JEEP WRANGLER 2017 JK / 3.G Owners Manual

have these additives will help improve fuel economy,
reduce emissions, and maintain vehicle performance.Designated TOP TIER Detergent Gaso-
line contains a higher level of detergents
to further aide in minimizing engine
and fuel system deposits. When avail-
able, the usage of Top Tier Detergent
gasoline is recommended. Visit
www.toptiergas.com for a list of TOP
TIER Detergent Gasoline Retailers.
Indiscriminate use of fuel system cleaning agents should be
avoided. Many of these materials intended for gum and
varnish removal may contain active solvents or similar
ingredients. These can harm fuel system gasket and dia-
phragm materials.
Gasoline/Oxygenate Blends
Some fuel suppliers blend unleaded gasoline with oxygen-
ates such as ethanol.
CAUTION!
DO NOT use gasoline containing methanol or gasoline
containing more than 15% ethanol (E-15). Use of these
blends may result in starting and drivability problems,
damage critical fuel system components, cause emis-
sions to exceed the applicable standard, and/or cause the
“Malfunction Indicator Light” to illuminate. Please ob-
serve pump labels as they should clearly communicate if
a fuel contains greater than 15% ethanol (E-15).
Problems that result from using gasoline containing more
than 15% ethanol (E-15) or gasoline containing methanol
are not the responsibility of the manufacturer and may
void or not be covered under New Vehicle Limited War-
ranty.
E-85 Usage In Non-Flex Fuel Vehicles
Non-Flex Fuel Vehicles (FFV) are compatible with gasoline
containing up to 15% ethanol (E-15). Gasoline with higher
ethanol content may void the New Vehicle Limited War-
ranty.
9
TECHNICAL SPECIFICATIONS 439

If a Non-FFV vehicle is inadvertently fueled with E-85 fuel,
the engine will have some or all of these symptoms:
•Operate in a lean mode.
• OBD II “Malfunction Indicator Light” on.
• Poor engine performance.
• Poor cold start and cold drivability.
• Increased risk for fuel system component corrosion.
CNG And LP Fuel System Modifications
Modifications that allow the engine to run on compressed
natural gas (CNG) or liquid propane (LP) may result in
damage to the engine, emissions, and fuel system compo-
nents. Problems that result from running CNG or LP are
not the responsibility of the manufacturer and may void or
not be covered under the New Vehicle Limited Warranty.
MMT In Gasoline
Methylcyclopentadienyl Manganese Tricarbonyl (MMT) is
a manganese-containing metallic additive that is blended
into some gasoline to increase octane. Gasoline blended
with MMT provides no performance advantage beyond
gasoline of the same octane number without MMT. Gaso-
line blended with MMT reduces spark plug life and reduces emissions system performance in some vehicles.
The manufacturer recommends that gasoline without
MMT be used in your vehicle. The MMT content of
gasoline may not be indicated on the gasoline pump;
therefore, you should ask your gasoline retailer whether
the gasoline contains MMT. MMT is prohibited in Federal
and California reformulated gasoline.
Fuel System Cautions
CAUTION!
Follow these guidelines to maintain your vehicle’s
performance:
•
The use of leaded gasoline is prohibited by Federal
law. Using leaded gasoline can impair engine perfor-
mance and damage the emissions control system.
• An out-of-tune engine or certain fuel or ignition
malfunctions can cause the catalytic converter to
overheat. If you notice a pungent burning odor or
some light smoke, your engine may be out of tune or
malfunctioning and may require immediate service.
Contact your authorized dealer for service assistance.
(Continued)
440 TECHNICAL SPECIFICATIONS

CAUTION!(Continued)
•The use of fuel additives, which are now being sold
as octane enhancers, is not recommended. Most of
these products contain high concentrations of metha-
nol. Fuel system damage or vehicle performance
problems resulting from the use of such fuels or
additives is not the responsibility of the manufac-
turer and may void or not be covered under the New
Vehicle Limited Warranty.
NOTE: Intentional tampering with the emissions control
system can result in civil penalties being assessed against
you.
Carbon Monoxide Warnings
WARNING!
Carbon monoxide (CO) in exhaust gases is deadly.
Follow the precautions below to prevent carbon mon-
oxide poisoning:
• Do not inhale exhaust gases. They contain carbon
monoxide, a colorless and odorless gas, which can
kill. Never run the engine in a closed area, such as a
garage, and never sit in a parked vehicle with the
engine running for an extended period. If the vehicle
is stopped in an open area with the engine running
for more than a short period, adjust the ventilation
system to force fresh, outside air into the vehicle.
• Guard against carbon monoxide with proper main-
tenance. Have the exhaust system inspected every
time the vehicle is raised. Have any abnormal condi-
tions repaired promptly. Until repaired, drive with
all side windows fully open.
9
TECHNICAL SPECIFICATIONS 441

FLUID CAPACITIES
U.S.Metric
Fuel (Approximate)
Two Door Models 18.6 Gallons70 Liters
Four Door Models 22.5 Gallons85 Liters
Engine Oil with Filter
3.6L Engine 6 Quarts5.6 Liters
Cooling System *
3.6L Engine (MOPAR Antifreeze/
Engine Coolant 10 Year/150,000 Mile
Formula or equivalent) 10.5 Quarts
9.9 Liters
* Includes coolant recovery bottle filled to MAX level.
442 TECHNICAL SPECIFICATIONS

FLUIDS AND LUBRICANTS
Engine
ComponentFluid, Lubricant, or Genuine Part
Engine Coolant We recommend you use MOPAR Antifreeze/Coolant 10
Year/150,000 Mile Formula OAT (Organic Additive Tech-
nology) or equivalent meeting the requirements of FCA
Material Standard MS.90032.
Engine Oil We recommend you use API Certified SAE 5W-20 Engine
Oil, meeting the requirements of FCA Material Standard
MS-6395 such as MOPAR, Pennzoil, and Shell Helix. Refer
to your engine oil filler cap for correct SAE grade.
Engine Oil Filter We recommend you use MOPAR Engine Oil Filter or
equivalent.
Spark Plugs We recommend you use MOPAR Spark Plugs.
Fuel Selection 87 Octane, 0-15% Ethanol.
9
TECHNICAL SPECIFICATIONS 443

CAUTION!
•Mixing of engine coolant (antifreeze) other than
specified Organic Additive Technology (OAT) en-
gine coolant (antifreeze), may result in engine dam-
age and may decrease corrosion protection. Organic
Additive Technology (OAT) engine coolant is differ-
ent and should not be mixed with Hybrid Organic
Additive Technology (HOAT) engine coolant (anti-
freeze) or any “globally compatible” coolant (anti-
freeze). If a non-OAT engine coolant (antifreeze) is
introduced into the cooling system in an emergency,
the cooling system will need to be drained, flushed,
and refilled with fresh OAT coolant (conforming to
MS.90032), by an authorized dealer as soon as pos-
sible.
• Do not use water alone or alcohol-based engine
coolant (antifreeze) products. Do not use additional
rust inhibitors or antirust products, as they may not
be compatible with the radiator engine coolant and
may plug the radiator.
• This vehicle has not been designed for use with
propylene glycol-based engine coolant (antifreeze).
Use of propylene glycol-based engine coolant (anti-
freeze) is not recommended.
444 TECHNICAL SPECIFICATIONS

Chassis
ComponentFluid, Lubricant, or Genuine Part
Automatic Transmission – If Equipped Use only ATF+4 Automatic Transmission Fluid. Failure to
use ATF+4 fluid may affect the function or performance of
your transmission. We recommend MOPAR ATF+4 fluid.
Manual Transmission – If Equipped We recommend you use MOPAR Manual Transmission
Lubricant meeting the requirements of FCA Material Stan-
dard MS-9224.
Transfer Case We recommend you use MOPAR ATF+4 Automatic Trans-
mission Fluid.
Axle Differential (Front) We recommend you use MOPAR Gear & Axle Lubricant
(SAE 80W-90) (API GL-5).
Axle Differential (Rear) 226 RBI (Model 44)– We recommend you use MOPAR
Gear & Axle Lubricant (SAE 80W-90) (API GL-5) or equiva-
lent. For trailer towing, use MOPAR Synthetic Gear & Axle
Lubricant (SAE 75W-140). Models equipped with Trac-Lok
require an additive.
Brake Master Cylinder We recommend you use MOPAR DOT 3 Brake Fluid, SAE
J1703. If DOT 3, SAE J1703 brake fluid is not available, then
DOT 4 is acceptable.
Power Steering Reservoir We recommend you use MOPAR Power Steering Fluid +4,
MOPAR ATF+4 Automatic Transmission Fluid.
9
TECHNICAL SPECIFICATIONS 445

MULTIMEDIA
CONTENTS
RADIO 130 ........................... .449
▫ Operating Instructions — Radio Mode ........456
▫ Operation Instructions — CD MODE For
CD And MP3 Audio Play .................451
▫ Notes On Playing MP3 Files ...............453
▫ Operation Instructions — Auxiliary Mode .....455
 RADIO 130 WITH SATELLITE RADIO ........455
▫ Operating Instructions — Radio Mode ........456
▫ Operation Instructions — CD MODE For
CD And MP3 Audio Play .................460
▫ Notes On Playing MP3 Files ...............461
▫ LIST Button — CD Mode For MP3 Play .......463
▫ INFO Button — CD Mode For MP3 Play ......464
▫ Uconnect (Satellite Radio) — If Equipped .....464▫
Operating Instructions — Uconnect
(Satellite) Mode ....................... .466
▫ Operating Instructions (Uconnect Phone) —
If Equipped .......................... .467
 RADIO 430/430N CD/DVD/HDD/NAV —
IF EQUIPPED ......................... .467
▫ Operating Instructions (Voice Command
System) — If Equipped ...................467
▫ Operating Instructions (Uconnect Phone) —
If Equipped .......................... .468
 CYBERSECURITY ....................... .468
 STEERING WHEEL AUDIO CONTROLS .......469
▫ Radio Operation ....................... .470
▫ CD Player ........................... .470

AUX/USB/MP3 CONTROL — IF EQUIPPED .....470
10

RADIO OPERATION AND MOBILE PHONES . . . .471
▫Regulatory And Safety Information ..........471
 CD/DVD DISC MAINTENANCE ............472
 UCONNECT PHONE — IF EQUIPPED ........472
▫ Operation ........................... .474
▫ Help Command ....................... .475
▫ Cancel Command ...................... .475
▫ Pair (Link) Uconnect Phone To
A Mobile Phone ....................... .475
▫ Dial By Saying A Number .................476
▫ Call By Saying A Name ..................476
▫ Phonebook Download – Automatic Phonebook
Transfer From Mobile Phone ...............477
▫ Add Names To Your Uconnect Phonebook .....477▫
Edit Uconnect Phonebook Entries ...........478
▫ Delete Uconnect Phonebook Entry ...........478
▫ List All Names In The Uconnect Phonebook . . . .479
▫ Phone Call Features .....................479
▫ Uconnect Phone Features .................482
▫ Advanced Phone Connectivity .............486
▫ Things You Should Know About
Your Uconnect Phone ....................487
▫ General Information ....................495
 VOICE COMMAND — IF EQUIPPED .........495
▫ Voice Command System Operation ..........495
▫ Commands .......................... .497
▫ Voice Training ........................ .500
448 MULTIMEDIA
