Cavity Cartridge Fuse Mini-Fuse Description
7 – 30 Amp Green Ignition Off Draw
8 – 30 Amp Green Ignition Off Draw
9 40 Amp Green – Power Seats
10 – 20 Amp Yellow Power Locks/Interior Lighting
11 – 15 Amp Lt Blue Power Outlet
12 – 20 Amp Yellow 115V AC Inverter – If Equipped
13 – 20 Amp Yellow Cigar Lighter
14 – 10 Amp Red Instrument Cluster
15 40 Amp Green – Radiator Fan
16 – 15 Amp Lt Blue Dome Lamp/Sunroof/Rear Wiper
Motor
17 – 10 Amp Red Wireless Control Module
18 40 Amp Green – Auto Shutdown Relay
19 – 20 Amp Yellow Radio Amplifiers
20 – 15 Amp Lt Blue Radio
276

Cavity Cartridge Fuse Mini-Fuse Description
21 – 10 Amp Red Intrusion Module/Siren – If
Equipped
22 – 10 Amp Red Heating, AC/Compass
23 – 15 Amp Lt Blue Auto Shutdown Relay
24 – 15 Amp Lt Blue Power Sunroof – If Equipped
25 – 10 Amp Red Heated Mirror – If Equipped
26 – 15 Amp Lt Blue Auto Shutdown Relay
27 – 10 Amp Red Airbag Control Module
28 – 10 Amp Red Airbag Control Module/Occupant
Classification Module
29 – – Hot Vehicle (No Fuse Required)
30 – 20 Amp Yellow Heated Seat – If Equipped
31 – 10 Amp Red Headlamp Washer – If Equipped
32 30 Amp Pink – Auto Shutdown Relay
33 – 10 Amp Red J1962 Conn/Powertrain Control
Module
