WARNING!
Failure to engage a position completely can cause
transfer case damage or loss of power and vehicle
control. You could have an injury accident. Do not
drive the vehicle unless the transfer case is fully
engaged.
TRAC-LOK™ REAR AXLE
The Trac-Lok™ rear axle provides a constant driving
force to both rear wheels and reduces wheel spin caused
by the loss of traction at one driving wheel. If traction
differs between the two rear wheels, the differential
automatically proportions the usable torque by providing
more torque to the wheel that has traction.
Trac-Lok™ is especially helpful during slippery driving
conditions. With both rear wheels on a slippery surface, aslight application of the accelerator will supply maxi-
mum traction. When starting with only one rear wheel on
an excessively slippery surface, slight application of the
parking brake may be necessary to gain maximum trac-
tion.
WARNING!
On vehicles equipped with a limited-slip differen-
tial, never run the engine with one rear wheel off the
ground. The vehicle may drive through the rear
wheel remaining on the ground and cause you to
lose control of your vehicle.
194 STARTING AND OPERATING

NOTE:Refer to “Recommended Fluids, Lubricants, and
Genuine Parts” in Section 7 for axle differential lubrica-
tion specifications for towing.
RECREATIONAL TOWING (BEHIND
MOTORHOME, ETC.)
CAUTION!
Internal damage to the transfer case will occur if a
front or rear wheel lift is used when recreational
towing.
NOTE:The transfer case must be shifted into N (Neu-
tral) for recreational towing.
Shifting Into Neutral (N)
Use the following procedure to prepare your vehicle for
recreational towing.
CAUTION!
It is necessary to follow these steps to be certain that
the transfer case is fully in N (Neutral) before
recreational towing to prevent damage to internal
parts.
1. Depress brake pedal.
2. Shift automatic transmission into N (Neutral) or de-
press clutch pedal on manual transmission.
3. Shift transfer case lever into N (Neutral).
4. Start engine.
232 STARTING AND OPERATING

Cavity Fuse/Color Description
13 40 Amp Green Accessories
14 Open
15 50 Amp Red IOD
16 Open
17 20 Amp Yellow Power
18 20 Amp Yellow Horn
19 20 Amp Yellow Fog Lights
20 15 Amp Lt. Blue Radio
21 10 Amp Red A/C Clutch
22 25 Amp Natural Ignition Switch
23 20 Amp Yellow Fuel
24 20 Amp Yellow Off Road
25 Open
26 10 Amp Red Accessories
27 20 Amp Yellow MFSW
28 10 Amp Red Clutch OverrideCavity Fuse/Color Description
29 Relay ASD
30 Relay A/C Clutch
31 Relay Transmission
32 Relay Starter
33 Relay ABS
34 Open
35 Relay Fog Lamp
36 Relay Horn
37 Relay Fuel Pump
38 Relay HBL (Rear Window De-
froster)
39 Relay Front Differential Locker
(Rubicon) or High Speed
Fan (2.4L Engines)
40 Relay Rear Differential Locker
(Rubicon) or Low Speed
Fan (2.4L Engines)
MAINTAINING YOUR VEHICLE 289
7

Chassis
Component Fluid, Lubricant, or Genuine Part
Automatic Transmission MoparATF+4 Automatic Transmission Fluid or equivalent.
Manual Transmission MoparManual Transmission Lubricant or equivalent (meeting the require-
ments of DaimlerChrysler Material Standard MS-9224)
Transfer Case MoparATF+4 Automatic Transmission Fluid or equivalent.
Axle Differential (Front) MoparGear & Axle Lubricant (SAE 80W-90) (API GL-5) or equivalent. For
trailer towing, use MoparSynthetic Gear & Axle Lubricant (SAE 75W-140)
or equivalent.
Axle Differential (Rear)194 RBI (Model 35) and 216 RBI (Model 44)- MoparGear & Axle Lubri-
cant (SAE 80W-90) (API GL-5) or equivalent. For trailer towing, use Mopar
Synthetic Gear & Axle Lubricant (SAE 75W-140) or equivalent. Models
equipped with Trac-Lok require an additive.194 RBI (Model 35) 4.56 Ratio
(2.4L Engine with 42RLE Automatic Transmission) and Rubicon 216 RBI
(Model 44)- MoparSynthetic Gear & Axle Lubricant (SAE 75W-140) or
equivalent. Models equipped with Trac-Lok require an additive.
MAINTAINING YOUR VEHICLE 297
