JEEP WRANGLER 2005 TJ / 2.G Owners Manual

Fog Lights.............................. H3
Front Park/Turn Lights (2).................3157
Front Side Marker Lights (2).......... 168orW3W
Headlights (2)...................... H6024BL
Stop/Tail/Turn Lights (2)..................1157
Underhood Light......................... 561
License Light...........................1157
NOTE:Numbers refer to commercial bulb types that
can be purchased from your local authorized dealer.
If a bulb needs to be replaced, visit your authorized
dealer or refer to the applicable Service Manual.
BULB REPLACEMENT
Head Light
1. Remove headlight bezel screws as shown.2. Remove the headlight bezel.
3. Remove the screws for the headlight retaining ring,
then remove ring.
MAINTAINING YOUR VEHICLE 291
7

4. Remove and replace the lamp.
Front Park/Turn Signal
1. Reach under the front fender and locate the front
park/turn signal socket.2. Turn the socket assembly counter–clockwise 1/3 turn
and remove it from the housing. Pull the bulb straight
from the socket to replace.
Front Side Marker
1. Reach under the front fender and locate the front side
marker socket.
2. Turn the socket assembly counter–clockwise 1/3 turn
and remove it from the housing. Pull the bulb straight
from the socket to replace.
Front Fog Light
1. Remove the three screws that attach the lamp bezel to
the lamp housing.
2. Separate the reflector from the light housing.
292 MAINTAINING YOUR VEHICLE

3. Squeeze the bulb/element spring retainer from the
reflector.
4. Disconnect the electrical connector.CAUTION!
Do not touch the new bulb with your fingers. Oil
contamination will severely shorten bulb life. If the
bulb comes in contact with any oily surface, clean
the bulb with rubbing alcohol.
MAINTAINING YOUR VEHICLE 293
7

Rear Tail, Stop, Turn Signal, and Back-Up Lights
1. Remove the screws attaching the lens to the tailight
housing.
2. Separate the lens from the housing.
3. Push the bulb in, turn it counter-clockwise 1/3 turn,
then remove it from the housing, and replace.
Center High Mounted Stop Light (CHMSL)
The stop lamp is mounted on a bracket that extends
upward from the tailgate. Remove the two screws hold-
ing the lens in place. Take the lens off and pull the bulb
from the socket.
294 MAINTAINING YOUR VEHICLE

FLUID CAPACITIES
U.S. Metric
Fuel (Approximate)19 Gallons 71.9 Liters
Engine Oil with Filter
2.4 Liter Engine (SAE 5W-30, API Certified Engine Oil) 5 Qts 4.7 Liters
4.0 Liter Engine (SAE 10W-30, API Certified Engine Oil) 6 Qts 5.7 Liters
Cooling System *
2.4 Liter Engine (MoparAntifreeze/Engine Coolant 5 Year/
100,000 Mile Formula)9 Qts 8.5 Liters
4.0 Liter Engine (MoparAntifreeze/Engine Coolant 5 Year/
100,000 Mile Formula)10.5 Qts 9.9 Liters
* Includes heater and coolant recovery bottle filled to MAX level.
MAINTAINING YOUR VEHICLE 295
7

RECOMMENDED FLUIDS, LUBRICANTS AND GENUINE PARTS
Engine
Component Fluid, Lubricant, or Genuine Part
Engine Coolant MoparAntifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Or-
ganic Additive Technology)
Engine Oil API Certified SAE 5W-30 Engine Oil is recommended for the 2.4L engine. API
Certified SAE 10W-30 Engine Oil is recommended for the 4.0L engine. Meets
the requirements of DaimlerChrysler Material Standard MS-6395.
Spark Plugs Refer to the Vehicle Emission Control Information label in the engine compart-
ment.
Oil Filter (2.4L Engine) MoparOil Filter (P/N 4105409)
Oil Filter (4.0L Engine) MoparOil Filter (P/N 05281090)
Fuel Selection 87 Octane
296 MAINTAINING YOUR VEHICLE

Chassis
Component Fluid, Lubricant, or Genuine Part
Automatic Transmission MoparATF+4 Automatic Transmission Fluid or equivalent.
Manual Transmission MoparManual Transmission Lubricant or equivalent (meeting the require-
ments of DaimlerChrysler Material Standard MS-9224)
Transfer Case MoparATF+4 Automatic Transmission Fluid or equivalent.
Axle Differential (Front) MoparGear & Axle Lubricant (SAE 80W-90) (API GL-5) or equivalent. For
trailer towing, use MoparSynthetic Gear & Axle Lubricant (SAE 75W-140)
or equivalent.
Axle Differential (Rear)194 RBI (Model 35) and 216 RBI (Model 44)- MoparGear & Axle Lubri-
cant (SAE 80W-90) (API GL-5) or equivalent. For trailer towing, use Mopar
Synthetic Gear & Axle Lubricant (SAE 75W-140) or equivalent. Models
equipped with Trac-Lok require an additive.194 RBI (Model 35) 4.56 Ratio
(2.4L Engine with 42RLE Automatic Transmission) and Rubicon 216 RBI
(Model 44)- MoparSynthetic Gear & Axle Lubricant (SAE 75W-140) or
equivalent. Models equipped with Trac-Lok require an additive.
MAINTAINING YOUR VEHICLE 297
7

Component Fluid, Lubricant, or Genuine Part
Brake Master Cylinder MoparDOT 3 Brake Fluid, SAE J1703 should be used. If DOT 3, SAE J1703
brake fluid is not available, then DOT 4 is acceptable. Use only recom-
mended brake fluids.
Power Steering Reservoir MoparATF+4 Automatic Transmission Fluid or equivalent.
Steering Gear & Linkage, Ball
Joints, Prop Shafts & Yokes, Wheel
BearingsMoparMulti-Purpose Grease NLGI Grade 2 EP, GC-LB or equivalent.
298 MAINTAINING YOUR VEHICLE

MAINTENANCE SCHEDULES
CONTENTS

Emission Control System Maintenance........300

Maintenance Schedules...................300▫Schedule “B”........................303
▫Schedule “A”........................314
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

EMISSION CONTROL SYSTEM MAINTENANCE
The “Scheduled” maintenance services, listed inbold
typemust be done at the times or mileages specified to
assure the continued proper functioning of the emission
control system. These, and all other maintenance services
included in this manual, should be done to provide best
vehicle performance and reliability. More frequent main-
tenance may be needed for vehicles in severe operating
conditions such as dusty areas and very short trip
driving.
Inspection and service also should be done any time a
malfunction is suspected.
NOTE:Maintenance, replacement, or repair of the emis-
sion control devices and systems on your vehicle may be
performed by any automotive repair establishment or
individual using any automotive part which has been
certified pursuant to U.S. EPA or, in the State of Califor-
nia, California Air Resources Board regulations.
MAINTENANCE SCHEDULES
There are two maintenance schedules that show the
requiredservice for your vehicle.
First is ScheduleB. It is for vehicles that are operated
under the conditions that are listed below and at the
beginning of the schedule.
•Day or night temperatures are below 32°F (0°C)
•Stop and go driving
•Excessive engine idling
•Driving in dusty conditions
•Short trips of less than 10 miles (16.2 km)
•More than 50% of your driving is at sustained high
speeds during hot weather, above 90°F (32°C)
•Trailer towing
•Taxi, police, or delivery service (commercial service)
