Page 382 of 554
range. Two-wheel drive vehicles and four-wheel drive
vehicles in 2H range have two operating modes.
4H Range (4WD Models) or 2WD Models
On
This is the normal operating mode for ESP in 4H and
2WD vehicles. Whenever the vehicle is started or the
transfer case (if equipped) is shifted from 4L range or
NEUTRAL back to 4H range, the ESP system will be in
this mode. This mode should be used for most all driving
situations. The ESP should only be turned to “Partial Off”
or “Full Off” for specific reasons as noted below.
Partial Off
This mode is entered by momentarily pressing the ESP
OFF switch. When inPartial Offmode, the TCS portion
of ESP has been disabled and the “ESP/TCS Indicator
Light” will be illuminated. All other stability features of
ESP function normally. This mode is intended to be used
if the vehicle is in deep snow, sand, or gravel conditions and more wheel spin than ESP would normally allow is
required to gain traction. To turn ESP on again, momen-
tarily press the ESP OFF switch. This will restore the
normal “ESP On” mode of operation.
NOTE:
To improve the vehicle’s traction when driving
with snow chains, or starting off in deep snow, sand, or
ESP OFF Switch
5
STARTING AND OPERATING 381
Page 410 of 554
•Tire Pressure Monitoring Telltale Light
A tire pressure monitoring sensor is located in the spare
wheel if the vehicle is equipped with a matching full size
spare wheel and tire assembly. The matching full size
spare tire can be used in place of any of the four road
tires. A low spare tire will not cause the “Tire Pressure
Monitoring Telltale Light” to illuminate or the chime to
sound. The “Tire Pressure Monitoring Telltale Light” will
illuminate in the instrument cluster, and an au-
dible chime will be activated when one or more of
the four active road tire pressures are low. Should this
occur, you should stop as soon as possible, check the
inflation pressure of each tire on your vehicle, and inflate
each tire to the vehicle’s recommended cold placard
pressure value. The system will automatically update
and the “Tire Pressure Monitoring Telltale Light” will
extinguish once the updated tire pressures have been received. The vehicle may need to be driven for up to
20 minutes above 15 mph (25 km/h) to receive this
information.
The “Tire Pressure Monitoring Telltale Light” will flash
on and off for 75 seconds, and will remain on solid when
a system fault is detected. The system fault will also
sound a chime. If the ignition key is cycled, this sequence
will repeat, providing the system fault still exists. A
system fault can occur by any of the following scenarios:
1. Jamming due to electronic devices or driving next to
facilities emitting the same Radio Frequencies as the TPM
sensors.
2. Installing some form of aftermarket window tinting
that affects radio wave signals.
3. Lots of snow or ice around the wheels or wheel
housings.
4. Using tire chains on the vehicle.
5
STARTING AND OPERATING 409
