tow JEEP WRANGLER UNLIMITED 2022 Owners Manual

:$51,1*
All occupants, including the driver, should
not operate a vehicle or sit in a vehicle’s seat
until the head restraints are placed in their
proper positions in order to minimize the risk
of neck injury in the event of a crash.
Head restraints should never be adjusted
while the vehicle is in motion. Driving a
vehicle with the head restraints improperly
adjusted or removed could cause serious
injury or death in the event of a collision.
1 — Release Button
2 — Adjustment Button
WARNING!
A loose head restraint thrown forward in a
collision or hard stop could cause serious
injury or death to occupants of the vehicle.
Always securely stow removed head
restraints in a location outside the occu-
pant compartment.
ALL the head restraints MUST be rein -
stalled in the vehicle to properly protect the
occupants. Follow the re-installation
instructions above prior to operating the
vehicle or occupying a seat.

:$51,1*
Do not drive the vehicle without the rear
seat head restraints installed while passen-
gers are occupying the rear seat. In a colli -
sion, people riding in this area without the
head restraints installed are more likely to
be seriously injured or killed.
A loose head restraint thrown forward in a
collision or hard stop could cause serious
injury or death to occupants of the vehicle.
Always securely stow removed head
restraints in a location outside the occu -
pant compartment.
ALL the head restraints MUST be rein -
stalled in the vehicle to properly protect the
occupants. Follow the reinstallation instruc -
tions above prior to operating the vehicle or
occupying a seat.
2

21_JL_OM_EN_USC_t.book Page 41

:$51,1* (ContinuedyfCAU7,ON
Towing the vehicle, coasting, or driving for
any other reason with the transmission in
NEUTRAL can cause severe transmission
damage.
For Recreational Towing Ú page 199.
For Towing A Disabled Vehicle Úpage 357.

:$51,1*
Drivers must be careful when backing up
even when using ParkSense. Always check
carefully behind your vehicle, look behind
you, and be sure to check for pedestrians,
animals, other vehicles, obstructions, and
blind spots before backing up. You are
responsible for safety and must continue to
pay attention to your surroundings. Failure
to do so can result in serious injury or
death.
Before using ParkSense, it is strongly
recommended that the ball mount and
hitch ball assembly is disconnected from
the vehicle when the vehicle is not used for
towing. Failure to do so can result in injury
or damage to vehicles or obstacles
because the hitch ball will be much closer
to the obstacle than the rear fascia when
the loudspeaker sounds the continuous
tone. Also, the sensors could detect the ball
mount and hitch ball assembly, depending
on its size and shape, giving a false indica-
tion that an obstacle is behind the vehicle.
CAUTION!
ParkSense is only a parking aid and it is
unable to recognize every obstacle,
including small obstacles. Parking curbs
might be temporarily detected or not
detected at all. Obstacles located above or
below the sensors will not be detected
when they are in close proximity.
The vehicle must be driven slowly when
using ParkSense in order to be able to stop
in time when an obstacle is detected. It is
recommended that the driver looks over
his/her shoulder when using ParkSense.

6
(Continuedyf
Center Seat LATCH
Two-Door Models:
Four-Door Models:
Do not install child restraints with rigid lower
attachments in the center seating position. Only
install this type of child restraint in the outboard
seating positions. Child restraints with flexible,
webbing mounted lower attachments can be
installed in any rear seating position.Always follow the directions of the child
restraint manufacturer when installing your
child restraint. Not all child restraint systems
will be installed as described here.
To Install A LATCH-Compatible Child
Restraint
If the selected seating position has a
Switchable Automatic Locking Retractor (ALRyf
seat belt, stow the seat belt, following the
instructions below. See Ú
page 336 to check
what type of seat belt each seating position has.

1. Loosen the adjusters on the lower straps and on the tether strap of the child seat so
that you can more easily attach the hooks
or connectors to the vehicle anchorages.

2. Place the child seat between the lower anchorages for that seating position. If the
second row seat can be reclined, you may
recline the seat and/or raise the head
restraint (if adjustableyfWRJHWDEHWWHUILW,I
the rear seat can be moved forward and
rearward in the vehicle, you may wish to move it to its rear-most position to make
room for the child seat. You may also move
the front seat forward to allow more room
for the child seat.
3. Attach the lower hooks or connectors of the child restraint to the lower anchorages in
the selected seating position.
4. If the child restraint has a tether strap, connect it to the top tether anchorage. See
Úpage 339 for directions to attach a tether
anchor.
5. Tighten all of the straps as you push the child restraint rearward and downward into
the seat. Remove slack in the straps
according to the child restraint
manufacturer’s instructions.
6. Test that the child restraint is installed tightly by pulling back and forth on the child
seat at the belt path. It should not move
more than 1 inch (25.4 mmyfLQDQ\
direction.
How To Stow An Unused Switchable-ALR
(ALRyf6HDW%HOW:
When using the LATCH attaching system to
install a child restraint, stow all ALR seat belts
that are not being used by other occupants or
WARNING!
This vehicle does not have a center seating
position. Do not use the center lower LATCH
anchorages to install a child seat in the cen -
ter of the back seat.
WARNING!
Never use the same lower anchorage to
attach more than one child restraint. If you
are installing LATCH-compatible child
restraints next to each other, you must use
the seat belt for the center position. You can
then use either the LATCH anchors or the
vehicle’s seat belt for installing child seats in
the outboard positions.
Please see Ú page 335 for typical installa -
tion instructions.
WARNING! (Continuedyf

WARNING!
A loose tire or jack thrown forward in a colli-
sion or hard stop, could endanger the occu -
pants of the vehicle. Always stow the jack
parts and the spare tire in the places pro -
vided.
WARNING!
Do not attempt jump starting if the battery is
frozen. It could rupture or explode and cause
personal injury.
CAUTION!
Do not use a portable battery booster pack or
any other booster source with a system volt -
age greater than 12 Volts or damage to the
battery, starter motor, alternator or electrical
system may occur.

:$51,1*
<RXRURWKHUVFDQEHEDGO\EXUQHGE\KRW
HQJLQHFRRODQWDQWLIUHH]H\fRUVWHDPIURP
\RXUUDGLDWRU,I\RXVHHRUKHDUVWHDPFRPLQJ
IURPXQGHUWKHKRRGGRQRWRSHQWKHKRRG
XQWLOWKHUDGLDWRUKDVKDGWLPHWRFRRO1HYHU
WU\WRRSHQDFRROLQJV\VWHPSUHVVXUHFDS
ZKHQWKHUDGLDWRURUFRRODQWERWWOHLVKRW
:$51,1*
$OZD\VVHFXUH\RXUYHKLFOHE\IXOO\DSSO\LQJ
WKHSDUNLQJEUDNHEHIRUHDFWLYDWLQJWKH0DQ-
ual Park Release. In addition, you should be
seated in the driver’s seat with your foot
firmly on the brake pedal when activating the
Manual Park Release. Activating the Manual
Park Release will allow your vehicle to roll
away if it is not secured by the parking brake,
or by proper connection to a tow vehicle. Acti -
vating the Manual Park Release on an unse -
cured vehicle could lead to serious injury or
death for those in or around the vehicle.

&$87,21
Do not use sling type equipment when
towing. Vehicle damage may occur.
When securing the vehicle to a flatbed
truck, do not attach to front or rear suspen-
sion components. Damage to your vehicle
may result from improper towing.
CAUTION!
Front or rear wheel lifts must not be used (if
the remaining wheels are on the groundyf
Internal damage to the transmission or
transfer case will occur if a front or rear
wheel lift is used when towing.

WARNING!
If operating the vehicle without carpet in
place the floor may become hot, and there
is a risk of burns.
An improperly attached, damaged, folded,
or damaged grommets may cause your
carpet to interfere with the accelerator,
brake, or clutch pedals and cause a loss of
vehicle control. To prevent SERIOUS INJURY
or DEATH: ALWAYS securely attach your
carpet using the grommets.
ALWAYS make sure objects cannot fall or
slide into the driver’s side floor area when
the vehicle is moving. Objects can become
trapped under accelerator, brake, or clutch
pedals and could cause a loss of vehicle
control.
NEVER place any objects under the carpet
(e.g., towels, keys, etc.yf7KHVHREMHFWV
could change the position of the carpet and
may cause interference with the acceler-
ator, brake, or clutch pedals.
WARNING! (Continuedyf
8

21_JL_OM_EN_USC_t.book Page 425
