check engine JEEP WRANGLER 2005 TJ / 2.G Owner's Manual

children, do not store ethylene glycol based antifreeze/
coolant in open containers or allow it to remain in
puddles on the ground. If ingested by a child, contact a
physician immediately. Clean up any ground spills im-
mediately.
Engine Coolant Level
The coolant bottle provides a quick visual method for
determining that the coolant level is adequate. With the
engine idling, and warm to normal operating tempera-
ture, the level of the antifreeze/coolant in the bottle
should be between the ranges indicated on the bottle.
The radiator normally remains completely full, so there is
not need to remove the radiator cap unless checking for
antifreeze/coolant freeze point or replacing antifreeze/
coolant. Advise your service attendant of this. As long as
the engine operating temperature is satisfactory, the
coolant bottle need only be checked once a month.When additional antifreeze/coolant is needed to main-
tain the proper level, it should be added to the coolant
bottle. Do not overfill.
Points To Remember
NOTE:When the vehicle is stopped after a few miles of
operation, you may observe vapor coming from the front
of the engine compartment. This is normally a result of
moisture from rain, snow, or high humidity accumulat-
ing on the radiator and being vaporized when the
thermostat opens, allowing hot antifreeze/coolant to
enter the radiator.
If an examination of your engine compartment shows no
evidence of radiator or hose leaks, the vehicle may be
safely driven. The vapor will soon dissipate.
•Do not overfill the coolant bottle.
•Check antifreeze/coolant freeze point in the radiator
and in the coolant recovery bottle. If antifreeze/
270 MAINTAINING YOUR VEHICLE

should be checked when pads are replaced. However,
low fluid level may be caused by a leak and a checkup
may be needed.
Use only manufacturer’s recommended brake fluid, refer
to Recommended Fluids, Lubricants, and Genuine Parts
for correct fluid type.
WARNING!
•Use of a brake fluid that may have a lower initial
boiling point or unidentified as to specification,
may result in sudden brake failure during hard
prolonged braking. You could have an accident.
•Overfilling the brake fluid reservoir can result in
spilling brake fluid on hot engine parts and the
brake fluid catching fire.
Use only brake fluid that has been in a tightly closed
container to avoid contamination from foreign matter. Do
not allow petroleum base fluid to contaminate the brake
fluid as seal damage will result.
Automatic Transmission
Selection of Lubricant
It is important that the proper lubricant is used in the
transmission to assure optimum transmission perfor-
mance. Use only manufacturer’s recommended transmis-
sion fluid, refer to Recommended Fluids, Lubricants, and
Genuine Parts for correct fluid type. It is important that
the transmission fluid be maintained at the prescribed
level using the recommended fluid.
274 MAINTAINING YOUR VEHICLE

CAUTION!
Using a transmission fluid other than the manufac-
turer’s recommended fluid may cause deterioration
in transmission shift quality and/or torque converter
shudder. Using a transmission fluid other than the
manufacturer’s recommended fluid will result in
more frequent fluid and filter changes. Refer to
Recommended Fluids, Lubricants, and Genuine
Parts for correct fluid type.
Fluid Level Check — 42RLE
This fluid level should be checked when the engine is
fully warmed up and the fluid in the transmission is
heated to its normal operating temperature. Operation of
the transmission with an improper fluid level will greatly
reduce the life of the transmission and of the fluid.To check the automatic transmission fluid level properly,
the following procedure must be used:
1. The vehicle must be on level ground.
2. The engine should be running at curb idle speed for a
minimum of 60 seconds.
3. Fully apply parking brake.
4. Apply the brakes and shift the transmission momen-
tarily into each gear position ending in P (Park).
5. The fluidMUSTbe checked with the transmission in
P (Park) to be sure that the fluid level is accurate.
6. Wipe the dipstick clean and reinsert until seated.
Remove dipstick and note reading.
At normal operating temperature (approximately 180° F
(82° C), the fluid level is correct if it is in the HOT region
MAINTAINING YOUR VEHICLE 275
7

Seat Belt Maintenance
Do not bleach, dye or clean the belts with chemical
solvents or abrasive cleaners. This will weaken the fabric.
Sun damage will also weaken the fabric.
If the belts need cleaning, use a mild soap solution or
lukewarm water. Do not remove the belts from the
vehicle to wash them.
Replace the belts if they appear frayed or worn or if the
buckles do not work properly.
Maintenance After Off-Road Driving
After extended operation in mud, sand or water, or
similar dirty conditions, have your brake drums, brake
linings, and axle joints inspected and cleaned as soon as
possible. This will prevent any abrasive material from
causing excessive wear or unpredictable braking action.
Following off-road usage, completely inspect the under-
body of your vehicle. Check tires, body structure, steer-
ing, suspension and exhaust system for damage. Checkthreaded fasteners for looseness, particularly on the
chassis, drivetrain components, steering and suspension.
Retighten, if required, to torque values specified in the
Service Manual. Also check for accumulations of vegeta-
tion or brush that could become a fire hazard, or conceal
damage to fuel lines, brake hoses, axle pinion seals, and
propeller shafts. Check air conditioning drain tube on the
lower dash wall in the engine compartment for mud or
debris, and clean as required. A plugged tube will
adversely affect air conditioning performance.CAUTION!
Under frequent heavy-duty driving conditions,
change all lubricants, and lubricate body compo-
nents and steering linkage more often than in nor-
mal service to prevent excessive wear.
MAINTAINING YOUR VEHICLE 285
7

•Off-road or desert driving
•If equipped for and operated with E-85 (ethanol)
fuel.
NOTE:IfANYof these apply to you then change your
engine oil every 3,000 miles (5 000 km) or 3 months,
whichever comes first and follow “Schedule B” of the
“Maintenance Schedules” section of this manual.
NOTE:IfANYof these apply to you then flush and
replace your engine coolant/anti-freeze every 102,000
miles (163 000 km) or 60 months, whichever comes first,
and follow “Schedule B” of the “Maintenance Schedules”
section of this manual.
NOTE:Most vehicles are operated under the conditions
listed for Schedule “B.”
Second is Schedule“A”. It is for vehicles that are not
operated under any of the conditions listed under Sched-
ule “B.”Use the schedule that best describes your driving condi-
tions. Where time and mileage are listed, follow the
interval that occurs first.
CAUTION!
Failure to perform the required maintenance items
may result in damage to the vehicle.
At Each Stop for Fuel
•Check the engine oil level about 5 minutes after a fully
warmed engine is shut off. Checking the oil level while
the vehicle is on level ground will improve the accu-
racy of the oil level reading. Add oil only when the
level is at or below the ADD or MIN mark.
•Check the windshield washer solvent, add as required.
MAINTENANCE SCHEDULES 301
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Once a Month
•Check the tire pressure and look for unusual wear or
damage.
•Inspect the battery and clean and tighten the terminals
as required.
•Check the fluid levels of the coolant reservoir, brake
master cylinder, and transmission, and add as needed.
•Check all lights and all other electrical items for correct
operation.
At Each Oil Change
•Change the engine oil filter.
•Inspect the exhaust system.
•Inspect brake hoses.
•Check the coolant level, hoses, and clamps.
•Inspect manual transmission fluid level — if
equipped.
•After completion of off-road operation, the underside
of the vehicle should be thoroughly inspected. Exam-
ine threaded fasteners for looseness.
302 MAINTENANCE SCHEDULES
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

About Your Brakes....................... 198
ABS (Anti-Lock Brake) System............147,200
Add-A-Trunk........................... 72
Adding Washer Fluid..................... 138
Air Cleaner, Engine (Engine Air Cleaner Filter) . . . 260
Air Conditioner Maintenance............... 262
Air Conditioning........................ 171
Air Conditioning Controls................. 172
Air Conditioning, Operating Tips............ 174
Air Conditioning Refrigerant............... 263
Air Filter.............................. 260
Air Pressure, Tires....................... 216
Airbag................................ 27
Airbag Deployment....................... 31
Airbag Light.........................33,145
Airbag Maintenance....................... 33
Alignment and Balance................... 220
Alterations/Modifications, Vehicle............. 9
Antenna, Satellite Radio................... 167Antifreeze (Engine Coolant)................ 295
Anti-Lock Brake System (ABS).............. 200
Anti-Lock Warning Light.................. 147
Appearance Care........................ 279
Automatic Dimming Mirror................. 50
Automatic Transmission................184,274
Adding Fluid......................... 276
Fluid and Filter Changes................. 274
Fluid Level Check...................... 275
Fluid Type........................... 274
Gear Ranges.......................... 185
Shifting............................. 184
Special Additives...................... 276
Torque Converter...................... 190
Auxiliary Electrical Outlet.................. 69
Auxiliary Power Outlet.................... 69
Battery............................... 261
Emergency Starting..................... 242
332 INDEX

Voltmeter............................ 143
Belts, Drive............................ 257
Belts, Seat.............................. 20
Body Mechanism Lubrication............... 264
B-Pillar Location........................ 211
Brake System........................... 272
Anti-Lock........................... 200
Hoses.............................. 272
Master Cylinder....................... 273
Parking............................. 196
Warning Light........................ 147
Brakes............................... 198
Brake/Transmission Interlock............... 185
Break-In Recommendations, New Vehicle........ 44
Bulb Replacement.....................290,291
Calibration, Compass...................... 52
Capacities, Fluid........................ 295Caps, Filler
Fuel................................ 226
Power Steering........................ 263
Car Washes............................ 280
Carbon Monoxide Warning................. 225
Carpeting............................. 283
Cassette Tape and Player Maintenance......... 167
Catalytic Converter...................... 258
Caution, Exhaust Gas...................... 44
CD Changer........................... 154
CD Player....................150,152,156,159
CD Player Maintenance................... 168
Cellular Phone.......................... 169
Center High Mounted Stop Light............ 294
Chains, Tire............................ 221
Changing A Flat Tire..................... 238
Chart, Tire Sizing........................ 208
Check Engine Light
(Malfunction Indicator Light)...........145,251
INDEX 333
10

Oil Filter............................ 257
Oil Pressure Gauge..................... 145
Oil Selection.......................... 295
Overheating.......................... 237
Starting............................. 178
Temperature Gauge..................... 145
Engine Oil Viscosity...................... 256
Engine Oil Viscosity Chart................. 256
Entry System, Illuminated.................. 17
Exhaust Gas Caution...................44,225
Exhaust System......................... 266
Extender, Seat Belt........................ 26
Exterior Finish Care...................... 280
Fabric Care.........................280,283
Fabric Top............................. 280
Filters
Air Cleaner.......................... 260
Engine Fuel.......................... 260Engine Oil........................... 257
Finish Care............................ 280
Flashers
Hazard Warning....................... 236
Turn Signal.....................143,292,294
Flooded Engine Starting................... 179
Fluid Capacities......................... 295
Fluid Level Checks...................... 278
Automatic Transmission................. 274
Engine Oil........................... 253
Manual Transmission................... 276
Power Steering........................ 263
Fog Light Service........................ 292
Fog Lights...........................63,292
Folding Rear Seat........................ 57
Folding Windshield...................... 130
Four Wheel Drive....................... 190
Shifting............................. 192
Four Wheel Drive Operation.............190,191
336 INDEX

Lead Free Gasoline...................... 222
Lights................................. 61
Airbag............................33,145
Anti-Lock........................... 147
Anti-Lock Warning..................... 147
Back-Up............................. 294
Brake Warning........................ 147
Bulb Replacement...................... 291
Center Mounted Stop................... 294
Check Engine......................... 145
Check Gauges........................ 145
Cruise.............................. 143
Daytime Running....................... 64
Dimmer Switch, Headlight................ 63
Fog ..............................63,292
Headlight Switch....................... 62
Headlights........................... 291
High Beam........................... 144
High Beam Indicator.................... 144Instrument Cluster...................... 62
Interior.............................. 61
Lights On Reminder..................... 63
Low Fuel............................ 147
Passing.............................. 63
Rear Servicing........................ 294
Rear Tail............................ 294
Seat Belt Reminder..................... 144
Sentry Key........................... 143
Service.............................. 291
Side Marker.......................... 294
Turn Signal...................63,143,292,294
Warning (Instrument Cluster Description)..... 143
Loading Vehicle
Tires ............................... 211
Locks................................. 18
Door................................ 18
Steering Wheel......................... 17
INDEX 339
10
