CAUTION!
•Mixing of engine coolant (antifreeze) other than specified Organic Additive Tech-
nology (OAT) engine coolant (antifreeze), may result in engine damage and may
decrease corrosion protection. Organic Additive Technology (OAT) engine coolant is
different and should not be mixed with Hybrid Organic Additive Technology (HOAT)
engine coolant (antifreeze) or any “globally compatible” coolant (antifreeze). If a
non-OAT engine coolant (antifreeze) is introduced into the cooling system in an
emergency, the cooling system will need to be drained, flushed, and refilled with
fresh OAT coolant (conforming to MS.90032), by an authorized dealer as soon as
possible.
• Do not use water alone or alcohol-based engine coolant (antifreeze) products.Do not use additional rust inhibitors or antirust products, as they may not be
compatible with the radiator engine coolant and may plug the radiator.
• This vehicle has not been designed for use with propylene glycol-based engine
coolant (antifreeze). Use of propylene glycol-based engine coolant (antifreeze)
is not recommended.
Chassis
Component Fluid, Lubricant, or Genuine Part
Automatic Transmission – If Equipped
Use only ATF+4 Automatic Transmission
Fluid. Failure to use ATF+4 fluid may affect
the function or performance of your transmis-
sion. We recommend MOPAR ATF+4 fluid.
Manual Transmission – If EquippedWe recommend you use MOPAR Manual
Transmission Lubricant meeting the require-
ments of FCA US Material Standard MS-
9224.
Transfer Case We recommend you use MOPAR ATF+4
Automatic Transmission Fluid.
Axle Differential (Front) We recommend you use MOPAR Gear &
Axle Lubricant (SAE 80W-90) (API GL-5).
Axle Differential (Rear)
226 RBI (Model 44) – We recommend you use
MOPAR Gear & Axle Lubricant (SAE 80W-90)
(API GL-5) or equivalent. For trailer towing,
use MOPAR Synthetic Gear & Axle Lubricant
(SAE 75W-140). Models equipped with Trac-
Lok require an additive.
Brake Master Cylinder We recommend you use MOPAR DOT 3
Brake Fluid, SAE J1703. If DOT 3, SAE
J1703 brake fluid is not available, then
DOT 4 is acceptable.
Power Steering Reservoir We recommend you use MOPAR Power
Steering Fluid +4, MOPAR ATF+4 Auto-
matic Transmission Fluid.
MAINTAINING YOUR VEHICLE
125

Once A Month Or Before A Long Trip:
• Check engine oil level
• Check windshield washer fluid level
• Check the tire inflation pressures and look for unusual wear or damage
• Check the fluid levels of the coolant reservoir, brake master cylinder, powersteering and automatic transmission, and fill as needed
• Check function of all interior and exterior lights
Required Maintenance Intervals
Refer to the maintenance schedules on the following page for the required mainte-
nance intervals.
At Every Oil Change Interval As Indicated By Oil Change Indicator System:
• Change oil and filter
• Rotate the tires. Rotate at the first sign of irregular wear, even if it occurs before the oil
indicator system turns on.
• Inspect battery and clean and tighten terminals as required
• Inspect automatic transmission fluid if equipped with dipstick
• Inspect brake pads, shoes, rotors, drums, hoses and park brake
• Inspect engine cooling system protection and hoses
• Inspect exhaust system
• Inspect engine air cleaner if using in dusty or off-road conditions
• Inspect all door latches for presence of grease, reapply if necessary.
MAINTAINING YOUR VEHICLE
127

Mileage or time passed
(whichever comes first)
20,000
30,000
40,000
50,000
60,000
70,000
80,000
90,000
100,000
110,000
120,000
130,000
140,000
150,000
Or Years: 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Or Kilometers:
32,000
48,000
64,000
80,000
96,000
112,000
128,000
144,000
160,000
176,000
192,000
208,000
224,000
240,000
Change automatic transmission fluid and
filter if using your vehicle for any of the
following: police, taxi, fleet, or frequent
trailer towing. XX
Change the automatic transmission fluid
and filter. X
Change the manual transmission fluid if
using your vehicle for any of the follow-
ing: trailer towing, snow plowing, heavy
loading, taxi, police, delivery service
(commercial service), off-road, desert
operation or more than 50% of your driv-
ing is at sustained high speeds during
hot weather, above 90°F (32°C). XX X X X
Change transfer case fluid if using your
vehicle for any of the following: police,
taxi, fleet, or frequent trailer towing. XX
Inspect and replace PCV valve if neces-
sary. X
Change front and rear axle fluid if using
your vehicle for police, taxi, fleet, off-
road or frequent trailer towing. XX X** The spark plug change interval is mileage based only, yearly intervals do not apply.
MAINTAINING YOUR VEHICLE
129

Adding Engine Coolant(Antifreeze) .............126
Adding Washer Fluid .........126
Air Bag AdvancedFrontAirBag ......14
AdvanceFrontAirBag ......13
AirBagComponents ........13
AirBags ...............13
Air Bag Warning
Light ...........13,16,105
Enhanced Accident
Response ...........15,120
Event Data Recorder (EDR). .16, 120
FrontAirBag ............13
Rollover ...............13
SideImpacts ............13
AirBagLight..............16
Air Cleaner, Engine (Engine Air Cleaner Filter) ...........126
Air Conditioner Maintenance ....126
Air Conditioning ............36
Air Conditioning Refrigerant .....126
Air Conditioning System .......126
Air Recirculation ............36
Alarm Arm The System ..........11
Disarm The System ........12
Vehicle Security Alarm ......11
Alarm (Security Alarm) .....11,106
Antifreeze (Engine Coolant) . .124, 126 Disposal ..............126
Anti-Lock Warning Light .......105
Appearance Care ...........126
Assistance Towing ..........101
Audio Jack ........57,60,64,69
Audio Settings ........57,59,62
Audio Systems (Radio) .........56
Automatic Temperature Control (ATC).................36
Automatic Transmission FluidType ............125
AxleFluid...............125
Battery .................126
Body Mechanism Lubrication ....126
BrakeFluid ..............125
Brakes.................126
Brake System .............126 Master Cylinder
.........126
Warning Light ..........103
Break-In Recommendations, New Vehicle ................28
Bulb Replacement ..........138
Bulbs,Light..............138
Calibration, Compass .........87
Canada...............3,140
Capacities, Fluid ...........124
Caps, Filler Oil (Engine) ............126
CarWashes ..............126
CD (Compact Disc) Player . .57, 60, 63
Change Oil Indicator .........105
ChangingAFlatTire .........108
Charging System Light ........104
Child Restraints ............17
Installing Child Restraints Using
The Vehicle Seat Belt .......19
Lower Anchors And Tethers For
Children ..............20
Using The Top Tether Anchorage..20
Child Seat Installation .........17
Cleaning Wheels ..............126
Windshield Wiper Blades ....126
Climate Control .............36
Clock Setting .......56,59,62,65
Cluster Warning/Indicator Lights AirBagWarningLight ......105
Anti-Lock Brake (ABS) Light . .105
Brake Warning Light .......103
Charging System Light .....104
Electronic Throttle Control (ETC)
Indicator Light ..........105
Front Fog Light Indicator ....106
High Beam Indicator ......106
Malfunction Indicator Light
(MIL)................104
Oil Pressure Warning Light . . .104
Tire Pressure Monitoring System
(TPMS) Light ...........101
Turn Signal Indicator ......106
Vehicle Security Light ......106
Clutch .................126
ClutchFluid..............126
CompactSpareTire..........136
