13. Oil Pressure Gauge
Indicates engine oil pressure. This gauge does not
indicate oil level, and pressure varies with engine
speed, temperature and oil viscosity. Consistent lower
readings indicate possible malfunction. Seek authorized
service.
14. Coolant Temperature Gauge
Indicates engine coolant temperature. The red
zone to the far right indicates possible overheat-
ing. Seek authorized service immediately if the
gauge operates in the red zone. In U.S. vehicles, tempera-
ture is indicated in degrees fahrenheit; in Canadian
vehicles in degrees centigrade.
15. Airbag Warning Light
This indicator lights and remains lit for 6 to 8
seconds when the ignition is first turned on. If
the light does not come on for 6 to 8 seconds,stays on or comes on while driving, have the airbag
system checked by an authorized dealer.
16. Check Gauges Warning Light
This light monitors the engine coolant tem-
perature, engine oil pressure, and voltage
gauges. If it detects an extreme condition a
chime will sound and the light will come on. If the light
comes on, check the operation of these gauges for a
malfunction condition.
17. Malfunction Indicator Light
This light is a part of an Onboard Diagnostic
System called OBD II that monitors engine, and
automatic transmission control systems. The light
will illuminate when the ignition is in the ON position
before engine start. If the bulb does not come on when
turning the key from OFF to ON, have the condition
checked promptly.
UNDERSTANDING YOUR INSTRUMENT PANEL 145
4

Defrost
Outside air comes from the windshield outlets
with a small amount being directed through the
floor outlets. Use this setting when necessary to defrost
your windshield.
NOTE:For improved safety, the A/C compressor is
activated when “Mix” or “Defrost” modes are selected.
This is done to assist in drying the air and it will help in
keeping the windshield from fogging.
Operating Tips
Summer Operation
The engine cooling system in air conditioned vehicles
must be protected with a high-quality antifreeze coolant
to provide proper corrosion protection and to protect
against engine overheating. A 50% solution of ethylene
glycol antifreeze coolant in water is recommended.
Winter Operation
The air from the heater system will heat faster in cold
weather if you use lower blower speeds until the engine
warms up. When operating the system during the winter
months, make sure the air intake, located directly in front
of the windshield, is free of ice, slush, snow, or other
obstructions.
Window Fogging
In mild but rainy or humid weather, the windows might
fog on the inside. To clear the fog off all of the windows,
turn the mode control knob to the “Panel” position (with
snowflake). Adjust the temperature control and blower
speed to maintain comfort. Direct the panel outlets
toward the side windows. Interior fogging on the wind-
shield can be quickly removed by selecting the “Defrost”
position.
174 UNDERSTANDING YOUR INSTRUMENT PANEL

system should be drained, flushed and refilled with fresh
antifreeze/coolant. Check the front of the A/C condenser
(if equipped) or radiator for any accumulation of bugs,
leaves, etc. If dirty, clean by gently spraying water from a
garden hose vertically down the face of the A/C con-
denser (if equipped) or the back of the radiator core.
Check the engine cooling system hoses for brittle rubber,
cracking, tears, cuts, and tightness of the connection at
the coolant recovery bottle and radiator. Inspect the
entire system for leaks.
With the engine at normal operating temperature (but
not running), check the cooling system pressure cap for
proper vacuum sealing by draining a small amount of
antifreeze/coolant from the radiator drain cock. If the cap
is sealing properly, the antifreeze/coolant will begin to
drain from the coolant recovery bottle. DO NOT RE-
MOVE THE COOLANT PRESSURE CAP WHEN THE
COOLING SYSTEM IS HOT.Cooling System — Drain, Flush, And Refill
At the intervals shown in the appropriate “Maintenance
Schedule,” the system should be drained, flushed, and
refilled.
If the solution is dirty and contains a considerable
amount of sediment, clean and flush with reliable cooling
system cleaner. Follow with a thorough rinsing to remove
all deposits and chemicals. Properly dispose of old
antifreeze/coolant solution.
Discard old antifreeze/coolant solution according to rec-
ommended procedure.
Selection Of Engine Coolant
Use only the manufacturer’s recommended antifreeze/
coolant, refer to Recommended Fluids, Lubricants, and
Genuine Parts for correct antifreeze/coolant type.
MAINTAINING YOUR VEHICLE 267
7

CAUTION!
•Mixing of antifreeze/coolant other than the speci-
fied HOAT antifreeze/coolant may result in de-
creased corrosion protection and engine damage.
If a non-HOAT antifreeze/coolant is introduced
into the cooling system in an emergency, it should
be replaced with the specified antifreeze/coolant
as soon as possible.
•Do not use plain water alone or alcohol base
antifreeze/coolant products. Do not use additional
rust inhibitors or antirust products, as they may
not be compatible with the antifreeze/coolant and
may plug the radiator.
•This vehicle has not been designed for use with
Propylene Glycol based antifreeze/coolant. Use of
Propylene Glycol base antifreeze/coolant is not
recommended.
Adding Engine Coolant
Your vehicle has been built with an improved antifreeze/
coolant that allows extended maintenance intervals. This
antifreeze/coolant can be used up to 5 Years or 100,000
miles before replacement. To prevent reducing this ex-
tended maintenance period, it is important that you use
the same antifreeze/coolant throughout the life of your
vehicle. Please review these recommendations for using
Hybrid Organic Additive Technology (HOAT)
antifreeze/coolant.
When adding antifreeze/coolant, a minimum solution of
50% recommended Mopar Antifreeze/ Coolant 5 Year/
100,000 Mile Formula HOAT (Hybrid Organic Additive
Technology), or equivalent, in water should be used. Use
higher concentrations (not to exceed 70%) if temperatures
below -34°F (-37°C) are anticipated.
268 MAINTAINING YOUR VEHICLE

Use only high purity water such as distilled or deionized
water when mixing the water/antifreeze (coolant) solu-
tion. The use of lower quality water will reduce the
amount of corrosion protection in the engine cooling
system.
Please note that it is the owner’s responsibility to main-
tain the proper level of protection against freezing ac-
cording to the temperatures occurring in the area where
the vehicle is operated.
NOTE:Mixing antifreeze/coolant types will decrease
the life of the antifreeze/coolant and will require more
frequent antifreeze/coolant changes.
Cooling System Pressure Cap
The cap must be fully tightened to prevent loss of
antifreeze/coolant, and to insure that antifreeze/coolant
will return to the radiator from the coolant reserve tank.The cap should be inspected and cleaned if there is any
accumulation of foreign material on the sealing surfaces.
WARNING!
The warning words DO NOT OPEN HOT on the
cooling system pressure cap are a safety precaution.
Never add antifreeze/coolant when the engine is
overheated. Do not loosen or remove the cap to cool
an overheated engine. Heat causes pressure to build
up in the cooling system. To prevent scalding or
injury, do not remove the pressure cap while the
system is hot or under pressure.
Disposal of Used Engine Coolant
Used ethylene glycol based antifreeze/coolant is a regu-
lated substance requiring proper disposal. Check with
your local authorities to determine the disposal rules for
your community. To prevent ingestion by animals or
MAINTAINING YOUR VEHICLE 269
7

children, do not store ethylene glycol based antifreeze/
coolant in open containers or allow it to remain in
puddles on the ground. If ingested by a child, contact a
physician immediately. Clean up any ground spills im-
mediately.
Engine Coolant Level
The coolant bottle provides a quick visual method for
determining that the coolant level is adequate. With the
engine idling, and warm to normal operating tempera-
ture, the level of the antifreeze/coolant in the bottle
should be between the ranges indicated on the bottle.
The radiator normally remains completely full, so there is
not need to remove the radiator cap unless checking for
antifreeze/coolant freeze point or replacing antifreeze/
coolant. Advise your service attendant of this. As long as
the engine operating temperature is satisfactory, the
coolant bottle need only be checked once a month.When additional antifreeze/coolant is needed to main-
tain the proper level, it should be added to the coolant
bottle. Do not overfill.
Points To Remember
NOTE:When the vehicle is stopped after a few miles of
operation, you may observe vapor coming from the front
of the engine compartment. This is normally a result of
moisture from rain, snow, or high humidity accumulat-
ing on the radiator and being vaporized when the
thermostat opens, allowing hot antifreeze/coolant to
enter the radiator.
If an examination of your engine compartment shows no
evidence of radiator or hose leaks, the vehicle may be
safely driven. The vapor will soon dissipate.
•Do not overfill the coolant bottle.
•Check antifreeze/coolant freeze point in the radiator
and in the coolant recovery bottle. If antifreeze/
270 MAINTAINING YOUR VEHICLE

Schedule “B”
Follow this schedule if you usually operate your vehicle
under one or more of the following conditions.
•Day or night temperatures are below 32°F (0°C)
•Stop and go driving
•Excessive engine idling
•Driving in dusty conditions
•Short trips of less than 10 miles (16.2 km)
•More than 50% of your driving is at sustained high
speeds during hot weather, above 90°F (32°C)
•Trailer towing
•Taxi, police, or delivery service (commercial service)
•Off-road or desert driving
•If equipped for and operated with E-85 (ethanol)
fuel.
NOTE:IfANYof these apply to you then change your
engine oil every 3,000 miles (5 000 km) or 3 months,
whichever comes first and follow “Schedule B” of the
“Maintenance Schedules” section of this manual.
NOTE:IfANYof these apply to you then flush and
replace your engine coolant/anti-freeze every 102,000
miles (163 000 km) or 60 months, whichever comes first,
and follow “Schedule B” of the “Maintenance Schedules”
section of this manual.
SCHEDULE “B” 303
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Child Restraint......................34,38,41
Child Restraint Tether Anchors.............37,38
Climate Control......................... 169
Clock................................ 148
Clutch Interlocking Ignition System........178,183
Compact Disc Maintenance................. 168
Compass.............................. 50
Compass Calibration...................... 52
Compass Variance........................ 53
Console............................... 72
Console, Floor........................... 72
Contract, Service........................ 324
Converter, Catalytic...................... 258
Cooling System......................... 266
Adding Coolant (Antifreeze).............. 268
Coolant Capacity...................... 295
Coolant Level......................... 270
Disposal of Used Coolant................ 269
Drain, Flush, and Refill.................. 267Inspection........................... 266
Points to Remember.................... 270
Pressure Cap......................... 269
Selection of Coolant..................267,295
Temperature Gauge..................... 145
Corrosion Protection..................... 279
Crankcase Emission Control System.......... 260
Cruise Control (Speed Control)............... 66
Cruise Light........................... 143
Cup Holder............................ 70
Customer Assistance..................... 322
Daytime Running Lights................... 64
Dealer Service.......................... 252
Defroster, Rear Window................... 137
Defroster, Windshield..................171,173
Delay (Intermittent) Wipers................. 64
Deploying, Airbag........................ 31
Diagnostic System, Onboard................ 250
334 INDEX

Dimmer Switch, Headlight.................. 63
Dipsticks
Oil (Engine).......................... 253
Disabled Vehicle Towing................... 244
Disposal
Engine Oil........................... 257
Used Coolant......................... 269
Door Locks............................. 18
Doors................................. 18
Drive Belts............................ 257
Driving............................... 202
Off-Pavement......................... 202
Off-Road............................ 202
Dual Top.............................. 73
Electrical Outlet, Auxiliary.................. 69
Electrical Power Outlets.................... 69
Electronic Speed Control................... 66
Emergency Brake........................ 196Emergency, In Case of
Brake Warning Light.................... 147
Coolant Temperature Gauge.............. 145
Engine Oil Pressure Gauge............... 145
Jacking............................. 238
Jump Starting......................... 242
Emission Control System Maintenance......251,300
Engine
Air Cleaner.......................... 260
Block Heater......................... 180
Break-In Recommendations................ 44
Compartment......................... 249
Exhaust Gas Caution..................44,225
Fails to Start.......................... 179
Flooded, Starting...................... 179
Fuel Requirements..................222,295
Jump Starting......................... 242
Oil ..............................253,295
Oil Disposal.......................... 257
INDEX 335
10

Front Axle............................. 278
Fuel................................. 222
Filler Cap............................ 226
Filter............................... 260
Gasoline............................ 222
Gauge.............................. 148
Materials Added....................... 224
Octane Rating........................ 223
Requirements......................... 295
Tank Capacity........................ 295
Fuel System Caution...................224,227
Fuses................................ 286
GasCap .............................. 226
Gasoline.............................. 222
Gasoline, Reformulated................... 223
Gasoline/Oxygenate Blends................ 223
Gauges
Coolant Temperature.................... 145Fuel................................ 148
Odometer........................... 146
Oil Pressure.......................... 145
Speedometer......................... 144
Tachometer.......................... 143
Voltmeter............................ 143
Gear Ranges........................183,185
Glass Cleaning.......................... 283
Glove Compartment...................... 71
HardTop .............................. 86
Hard Top Removal....................... 87
Hazard Warning Flasher................... 236
Headlights
Bulb Replacement...................... 291
Dimmer Switch........................ 63
Replacing............................ 291
Switch............................... 62
Heater............................... 169
INDEX 337
10
