assist Warning .................. 476
Brake Warning ...................... 290
Bulb Replacement .................... 617
Cargo ............................. 270
Center Mounted Stop .................. 621
Daytime Running .................... 183
Dimmer Switch, Headlight .............. 180
Electronic Stability Program (ESP) Indicator . . 476
Exterior ............................ 98
Fog ............................ 287,619
Fuses ............................. 610
Hazard Warning Flasher ............... 548
Headlights ...................... 617,618Headlights On With Wipers
............. 181
High Beam Indicator .................. 287
Hill Descent Control Indicator ........... 287
Illuminated Entry ..................... 23
Low Fuel .......................... 306
Malfunction Indicator (Check Engine) ...... 285
Map Reading ....................... 186
Reading ........................ 186,240
Rear Servicing ....................... 620
Rear Tail ........................... 620
Seat Belt Reminder ................... 290
Security Alarm (Theft Alarm) ............ 293
Service ............................ 617
Service Engine Soon
(Malfunction Indicator) ................ 285
Side Marker ........................ 620
SmartBeams ........................ 182
Tire Pressure Monitoring (TPMS) ......... 288
Tow/Haul Indicator .................. 287
10
INDEX 665
