headlamp JEEP RENEGADE 2017 1.G Owners Manual

▫Keyless Enter-N-Go — Passive Entry — If
Equipped .............................32
▫ Dead Lock Device — If Equipped ............36
▫ Child Locks ...........................37
 SEATS ................................38
▫ Manual Front Seats ......................38
▫ Power Adjustment (Front) — If Equipped ......39
▫ Heated Seats — If Equipped ................41
▫ Rear Seats ............................42
 HEAD RESTRAINTS ......................46
▫ Front Head Restraints ....................46
▫ Rear Head Restraints .....................47
 STEERING WHEEL .......................48
▫ Tilt/Telescoping Steering Column ............48
▫ Heated Steering Wheel — If Equipped .........48
 MIRRORS ..............................49
▫ Inside Day/Night Mirror ..................49 ▫
Auto Dimming Mirror — If Equipped .........49
▫ Outside Mirrors ........................50
▫ Folding Mirror .........................51
▫ Heated Mirrors — If Equipped .............51
 EXTERIOR LIGHTS .......................52
▫ Headlights ............................52
▫ Daytime Running Lights (DRL) — If Equipped . .52
▫ High Beams ...........................52
▫ Flash-To-Pass ..........................53
▫ Automatic Lighting — If Equipped ..........53
▫ Automatic High Beam Headlamp Control — If
Equipped .............................54
▫ Parking Lights .........................54
▫ Headlight Delay ........................54
▫ Front Fog Lights — If Equipped .............55
▫ Turn Signals ...........................55
 INTERIOR LIGHTS .......................56
16 GETTING TO KNOW YOUR VEHICLE

Automatic High Beam Headlamp Control — If
Equipped
The Automatic High Beam Headlamp Control system
provides increased forward lighting at night by automat-
ing high beam control through the use of a digital camera
mounted on the inside rearview mirror. This camera de-
tects vehicle specific light and automatically switches from
high beams to low beams until the approaching vehicle is
out of view.
NOTE:
•The Automatic High Beam Headlamp Control can be
turned on or off using the Uconnect System. Refer to
“Uconnect Settings” in “Multimedia” for further infor-
mation.
• Broken, muddy, or obstructed headlights and taillights
of vehicles in the field of view will cause headlights to
remain on longer (closer to the vehicle). Also, dirt, film,
and other obstructions on the windshield or camera lens
will cause the system to function improperly.
Parking Lights
From the O (off) position, rotate the headlight switch to the
first detent (parking position) to turn on the parking lights.
The parking light indicator in the instrument cluster will
illuminate.
Headlight Delay
This feature provides the safety of headlight illumination
for up to 90 seconds when leaving your vehicle in an unlit
area.
The time delay of the headlights is programmable between
0, 30, 60 and 90 seconds. Refer to “Uconnect Settings” in
“Multimedia” for further information.
Headlight Delay Activation
To activate the delay feature, place the ignition in the OFF
position while the headlights are still on. Then, turn off the
headlights within two minutes. The delay interval begins
when the headlight switch is turned off from the “Low-
beam” position.
If the headlight switch is in AUTO position and headlights
were on before the ignition is OFF, the delay interval begins
automatically.
54 GETTING TO KNOW YOUR VEHICLE

Exterior Bulbs
LampsBulb Number
Bi-Xenon HID Headlamps (Serviced At An Authorized Dealer)
Low Beam/High Beam Headlamps H13
Front Position/Daytime Running Lights (DRL) P21/5W
Front Direction Indicator Lamps PY21W
Front Fog Lamps H11
Side Indicators (Front And Side View Mirror) WY5W
Tail/Brake Lights/Turn Indicators P21W
Center High Mounted Stop Lamp (CHMSL) LED (Serviced At An Authorized Dealer)
Reverse W16W
License Plate Lamp W5W
7
IN CASE OF EMERGENCY 319

Replacing Exterior Bulbs
Headlamps
Hi/Lo Beam Light Halogen
To replace the bulbs proceed as follows:
1. Open the engine compartment and remove the head-lamp bulb cap.
2. Rotate the headlamp bulb socket counterclockwise then pull outwards. 3. Push on the locking tab on the headlamp bulb connector
and remove the bulb and socket.
Headlamp Bulb Cap
Headlamp Bulb Socket
320 IN CASE OF EMERGENCY

4. Install the new headlamp bulb making sure it is prop-erly locked.
5. Install the headlamp bulb and socket; turn it clockwise making sure it is properly locked.
WARNING!
Carry out the operation of replacing lamps only with
the engine off. Also make sure that the engine is cold,
to avoid the danger of burns.
Headlamp Bulb ConnectorHeadlamp Bulb
7
IN CASE OF EMERGENCY 321

Mileage or time passed
(whichever comes first)
10,000
20,000
30,000
40,000
50,000
60,000
70,000
80,000
90,000
100,000
110,000
120,000
130,000
140,000
150,000
Or Years: 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Or Kilometers:
16,000
32,000
48,000
64,000
80,000
96,000
112,000
128,000
144,000
160,000
176,000
192,000
208,000
224,000
240,000
Check operation of lighting sys-
tem (headlamps, direction indi-
cators, hazard warning lights,
luggage compartment, passen-
ger compartment, glove com-
partment, instrument panel
warning lights, etc.). •••••••••••••••
Check and, if necessary, top up
fluid levels (brakes/hydraulic
clutch, windshield washer, bat-
tery, engine coolant, etc.). •••••••••••••••
Check engine control system
operation (via diagnostic tool). •••••••••••••••
Visually inspect condition of:
exterior bodywork, underbody
protection, pipes and hoses (ex-
haust - fuel system - brakes),
rubber elements (boots,
sleeves, bushings, etc.). •••• • • •
8
SERVICING AND MAINTENANCE 377

Lights
After pressing the “Lights” button on the touchscreen, the
following settings will be available:
Setting NameSelectable Options
Headlight Sensitiv- ity — If Equipped Level 1
Level 2Level 3
NOTE:
•When this feature is selected, it allows the Headlight Sensitivity to be adjusted according to three levels.
•The greater the sensitivity set, the less the external light variation required to turn on the lights (e.g. with a setting
on level 3 at sunset the headlights turn on earlier than in levels 1 and 2). To change the Headlight Sensitivity set-
ting, press the “1,” “2” or “3” button on the touchscreen to select your desired Headlight Sensitivity level.
Headlight Off Delay 0 sec30 sec 60 sec 90 sec
Greeting Lights — If Equipped On
Off
Automatic High
Beam Headlamps — If Equipped On
Off
Daytime Running Lights — IfEquipped Ye s
N o
NOTE: When this feature is selected, the headlights will turn on while the engine is running.
