Fig. 12 ENGINE/TRANSMISSION, 2.4L
KJ8W-91 CONNECTOR/GROUND/SPLICE LOCATION8Wa-91-25
CONNECTOR/GROUND/SPLICE LOCATION (Continued)

Fig. 13 ENGINE COMPARTMENT, 2.4L
8Wa - 91 - 26 8W-91 CONNECTOR/GROUND/SPLICE LOCATIONKJ
CONNECTOR/GROUND/SPLICE LOCATION (Continued)

Fig. 14 RIGHT REAR ENGINE COMPARTMENT, 2.4L
KJ8W-91 CONNECTOR/GROUND/SPLICE LOCATION8Wa-91-27
CONNECTOR/GROUND/SPLICE LOCATION (Continued)

Fig. 15 ENGINE, 2.4L
8Wa - 91 - 28 8W-91 CONNECTOR/GROUND/SPLICE LOCATIONKJ
CONNECTOR/GROUND/SPLICE LOCATION (Continued)

Fig. 16 RIGHT REAR ENGINE COMPARTMENT, 2.4L
KJ8W-91 CONNECTOR/GROUND/SPLICE LOCATION8Wa-91-29
CONNECTOR/GROUND/SPLICE LOCATION (Continued)

Fig. 17 DIESEL ENGINE
8Wa - 91 - 30 8W-91 CONNECTOR/GROUND/SPLICE LOCATIONKJ
CONNECTOR/GROUND/SPLICE LOCATION (Continued)

Fig. 18 DIESEL ENGINE COMPARTMENT
KJ8W-91 CONNECTOR/GROUND/SPLICE LOCATION8Wa-91-31
CONNECTOR/GROUND/SPLICE LOCATION (Continued)

Fig. 19 DIESEL ENGINE COMPARTMENT
8Wa - 91 - 32 8W-91 CONNECTOR/GROUND/SPLICE LOCATIONKJ
CONNECTOR/GROUND/SPLICE LOCATION (Continued)

Fig. 20 LEFT SIDE DIESEL ENGINE
KJ8W-91 CONNECTOR/GROUND/SPLICE LOCATION8Wa-91-33
CONNECTOR/GROUND/SPLICE LOCATION (Continued)

Fig. 21 FRONT DIESEL ENGINE
8Wa - 91 - 34 8W-91 CONNECTOR/GROUND/SPLICE LOCATIONKJ
CONNECTOR/GROUND/SPLICE LOCATION (Continued)
