remote start JEEP WRANGLER 2016 JK / 3.G User Guide

Remote Start Abort Message On Electronic
Vehicle Information Center (EVIC) — If Equipped
The following messages will display in the EVIC if the
vehicle fails to remote start or exits remote start prema-
turely:
•Remote Start Aborted — Door Ajar
• Remote Start Aborted — Hood Ajar
• Remote Start Aborted — Fuel Low
• Remote Start Aborted — L/Gate Ajar
• Remote Start Aborted — System Fault
The EVIC message stays active until the ignition is turned
to the ON/RUN position.
To Enter Remote Start
Push and release the REMOTE START button on
the RKE transmitter twice within five seconds.
The vehicle doors will lock, the parking lights
will flash and the horn will chirp twice (if
programmed). Then, the engine will start and the vehicle
will remain in the Remote Start mode for a 15-minute cycle.
NOTE:
• The park lamps will turn on and remain on during
Remote Start mode.
• For security, power window operation is disabled
when the vehicle is in the Remote Start mode.
• The engine can be started two consecutive times (two
15-minute cycles) with the RKE transmitter. However,
the ignition switch must be cycled to the ON/RUN
position before you can repeat the start sequence for a
third cycle.
30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Remote start will also cancel if any of the following occur:
•The engine stalls or RPM exceeds 2500.
• Any engine warning lamps come on.
• The hood is opened.
• The hazard switch is pushed.
• The transmission is moved out of PARK.
• The brake pedal is pushed.
To Exit Remote Start Mode Without Driving The
Vehicle
Push and release the REMOTE START button one time or
allow the engine to run for the entire 15-minute cycle.
NOTE: To avoid unintentional shut downs, the system
will disable the one time push of the REMOTE START
button for two seconds after receiving a valid Remote
Start request.
To Exit Remote Start Mode And Drive The Vehicle
Before the end of the 15-minute cycle, push and release
the UNLOCK button on the RKE transmitter to unlock
the doors and disarm the Vehicle Security Alarm (if
equipped). Then, insert the key into the ignition switch
and turn the switch to the ON/RUN position.
NOTE: The ignition switch must be in the ON/RUN
position in order to drive the vehicle.
General Information
The following regulatory statement applies to all Radio
Frequency (RF) devices equipped in this vehicle:
This device complies with Part 15 of the FCC Rules and
with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 31

Rear Power Windows — Four-Door Models
The rear passenger window switches are located on the
back of the center floor console. Push the switch down-
ward to open the window and upward to close the
window.
Wind Buffeting
Wind buffeting can be described as the perception of
pressure on the ears or a helicopter-type sound in the
ears. Your vehicle may exhibit wind buffeting with the
windows down in certain open or partially open posi-
tions. This is a normal occurrence and can be minimized
by adjusting the window opening.
REAR SWING GATE
The rear swing gate can be unlocked by using the key,
Remote Keyless Entry (RKE) transmitter, or by activating
the power door lock switches located on the front doors.
To open the swing gate, push the button on the gate
handle.
Rear Power Window Switches (Four-Door Models)
46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

•Power — Allows you to turn the power ON and OFF
(if equipped).
• Lock — Locks out rear remote controls (if equipped).
• CH1/CH2 — Allows the user to change the mode of
either the IR1 or IR2 wireless headphones by pushing
the AUDIO/SELECT button (if equipped).
• Set Home Clock — Pushing the SELECT button
allows you to set the clock. Turn the TUNE/SCROLL
control knob to adjust the hours and then push and
turn the TUNE/SCROLL control knob to adjust the
minutes. Push the TUNE/SCROLL control knob again
to save changes.
• Player Defaults — Selecting this item will allow the
user to scroll through the following items and set
defaults according to customer preference. Menu Language — If Equipped
Selecting this item will allow the user to choose the
default startup DVD menu language (effective only if
language supported by disc). If you want to select a
language not listed, then scroll down and select
other.
Enter the four-digit country code using the TUNE/
SCROLL control knob to scroll up and down to select the
number and then push to select.
Audio Language — If Equipped
Selecting this item allows you to choose a default audio
language (effective only if the language is supported by
the disc). You can select a language not listed by scrolling
down and selecting other.Enter the country code using
the TUNE/SCROLL control knob to scroll up and down
to select the number and then push to select.
390 UNDERSTANDING YOUR INSTRUMENT PANEL

Disabled Vehicle Towing....................589
Disarming, Security System ...................21
Disposal Antifreeze (Engine Coolant) ................628
Door Locks ..............................38
Child-Protection Door Lock — Rear Doors ......42
Door Locks ............................38
KeyFob...............................38
Remote ...............................38
Remote Keyless Entry (RKE) ................38
Door Locks, Automatic ......................41
Doors ..................................32
Driver’s Seat Back Tilt ..................... .154
Driving ............................... .462
Dual Top ........................... .194, 198
Electrical Outlet, Auxiliary (Power Outlet) ........185
Electrical Power Outlets .....................185
Electric Remote Mirrors .....................113 Electronic Brake Control System
...............481
Anti-Lock Brake System ..................482
Electronic Roll Mitigation .................495
Traction Control System ...................487
Electronic Speed Control (Cruise Control) ........181
Electronic Stability Control (ESC) ..............488
Electronic Throttle Control Warning Light ........323
Electronic Vehicle Information Center (EVIC) ......344
Emergency Brake ........................ .478
Emergency, In Case Of Jacking .............................. .573
Jump Starting ......................... .581
Tow Hooks ........................... .586
Emission Control System Maintenance ..........597
Engine Air Cleaner .......................... .603
Block Heater ......................... .437
Break-In Recommendations .................98
Compartment ......................... .595
686 INDEX

Door Locks............................40
Inverter ............................. .189
Mirrors ..............................113
Steering .......................... .476, 477
Windows ..............................43
Power Steering Fluid ...................... .662
Pregnant Women And Seat Belts ...............59
Preparation For Jacking .....................575
Pretensioners Seat Belts ..............................59
Programmable Electronic Features .............354
Radial Ply Tires ......................... .512
Radiator Cap (Coolant Pressure Cap) ...........628
Radio Frequency General Information .................19, 28, 31
Radio Operation ...................... .384, 413
Radio (Sound Systems) .....................384
Rear Axle (Differential) .....................638 Rear Swing Gate
...........................46
Rear Window Defroster .....................302
Rear Window Features .....................301
Rear Wiper/Washer ....................... .301
Recorder, Event Data .......................74
Recreational Towing ...................... .563
Shifting Into Transfer Case Neutral (N) ........565
Shifting Out Of Transfer Case Neutral (N) ......567
Reformulated Gasoline .....................535
Refrigerant ..............................611
Release, Hood ........................... .167
Reminder, Seat Belt .........................49
Remote Control Door Locks ............................22
Starting System .........................28
Remote Keyless Entry (RKE) ..................22
Remote Sound System (Radio) Controls ..........411
Remote Starting System ......................28
Replacement Bulbs ....................... .654
694 INDEX

Side Window Demisters (Defrosters)............427
Signals, Turn ...................104, 170, 657, 658
Snow Chains (Tire Chains) ...................521
Snow Tires ............................. .514
Soft Top ............................ .225, 258
Spare Tire .....................515, 516, 517, 575
Spark Plugs ............................ .660
Specifications Fuel (Gasoline) ........................ .660
Oil................................. .660
Speed Control Accel/Decel .......................... .184
Cancel .............................. .183
Resume ............................. .183
Speed Control (Cruise Control) ................181
Starting ......................... .28, 434, 435
Automatic Transmission ..................434
Cold Weather ......................... .435
Engine Block Heater .....................437 Engine Fails To Start
.....................435
Manual Transmission ....................434
Remote ...............................28
Starting And Operating .....................435
Starting Procedures ....................... .435
Steering Power ........................... .476, 477
Tilt Column .......................... .180
Wheel, Tilt ........................... .180
Steering Wheel Audio Controls ................411
Steering Wheel Mounted Sound System Controls . . .411
Storage ............................... .654
Storage, Behind the Seat ....................193
Storage, Vehicle ...................... .426, 654
Storing Your Vehicle ...................... .654
Stuck, Freeing ........................... .585
Sunrider ........................... .255, 291
Supplemental Restraint System - Air Bag .........63
Sway Bar Disconnect, Electronic ...............460
10
INDEX 697

Sway Control, Trailer...................... .496
Swing Gate, Rear ..........................46
Synthetic Engine Oil ...................... .602
System, Remote Starting .....................28
Temperature Control, Automatic (ATC) ..........419
Tilt Steering Column ...................... .180
Tip Start ............................... .435
Tire And Loading Information Placard .......505, 506
Tire Markings ........................... .499
Tires ....................... .103, 509, 515, 679
Aging (Life Of Tires) .....................519
Air Pressure .......................... .509
Chains .............................. .521
Changing ............................ .573
Compact Spare ........................ .516
General Information ..................509, 515
High Speed .......................... .512
Inflation Pressures ...................... .510Jacking
.......................... .573, 578
Life Of Tires .......................... .519
Load Capacity ..................... .505, 506
Pressure Monitor System (TPMS) ............523
Pressure Warning Light ...................328
Quality Grading ....................... .679
Radial .............................. .512
Replacement .......................... .519
Rotation ............................. .522
Safety ........................... .499, 509
Sizes ............................... .500
Snow Tires ........................... .514
Spare Tire ...................515, 516, 517, 575
Spinning ............................ .517
Tread Wear Indicators ....................518
Tire Safety Information .....................499
Tongue Weight/Trailer Weight ................555
T

o Open Hood .......................... .167
Tow Hooks, Emergency .....................586
698 INDEX
