KIA Amanti 2004 1.G Owner's Manual
Manufacturer: KIA, Model Year: 2004, Model line: Amanti, Model: KIA Amanti 2004 1.GPages: 296, PDF Size: 29.34 MB
Page 291 of 296
Maintenance54
7
1
2
3
4
5
6
7
8
9
INTERIOR CARE Interior general precautions Prevent caustic solutions such as
perfume and cosmetic oil from con-
tacting the dashboard because they
may cause damage or discoloration.
If they do contact the dashboard,
wipe them off immediately. See the
instructions that follow for the proper
way to clean vinyl.Cleaning the upholstery and
interior trim Vinyl Remove dust and loose dirt from
vinyl with a whisk broom or vacuum
cleaner. Clean vinyl surfaces with a
vinyl cleaner.
Fabric Remove dust and loose dirt from fab-
ric with a whisk broom or vacuum
cleaner. Clean with a mild soap solu-
tion recommended for upholstery or
carpets. Remove fresh spots imme-
diately with a fabric spot cleaner. If
fresh spots do not receive immediate
attention, the fabric can be stained
and its color can be affected. Also, its
fire-resistant properties can be
reduced if the material is not proper-
ly maintained.
Cleaning the lap/shoulder belt
webbing Clean the belt webbing with any mild
soap solution recommended for
cleaning upholstery or carpet. Follow
the instructions provided with the
soap. Do not bleach or re-dye the
webbing because this may weaken
it.Cleaning the interior window
glass If the interior glass surfaces of the
vehicle become fogged (that is, cov-
ered with an oily, greasy or waxy
film), they should be cleaned with
glass cleaner. Follow the directions
on the glass cleaner container.✽ ✽
NOTICEDo not scrape or scratch the inside
of the rear window. This may result
in damage to the rear window
defroster grid.
CAUTION
Using anything but recommend-
ed cleaners and proceduresmay affect the fabric ’s appear-
ance and fire-resistant proper- ties.
Opirus CAN 7-1.qxd 7/8/03 2:26 PM Page 54
Page 292 of 296
1
2
3
4
5
6
7
8
9
Specifications / 8-2
Specifications
Opirus CAN 8-1.qxd 7/8/03 2:31 PM Page 1
Page 293 of 296
Specifications28
1
2
3
4
5
6
7
8
9
DimensionsWeights
Itemmm (in)
Overall length 4,979 (196.0)
Overall width 1,850 (72.8)
Overall height 1,486 (58.5)
Front tread 1,570 (61.8)
Rear tread 1,560 (61.4)
Wheelbase 2,800 (110.2)
Itemkg (lb)
Curb weight 1834~1857 (4043~4094)
GVWR 2300 (5071)
GAWR Front
1350 (2976)
Rear 1150 (2535)
SPECIFICATIONSThe specifications given here are for general information only. Please check with an authorized Kia dealer for more
precise and more up-to-date information.
Opirus CAN 8-1.qxd 7/8/03 2:31 PM Page 2
Page 294 of 296
83
1
2
3
4
5
6
7
8
9
Specifications
EngineElectrical system
ItemGasoline Engine
BoreXStroke 93 mm X 85.8 mm (3.66 in X 3.38 in)
Displacement 3497 cc (213.3 cu.in)
Compression Ratio 10.0
SizeGasoline Engine
Battery 12V / 80AH (20HR)
Alternator 13.5V / 120A
Starter 12V-1.2kW
Spark Plug Gap
1.0 mm ~ 1.1 mm
Specification PFR5N-11, RC10PYPB4
Opirus CAN 8-1.qxd 7/8/03 2:31 PM Page 3
Page 295 of 296
Specifications48
1
2
3
4
5
6
7
8
9
Gear ratio
Tires
ItemFrontRear
Tire size 225/60R16 98H 225/60R16 98H
210 (30) 210 (30)
Wheel size 6.5J x 16 6.5J x 16
Wheel lug nut torque 9~11 9~11
kg·m (lb·ft, N·m) (65~79, 88~107) (65~79, 88~107)
Inflation pressure
kPa (psi)
Engine Gasoline
Gear Automatic transmission
1st 3.789
2nd 2.057
3rd 1.421
4th 1.039
5th 0.731
Reverse 3.865
F.G.R 3.333
Opirus CAN 8-1.qxd 7/8/03 2:31 PM Page 4
Page 296 of 296
85
1
2
3
4
5
6
7
8
9
Specifications
Light Bulbs
*1)HID(High Intensity Discharge) type
*2)With sunroof
* This mark indicates the filament is not used Capacities
Light Bulb
Wattage
Headlights (High/Low) 55/55 or 35*
1)
Front turn signal lights (LED type) 13.2
Position lights 5
Side mark lights 5
Front fog lights (if equipped) 55
Stop and tail lights 28/8
Rear turn signal lights 28/8*
Back-up lights 16
High mounted stop light (LED type) 2.54
License plate lights 5
Front map lamp 5 or 10*
2)
Center dome lamp 10
Door courtesy lamps 5
Vanity mirror lamps 3
Trunk room lamp 5
Foot lamp 5
Glove box lamp 5
LubricantVolume Classification
Engine oil
*1
4.3 l(4.5 qt.)
API SERVICE SH or above
Transaxle
8.5 l(9.0 qt.) DIAMOND ATF SP-III,
fluid SK ATF SP-III
Power steering 1.0 l(1.1 qt.) PSF-III
Coolant 10.2
l
Ethylene glycol base for
(10.8 qt.
) aluminum radiator
Brake fluid 0.7~0.8
l
FMVSS116 DOT-3
(
0.7~0.8 qt.
) or DOT-4
Fuel 70
l Unleaded gasoline with
(18.5 gal) AKI 87 or higher
*¹Refer to the recommended SAE viscosity numbers on the page 7-49.
