Throttle pos sensor JEEP LIBERTY 2002 KJ / 1.G Service Manual

SPECIFICATIONS
TORQUE
DESCRIPTION N-m Ft. Lbs. In. Lbs.
Accelerator Pedal Bracket
Mounting Nuts12 - 105
Crankshaft Position Sensor - 2.4L 28 21 -
Crankshaft Position Sensor - 3.7L 28 21 -
Camshaft Position Sensor - 2.4L 12 - 106
Camshaft Position Sensor - 3.7L 12 - 106
Engine Coolant Temperature
Sensor11 - 9 6
EVAP Canister-to-Body Bolts 48 35 -
EVAP Canister-to-Canis. Bracket
Bolt/Nut11 - 100
Fuel Filler Hose Clamp at Tank 3 - 30
Fuel Filler Housing-to-Body
Screws2-17
Fuel Filter Mounting Nut at Tank 5.5 - 49
Fuel Pump Module Access Plate
Nuts3-26
Fuel Rail Mounting Bolts - 3.7L 11 - 100
Fuel Rail Mounting Bolts - 2.4L 28 - 250
Fuel Tank Heat Sheild Nuts 5.5 - 49
Fuel Tank Mounting Strap Bolts 61 45 -
Fuel Tank Skid Plate and Trailer
Hitch88 65 -
IAC Motor Mounting Screws 7 - 60
Leak Detection Pump Mounting
Bracket-to-Fuel Tank Nuts5.5 - 49
Leak Detection Pump-to-Bracket
Nuts1.2 - 11
Map Sensor Mounting Screws 3 - 25
PCM-to-Mounting Bracket
Mounting Screws4-35
Power Steering Pressure Switch 14-22 - 124-195
TPS Mounting Screws 7 - 60
Throttle Body Mounting Bolts 11 - 100
Oxygen Sensors 30 22 -
25 - 26 EVAPORATIVE EMISSIONSKJ
EVAPORATIVE EMISSIONS (Continued)

PLATE LAMP UNIT - INSTALLATION,
LICENSE...........................8L-46
PLATE LAMP UNIT - REMOVAL, LICENSE . . 8L-45
PLATES - INSTALLATION, EXTERIOR
NAME............................23-141
PLATES - REMOVAL, EXTERIOR NAME . . . 23-140
PLUG - CLEANING SPARK PLUGS,
SPARK .............................8I-15
PLUG - DESCRIPTION, SPARK...........8I-12
PLUG - INSTALLATION, SPARK..........8I-15
PLUG - OPERATION, SPARK............8I-12
PLUG - REMOVAL, SPARK..............8I-15
PLUG CABLE RESISTANCE, 2.4L - SPARK . . . 8I-3
PLUG CONDITIONS - DIAGNOSIS AND
TESTING, SPARK.....................8I-13
PLUGS - STANDARD PROCEDURE,
ENGINE CORE AND OIL GALLERY........9-10
PLUGS, SPARK PLUG - CLEANING
SPARK .............................8I-15
PLUGS, SPECIFICATIONS - SPARK........8I-3
POLISHING - DESCRIPTION, FINESSE
SANDING/BUFFING..................23-163
PORT - DESCRIPTION, REFRIGERANT
SYSTEM SERVICE.....................24-2
PORT - OPERATION, REFRIGERANT
SYSTEM SERVICE.....................24-2
POSITION LAMP BULB - INSTALLATION,
FRONT.............................8L-28
POSITION LAMP BULB - REMOVAL,
FRONT.............................8L-28
POSITION SENSOR - DESCRIPTION . 21-209,21-247
POSITION SENSOR - DESCRIPTION,
CRANKSHAFT.......................14-30
POSITION SENSOR - DESCRIPTION,
THROTTLE..........................14-47
POSITION SENSOR - INSTALLATION....21-210,
21-247
POSITION SENSOR - INSTALLATION,
CRANKSHAFT.......................14-32
POSITION SENSOR - INSTALLATION,
THROTTLE..........................14-48
POSITION SENSOR - OPERATION . 21-209,21-247
POSITION SENSOR - OPERATION,
CRANKSHAFT.......................14-31
POSITION SENSOR - OPERATION,
THROTTLE..........................14-47
POSITION SENSOR - REMOVAL . . 21-210,21-247
POSITION SENSOR - REMOVAL,
CRANKSHAFT.......................14-31
POSITION SENSOR - REMOVAL,
THROTTLE..........................14-47
POSITION SWITCH - DESCRIPTION,
CLUTCH PEDAL.......................6-11
POSITION SWITCH - DIAGNOSIS AND
TESTING, CLUTCH PEDAL...............6-11
POSITION SWITCH - OPERATION,
CLUTCH PEDAL.......................6-11
POTENTIAL - STANDARD PROCEDURE,
TESTING OF VOLTAGE..............8W-01-9
POWER BRAKE BOOSTER -
DESCRIPTION........................5-21
POWER BRAKE BOOSTER -
INSTALLATION........................5-23
POWER BRAKE BOOSTER - OPERATION . . . 5-21
POWER BRAKE BOOSTER - REMOVAL.....5-22
POWER DISTRIBUTION - DESCRIPTION . 8W-97-1
POWER DISTRIBUTION - OPERATION . . 8W-97-1
POWER DISTRIBUTION CENTER -
DESCRIPTION.....................8W-97-6
POWER DISTRIBUTION CENTER -
OPERATION.......................8W-97-7
POWER DISTRIBUTION CENTER -
REMOVAL........................8W-97-7
POWER DISTRIBUTION CENTER
ASSEMBLY, ASSEMBLY.............8W-97-10
POWER DISTRIBUTION CENTER
DISASSEMBLY, DISASSEMBLY........8W-97-7
POWER DISTRIBUTION SYSTEMS,
SPECIAL TOOLS...................8W-97-2
POWER GROUNDS - DESCRIPTION......8E-13
POWER LOCKS - DESCRIPTION
..........8N-1
POWER LOCKS - DIAGNOSIS AND
TESTING
............................8N-3
POWER LOCKS - OPERATION
............8N-3
POWER MIRROR SWITCH - DIAGNOSIS
AND TESTING
.......................8N-12
POWER MIRROR SWITCH -
INSTALLATION
......................8N-13POWER MIRROR SWITCH - REMOVAL . . . 8N-13
POWER MIRRORS - DESCRIPTION......8N-11
POWER MIRRORS - DIAGNOSIS AND
TESTING...........................8N-11
POWER MIRRORS - OPERATION........8N-11
POWER OUTLET - DESCRIPTION.....8W-97-11
POWER OUTLET - DIAGNOSIS AND
TESTING........................8W-97-11
POWER OUTLET - INSTALLATION....8W-97-13
POWER OUTLET - OPERATION.......8W-97-11
POWER OUTLET - REMOVAL........8W-97-12
POWER SEAT SWITCH - DESCRIPTION,
LEFT..............................8N-16
POWER SEAT SWITCH - DESCRIPTION,
RIGHT.............................8N-19
POWER SEAT SWITCH - DIAGNOSIS
AND TESTING, LEFT..................8N-17
POWER SEAT SWITCH - DIAGNOSIS
AND TESTING, RIGHT.................8N-19
POWER SEAT SWITCH - INSTALLATION,
LEFT..............................8N-18
POWER SEAT SWITCH - INSTALLATION,
RIGHT.............................8N-20
POWER SEAT SWITCH - OPERATION,
LEFT..............................8N-17
POWER SEAT SWITCH - OPERATION,
RIGHT.............................8N-19
POWER SEAT SWITCH - REMOVAL, LEFT . 8N-18
POWER SEAT SWITCH - REMOVAL,
RIGHT.............................8N-20
POWER SEATS - DESCRIPTION...........8N-14
POWER SEATS - DIAGNOSIS AND
TESTING...........................8N-15
POWER SEATS - OPERATION...........8N-15
POWER STEERING FLOW AND
PRESSURE - DIAGNOSIS AND
TESTING............................19-3
POWER STEERING PRESSURE SWITCH -
DESCRIPTION.......................19-22
POWER STEERING PRESSURE SWITCH -
INSTALLATION.......................19-22
POWER STEERING PRESSURE SWITCH -
OPERATION.........................19-22
POWER STEERING PRESSURE SWITCH -
REMOVAL..........................19-22
POWER STEERING PUMP - INITIAL
OPERATION - STANDARD PROCEDURE . . . 19-18
POWER STEERING PUMP, SPECIAL
TOOLS.............................19-20
POWER STEERING SYSTEM -
DIAGNOSIS AND TESTING..............19-1
POWER WINDOWS - DESCRIPTION......8N-21
POWER WINDOWS - DIAGNOSIS AND
TESTING...........................8N-21
POWER WINDOWS - OPERATION........8N-21
POWERED - STARTER MOTOR, GAS......8F-39
POWERED - TORQUE, GAS.............8F-38
POWERING SEVERAL LOADS -
STANDARD PROCEDURE, TESTING
FOR A SHORT TO GROUND ON FUSES . 8W-01-9
PRECAUTIONS - CAUTION,
REFRIGERANT HOSES/LINES/TUBES
......24-40
PRECAUTIONS - OPERATION, SERVICE
....19-5
PRECAUTIONS AND WARNINGS,
WARNING - SAFETY
...................23-1
PRECAUTIONS, WARNING -
WINDSHIELD SAFETY
................23-173
PREFERENCES - STANDARD
PROCEDURE, RKE TRANSMITTER
CUSTOMER
..........................8N-8
PRELIMINARY - DIAGNOSIS AND
TESTING
...........................21-78
PRELIMINARY CHECKS - DIAGNOSIS
AND TESTING
.........................7-3
PREPARATION - STANDARD
PROCEDURE, ENGINE GASKET
SURFACE
.............................9-9
PRESS CONTAINER - DESCRIPTION,
COOLANT RECOVERY
..................7-19
PRESS CONTAINER - OPERATION,
COOLANT RECOVERY
..................7-19
PRESSURE - DIAGNOSIS AND TESTING,
CYLINDER COMPRESSION
...............9-8
PRESSURE - DIAGNOSIS AND TESTING,
ENGINE OIL
..........................9-60
PRESSURE - DIAGNOSIS AND TESTING,
POWER STEERING FLOW
...............19-3PRESSURE BLEEDING - STANDARD
PROCEDURE..........................5-5
PRESSURE CAP - CLEANING, RADIATOR . . . 7-25
PRESSURE CAP - DESCRIPTION,
RADIATOR...........................7-25
PRESSURE CAP - DIAGNOSIS AND
TESTING, RADIATOR...................7-25
PRESSURE CAP - INSPECTION,
RADIATOR...........................7-25
PRESSURE CAP - OPERATION,
RADIATOR...........................7-25
PRESSURE HOSE - INSTALLATION.......19-21
PRESSURE HOSE - REMOVAL..........19-21
PRESSURE INDICATOR - DESCRIPTION,
LOW OIL ...........................8J-23
PRESSURE INDICATOR - OPERATION,
LOW OIL ...........................8J-23
PRESSURE LEAK DOWN TEST -
DIAGNOSIS AND TESTING, FUEL.........14-3
PRESSURE LEAKAGE - DIAGNOSIS AND
TESTING, CYLINDER COMBUSTION........9-8
PRESSURE (LP) SENSOR -
DESCRIPTION, LINE.................21-144
PRESSURE (LP) SENSOR -
INSTALLATION, LINE.................21-144
PRESSURE (LP) SENSOR - OPERATION,
LINE..............................21-144
PRESSURE (LP) SENSOR - REMOVAL,
LINE..............................21-144
PRESSURE REGULATOR - DESCRIPTION,
FUEL..............................14-13
PRESSURE REGULATOR -
INSTALLATION, FUEL...................14-14
PRESSURE REGULATOR - OPERATION,
FUEL..............................14-14
PRESSURE REGULATOR - REMOVAL,
FUEL..............................14-14
PRESSURE RELEASE - STANDARD
PROCEDURE, FUEL SYSTEM.............14-4
PRESSURE RELIEF VALVE -
DESCRIPTION, HIGH..................24-42
PRESSURE RELIEF VALVE - OPERATION,
HIGH..............................24-42
PRESSURE SENSOR/SWITCH -
DESCRIPTION, OIL....................9-65
PRESSURE SENSOR/SWITCH -
INSTALLATION, OIL....................9-65
PRESSURE SENSOR/SWITCH -
OPERATION, OIL......................9-65
PRESSURE SENSOR/SWITCH -
REMOVAL, OIL.......................9-65
PRESSURE, SPECIFICATIONS - FUEL
SYSTEM............................14-5
PRESSURE SWITCH - DESCRIPTION, A/C
HIGH..............................24-17
PRESSURE SWITCH - DESCRIPTION, A/C
LOW ..............................24-18
PRESSURE SWITCH - DESCRIPTION,
POWER STEERING...................19-22
PRESSURE SWITCH - DIAGNOSIS AND
TESTING, A/C HIGH...................24-18
PRESSURE SWITCH - DIAGNOSIS AND
TESTING, A/C LOW
...................24-19
PRESSURE SWITCH - INSTALLATION,
A/C HIGH
...........................24-18
PRESSURE SWITCH - INSTALLATION,
A/C LOW
...........................24-19
PRESSURE SWITCH - INSTALLATION,
POWER STEERING
...................19-22
PRESSURE SWITCH - OPERATION, A/C
HIGH
..............................24-18
PRESSURE SWITCH - OPERATION, A/C
LOW
..............................24-18
PRESSURE SWITCH - OPERATION,
POWER STEERING
...................19-22
PRESSURE SWITCH - REMOVAL, A/C
HIGH
..............................24-18
PRESSURE SWITCH - REMOVAL, A/C
LOW
..............................24-19
PRESSURE SWITCH - REMOVAL,
POWER STEERING
...................19-22
PRESSURE TEST - DIAGNOSIS AND
TESTING, FUEL PUMP
.................14-15
PRESSURE TEST - DIAGNOSIS AND
TESTING, HYDRAULIC
.................21-79
PRIMARY WEATHERSTRIP -
INSTALLATION, DOOR
................23-185
KJINDEX 19
Description Group-Page Description Group-Page Description Group-Page

SEAL - INSTALLATION, REAR OUTPUT
SHAFT............................21-212
SEAL - NV1500 - INSTALLATION,
EXTENSION HOUSING.................21-32
SEAL - NV1500 - REMOVAL, EXTENSION
HOUSING...........................21-32
SEAL - NV3550 - INSTALLATION,
EXTENSION HOUSING.................21-74
SEAL - NV3550 - REMOVAL, EXTENSION
HOUSING...........................21-74
SEAL - REAR - INSTALLATION,
CRANKSHAFT OIL.....................9-48
SEAL - REAR - REMOVAL, CRANKSHAFT
OIL ................................9-48
SEAL - REMOVAL, ADAPTER HOUSING . . 21-124
SEAL - REMOVAL, A-PILLAR...........23-185
SEAL - REMOVAL, COWL/PLENUM......23-187
SEAL - REMOVAL, COWL/PLENUM
WINDOW BAFFLE...................23-187
SEAL - REMOVAL, FRONT OUTPUT
SHAFT......................21-208,21-246
SEAL - REMOVAL, GLASS PANEL.......23-178
SEAL - REMOVAL, OIL PUMP FRONT....21-152
SEAL - REMOVAL, PINION.....3-102,3-38,3-68
SEAL - REMOVAL, REAR OUTPUT SHAFT . 21-210
SEAL AREA LEAKS - DIAGNOSIS AND
TESTING, REAR.......................9-61
SEALER LOCATIONS - SPECIFICATIONS . . . 23-87
SEALS - DESCRIPTION, VALVE GUIDE . 9-29,9-38
SEALS - INSTALLATION, AXLE SHAFT....3-102,
3-38
SEALS - REMOVAL, AXLE SHAFT....3-101,3-37
SEAT - FRONT - INSTALLATION........23-165
SEAT - FRONT - REMOVAL............23-165
SEAT - REAR - INSTALLATION.........23-168
SEAT - REAR - REMOVAL.............23-168
SEAT BACK - FRONT - INSTALLATION . . . 23-166
SEAT BACK - FRONT - REMOVAL.......23-166
SEAT BACK - REAR - INSTALLATION....23-168
SEAT BACK - REAR - REMOVAL........23-168
SEAT BACK COVER - FRONT -
INSTALLATION......................23-167
SEAT BACK COVER - FRONT - REMOVAL . 23-166
SEAT BACK COVER - REAR -
INSTALLATION......................23-169
SEAT BACK COVER - REAR - REMOVAL . . 23-169
SEAT BACK CUSHION - FRONT -
INSTALLATION......................23-167
SEAT BACK CUSHION - FRONT -
REMOVAL.........................23-167
SEAT BACK CUSHION - REAR -
INSTALLATION......................23-170
SEAT BACK CUSHION - REAR -
REMOVAL.........................23-170
SEAT BACK FRAME - REAR -
INSTALLATION......................23-171
SEAT BACK FRAME - REAR - REMOVAL . . 23-171
SEAT BACK LATCH / LOCK -
INSTALLATION, FOLDING REAR........23-170
SEAT BACK LATCH / LOCK - REMOVAL,
FOLDING REAR.....................23-170
SEAT BACK LATCH STRIKER -
INSTALLATION, REAR................23-171
SEAT BACK LATCH STRIKER - REMOVAL,
REAR.............................23-170
SEAT BACK RECLINER - FRONT -
INSTALLATION......................23-166
SEAT BACK RECLINER - FRONT -
REMOVAL.........................23-166
SEAT BELT & RETRACTOR -
INSTALLATION, FRONT................8O-24
SEAT BELT & RETRACTOR -
INSTALLATION, REAR CENTER..........8O-33
SEAT BELT & RETRACTOR -
INSTALLATION, REAR OUTBOARD.......8O-34
SEAT BELT & RETRACTOR - REMOVAL,
FRONT.............................8O-23
SEAT BELT & RETRACTOR - REMOVAL,
REAR CENTER.......................8O-32
SEAT BELT & RETRACTOR - REMOVAL,
REAR OUTBOARD....................8O-33
SEAT BELT BUCKLE - INSTALLATION,
FRONT
.............................8O-26
SEAT BELT BUCKLE - INSTALLATION,
REAR
..............................8O-35
SEAT BELT BUCKLE - REMOVAL, FRONT
. . 8O-25
SEAT BELT BUCKLE - REMOVAL, REAR
. . . 8O-34
SEAT BELT SWITCH - DESCRIPTION
.....8O-35SEAT BELT SWITCH - OPERATION.......8O-36
SEAT BELT TENSIONER - DESCRIPTION . . . 8O-36
SEAT BELT TENSIONER - OPERATION....8O-36
SEAT BELT TURNING LOOP ADJUSTER -
INSTALLATION......................8O-38
SEAT BELT TURNING LOOP ADJUSTER -
REMOVAL..........................8O-37
SEAT CUSHION - FRONT -
INSTALLATION......................23-167
SEAT CUSHION - FRONT - REMOVAL....23-167
SEAT CUSHION - REAR - INSTALLATION . 23-171
SEAT CUSHION - REAR - REMOVAL.....23-171
SEAT CUSHION COVER - FRONT -
INSTALLATION......................23-167
SEAT CUSHION COVER - FRONT -
REMOVAL.........................23-167
SEAT CUSHION SIDE SHIELDS -
INSTALLATION......................23-167
SEAT CUSHION SIDE SHIELDS -
REMOVAL.........................23-167
SEAT ELEMENT - DESCRIPTION, HEATED . 8G-13
SEAT ELEMENT - DIAGNOSIS AND
TESTING, HEATED....................8G-13
SEAT ELEMENT - OPERATION, HEATED . . . 8G-13
SEAT HEATER SWITCH - DESCRIPTION,
DRIVER............................8G-11
SEAT HEATER SWITCH - DESCRIPTION,
PASSENGER........................8G-14
SEAT HEATER SWITCH - INSTALLATION,
DRIVER............................8G-13
SEAT HEATER SWITCH - INSTALLATION,
PASSENGER........................8G-15
SEAT HEATER SWITCH - OPERATION,
DRIVER............................8G-12
SEAT HEATER SWITCH - OPERATION,
PASSENGER........................8G-14
SEAT HEATER SWITCH - REMOVAL,
DRIVER............................8G-13
SEAT HEATER SWITCH - REMOVAL,
PASSENGER........................8G-15
SEAT MODULE - DESCRIPTION, HEATED . . 8E-21
SEAT MODULE - DIAGNOSIS AND
TESTING, HEATED....................8E-22
SEAT MODULE - INSTALLATION, HEATED . . 8E-24
SEAT MODULE - OPERATION, HEATED....8E-21
SEAT MODULE - REMOVAL, HEATED.....8E-24
SEAT RISER - INSTALLATION, MANUAL . . 23-168
SEAT RISER - REMOVAL, MANUAL......23-167
SEAT SENSOR - DIAGNOSIS AND
TESTING, HEATED....................8G-14
SEAT SWITCH - DESCRIPTION, LEFT
POWER............................8N-16
SEAT SWITCH - DESCRIPTION, RIGHT
POWER............................8N-19
SEAT SWITCH - DIAGNOSIS AND
TESTING, HEATED..............8G-12,8G-14
SEAT SWITCH - DIAGNOSIS AND
TESTING, LEFT POWER...............8N-17
SEAT SWITCH - DIAGNOSIS AND
TESTING, RIGHT POWER..............8N-19
SEAT SWITCH - INSTALLATION, LEFT
POWER............................8N-18
SEAT SWITCH - INSTALLATION, RIGHT
POWER............................8N-20
SEAT SWITCH - OPERATION, LEFT
POWER............................8N-17
SEAT SWITCH - OPERATION, RIGHT
POWER............................8N-19
SEAT SWITCH - REMOVAL, LEFT POWER . 8N-18
SEAT SWITCH - REMOVAL, RIGHT
POWER............................8N-20
SEAT SYSTEM - DESCRIPTION, HEATED . . 8G-10
SEAT SYSTEM - DIAGNOSIS AND
TESTING, HEATED
....................8G-11
SEAT SYSTEM - OPERATION, HEATED
....8G-10
SEAT TRACK - DESCRIPTION
...........8N-15
SEAT TRACK - DIAGNOSIS AND TESTING
. 8N-16
SEAT TRACK - INSTALLATION
..........23-168
SEAT TRACK - INSTALLATION
..........8N-16
SEAT TRACK - OPERATION
.............8N-15
SEAT TRACK - REMOVAL
.............23-168
SEAT TRACK - REMOVAL
..............8N-16
SEATBELT INDICATOR - DESCRIPTION
....8J-27
SEATBELT INDICATOR - OPERATION
......8J-28
SEATS - DESCRIPTION, INTAKE/
EXHAUST VALVES
.....................9-26
SEATS - DESCRIPTION, POWER
.........8N-14SEATS - DIAGNOSIS AND TESTING,
POWER............................8N-15
SEATS - INSTALLATION, INTAKE/
EXHAUST VALVES.................9-28,9-36
SEATS - OPERATION, POWER..........8N-15
SEATS - REMOVAL, INTAKE/EXHAUST
VALVES .........................9-27,9-35
SECTION IDENTIFICATION AND
INFORMATION - DESCRIPTION........8W-01-6
SECURITY - DESCRIPTION, VEHICLE
THEFT..............................8Q-1
SECURITY - OPERATION, VEHICLE THEFT . . 8Q-3
SECURITY INDICATOR - DESCRIPTION....8J-28
SECURITY INDICATOR - OPERATION.....8J-28
SECURITY SYSTEM - DIAGNOSIS AND
TESTING, VEHICLE THEFT..............8Q-6
SENDING UNIT - DIAGNOSIS AND
TESTING, FUEL LEVEL.................14-9
SENDING UNIT / SENSOR -
DESCRIPTION, FUEL LEVEL.............14-9
SENDING UNIT / SENSOR -
INSTALLATION, FUEL LEVEL............14-10
SENDING UNIT / SENSOR - OPERATION,
FUEL LEVEL..........................14-9
SENDING UNIT / SENSOR - REMOVAL,
FUEL LEVEL..........................14-9
SENSE - DESCRIPTION, IGNITION
CIRCUIT............................8E-13
SENSE - OPERATION, IGNITION CIRCUIT . . 8E-15
SENSE - PCM INPUT - OPERATION, ASD . . . 8I-4
SENSITIVE DEVICES - STANDARD
PROCEDURE, ELECTROSTATIC
DISCHARGE (ESD).................8W-01-8
SENSOR - DESCRIPTION, AMBIENT
TEMP..............................8M-9
SENSOR - DESCRIPTION, BATTERY
TEMPERATURE......................8F-24
SENSOR - DESCRIPTION, CRANKSHAFT
POSITION..........................14-30
SENSOR - DESCRIPTION, ENGINE
COOLANT TEMPERATURE...............7-19
SENSOR - DESCRIPTION, FRONT
IMPACT............................8O-21
SENSOR - DESCRIPTION, FUEL LEVEL
SENDING UNIT.......................14-9
SENSOR - DESCRIPTION, INPUT SPEED . 21-143
SENSOR - DESCRIPTION, INTAKE AIR
TEMPERATURE......................14-36
SENSOR - DESCRIPTION, KNOCK........8I-11
SENSOR - DESCRIPTION, LINE
PRESSURE (LP)....................21-144
SENSOR - DESCRIPTION, MAP..........14-38
SENSOR - DESCRIPTION, OUTPUT
SPEED............................21-152
SENSOR - DESCRIPTION, OXYGEN.......14-40
SENSOR - DESCRIPTION, POSITION....21-209,
21-247
SENSOR - DESCRIPTION, THROTTLE
POSITION..........................14-47
SENSOR - DESCRIPTION,
TRANSMISSION RANGE..............21-168
SENSOR - DESCRIPTION,
TRANSMISSION TEMPERATURE........21-170
SENSOR - DIAGNOSIS AND TESTING,
AMBIENT TEMPERATURE...............8M-9
SENSOR - DIAGNOSIS AND TESTING,
HEATED SEAT .......................8G-14
SENSOR - INSTALLATION, BATTERY
TEMPERATURE......................8F-24
SENSOR - INSTALLATION, CRANKSHAFT
POSITION..........................14-32
SENSOR - INSTALLATION, ENGINE
COOLANT TEMPERATURE...............7-21
SENSOR - INSTALLATION, FRONT
IMPACT............................8O-22
SENSOR - INSTALLATION, FRONT
WHEEL SPEED........................5-34
SENSOR - INSTALLATION, FUEL LEVEL
SENDING UNIT......................14-10
SENSOR - INSTALLATION, INPUT SPEED . 21-143
SENSOR - INSTALLATION, INTAKE AIR
TEMPERATURE
......................14-38
SENSOR - INSTALLATION, KNOCK
........8I-12
SENSOR - INSTALLATION, LINE
PRESSURE (LP)
....................21-144
SENSOR - INSTALLATION, MAP
.........14-40
SENSOR - INSTALLATION, OUTPUT
SPEED
............................21-152
KJINDEX 23
Description Group-Page Description Group-Page Description Group-Page

SENSOR - INSTALLATION, OXYGEN......14-43
SENSOR - INSTALLATION, POSITION....21-210,
21-247
SENSOR - INSTALLATION, REAR WHEEL
SPEED..............................5-35
SENSOR - INSTALLATION, THROTTLE
POSITION..........................14-48
SENSOR - OPERATION, AMBIENT TEMP . . . 8M-9
SENSOR - OPERATION, BATTERY
TEMPERATURE......................8F-24
SENSOR - OPERATION, CRANKSHAFT
POSITION..........................14-31
SENSOR - OPERATION, ENGINE
COOLANT TEMPERATURE...............7-20
SENSOR - OPERATION, FRONT IMPACT . . . 8O-21
SENSOR - OPERATION, FUEL LEVEL
SENDING UNIT.......................14-9
SENSOR - OPERATION, INPUT SPEED . . . 21-143
SENSOR - OPERATION, INTAKE AIR
TEMPERATURE......................14-36
SENSOR - OPERATION, KNOCK..........8I-11
SENSOR - OPERATION, LINE PRESSURE
(LP)..............................21-144
SENSOR - OPERATION, MAP...........14-38
SENSOR - OPERATION, OUTPUT SPEED . . 21-152
SENSOR - OPERATION, OXYGEN........14-40
SENSOR - OPERATION, POSITION......21-209,
21-247
SENSOR - OPERATION, THROTTLE
POSITION..........................14-47
SENSOR - OPERATION, TRANSMISSION
RANGE............................21-168
SENSOR - OPERATION, TRANSMISSION
TEMPERATURE.....................21-170
SENSOR - REMOVAL, BATTERY
TEMPERATURE......................8F-24
SENSOR - REMOVAL, CRANKSHAFT
POSITION..........................14-31
SENSOR - REMOVAL, ENGINE COOLANT
TEMPERATURE.......................7-20
SENSOR - REMOVAL, FRONT IMPACT....8O-22
SENSOR - REMOVAL, FRONT WHEEL
SPEED..............................5-34
SENSOR - REMOVAL, FUEL LEVEL
SENDING UNIT.......................14-9
SENSOR - REMOVAL, INPUT SPEED.....21-143
SENSOR - REMOVAL, INTAKE AIR
TEMPERATURE......................14-37
SENSOR - REMOVAL, KNOCK...........8I-12
SENSOR - REMOVAL, LINE PRESSURE
(LP)..............................21-144
SENSOR - REMOVAL, MAP.............14-39
SENSOR - REMOVAL, OUTPUT SPEED . . . 21-152
SENSOR - REMOVAL, OXYGEN..........14-41
SENSOR - REMOVAL, POSITION . . 21-210,21-247
SENSOR - REMOVAL, REAR WHEEL
SPEED..............................5-35
SENSOR - REMOVAL, THROTTLE
POSITION..........................14-47
SENSOR CIRCUIT - DIAGNOSIS AND
TESTING, AMBIENT TEMPERATURE.......8M-9
SENSOR RETURN - DESCRIPTION.......8E-14
SENSOR/SWITCH - DESCRIPTION, OIL
PRESSURE..........................9-65
SENSOR/SWITCH - INSTALLATION, OIL
PRESSURE
..........................9-65
SENSOR/SWITCH - OPERATION, OIL
PRESSURE
..........................9-65
SENSOR/SWITCH - REMOVAL, OIL
PRESSURE
..........................9-65
SENTRY KEY IMMOBILIZER MODULE -
DESCRIPTION
.......................8E-15
SENTRY KEY IMMOBILIZER MODULE -
INSTALLATION
.......................8E-18
SENTRY KEY IMMOBILIZER MODULE -
OPERATION
.........................8E-16
SENTRY KEY IMMOBILIZER MODULE -
REMOVAL
..........................8E-17
SENTRY KEY TRANSPONDER
PROGRAMMING - STANDARD
PROCEDURE
.........................8Q-8
SERPENTINE DRIVE BELT - DIAGNOSIS
AND TESTING
........................7-15
SERVO - DESCRIPTION
.................8P-4
SERVO - INSTALLATION
................8P-5
SERVO - OPERATION
..................8P-4
SERVO - REMOVAL
....................8P-4SETTING TRANSMITTER CODES -
STANDARD PROCEDURE...............8M-9
SEVERAL LOADS - STANDARD
PROCEDURE, TESTING FOR A SHORT
TO GROUND ON FUSES POWERING . . . 8W-01-9
SHAFT - CAUTION, HALF................3-10
SHAFT - DIAGNOSIS AND TESTING,
HALF...............................3-10
SHAFT - DIAGNOSIS AND TESTING,
PROPELLER...........................3-1
SHAFT - FRONT - INSTALLATION,
PROPELLER...........................3-6
SHAFT - FRONT - REMOVAL,
PROPELLER...........................3-6
SHAFT - INSTALLATION, BALANCE........9-74
SHAFT - INSTALLATION, HALF...........3-11
SHAFT - INSTALLATION, IDLER..........9-77
SHAFT - INSTALLATION, INTERMEDIATE . . 19-11
SHAFT - REAR - INSTALLATION,
PROPELLER...........................3-7
SHAFT - REAR - REMOVAL, PROPELLER....3-7
SHAFT - REMOVAL, BALANCE...........9-74
SHAFT - REMOVAL, HALF...............3-10
SHAFT - REMOVAL, IDLER..............9-77
SHAFT - REMOVAL, INTERMEDIATE......19-11
SHAFT ANGLE - STANDARD
PROCEDURES, PROPELLER..............3-3
SHAFT SEAL - INSTALLATION, FRONT
OUTPUT.....................21-208,21-246
SHAFT SEAL - INSTALLATION, REAR
OUTPUT............................21-212
SHAFT SEAL - REMOVAL, FRONT
OUTPUT.....................21-208,21-246
SHAFT SEAL - REMOVAL, REAR OUTPUT . 21-210
SHAFT SEALS - INSTALLATION, AXLE....3-102,
3-38
SHAFT SEALS - REMOVAL, AXLE....3-101,3-37
SHAFT, SPECIFICATIONS - HALF..........3-11
SHAFT, SPECIFICATIONS - PROPELLER.....3-6
SHAFTS - INSTALLATION, AXLE . 3-101,3-37,3-65
SHAFTS - REMOVAL, AXLE.....3-101,3-37,3-65
SHIELD - INSTALLATION, FRONT
WHEELHOUSE SPLASH...............23-143
SHIELD - INSTALLATION, REAR
WHEELHOUSE SPLASH...............23-144
SHIELD - REMOVAL, FRONT
WHEELHOUSE SPLASH...............23-143
SHIELD - REMOVAL, REAR
WHEELHOUSE SPLASH...............23-144
SHIELDS - DESCRIPTION, HEAT..........11-4
SHIELDS - INSTALLATION, SEAT
CUSHION SIDE.....................23-167
SHIELDS - REMOVAL, SEAT CUSHION
SIDE.............................23-167
SHIFT BEZEL - INSTALLATION.........23-158
SHIFT BEZEL - REMOVAL.............23-158
SHIFT BOOT - INSTALLATION, 4WD
FLOOR............................23-156
SHIFT BOOT - REMOVAL, 4WD FLOOR . . . 23-156
SHIFT INTERLOCK SYSTEM -
DESCRIPTION, BRAKE TRANSMISSION . . 21-124
SHIFT INTERLOCK SYSTEM - DIAGNOSIS
AND TESTING, BRAKE TRANSMISSION . . 21-125
SHIFT INTERLOCK SYSTEM -
OPERATION, BRAKE TRANSMISSION....21-125
SHIFT LEVER - INSTALLATION . . . 21-214,21-249
SHIFT LEVER - REMOVAL.......21-213,21-248
SHIFT MECHANISM - DESCRIPTION.....21-160
SHIFT MECHANISM - INSTALLATION....21-160
SHIFT MECHANISM - OPERATION
......21-160
SHIFT MECHANISM - REMOVAL
........21-160
SHOCK - INSTALLATION
................2-18
SHOCK - REMOVAL
....................2-18
SHOES - INSTALLATION, DRUM BRAKE
....5-11
SHOES - REMOVAL, DRUM BRAKE
.......5-11
SHORT TO GROUND - STANDARD
PROCEDURE, TESTING FOR A
........8W-01-9
SHORT TO GROUND ON FUSES
POWERING SEVERAL LOADS -
STANDARD PROCEDURE, TESTING
FOR A
...........................8W-01-9
SIDE - INSTALLATION, LEFT
.........2-12,2-15
SIDE - INSTALLATION, RIGHT
........2-12,2-15
SIDE - REMOVAL, LEFT
.............2-11,2-15
SIDE - REMOVAL, RIGHT
...........2-11,2-14
SIDE BEZEL - INSTALLATION,
INSTRUMENT PANEL PASSENGER
......23-154SIDE BEZEL - REMOVAL, INSTRUMENT
PANEL PASSENGER..................23-154
SIDE BEZELS - INSTALLATION,
INSTRUMENT PANEL DRIVER..........23-154
SIDE BEZELS - REMOVAL, INSTRUMENT
PANEL DRIVER.....................23-153
SIDE CURTAIN AIRBAG - DESCRIPTION . . . 8O-38
SIDE CURTAIN AIRBAG - INSTALLATION . . 8O-41
SIDE CURTAIN AIRBAG - OPERATION....8O-39
SIDE CURTAIN AIRBAG - REMOVAL......8O-40
SIDE IMPACT AIRBAG CONTROL
MODULE - DESCRIPTION..............8O-43
SIDE IMPACT AIRBAG CONTROL
MODULE - INSTALLATION.............8O-45
SIDE IMPACT AIRBAG CONTROL
MODULE - OPERATION................8O-43
SIDE IMPACT AIRBAG CONTROL
MODULE - REMOVAL.................8O-44
SIDE MOLDINGS - INSTALLATION, BODY . 23-140
SIDE MOLDINGS - REMOVAL, BODY....23-140
SIDE RAIL WEATHERSTRIP/RETAINER -
INSTALLATION......................23-186
SIDE RAIL WEATHERSTRIP/RETAINER -
REMOVAL.........................23-186
SIDE SHIELDS - INSTALLATION, SEAT
CUSHION..........................23-167
SIDE SHIELDS - REMOVAL, SEAT
CUSHION..........................23-167
SIDE VIEW MIRROR - INSTALLATION....23-145
SIDE VIEW MIRROR - REMOVAL.......23-145
SIDEVIEW MIRROR - REMOVAL..........8N-13
SIGNAL INDICATOR - DESCRIPTION,
TURN..............................8J-34
SIGNAL INDICATOR - OPERATION, TURN . . 8J-34
SILL SCUFF PLATE - INSTALLATION,
DOOR............................23-157
SILL SCUFF PLATE - REMOVAL, DOOR . . . 23-157
SINGLE CARDAN UNIVERSAL JOINTS -
ASSEMBLY...........................3-9
SINGLE CARDAN UNIVERSAL JOINTS -
DISASSEMBLY.........................3-8
SIREN - DESCRIPTION................8Q-16
SIREN - INSTALLATION...............8Q-17
SIREN - OPERATION..................8Q-17
SIREN - REMOVAL...................8Q-17
SKID PLATE - INSTALLATION, FRONT......13-6
SKID PLATE - INSTALLATION, FUEL
TANK ...............................13-9
SKID PLATE - INSTALLATION, TRANSFER
CASE...............................13-7
SKID PLATE - REMOVAL, FRONT.........13-6
SKID PLATE - REMOVAL, FUEL TANK......13-9
SKID PLATE - REMOVAL, TRANSFER
CASE...............................13-7
SKIS INDICATOR - DESCRIPTION........8J-31
SKIS INDICATOR - OPERATION..........8J-31
SKIS INITIALIZATION - STANDARD
PROCEDURE.........................8Q-8
SLEEVE - INSTALLATION, HEADREST....23-164
SLEEVE - REMOVAL, HEADREST.......23-164
SOLENOID - DESCRIPTION, EVAP/PURGE . 25-27
SOLENOID - INSTALLATION, EVAP/
PURGE.............................25-27
SOLENOID - OPERATION, EVAP/PURGE . . . 25-27
SOLENOID - REMOVAL, EVAP/PURGE.....25-27
SOLENOID SWITCH VALVE -
DESCRIPTION......................21-161
SOLENOID SWITCH VALVE - OPERATION . 21-161
SOLENOIDS - DESCRIPTION...........21-161
SOLENOIDS - OPERATION.............21-162
SOLENOID/TRS ASSEMBLY -
DESCRIPTION, TRANSMISSION........21-169
SOLENOID/TRS ASSEMBLY -
INSTALLATION, TRANSMISSION........21-170
SOLENOID/TRS ASSEMBLY -
OPERATION, TRANSMISSION..........21-169
SOLENOID/TRS ASSEMBLY - REMOVAL,
TRANSMISSION.....................21-170
SPACER - INSTALLATION, COLLAPSIBLE . . . 3-70
SPACER - REMOVAL, COLLAPSIBLE.......3-70
SPARE TIRE - INSTALLATION............22-9
SPARE TIRE - REMOVAL
................22-8
SPARE TIRE &TEMPORARY -
DESCRIPTION
........................22-6
SPARK PLUG - CLEANING SPARK
PLUGS
.............................8I-15
SPARK PLUG - DESCRIPTION
...........8I-12
SPARK PLUG - INSTALLATION
...........8I-15
24 INDEXKJ
Description Group-Page Description Group-Page Description Group-Page

TANK - REMOVAL, FUEL...............14-25
TANK CHECK VALVE - DESCRIPTION,
FUEL..............................14-28
TANK CHECK VALVE - INSTALLATION,
FUEL..............................14-28
TANK CHECK VALVE - OPERATION, FUEL . . 14-28
TANK CHECK VALVE - REMOVAL, FUEL . . . 14-28
TANK SKID PLATE - INSTALLATION,
FUEL...............................13-9
TANK SKID PLATE - REMOVAL, FUEL......13-9
TASK MANAGER - DESCRIPTION........25-17
TASK MANAGER - OPERATION..........25-21
TCM QUICK LEARN - STANDARD
PROCEDURE........................8E-21
TEMP INDICATOR - DESCRIPTION,
TRANS.............................8J-33
TEMP INDICATOR - OPERATION, TRANS . . 8J-34
TEMP SENSOR - DESCRIPTION,
AMBIENT...........................8M-9
TEMP SENSOR - OPERATION, AMBIENT . . . 8M-9
TEMPERATURE GAUGE - DESCRIPTION,
ENGINE............................8J-18
TEMPERATURE GAUGE - OPERATION,
ENGINE............................8J-18
TEMPERATURE SENSOR - DESCRIPTION,
BATTERY...........................8F-24
TEMPERATURE SENSOR - DESCRIPTION,
ENGINE COOLANT.....................7-19
TEMPERATURE SENSOR - DESCRIPTION,
INTAKE AIR .........................14-36
TEMPERATURE SENSOR - DESCRIPTION,
TRANSMISSION.....................21-170
TEMPERATURE SENSOR - DIAGNOSIS
AND TESTING, AMBIENT...............8M-9
TEMPERATURE SENSOR -
INSTALLATION, BATTERY..............8F-24
TEMPERATURE SENSOR -
INSTALLATION, ENGINE COOLANT........7-21
TEMPERATURE SENSOR -
INSTALLATION, INTAKE AIR............14-38
TEMPERATURE SENSOR - OPERATION,
BATTERY...........................8F-24
TEMPERATURE SENSOR - OPERATION,
ENGINE COOLANT.....................7-20
TEMPERATURE SENSOR - OPERATION,
INTAKE AIR .........................14-36
TEMPERATURE SENSOR - OPERATION,
TRANSMISSION.....................21-170
TEMPERATURE SENSOR - REMOVAL,
BATTERY...........................8F-24
TEMPERATURE SENSOR - REMOVAL,
ENGINE COOLANT.....................7-20
TEMPERATURE SENSOR - REMOVAL,
INTAKE AIR .........................14-37
TEMPERATURE SENSOR CIRCUIT -
DIAGNOSIS AND TESTING, AMBIENT.....8M-9
TENSIONER - DESCRIPTION, SEAT BELT . . 8O-36
TENSIONER - OPERATION, SEAT BELT....8O-36
TERMINAL - INSTALLATION.........8W-01-14
TERMINAL - REMOVAL.............8W-01-14
TEST - DIAGNOSIS AND TESTING, FUEL
PRESSURE LEAK DOWN................14-3
TEST - DIAGNOSIS AND TESTING, FUEL
PUMP AMPERAGE....................14-16
TEST - DIAGNOSIS AND TESTING, FUEL
PUMP CAPACITY.....................14-15
TEST - DIAGNOSIS AND TESTING, FUEL
PUMP PRESSURE....................14-15
TEST - DIAGNOSIS AND TESTING,
HYDRAULIC PRESSURE...............21-79
TEST - DIAGNOSIS AND TESTING, ROAD . . . 8P-2
TEST - STANDARD PROCEDURE,
BUILT-IN INDICATOR..................8F-10
TEST - STANDARD PROCEDURE,
HYDROMETER.......................8F-11
TEST - STANDARD PROCEDURE,
IGNITION-OFF DRAW..................8F-14
TEST - STANDARD PROCEDURE, LOAD . . . 8F-12
TEST - STANDARD PROCEDURE,
OPEN-CIRCUIT VOLTAGE
...............8F-12
TEST - STANDARD PROCEDURE,
VERIFICATION
........................8O-8
TEST MODE - DESCRIPTION, CIRCUIT
ACTUATION
..........................25-2
TEST MODE - DESCRIPTION, STATE
DISPLAY
............................25-2
TESTER - STANDARD PROCEDURE,
USING MIDTRONICS ELECTRICAL
.......8F-15TETHER ANCHOR - DESCRIPTION, CHILD . 8O-13
TETHER ANCHOR - OPERATION, CHILD . . . 8O-13
THEFT SECURITY - DESCRIPTION,
VEHICLE............................8Q-1
THEFT SECURITY - OPERATION, VEHICLE . . 8Q-3
THEFT SECURITY SYSTEM - DIAGNOSIS
AND TESTING, VEHICLE................8Q-6
THERMAL GUARD - DESCRIPTION.......8F-20
THERMAL GUARD - INSTALLATION......8F-20
THERMAL GUARD - OPERATION.........8F-20
THERMAL GUARD - REMOVAL..........8F-20
THERMOSTAT - DIAGNOSIS AND
TESTING............................7-21
THERMOSTAT - OPERATION, ENGINE
COOLANT............................7-21
THREAD REPAIR - STANDARD
PROCEDURE, ALUMINUM..............21-81
THREADED HOLE REPAIR -
DESCRIPTION......................Intro.-4
THREADS - STANDARD PROCEDURE,
REPAIR DAMAGED OR WORN............9-9
THROTTLE BODY - DESCRIPTION........14-43
THROTTLE BODY - INSTALLATION.......14-44
THROTTLE BODY - OPERATION.........14-43
THROTTLE BODY - REMOVAL...........14-43
THROTTLE CONTROL CABLE -
INSTALLATION.......................14-46
THROTTLE CONTROL CABLE - REMOVAL . . 14-45
THROTTLE POSITION SENSOR -
DESCRIPTION.........................14-47
THROTTLE POSITION SENSOR -
INSTALLATION.......................14-48
THROTTLE POSITION SENSOR -
OPERATION.........................14-47
THROTTLE POSITION SENSOR -
REMOVAL..........................14-47
TIE ROD END - INSTALLATION..........19-16
TIE ROD END - REMOVAL..............19-16
TIE ROD END REMOVAL TOOL, SPECIAL
TOOLS - OUTER.....................19-15
TIME INDICATOR - DESCRIPTION, FULL . . . 8J-29
TIME INDICATOR - DESCRIPTION, PART . . 8J-29
TIME INDICATOR - OPERATION, FULL....8J-30
TIME INDICATOR - OPERATION, PART....8J-29
TIMING - DESCRIPTION, VALVE..........9-71
TIMING - OPERATION, VALVE............9-71
TIMING - SPECIFICATIONS, IGNITION......8I-2
TIMING BELT / CHAIN COVER(S) -
INSTALLATION........................9-76
TIMING BELT / CHAIN COVER(S) -
REMOVAL...........................9-74
TIMING CHAIN WEAR, STANDARD
PROCEDURE - MEASURING.............9-71
TIRE - INSTALLATION, SPARE...........22-9
TIRE - REMOVAL, SPARE...............22-8
TIRE INFLATION - DIAGNOSIS AND
TESTING............................22-7
TIRE NOISE OR VIBRATION - DIAGNOSIS
AND TESTING........................22-8
TIRE ROTATION - STANDARD
PROCEDURE.........................22-2
TIRE &TEMPORARY - DESCRIPTION,
SPARE..............................22-6
TIRE WEAR PATTERNS - DIAGNOSIS
AND TESTING........................22-8
TIRES - DESCRIPTION.................22-6
TIRES - DESCRIPTION, RADIAL-PLY.......22-6
TIRES - DESCRIPTION, REPLACEMENT....22-7
TIRES AND WHEEL RUNOUT -
DIAGNOSIS AND TESTING..............22-1
TO GROUND - STANDARD PROCEDURE,
TESTING FOR A SHORT.............8W-01-9
TO GROUND ON FUSES POWERING
SEVERAL LOADS - STANDARD
PROCEDURE, TESTING FOR A SHORT . . 8W-01-9
TO USE WIRING DIAGRAMS -
DESCRIPTION, HOW................8W-01-1
TOE ADJUSTMENT - STANDARD
PROCEDURE..........................2-5
TOE ADJUSTMENT - STANDARD
PROCEDURE, CAMBER, CASTER..........2-5
TOOL, SPECIAL TOOLS - OUTER TIE
ROD END REMOVAL..................19-15
TOOLS - 3.7L ENGINE, SPECIAL
..........9-15
TOOLS - 8 1/4 AXLE, SPECIAL
...........3-98
TOOLS - BASE BRAKES, SPECIAL
.........5-7
TOOLS - BODY, SPECIAL
................23-5
TOOLS - COOLING, SPECIAL
.............7-14TOOLS - FRONT AXLE, SPECIAL..........3-34
TOOLS - FRONT SUSPENSION, SPECIAL....2-8
TOOLS - FUEL SYSTEM, SPECIAL........14-6
TOOLS - OUTER TIE ROD END REMOVAL
TOOL, SPECIAL......................19-15
TOOLS - POWER DISTRIBUTION
SYSTEMS, SPECIAL................8W-97-2
TOOLS - POWER STEERING PUMP,
SPECIAL...........................19-20
TOOLS - REAR AXLE, SPECIAL...........3-63
TOOLS - RFE TRANSMISSION, SPECIAL . . 21-120
TOOLS - STEERING COLUMN, SPECIAL....19-8
TOOLS - WIRING/TERMINAL, SPECIAL . 8W-01-10
TOOLS, BATTERY SYSTEM - SPECIAL.....8F-7
TOOLS, SPECIFICATIONS - SPECIAL....3-12,3-6
TOOLS, SPECIFICATIONS - SPECIAL......8F-24
TOP COVER - INSTALLATION,
INSTRUMENT PANEL.................23-153
TOP COVER - REMOVAL, INSTRUMENT
PANEL............................23-152
TORQUE - SPECIFICATIONS.............13-6
TORQUE CHART, SPECIFICATIONS . . 19-15,19-19,
19-8
TORQUE CHART, SPECIFICATIONS.....2-17,2-8
TORQUE CONVERTER - DESCRIPTION . . . 21-162
TORQUE CONVERTER - INSTALLATION . . . 21-167
TORQUE CONVERTER - OPERATION.....21-166
TORQUE CONVERTER - REMOVAL......21-167
TORQUE, EXCEPT DIESEL..............8F-23
TORQUE, GAS POWERED..............8F-38
TORQUE, IGNITION SYSTEM.............8I-3
TORQUE REFERENCES - DESCRIPTION . . Intro.-7
TORQUE, SPECIFICATIONS...............5-7
TORQUE, SPECIFICATIONS..............7-13
TORQUE, SPECIFICATIONS.............25-26
TORQUE, SPECIFICATIONS..............9-12
TORQUE, SPECIFICATIONS..............14-5
TORQUE, SPEED CONTROL.............8P-2
TOUCH-UP - DESCRIPTION, PAINT......23-163
TOW CONNECTOR - INSTALLATION,
TRAILER...........................8L-61
TOW CONNECTOR - REMOVAL, TRAILER . . 8L-61
TOW HOOK - INSTALLATION, FRONT......13-8
TOW HOOK - INSTALLATION, REAR.......13-8
TOW HOOK - REMOVAL, FRONT..........13-8
TOW HOOK - REMOVAL, REAR...........13-8
TOW RELAY - DESCRIPTION, TRAILER....8L-61
TOW RELAY - DIAGNOSIS AND TESTING,
TRAILER...........................8L-62
TOW RELAY - INSTALLATION, TRAILER . . . 8L-64
TOW RELAY - OPERATION, TRAILER.....8L-62
TOW RELAY - REMOVAL, TRAILER.......8L-63
TOW WIRING - DESCRIPTION, TRAILER . . 8L-64
TOWING - STANDARD PROCEDURE........0-6
TRACK - DESCRIPTION, SEAT..........8N-15
TRACK - DIAGNOSIS AND TESTING,
SEAT ..............................8N-16
TRACK - INSTALLATION, SEAT.........23-168
TRACK - INSTALLATION, SEAT..........8N-16
TRACK - OPERATION, SEAT............8N-15
TRACK - REMOVAL, SEAT.............23-168
TRACK - REMOVAL, SEAT..............8N-16
TRAC-LOK - ASSEMBLY, DIFFERENTIAL . . . 3-109,
3-77
TRAC-LOK - CLEANING, DIFFERENTIAL . . . 3-109,
3-77
TRAC-LOK - DISASSEMBLY,
DIFFERENTIAL...................3-107,3-75
TRAC-LOK - INSPECTION, DIFFERENTIAL . 3-109,
3-77
TRAC-LOKT- DIAGNOSIS AND TESTING . . 3-106,
3-74
TRAILER HITCH - INSTALLATION.........13-9
TRAILER HITCH - REMOVAL.............13-9
TRAILER TOW CONNECTOR -
INSTALLATION.......................8L-61
TRAILER TOW CONNECTOR - REMOVAL . . 8L-61
TRAILER TOW RELAY - DESCRIPTION....8L-61
TRAILER TOW RELAY - DIAGNOSIS AND
TESTING...........................8L-62
TRAILER TOW RELAY - INSTALLATION . . . 8L-64
TRAILER TOW RELAY - OPERATION......8L-62
TRAILER TOW RELAY - REMOVAL
.......8L-63
TRAILER TOW WIRING - DESCRIPTION
. . . 8L-64
TRANS COOLER - DESCRIPTION
.........7-32
TRANS TEMP INDICATOR -
DESCRIPTION
.......................8J-33
TRANS TEMP INDICATOR - OPERATION
. . . 8J-34
KJINDEX 27
Description Group-Page Description Group-Page Description Group-Page
