Page 416 of 464
: $ 5 1 , 1 *
7 L U H V D Q G W K H V S D U H W L U H V K R X O G E H U H S O D F H G
D I W H U V L [ \ H D U V U H J D U G O H V V R I W K H U H P D L Q L Q J
W U H D G ) D L O X U H W R I R O O R Z W K L V Z D U Q L Q J F D Q U H V X O W
L Q V X G G H Q W L U H I D L O X U H < R X F R X O G O R V H F R Q W U R O
D Q G K D Y H D F R O O L V L R Q U H V X O W L Q J L Q V H U L R X V L Q M X U \
R U G H D W K
: $ 5 1 , 1 *
Do not use a tire, wheel size, load rating, or
speed rating other than that specified for
your vehicle. Some combinations of unap-
proved tires and wheels may change
suspension dimensions and performance
characteristics, resulting in changes to
steering, handling, and braking of your
vehicle. This can cause unpredictable
handling and stress to steering and
suspension components. You could lose
control and have a collision resulting in
serious injury or death. Use only the tire and
wheel sizes with load ratings approved for
your vehicle.
Never use a tire with a smaller load index or
capacity, other than what was originally
equipped on your vehicle. Using a tire with
a smaller load index could result in tire
overloading and failure. You could lose
control and have a collision.
Failure to equip your vehicle with tires
having adequate speed capability can
result in sudden tire failure and loss of
vehicle control.
Page 419 of 464
: $ 5 1 , 1 *
/ L P L W H G X V H V S D U H V D U H I R U H P H U J H Q F \ X V H
R Q O \ , Q V W D O O D W L R Q R I W K L V O L P L W H G X V H V S D U H W L U H
D I I H F W V Y H K L F O H K D Q G O L Q J : L W K W K L V W L U H G R Q R W
G U L Y H P R U H W K D Q W K H V S H H G O L V W H G R Q W K H O L P-
ited use spare wheel. Keep inflated to the
cold tire inflation pressures listed on your Tire
and Loading Information Placard located on
the driver’s side B-pillar or the rear edge of
the driver’s side door. Replace (or repairyf W K H
original equipment tire at the first opportunity
and reinstall it on your vehicle. Failure to do
so could result in loss of vehicle control.
CAUTION!
Avoid products or automatic car washes that
use acidic solutions or strong alkaline addi -
tives or harsh brushes. Many aftermarket
wheel cleaners and automatic car washes
may damage the wheel's protective finish.
Such damage is not covered by the New Vehi -
cle Limited Warranty. Only car wash soap,
Mopar Wheel Cleaner or equivalent is recom -
mended.
CAUTION!
Do not use scouring pads, steel wool, a bristle
brush, metal polishes or oven cleaner. These
products may damage the wheel's protective
finish. Such damage is not covered by the
New Vehicle Limited Warranty. Only car wash
soap, Mopar Wheel Cleaner or equivalent is
recommended.
8
21_JL_OM_EN_USC_t.book Page 417
Page 433 of 464
TEC \b \f SPECIFICATIONS
VE \b \fE IDENTIFICATION NUMBER
The Vehicle Identification Number (VINyf L V I R X Q G
on the left front corner of the A-pillar, visible
from outside of the vehicle through the
windshield.
Vehicle Identification Number
NOTE:
It is illegal to remove or alter the VIN plate.
BRAKE SYSTEM
Your vehicle is equipped with dual hydraulic
brake systems. If either of the two hydraulic
systems loses normal capability, the remaining
system will still function. However, there will be some loss of overall braking effectiveness. You
may notice increased pedal travel during
application, greater pedal force required to slow
or stop, and potential activation of the Brake
Warning Light.
In the event power assist is lost for any reason
(i.e., repeated brake applications with the
engine offyf W K H E U D N H V Z L O O V W L O O I X Q F W L R Q
However, the effort required to brake the
vehicle will be much greater than that required
with the power system operating.
W \b \f AND TIRE TORQUE SPECIFICATIONS
Proper lug nut/bolt torque is very important to
ensure that the wheel is properly mounted to
the vehicle. Any time a wheel has been removed
and reinstalled on the vehicle, the lug nuts/
bolts should be torqued using a properly
calibrated torque wrench using a six sided (hexyf
deep wall socket.
TORQUE SPECIFICATIONS
**Use only authorized dealer recommended lug nuts/
bolts and clean or remove any dirt or oil before tightening.
Inspect the wheel mounting surface prior to
mounting the tire and remove any corrosion or
loose particles.
Spare Tire Torque Specifications
**Use only authorized dealer recommended lug nuts/
bolts and clean or remove any dirt or oil before tightening.
Lug Nut/Bolt
Torque **Lug Nut/
Bolt Size Lug Nut/Bolt
Socket Size
130 Ft-Lbs (176 N·myf M14 x 1.50 22 mm
Lug Nut/Bolt Torque **Lug Nut/
Bolt Size Lug Nut/Bolt
Socket Size
59 Ft-Lbs (80 N·myf M14 x 1.50 22 mm
