SERVICING AND MAINTENANCE353
The fuses protect electrical systems against
excessive current.
When a device does not work, you must check the
fuse element inside the blade fuse for a break/
melt.
Also, please be aware that using power outlets for
extended periods of time with the engine off may
result in vehicle battery discharge.

Blade Fuses

Underhood Fuses
The Power Distribution Center (PDC) is located on
the passenger side of the engine compartment,
behind the headlamp. This center contains
cartridge fuses, micro fuses, relays, and circuit
breakers. A description of each fuse and
component may be stamped on the inside cover,
otherwise the cavity number of each fuse is
stamped on the inside cover that corresponds to
the following chart.
1 — Fuse Element
2 — Blade Fuse with a good/functional fuse
element
3 — Blade fuse with a bad/not functional fuse
element (blown fuse)
CAUTION!
If it is necessary to wash the engine
compartment, take care not to directly hit the
fuse box, and the windshield wiper motor with
water.
CAUTION!
When installing the power distribution center
cover, it is important to ensure the cover is
properly positioned and fully latched. Failure to
do so may allow water to get into the power
distribution center and possibly result in an
electrical system failure.
8

23_WL_OM_EN_USC_t.book Page 353

SERVICING AND MAINTENANCE361
Interior Power Distribution Center
The Interior Power Distribution Center is located
underneath the steering column on the driver’s
side of the vehicle. This center contains cartridge
fuses, micro fuses, relays, and circuit breakers.
Fuse numbers are labeled next to each fuse cavity,
fuse descriptions correspond with the following
chart.

Interior PDC Location

NOTE:Fuses for safety systems must be serviced by an
authorized dealer.
CavityCartridge Fuse Micro FuseDescription

* If Equipped
F01 ––Spare
F02 25 Amp Clear –MTR Sunshade Sunroof Dual Pane /
MTR sunroof single Pane
F03 –15 Amp BlueMOD Seat Heater Frt (Steering
Wheel)*
F04 –10 Amp RedNight Vision Module / Driver
Monitoring Camera (DMC)
F05 ––Spare
F06 ––Spare
F07 ––Spare
F08 –15 Amp BlueAutomatic Gearbox Shifter Module
(AGSM) / Steering Column Lock
F09 ––Spare
8

23_WL_OM_EN_USC_t.book Page 361

SERVICING AND MAINTENANCE367
Rear Power Distribution Center
The Rear Power Distribution Center is located underneath the passenger seat. This center contains cartridge fuses, micro fuses, relays, and circuit breakers. The
following chart corresponds to the fuses inside.
NOTE:Fuses for safety systems must be serviced by an authorized dealer.
CavityCartridge Fuse Micro FuseDescription
* If Equipped
F01 ––Spare
F02 ––Spare
F03 Shunt –Auxiliary Battery Feed *
F04 ––Spare
F05 150 Amp Gray –Underhood PDC Feed *
F06 ––Spare
F07 ––Spare
F08 ––Spare
F09 ––Spare
F10 ––Spare
F11 50 Amp Red –Mod BCM Feed #2
F12 ––Spare
F13 ––Spare
F14 ––Spare
8

23_WL_OM_EN_USC_t.book Page 367
