Page 40 of 527
Manual Seat Height Adjustment — If Equipped
The driver’s seat height can be raised or lowered by using
the ratcheting handle, located on the outboard side of the
seat. Pull upward on the handle to raise the seat, push
downward on the handle to lower the seat.
Front Seatback Recline
Lean forward before lifting the handle, then lean back to
the desired position and release the handle. Lift the handle
to return the seatback to an upright position.
WARNING!
Do not ride with the seatback reclined so that the
shoulder belt is no longer resting against your chest. In
a collision you could slide under the seat belt, which
could result in serious injury or death.
Seat Height Adjustment
Recline Lever
38 GETTING TO KNOW YOUR VEHICLE
Page 48 of 527
NOTE:When a heat setting is selected, heat will be felt
within two to five minutes.
WARNING!
• Persons who are unable to feel pain to the skin
because of advanced age, chronic illness, diabetes,
spinal cord injury, medication, alcohol use, exhaus-
tion or other physical condition must exercise care
when using the seat heater. It may cause burns even
at low temperatures, especially if used for long
periods of time
• Do not place anything on the seat or seatback that
insulates against heat, such as a blanket or cushion.
This may cause the seat heater to overheat. Sitting in
a seat that has been overheated could cause serious
burns due to the increased surface temperature of the
seat.
HEAD RESTRAINTS
Head restraints are designed to reduce the risk of injury by
restricting head movement in the event of a rear impact.
Head restraints should be adjusted so that the top of the
head restraint is located above the top of your ear.
WARNING!
• All occupants, including the driver, should not oper-
ate a vehicle or sit in a vehicle’s seat until the head
restraints are placed in their proper positions in
order to minimize the risk of neck injury in the event
of a crash.
• Head restraints should never be adjusted while the
vehicle is in motion. Driving a vehicle with the head
restraints improperly adjusted or removed could
cause serious injury or death in the event of a
collision.
Front Head Restraints
To raise the head restraint, pull upward on the head
restraint. To lower the head restraint, push the adjustment
button located on the base of the head restraint, and push
downward on the head restraint.
To remove the head restraint, raise it as far as it can go then
push the adjustment button and the release button at the
base of each post while pulling the head restraint up. To
reinstall the head restraint, put the head restraint posts into
the holes and push downward. Then adjust it to the
appropriate height.
46 GETTING TO KNOW YOUR VEHICLE
Page 522 of 527
Front Seat...................... .237, 239, 241
Inspection ............................. .280
Operating Instructions .....................241
Pregnant Women ........................ .245
Pretensioners .......................... .245
Rear Seat ............................. .239
Reminder ............................. .201
Untwisting Procedure .....................243
Seats ....................................37
Adjustment .............................37
Easy Entry ..............................39
Fold And Tumble Rear .....................42
Heated .................................45
Height Adjustment ........................38
Rear Folding .............................44
Removal ...............................43
Seatback Release ..........................38
Tilting .................................38
Security Alarm ......................... .26, 201
Security System ............................26
Selection Of Coolant (Antifreeze) ...............443
Sentry Key (Immobilizer) ......................24
Sentry Key Programming ......................25
Sentry Key Replacement ......................25
Service Assistance ......................... .502Service Contract
.......................... .504
Service Manuals .......................... .506
Settings, Personal ......................... .191
Setting The Clock ...................... .449, 457
Shifting ................................ .293
Automatic Transmission ....................293
Manual Transmission ..................... .290
Transfer Case, Shifting Into Transfer Case
Neutral (N) ............................ .328
Transfer Case, Shifting Out Of Transfer Case
Neutral (N) ............................ .329
Shift Lever Override ....................... .362
Shoulder Belts ............................ .239
Signals, Turn .....................54, 282, 344, 345
Snow Chains (Tire Chains) ....................423
Snow Tires .............................. .420
Soft
Top ............................. .100, 131
Spare Tire ..................... .354, 420, 421, 422
Spark Plugs ............................. .443
Specifications Fuel (Gasoline) ......................... .443
Oil.................................. .443
Speed Control Accel/Decel ............................311
520 INDEX
